KitchenAid 5KFP1318 Series User manual

Food Processor
5KFP1318*
5KFP1319*
EN Use & Care manual 2
DE Gebrauchs- und Pegeanleitung 19
FR Manuel d’utilisation et d’entretien 36
IT Manuale d’uso e manutenzione 55
NL Gebruiks- en
onderhoudshandleiding 71
ES Manual de uso y cuidado 87
PT Manual de utilização e
manutenção 103
EL Εγχειρίδιο Χρήση και Φροντίδα 119
SV Handbok för skötsel och
användning 135
NO Håndbok for bruk og vedlikehold 151
FI Käyttö- ja huolto-opas 167
DA Vejledning til anvendelse og
vedligehold 183
IS Notenda & Meðhöndlunar
handbók 199
RU    
 215
PL Instrukcja obsługi i konserwacji 231
CS Návod k použití a údržbě 247
TR Kullanım ve Bakım kılavuzu 263
UK    
 279
AR  1

2
PARTS AND FEATURES
1Heavy-Duty Base
2Power Cord and Cord Storage
(not shown)
3Drive Pin
413-Cup (3.1 L) Work Bowl
5Handle Hinge
6Lid Hinge
7Slicing Knob
8Work Bowl Cover with 3-in-1 Feed
Tube
9Lid Latch
10 3-in-1 Food Pusher
11 Refrigerator Lid
12 Externally Adjustable Slicing Disc
(thin to thick)
13 Reversible Fine/Medium Shredding
Disc
14 Multipurpose Stainless Steel Blade
15 Dough Blade
16 Drive Adapter (Upper)
17 Drive Adapter (Lower)
2
O/Pulse
1
1
4
7
3
10
9
6
5
8
2
11
12
13
14
15
16
17

ENGLISH
3
PARTS AND FEATURES
18 Dicing Kit Cover
19 Dicing Blade
20 Dicing Kit Base
21 Dicing Kit Clean Out Tool
22 Storage Caddy
18
20
19
12
22
17
16
21
15
13
14
ACCESSORY GUIDE
Accessory Included with Model
5KFP1319* 5KFP1318*
External Adjustable Slice
• •
Storage Caddy
• •
Wide Mouth Opening • •
3-in-1 Feed Tube • •
Multipurpose Blade • •
Dough Blade • •
Thin and Medium Shred • •
Storage Lid •
Dicing Kit •

4
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions. Misuse of appliance may result in personal injury.
2. To protect against risk of electrical shock, do not put Food Processor in water
or other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they are closely supervised and instructed concerning use
of the appliance by a person responsible for their safety. Close supervision is
necessary when any appliance is used by or near children.
4. Turn the appliance OFF, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the Power Cord.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorised Service Centre for examination, repair, or
electrical or mechanical adjustment.
7. The use of attachments not recommended or sold by KitchenAid may cause
re, electric shock, or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Keep hands and utensils away from moving Blades or discs while processing
food to reduce the risk of severe injury to persons or damage to the Food
Processor. A scraper may be used but must be used only when the Food
Processor is not running.
11. Blades are sharp. Handle Carefully. Care should be taken when handling the
sharp cutting blades, emptying the bowl and during cleaning.
PRODUCT SAFETY

ENGLISH
5
12. To reduce the risk of injury, never place cutting Blade or discs on Base without
rst putting bowl properly in place.
13. Be certain Cover is securely locked in place before operating the Food
Processor.
14. Never feed food by hand. Always use the Food Pusher.
15. Do not attempt to defeat the Cover interlock mechanism.
16. Do not ll the bowl above the marked maximum ll line to avoid risk of injury
due to damage to the Cover or bowl.
17. Children should be supervised to ensure that they do not play with the
appliance
18. Never leave the appliance unattended while it is in operation.
19. European Union Only: This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
20. European Union only: Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved. Children
shall not play with the appliance.
21. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
22. Be careful if hot liquid is poured into the Food Processor as it can be ejected
out of the appliance due to a sudden steaming.
23. Refer to the “Care and Cleaning” section for instructions on cleaning the
surfaces in contact with food.
24. This appliance is intended to be used in household and similar applications
such as:
- staff kitchen areas in shops, ofces, or other working environments;
- farmhouses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
PRODUCT SAFETY
Instructions are also available online, visit our website at:
www.KitchenAid.co.uk or www.KitchenAid.eu

6
PRODUCT SAFETY
ELECTRICAL REQUIREMENTS
Voltage: 220-240 V~
Frequency: 50-60 Hz
NOTE: This Food Processor is equipped with a polarized plug (one Blade is wider than
the other). To reduce the risk of electrical shock, this plug will fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not modify the plug in any way.
ELECTRICAL EQUIPMENT WASTE DISPOSAL
Recycling the product
- This appliance is marked in compliance
with law in the EU and UK covering,
Waste Electrical and Electronic Equipment
(WEEE).
- By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product.
- The symbol on the product or on the
accompanying documentation indicates
that it should not be treated as domestic
waste but must be taken to an appropriate
collection centre for the recycling of electrical
and electronic equipment.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city office,
your household waste disposal service or the
shop where you purchased the product.
DECLARATION OF CONFORMITY (UK)
This appliance has been designed, constructed and distributed in compliance with
the safety requirements of UK Legislation: Electrical Equipment (Safety) Regulations
2016, Electromagnetic Compatibility Regulations 2016. The Ecodesign for Energy-
Related Products and Energy Information (Amendment) (EU Exit) Regulations 2019.
The Restriction of the Use of Certain Hazardous Stubstances in Electrical and Electronic
Equipment Regulations 2012.
DISPOSAL OF PACKING MATERIAL
The packing material is recyclable and is marked with the recycle symbol . The various
parts of the packing must therefore be disposed of responsibly and in full compliance
with local authority regulations governing waste disposal.
DECLARATION OF CONFORMITY (EU)
This appliance has been designed, constructed, and distributed in compliance with the
safety requirements of EC Directives: Low Voltage Directive 2014/35/EU, Electromagnetic
Compatibility Directive 2014/30/EU, RoHS Directive 2011/65/EU and following
amendments.

ENGLISH
7
Action Setting Food Accessory
Chop 1 or Pulse
Cheese*
Chocolate*
Fruits
Fresh herbs
Nuts*
Tofu
Vegetables
Beef***
Multipurpose Stainless
Steel Blade
Mince or Purée 2 or Pulse
Mix 1
Pasta Sauce
Pesto
Salsa
Sauces
Batters
Slice
(thin to thick)
1
Fruit (soft)
Potatoes
Tomatoes
Vegetables (soft) Externally Adjustable
Slicing Disc
2
Cheese
Fruit (hard)
Vegetables (hard)
Shred
(fine to medium)
1Potatoes
Vegetables (soft)
Reversible Fine/Medium
Shredding Disc
2
Cabbage
Cheese
Chocolate
Fruits (hard)
Vegetables (hard)
Dice 1
Potatoes
Vegetables
Fruit
Cheese
Dicing Kit
Knead 1Yeast**
Dough** Dough Blade
ACCESSORIES SELECTION GUIDE
GETTING STARTED
*For these ingredients it is not recommended to process quantities larger than 500g
(1∕4of work bowl) with the Multipurpose Stainless Steel Blade.
**For these ingredients it is not recommended to process quantities larger than 384g.
***Do not process more than 225g, chop beef into 1cm cubes prior to adding to bowl.
NOTE: Do not operate the appliance exceeding a maximum of 3 minutes. After 3
minutes the appliance needs to cool down to avoid overheating.

8
Before first use
Before using your Food Processor for the first time, wash all parts and accessories either
by hand or in the dishwasher (see “Care and Cleaning” section).
NOTE: Your Food Processor is designed so that all accessories may be stored inside the
Work Bowl.
Lift up the Lid Latch to unlock the Cover.
Tilt the Work Bowl Cover back and lift it
straight up so that the Lid Hinge pulls out
of the Handle Hinge.
Remove all parts and accessories from
the Work Bowl, and lift the Food Pusher
out of the Feed Tube.
Place the Work Bowl on the Base, aligning
the Handle with the raised button on the
right side of the Base. The bowl will click
into place and should be flush against the
Base when properly aligned.
Place the Drive Adapter in the Work
Bowl, lowering it onto the Drive Pin.
PRODUCT ASSEMBLY
1
3
2
4
IMPORTANT: Place the Food Processor on a dry, level countertop with the controls
facing forward. Do not plug in the Food Processor until it is completely assembled.

ENGLISH
9
PRODUCT ASSEMBLY
NOTE: For ease of assembly, install the desired Blade or Disc before attaching the Work
Bowl Cover.
NOTE: Your Food Processor will not operate unless the Work Bowl Cover is fully closed,
the large Food Pusher is in place, and the Work Bowl is properly seated on the Base.
To attach the Work Bowl Cover, hook the
Lid Hinge into the Handle Hinge on the
Work Bowl and close the Cover.
Once the Work Bowl Cover is closed, the
Lid Latch will lock in position.
5 6
INSTALLING THE MULTIPURPOSE BLADE OR DOUGH BLADE
Install the Lower Drive Adapter onto the
Upper Drive Adapter. Place the Blade on
the Drive Adapter. Rotate the Blade so it
falls down to the Base of the Adapter.
Install the Work Bowl Cover, and be sure
the Lid Latch is pushed down to the
locked position.
12

10
PRODUCT ASSEMBLY
TIP: You may need to adjust the Drive Adapter with a slight turn on the power shaft until
it drops into place. For easiest installation, make sure the Adjustment Knob is in the “0”
position.
INSTALLING THE EXTERNALLY ADJUSTABLE SLICING DISC
ADJUSTING THE SLICING THICKNESS
Hold the Slicing Disc by the finger grips
and lower it onto the Drive Adapter.
To attach the Work Bowl Cover, hook the
Lid Hinge into the Handle Hinge on the
Work Bowl and close the Cover.
Once the Work Bowl Cover is closed, the
Lid Latch will lock in position.
NOTE: The Knob only works with
the Externally Adjustable Slicing Disc.
Changing thickness settings with other
discs or Blades installed will have no effect
on operation.
NOTE: Your Food Processor will not
operate unless the Work Bowl Cover is
fully closed and the Work Bowl is properly
seated on the Base.
Set the desired thickness by moving the
Knob to the left for thinner slices and to
the right for thicker slices.
Thinner Thicker
1 2
3
1

ENGLISH
11
INSTALLING THE DICING KIT
With the Work Bowl removed from the
Base, place Dicing Kit Base, Blade (text
side up) , and Cover in the Work Bowl.
Align Dicing Kit Cover with wide mouth
feed shoot.
1
2
Place the Work Bowl Cover on the Work
Bowl. Take out small and/or medium
Feed Tube. Insert food to dice.
After dicing, remove the Work Bowl
Cover, Dicing Kit Cover and Dicing Blade,
then insert the Dicing Kit Clean Out Tool
into the Dicing Kit Base and push any
extra food through the grid.
1 2
3 4
PRODUCT ASSEMBLY
PRODUCT USAGE
Before operating the Food Processor, be
sure the Work Bowl, Blades/Disc, and Work
Bowl Cover are properly assembled on the
Base (see the “Product Assembly” section).

12
PRODUCT USAGE
2
O/Pulse
1
2
O/Pulse
1
2
O/Pulse
1
2
O/Pulse
1
To turn on, press 1 or 2. The Food
Processor will run continuously and the
indicator light will glow.
To turn off, press 1 or 2 again, or press
O/Pulse.
To use the Pulse function:
Press O/Pulse for short bursts, or press
and hold for longer bursts. The Pulse
function runs at speed 2 only. The Food
Processor will turn off when the O/Pulse
button is released.
When finished, press the O/Pulse button.
The indicator light will go out
and the Blade or Disc will slow to a stop.
Wait until the Blade or disc comes to a
complete stop before removing the Work
Bowl Cover. Be sure to turn off the Food
Processor before removing the Work
Bowl Cover, or before unplugging the
Food Processor.
1
3
2
4
USING THE 3-IN-1 FEED TUBE
The 3-in-1 Feed Tube features a 3-piece
Food Pusher.
Use the entire Feed Tube and the large
Food Pusher to process large items.
NOTE: The unit will not start if food is
loaded in the large Feed Tube above the
max fill line.
Use the medium Food Pusher in the Feed
Tube to process smaller items.
Use the small Food Pusher to slice or shred
the smallest, thinnest items.
Use the drizzle hole in the small Food
Pusher to slowly drizzle oil or other liquid
ingredients into the Work Bowl.
3-Piece
Food
Pusher

ENGLISH
13
PRODUCT DISASSEMBLY
REMOVING PROCESSED FOODS
2
O/Pulse
1
Turn the Food Processor off: Press the
O/Pulse button and unplug the Food
Processor before disassembling.
Lift the Lid Latch to unlock the Work
Bowl Cover, then lift the Cover to
remove.
If using the disc, remove it before
removing the bowl. Holding the disc by
the finger holes, lift it straight up.
Remove the Drive Adapter and
Multipurpose Blade, if using. The Blade
will stay in place on the Drive Adapter
when you remove the Adapter.
1 2
3 4
Lift the Work Bowl off of the Base to
remove food from the bowl with a
spatula.
5

14
CARE AND CLEANING
NOTE: If washing the Food Processor parts by hand, avoid the use of abrasive cleansers
or scouring pads. They may scratch or cloud the Work Bowl and Cover.
2
O/Pulse
1
2
O/Pulse
1
Press the O/Pulse button, then unplug
the Food Processor before cleaning.
Wipe the Base and cord with a warm,
damp cloth. Thoroughly dry with a soft
cloth. Do not use abrasive cleaners or
scouring pads. Do not immerse Base in
water or other liquid.
IMPORTANT: The BPA-free bowl requires special handling. If you choose to use a
dishwasher instead of hand washing, please follow these guidelines.
All parts are top rack dishwasher safe.
Avoid laying the bowl on its side.
Thoroughly dry all parts after washing.
Use gentle dishwashing cycles such as
normal. Avoid high-temperature cycles.
You can store up to two Blades and three
discs as well as the Drive Adapter inside
the Work Bowl by using the in bowl
Storage Caddy when the Food Processor
is not in use. Wrap the Power Cord
around the Cord Storage on the bottom
of the Base, then secure the plug by
clipping it to the housing.
1 2
3 4

ENGLISH
15
TROUBLESHOOTING GUIDE
Problem Solution
If your Food Processor should
malfunction or fail to operate,
check the following:
Check to see if the Food Processor is securely plugged
into an earthed electrical outlet.
Make sure that the Bowl and Lid are properly aligned
and locked in place.
Have you pressed more than one button at the same
time?
Unplug the Food Processor, then plug it back into the
outlet.
Is the fuse in the circuit to the
Food Processor in working
order?
If you have a circuit breaker box, be sure the circuit is
closed.
The Food Processor may need
to cool to room temperature:
If the speed light turns off and the O/Pulse light flashes,
wait until the O/Pulse light turns off and retry.
The Food Processor may take from 5-15 minutes to cool
completely.
The motor may be locked: If the speed light stays on while the O/Pulse light flashes,
press the O/Pulse button to reset the motor.
Food Processor not shredding
or slicing properly:
Make sure the raised-Blade side of the disc is positioned
face up on the Drive Adapter.
Make sure ingredients are suitable for slicing or
shredding.
Make sure the disc is positioned in the process position
(near the top of the bowl), and not the storage position
(low and inside of the bowl).
If the Work Bowl Cover won’t
close when using the disc: Make sure the disc is installed correctly, and is positioned properly on the Drive Adapter.
If the problem cannot be
corrected:
See the “Terms of KitchenAid Guarantee(“Guarantee”)”
sections.
Do not return the Food Processor to the retailer.
Retailers do not provide service.

16
TERMS OF KITCHENAID GUARANTEE
("GUARANTEE")
Covering U.K. - Ireland - South Africa - UAE
KitchenAid Europa, Inc., Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium
("Guarantor") grants the end-customer, who is a consumer, a Guarantee pursuant to the
following terms.
FOR U.K.:
The Guarantee applies in addition to and does not limit or affect the statutory warranty
rights of the end-customer against the seller of the product. In summary, the Consumer
Rights Act 2015 says products must be as described, fit for purpose and of satisfactory
quality. During the expected lifespan of your product your legal rights entitle you to the
following:
- Up to 30 days: if your product is faulty, then you can get an immediate refund.
- Up to six months: if your product can't be repaired or replaced, then you're
entitled to a full refund, in most cases.
- Up to six years: if your product does not last a reasonable length of time you
may be entitled to some money back.
These rights are subject to certain exceptions. For detailed information please visit the
Citizens Advice website www.adviceguide.org.uk or call 03454 04 05 06.
FOR IRELAND:
The Guarantee applies in addition to and does not limit or affect the statutory warranty
rights of the end-customer against the seller of the product under the European
Communities (Certain Aspects of the Sale of Consumer Goods and Associated Guarantees
Regulations 2003 (S.I. No. 11/2003)) and other enactments governing the sale of consumer
goods.
FOR SOUTH AFRICA:
The Guarantee applies in addition to and does not limit or affect the statutory warranty
rights of the end-customer against the seller of the product. In summary, the Consumer
Protection Act, 2008 says that products must be: (i) reasonably suitable for the purpose
for which they are intended; (ii) in good working order, of good quality and free of any
defects; (iii) useable and durable for a reasonable period of time, having regard to the use
to which they would normally be put and to all the surrounding circumstances; and (iv) in
compliance with any applicable standards or any other public regulations.
During the expected lifespan of your product and where the products are not purchased
online, your legal rights will entitle you to the following:
- You will be entitled to a full refund, if you did not have the opportunity to examine the
product before delivery and if you rejected delivery of the product on the basis that the
type and quality of the product was not as reasonably expected or did not reasonably
conform to the material specifications.
- Within 5 business days after delivery: you may rescind your purchase and request a
refund, if your purchase resulted from direct marketing.
- Within 10 business days after delivery: you will be entitled to a full refund, if it is found
that the product was unsuitable for a particular purpose specifically communicated to you
by the Guarantor.
- Within 15 business days after delivery: you will be entitled to a refund if: (i) the product
was not delivered to you; or (ii) if you returned the product to the Guarantor.
- Within 6 months after delivery: you will be entitled to a refund or a replacement product,
if the product is defective or fails to operate in terms of its specifications.

ENGLISH
17
Where you have purchased a product online your legal rights will be governed by the
Electronic Communications and Transactions Act, 2002 and you will be entitled to the
following:
- Within 7 days after conclusion of the transaction or after delivery: you may cancel your
purchase without reason and without penalty.
- Within 30 days of the date of cancellation of the transaction: you will be entitled to
receive a refund, if you have already made payment.
- You will only be liable for the direct costs of returning the product to the Guarantor.
FOR UAE:
The Guarantee applies in addition to and does not limit or affect the statutory warranty
rights of the end-customer against the seller of the product.
1) SCOPE AND TERMS OF THE GUARANTEE
a) The Guarantor grants the Guarantee for the products mentioned under Section 1.b)
which a consumer has purchased from a seller or a company of the KitchenAid-Group
within the following countries: U.K., Ireland, or South Africa, or the United Arab Emirates
(UAE).
b) The Guarantee period depends on the purchased product and is as follows:
5KFP1318*, 5KFP1319* Two years full guarantee from date of purchase.
c) The Guarantee period commences on the date of purchase, i.e. the date on which a
consumer purchased the product from a dealer or a company of the KitchenAid-Group.
d) The Guarantee covers the defect-free nature of the product.
e) The Guarantor shall provide the consumer with the following services under this
Guarantee, at the choice of the Guarantor, if a defect occurs during the Guarantee
period:
- Repair of the defective product or product part, or
- Replacement of the defective product or product part. If a product is no longer
available, the Guarantor is entitled to exchange the product for a product of equal or
higher value.
f) If the consumer wishes to make a claim under the Guarantee, the consumer has to
contact the country specific KitchenAid service centres or the Guarantor directly at
KitchenAid Europa, Inc. Nijverheidslaan 3, Box 5, 1853 Strombeek-Bever, Belgium;
Email-Address U.K.: CONSUMERCARE. [email protected]
Email-Address IRELAND: [email protected]
Toll Free Number U.K. & IRELAND: 00 800 381 040 26
FOR SOUTH-AFRICA:
Our local KitchenAid Distributor:
KitchenAid Africa
PO Box 52102
V&A Waterfront
Cape Town
8002
TERMS OF KITCHENAID GUARANTEE
("GUARANTEE")

18
TERMS OF KITCHENAID GUARANTEE
("GUARANTEE")
Contact our distributor:
Telephone: [phone]
You can contact our Customer Service Centre for Small Domestic Appliances
from 8.30 am to 1.00pm and from 1.30 pm to 5.00 pm or write to us at the following
address: [email protected]
FOR UAE:
AL GHANDI ELECTRONICS.
POST BOX NO. 9098,
DUBAI, UNITED ARAB EMIRATES
Toll free number: [phone]
g) The costs of repair, including spare parts, and any postage costs (if applicable) for
the delivery of a defect-free product or product part shall be borne by the Guarantor.
The Guarantor shall also bear the postage costs for returning the defective product or
product part if the Guarantor or the country specific KitchenAid customer service centre
requested the return of the defective product or product part. However, the consumer
shall bear the costs of appropriate packaging for the return of the defective product or
product part.
h) To be able to make a claim under the Guarantee, the consumer must present the
receipt or invoice of the purchase of the product.
2) LIMITATIONS OF THE GUARANTEE
a) The Guarantee applies only to products used for private purposes and not for
professional or commercial purposes.
b) The Guarantee does not apply in the case of normal wear and tear, improper or
abusive use, failure to follow the instructions for use, use of the product at the wrong
electrical voltage, installation and operation in violation of the applicable electrical
regulations, and use of force (e.g. blows).
c) The Guarantee does not apply if the product has been modified or converted, e.g.
conversions from 120 V products to 220-240 V products.
d) The provision of Guarantee services does not extend the Guarantee period, nor
does it initiate the commencement of a new Guarantee period. The Guarantee period
for installed spare parts ends with the Guarantee period for the entire product.
e) FOR SOUTH-AFRICA & UAE ONLY:
Further or other claims, in particular claims for damages, are excluded unless liability
is mandatory by law.
After expiry of the Guarantee period or for products for which the Guarantee does not
apply, the KitchenAid customer service centres are still available to the end-customer for
questions and information.
Further information is also available on our website:
- For U.K. & Ireland www.kitchenaid.eu
- For South-Africa: www.kitchenaidafrica.com
- For UAE: www.KitchenAid-MEA.com
PRODUCT REGISTRATION
Register your new KitchenAid appliance now: http://www.kitchenaid.eu/register
©2021 All rights reserved.

19
DEUTSCH
TEILE UND MERKMALE
1Robuster Sockel
2 Netzkabel und Aufbewahrung des Kabels
(nicht abgebildet)
3Antriebsstift
43,1L Arbeitsschüssel
5Scharnier auf dem Griff
6Deckelscharnier
7Schneideknopf
8Abdeckung der Arbeitsschüssel mit3-in-
1-Einfüllstutzen
9Deckelverriegelung
10 3-in-1-Stopfer
11 Kühlbehälterdeckel
12 Extern verstellbare Schneidscheibe
(dünn bis dick)
13 Beidseitig verwendbare, feine/mittlere
Reibscheibe
14 Vielzweckmesser aus Edelstahl
15 Teigmesser
16 Antriebsadapter (oben)
17 Antriebsadapter (unten)
2
O/Pulse
1
1
4
7
3
10
9
6
5
8
2
11
12
13
14
15
16
17

20
TEILE UND MERKMALE
18 Abdeckung Würfelzubehör
19 Würfelmesser
20 Basis Würfelzubehör
21 Reinigungszubehör Würfelzubehör
22 Aufbewahrungsbehälter
18
20
19
12
22
17
16
21
15
13
14
ZUBEHÖRANLEITUNG
Zubehör Im Lieferumfang enthalten
5KFP1319* 5KFP1318*
Extern verstellbare Scheibe
• •
Aufbewahrungsbehälter
• •
Große Öffnung • •
3-in-1-Einfüllstutzen • •
Vielzweckmesser • •
Teigmesser • •
Feines und mittelgrobes Reiben • •
Aufbewahrungsdeckel •
Würfelzubehör •
