KitchenAid 5KSB13 A Series User manual

Stand Blender
5KSB13**A

2
PARTS AND FEATURES
1Lid Centre Cap
2Lid with Vent Well
3Jar (1.4 Litre capacity)
3.1 Glass Jar**** (1.4 Litre capacity)
4Base
5Control Dial
6Reamer*
7Pulp Strainer/Basket*
8Juice Container* (1 Litre capacity)
9Gear Assembly*
10 Personal Jar** (0.4 Litre capacity)
11 Blade Assembly of Personal Jar**
12 Personal Jar Easy-Drink Lid**
13 Small Batch Jar*** (0.2 Litre capacity)
14 Blade Assembly of Small Batch Jar***
15 Small Batch Jar Lid***
*Accessories only included with Citrus Press model.
** Accessories only included with Personal Jar model.
*** Accessories only included with Small Batch Jar model.
**** Accessories only included with Glass Jar Blender model.
The Glass Blender Jar (1.4 Litre capacity) is clear, easy-to-clean (Dishwasher safe) and, with
the comfortable firm grip for better handling.
48oz
OUNCES
8oz= 1 Cup
44oz
40oz
36oz
32oz
28oz
24oz
20oz
16oz
12oz
1
2
3
4
5
9
8
7
6
10
13
11
12
14
15
3.1

ENGLISH
3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against risk of electrical shock do not put the Stand Blender Base in
water or other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. Turn the appliance OFF, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the power cord.
6. Avoid contacting moving parts.
7. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Contact the
manufacturer at their customer service telephone number for information on
examination, repair or adjustment.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Keep hands and utensils out of container while blending to reduce the risk of
severe injury to persons or damage to the Blender. A scraper may be used but
must be used only when the Blender is not running.
11. Blades are sharp. Care should be taken when handling the sharp cutting blades,
emptying the jar and during cleaning.
12. Be careful if hot liquid is poured into the blender as it can be ejected out of the
appliance due to sudden steaming.

4
ELECTRICAL REQUIREMENTS
Voltage: 220-240 VAC
Frequency: 50-60 Hz
Wattage: 650 Watts
NOTE: If the plug does not fit in the
outlet, contact a qualified electrician. Do
not modify the plug in any way. Do not
use an adapter.
Do not use an extension cord. If the
power supply cord is too short, have a
qualified electrician or service technician
to install an outlet near the appliance.
The cord should be arranged so that it
will not drape over the countertop or
tabletop where it can be pulled on by
children or tripped over unintentionally.
13. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
14. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
15. Always operate the Blender with cover in place.
16. When blending hot liquids or ingredients, Lid Centre Cap should remain in place
over the lid opening. Always start on lowest speed and slowly ramp to desired
speed when blending hot liquids or ingredients.
17. Do not blend hot liquids and ingredients in the Personal Jar or Small Batch Jar.
18. To reduce the risk of injury, never place blade assembly on the base without
Personal Jar or Small Batch Jar properly attached.
19. The use of attachments, including canning jars, not recommended or sold by the
manufacturer may cause a risk of injury to persons.
20. This appliance is intended to be used in household and similar applications such
as:
- staff kitchen areas in shops, ofces, or other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
PRODUCT SAFETY
GETTING STARTED
The Blender features 3 speeds and Ice Crush/Pulse function, allowing you to customise your
blend. Recipes can differ significantly and might work best on speed that are not obvious.
We encourage you to find the best speed match for your favourite recipes.
ACCESSORIES CAPACITY SPEED SUGGESTED ITEMS TO BLEND
Blender Jar 1.4 Litre
Speed 1, 2, 3,
and Pulse/Ice
crush
Smoothies, Icy drinks, Shakes / Malts,
Dips, Spreads and more.
Glass Blender Jar 1.4 Litre
Personal Jar 0.4 Litre Individual Smoothie, Icy drinks, Shakes /
Malts and lower volume recipes.
Small Batch Jar 0.2 Litre
Small volume recipes - Purées, Sauces,
Baby food, Dressings, Marinades, Pesto
and more.
Citrus Press 1 Litre Speed 1 Citrus juice, Grapefruit juice and more.

ENGLISH
5
BLENDER USAGE
Before first use, clean all parts and accessories (see Care and Cleaning section).
Be sure the countertop beneath the Blender and surrounding areas are dry and clean.
IMPORTANT: When moving your Blender, always support/lift from the Blender base. The
base will become disengaged from Jar if, carried by Blender Jar or Blender Jar handle only.
1
2
1500 ml
1250 ml
1000 ml
Add ingredients into Blender Jar OR Glass
Blender Jar (max. 1.4 Litre).
Secure the Lid and Lid Centre Cap.
1
Place the Blender Jar on the base by
aligning with the Slot to fit inside the jar
pad, so that the handle of the Jar will be
towards the Control Dial.
Plug the Blender into an earthed outlet.
2
Slot
O
1
2
3
P
Turn the Control Dial from (O) to desired
speed for constant operation.
3
When finished, turn the Blender off by
returning the Control Dial to (O).
Unplug the Blender before removing the
Blender Jar.
4
IMPORTANT: Allow the Blender to fully stop before removing the Lid, Jar, or pouring out
your blended ingredients.

6
IMPORTANT: Do not blend hot liquids and ingredients in the Personal Jar.
USING THE PERSONAL JAR
The Personal Jar is perfect in size for single servings or smaller recipes and handy to carry with
you on the go. Before first use, clean all parts and accessories (see “Care and Cleaning” section).
Add ingredients (max. 0.4 Litre). Add ice or
frozen items, then leafy greens, then soft
foods and liquids at last.
1
1
2
Secure the Blade Assembly on the Personal
Jar and rotate it clockwise until it is tight.
Place it on the Blender Base.
2
Slot
BLENDER USAGE
Place ingredients or Ice cubes into the
Blender Jar.
Firmly secure the Lid with Lid Centre Cap
on Blender Jar.
1
O
1
2
3
P
Turn and hold the Control Dial from (O) to
(
P
) as per desired interval of time.
When finished, release the Control Dial to
stop the Blender.
2
TIP: Use half of standard ice cube tray or 7-8 standard ice cubes at a time for blending.
The Pulse/Ice Crush (
P
) function has been optimised to crush and chop ice without adding
any liquid ingredients.
PULSE /ICE CRUSH FUNCTION USAGE
Your Blender offers a "Pulse/Ice Crush (
P
)" function with a soft start to avoid ingredient
splatter. In this function, the Blender will operate at optimal speed to crush ice. This function
will continue until you release the Control Dial, returning to (O).

ENGLISH
7
BLENDER USAGE
O
1
2
3
P
Turn the Control Dial from (O) to desired
speed for constant operation.
3
When finished, turn the Blender off by
returning Control Dial to (O).
Always remove the Personal Jar with the
Blade Assembly from the Base.
4
USING THE SMALL BATCH JAR
The Small Batch Jars are perfect for smaller recipes like sauces, dressings, marinades and
more. Before first use, clean all parts and accessories (see “Care and Cleaning” section).
Add ingredients into the Small Batch Jar
(max. 0.2 Litre).
1
1
2
Secure the Blade Assembly on Small Batch
Jar and rotate it clockwise until it is tight.
Place it on the Blender base.
2
Slot
O
1
2
3
P
Turn the Control Dial from (O) to desired
speed for constant operation.
3
When finished, turn the Blender off by
returning Control Dial to (O).
Always remove the Small Batch Jar with
Blade Assembly from the Base.
4
IMPORTANT: Do not blend hot liquids and ingredients in the Small Batch Jar.

8
O
1
2
3
P
Hold down the halved citrus fruit on the
Reamer. Turn the Control Dial from (O) to
speed (1) to start juicing.
3
When finished juicing, turn the Blender off
by returning Control Dial to (O).
Unplug the Blender.
4
1
2
Twist the Juice Container counterclockwise
and lift it by using handle. Pour and enjoy!
5
USING THE CITRUS PRESS
Before first use, clean all parts and accessories (see “Care and Cleaning” section).
1
2
Place the Gear Assembly on the base.
Then, place the Juice Container on the
Gear Assembly and twist clockwise to lock
in place.
1
Place the Pulp Basket and then the Reamer
into the Juice Container by aligning them
with the Drive Shaft.
2
Drive
Shaft

ENGLISH
9
48oz
OUNCES
8oz=1 Cup
44oz
40oz
36oz
32oz
28oz
24oz
20oz
16oz
12oz
Unplug the Blender before cleaning. Wipe
clean the Base, Power Cord and the Gear
Assembly of the Citrus Press with a warm,
damp cloth and dry with a soft cloth.
Dishwasher-safe, top rack only: Personal
Jar, Small Batch Jar, Lids, Blade Assembly,
Reamer, Juice Container, Pulp Basket and
Lid Centre Cap.
Blender Jar can also be washed in the
bottom rack.
CARE AND CLEANING
NOTE: To avoid damaging the Blender, do not immerse the Blender base or cord in
water. Do not use abrasive cleansers or scouring pads to avoid scratching the Blender.
USING THE CLEAN FUNCTION
Empty the Blender Jar. Fill half of the Jar
with warm water and add 1 or 2 drops of
dish-washing liquid.
Place the Blender Jar on the base. Secure
the Lid and Lid Centre Cap.
O
1
2
3
P
Turn the Control Dial to speed (3) and run
the Blender for 15-20 seconds.
Remove the Blender Jar, empty contents
and rinse with warm water and dry
thoroughly.
1 2

10
TROUBLESHOOTING GUIDE
PROBLEM SOLUTION
If Blender fails to start:
Check to see if the Blender is securely plugged into an
earthed electrical outlet.
If you have a circuit breaker box, make sure the circuit is
closed. Try unplugging the Blender, then plug it back into
an earthed electrical outlet.
If Blender stops while blending:
The Blender becomes overloaded or jammed. It will
automatically shut off to prevent damage to the motor.
Unplug the power cord. Remove the Blender Jar from the
base and use a spatula to rearrange ingredients in the
Blender Jar.
The Blender is overloaded, divide contents into smaller
batches. For certain recipes, adding liquid to the Blender
Jar may also reduce the load on the Blender.
If Blender stops while blending
with Personal Jar or Small Batch
Jar:
Unplug the power cord. Remove the Personal Jar or Small
Batch Jar from the base with the Blade Assembly. Shake
it a little bit. Place it back on the base, and then plug and
turn the Blender back on to continue regular use.
If the problem cannot be
corrected:
See the “Product Warranty and Customer Service”
sections. Contact an Authorised Service Centre for
assistance.
Do not return the Blender to the retailer – retailers do not
provide service.

ENGLISH
11
©2019 All rights reserved.
Specifications subject to change without notice.
In Australia:
For any questions, or to find the nearest Authorised KitchenAid Service Centre,
please find our contact details below.
NOTE: All service should be handled locally by an Authorised KitchenAid Service
Centre.
Toll free number: 1-800-990-990
Phone number: 02 49026500
Address Australia:
KitchenAid Australia Pty Ltd
6-8 Billbrooke Close
Cameron Park NSW 2285, Australia
Phone: [phone]
Mobile: [phone]
Email: [email protected]
In New Zealand:
Website: www.KitchenAid.co.nz
Email: [email protected]
Phone: [phone]
In other countries:
For all product related questions and after-sales matters, please contact your dealer
to obtain the name of the nearest Authorised KitchenAid Service/Customer Centre.
For more information, visit our website at:
www.KitchenAid.com.au
CUSTOMER SERVICE

W11344951A 03/19
©2019 All rights reserved.
Specifications subject to change without notice.
