KitchenAid KSM180LELB User manual

Stand Mixer
KSM180LELB
W11555038A.indb 1W11555038A.indb 1 21-01-2022 10:48:1621-01-2022 10:48:16

2
PARTS AND FEATURES
1Speed Control Lever
2Motor Head
3Attachment Hub
4Attachment Knob
5Motor Head Locking Lever
(not shown)
6Beater Shaft
7Beater Height Adjustment Screw
(not shown)
8Bowl
9Bowl Clamping Plate
10 Stainless Steel Pastry Beater* and
Nylon Scraper* **
11 Stainless Steel Flat Beater*
12 Stainless Steel Wire Whip*
13 Stainless Steel Dough Hook*
*Also available as an optional accessory.
**Can also be used to scrape your bowl.
3
5
4
2
1
7
9
8
6
10 11 12
13
W11555038A.indb 2W11555038A.indb 2 21-01-2022 10:48:1821-01-2022 10:48:18

ENGLISH
3
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Stand Mixer in water or
other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they are closely supervised and instructed concerning
use of the appliance by a person responsible for their safety. Close
supervision is necessary when any appliance is used by or near children.
Children should be supervised to ensure that they do not play with the
appliance.
4. Turn the appliance to “0” (OFF), then unplug from the outlet when not in use,
before assembling or disassembling parts, and before cleaning. To unplug,
grasp the plug and pull from the outlet. Never pull from the power cord.
5. Avoid contacting moving parts. Keep hands, hair, and clothing, as well
as spatulas and other utensils, away from beater during operation to reduce
the risk of injury to persons and/or damage to the Stand Mixer.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorized Service Facility for examination, repair,
or electrical or mechanical adjustment.
7. The use of accessories or attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
8. Do not use the Stand Mixer outdoors.
9. Do not let the cord hang over the edge of table or counter.
10. Remove the Flat Beater, Wire Whip, Pastry Beater, or Dough Hook from the
Stand Mixer before washing.
W11555038A.indb 3W11555038A.indb 3 21-01-2022 10:48:1921-01-2022 10:48:19

4
PRODUCT SAFETY
11. Allow the appliance to cool completely before putting on or taking off parts,
and before cleaning the appliance.
Important Security Measures required for compliance with regulations in
Mexico:
12. If the power cord is damaged, it must be replaced by the manufacturer or its
service agent or by qualified personnel to avoid any risk.
13. The appliance is not intended for use by persons (including children) who
suffer from reduced physical, sensory or mental capabilities or who lack the
necessary experience or knowledge unless such persons are supervised or
trained by a person authorized to operate the appliance.
14. Children must be supervised to ensure that they do not use the appliance as
a toy.
15. Do not touch hot surfaces. The surface of the heating element is subject to
residual heat after use. Use handles/knobs/buttons.
16. To protect against the risk of electric shock, do not immerse the cord,
plug/socket, or appliance in water or other liquids.
17. Do not use the device for any other use other than that for which it was
designed. Improper use of the appliance may lead to possible personal
injury.
18. Unplug the appliance from the outlet when not in use and before cleaning.
Let the appliance cool down before adding or removing components and
before cleaning.
19. This appliance is intended for use in the home and for similar applications,
such as the following:
a) By kitchen staff in retail areas, offices and other work environments;
b) Country houses;
c) By clients in hotels, motels or other residential-type settings;
d) Bedroom or dining room settings.
20. Do not use the appliance for any other use other than that for which it was
designed. It could lead to possible injury.
This product is designed for household use only.
SAVE THESE INSTRUCTIONS
W11555038A.indb 4W11555038A.indb 4 21-01-2022 10:48:1921-01-2022 10:48:19

ENGLISH
5
ELECTRICAL REQUIREMENTS
KSM180LELB
Voltage: 120 V~
Frequency: 60 Hz
Wattage: 325 W
NOTE: The power rating for your Stand
Mixer is printed on the serial plate.
Do not use an extension cord. If the
power supply cord is too short, have
a qualified electrician or service technician
install an outlet near the appliance.
The maximum rating is based on the
attachment that draws the greatest
load (power). Other recommended
attachments may draw significantly
less power.
GETTING STARTED
ACCESSORY USE TO MIX SUGGESTED ITEMS
Flat Beater* Normal to heavy
mixtures Cakes, creamed frostings, candies, cookies, biscuits, pie pastry, meatloaf, mashed potatoes.
Pastry Beater* Cut butter into
flour
For pie dough, biscuits and other pastries,
mashing fruits and vegetables, and shredding
meats.
Wire Whip* Mixtures that need air
incorporated
Eggs, egg whites, heavy cream, boiled frostings,
sponge cakes, mayonnaise, some candies.
Dough Hook* Mixing and kneading yeast
doughs Breads, rolls, pizza dough, buns.
CHOOSING THE RIGHT ACCESSORY
*Also available as an optional accessory.
NOTE: Nylon Scraper assists in cleaning the Pastry Beater*. It may also be useful in
scraping ingredients from the bowl.
PRODUCT SAFETY
W11555038A.indb 5W11555038A.indb 5 21-01-2022 10:48:1921-01-2022 10:48:19

6
SPEED CONTROL GUIDE
SPEED ACTION ACCESSORY DESCRIPTION
STIR STIR Flat Beater* For starting all mixing procedures, slow
stirring, and combining.
1
2
STIR Pastry Beater* Cut butter into flour to make pastry dough;
Mash fruits and vegetables.
SLOW
MIXING
Flat Beater* For slow mixing, mashing, and faster
stirring.
Dough Hook* To mix and knead yeast doughs, heavy batters, and candies; mix thin or splashy
batters.
4MIXING,
BEATING
Flat Beater* For mixing semi-heavy batters, such
as cookies, or to combine sugar and
shortening. Medium speed for cake mixes.
Pastry Beater* For shredding meats.
Wire Whip* For adding sugar to egg whites for
meringues.
6BEATING,
CREAMING
Flat Beater*
For medium-fast beating (creaming),
or whipping. Use to finish mixing cake,
doughnut, and other batters. High speed
for cake mixes.
Wire Whip* For medium-fast whipping of ingredients requiring incorporation of air, such as egg
whites.
8FAST BEATING,
WHIPPING Wire Whip* For whipping cream, egg whites,
and boiled frostings.
NOTE: The Speed Control Lever can be set to obtain speeds 1, 3, 5, 7 and 9 if a finer
adjustment is required. To move the Speed Control Lever with ease, lift up slightly as
you move it across the settings in either direction.
PRODUCT ASSEMBLY
Turn the Stand Mixer “0” (OFF) and
unplug.
1
Unlock and lift the Motor Head. Then,
lock** the head to keep it lifted.
2
*Also available as an optional accessory.
**Locking option is available on select models.
IMPORTANT: Do not exceed Speed 2 when preparing yeast doughs as this may cause
damage to the Stand Mixer.
W11555038A.indb 6W11555038A.indb 6 21-01-2022 10:48:1921-01-2022 10:48:19

ENGLISH
7
PRODUCT ASSEMBLY
Place the Bowl on the Clamping Plate
and twist to lock in place.
3
1
2
Slide and rotate the accessory, aligning
over the pin on the shaft.
4
Unlock the Motor Head and move it
down. Then, lock* the head to keep
it down. Before mixing, test lock by
attempting to raise the Motor Head.
5
(OPTIONAL) To adjust Beater to Bowl
Clearance: Tilt back and lock* the
Motor Head. Turn the screw slightly
counterclockwise (left) to raise the
beater, or clockwise (right) to lower it.
NOTE: If you overadjust the screw, the
locking lever may not lock into place.
*Locking option is available on select models.
W11555038A.indb 7W11555038A.indb 7 21-01-2022 10:48:2121-01-2022 10:48:21

8
PRODUCT USAGE
Plug it into a grounded 3 prong outlet.
Start with lower speed to avoid splashing,
and increase speed gradually.
Refer to the “Speed Control Guide”.
1
Do not scrape the Bowl while operating.
Scraping the Bowl once or twice during
mixing is usually sufficient.
2
W11555038A.indb 8W11555038A.indb 8 21-01-2022 10:48:2121-01-2022 10:48:21

ENGLISH
9
PRODUCT DISASSEMBLY
Unlock and lift the Motor Head. Then,
lock* the head to keep it lifted.
2
Press the accessory upward, turn it and
pull it away from the Beater Shaft.
3
Twist to unlock the Bowl from the
Clamping Plate.
4
Turn the Stand Mixer “0” (OFF) and
unplug.
1
KitchenAid offers a wide range of optional attachments such as the Spiralizer, Pasta
Cutters, or Food Grinder that may be attached to the Stand Mixer attachment power hub
as shown here.
Remove the Attachment Hub cover.
2
*Locking option is available on select models.
OPTIONAL ATTACHMENTS
Turn the Stand Mixer “0” (OFF) and
unplug.
1
W11555038A.indb 9W11555038A.indb 9 21-01-2022 10:48:2321-01-2022 10:48:23

10
Insert attachment into Attachment Hub,
making certain that attachment power
shaft fits into the square Attachment
Hub socket.
3
Tighten the Attachment Knob by turning
it clockwise until the attachment is
secured to the Stand Mixer.
4
OPTIONAL ATTACHMENTS
*Also available as an optional accessory.
DOUGH SCRAPER USAGE
Turn the Stand Mixer “0” (OFF) and
unplug. Remove dough from the Bread
Bowl with the help of Nylon Scraper.
1
W11555038A.indb 10W11555038A.indb 10 21-01-2022 10:48:2621-01-2022 10:48:26

ENGLISH
11
IMPORTANT: Do not immerse the Stand Mixer body in water or other liquids. Allow the
appliance to cool completely before putting on or taking off parts, and before cleaning
the appliance.
CARE AND CLEANING
Turn the Stand Mixer “0” (OFF) and
unplug.
1
Dishwasher-safe parts, top rack only:
Stainless Steel Flat Beater*, Stainless Steel
Pastry Beater* and Nylon Scraper** *,
Stainless Steel Wire Whip*, and Stainless
Steel Dough Hook*. Or, clean them
thoroughly in hot sudsy water and rinse
completely before drying. Do not store
beaters on shaft.
2
Wipe the Stand Mixer body with a soft,
damp cloth.
3NOTE: Stainless steel accessories are
dishwasher-safe.
*Also available as an optional accessory.
**Can also be used to scrape your bowl.
W11555038A.indb 11W11555038A.indb 11 21-01-2022 10:48:2621-01-2022 10:48:26

12
CARE AND CLEANING
CLEANING THE COPPER BOWL
IMPORTANT: Do not wash the Copper
Bowl in the dishwasher. Copper Bowl is
hand washable only.
1
Copper Bowl Care:
Copper Exterior:
Copper is a natural material. Variation
in color after use is expected, and this
patina finish will vary for each bowl. If
using a commercial copper cleaner to
polish, follow manufacturer’s directions
and buff with a soft dry cloth.
2
IMPORTANT
• Scrubbing too hard may scratch the copper finish.
• Avoid harsh or abrasive detergents.
• Do not use steel wool or steel scouring pads.
Before first use, wash with warm soapy water.
W11555038A.indb 12W11555038A.indb 12 21-01-2022 10:48:3121-01-2022 10:48:31

ENGLISH
13
TROUBLESHOOTING GUIDE
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
PROBLEM SOLUTION
If Stand Mixer warms up
during use:
Under heavy loads with extended mixing time periods, you
may not be able to comfortably touch the top of the unit.
This is normal.
If the Flat Beater hits the
bowl: Stop the Stand Mixer. See the “Product Assembly” section and adjust the beater to bowl clearance.
If Speed Control Lever does
not move smoothly or easily: To move the Speed Control Lever with ease, lift up slightly as you move it across the settings in either direction.
If your Stand Mixer should fail
to operate, please check the
following:
Is the Stand Mixer plugged in?
Is the fuse in the circuit to the Stand Mixer in working order?
If you have a Circuit Breaker Box, be sure the circuit is
closed.
Turn off the Stand Mixer for 10-15 seconds, then turn it back
on. If the Stand Mixer still does not start, allow it to cool for
30 minutes before turning it back on.
If the problem cannot be
corrected:
See the “Warranty and Service” section.
Do not return the Stand Mixer to the retailer; retailers do
not provide service.
W11555038A.indb 13W11555038A.indb 13 21-01-2022 10:48:3221-01-2022 10:48:32
