KitchenAid KSM3311X User manual

KSM3311X
KSM3316X
W10882018A_EN_v05.indd 1 4/20/16 3:27 PM

2 | PARTS AND FEATURES
PARTS AND FEATURES
PARTS AND ACCESSORIES
Pouring shield*
Flex Edge
beater*
Wire whip
Dough hook
Speed control
* Select models only and accessories sold separately.
** Bowl type may vary. Bowls are also available for purchase as separate accessories.
Motor head
Attachment hub
Beater shaft
Flat
beater*
Bowl**
W10882018A_EN_v05.indd 2 4/20/16 3:27 PM

ENGLISH
STAND MIXER SAFETY | 3
STAND MIXER SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. To avoid risk of electrical shock, do not put Stand Mixer in water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug the Stand Mixer from outlet when not in use, before putting on or taking
off parts, and before cleaning.
5. Avoid contacting moving parts. Keep hands, hair, and clothing, as well
as spatulas and other utensils, away from beater during operation to reduce
the risk of injury to persons and/or damage to the Stand Mixer.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the
nearest Authorized Service Facility for examination, repair or adjustment.
7. The use of accessories not recommended or sold by KitchenAid may cause
re, electric shock or injury.
8. Do not use the Stand Mixer outdoors.
9. Do not let the cord hang over the edge of table or counter.
Flat
beater*
Bowl**
W10882018A_EN_v05.indd 3 4/20/16 3:27 PM

4 | USING THE STAND MIXER
STAND MIXER SAFETY
10. Do not let the cord contact hot surfaces, including the stove.
11. Remove the at beater, wire whip, or spiral dough hook from
the Stand Mixer before washing.
SAVE THESE INSTRUCTIONS
THIS PRODUCT IS DESIGNED FOR HOUSEHOLD USE ONLY.
ELECTRICAL REQUIREMENTS
Voltage: 120 V
Frequency: 60 Hz
Wattage: 250 Watts
NOTE: The power rating for your
Stand Mixer is printed on the serial
plate.
Do not use an extension cord. If the
power supply cord is too short, have
a qualified electrician or serviceman
install an outlet near the appliance.
The maximum rating is based on the
attachment that draws the greatest
load (power). Other recommended
attachments may draw significantly
less power.
USING THE STAND MIXER
CHOOSING THE RIGHT ACCESSORY
ACCESSORY USE TO MIX DESCRIPTION
FLAT BEATER*
FLEX EDGE BEATER*
Normal
to heavy
mixtures
Cakes, Creamed frostings, Candies,
Cookies, Biscuits, Pie pastry, Meat loaf,
Mashed potatoes
WIRE WHIP Mixtures
that need air
incorporated
Eggs, Egg whites, Heavy cream,
Boiled frostings, Sponge cakes,
Mayonnaise, some Candies
DOUGH HOOK Mixing and
kneading yeast
doughs
Breads, Rolls, Pizza dough, Buns
* Select models only and accessories sold separately.
W10882018A_EN_v05.indd 4 4/20/16 3:27 PM

ENGLISH
USING THE STAND MIXER | 5
FOR DETAILED INFORMATION ON USING THE STAND MIXER:
Visit kitchenaid.com/quickstart for additional Instructions with videos, inspiring recipes,
and tips on how to use your Stand Mixer.
USING THE STAND MIXER
SPEED CONTROL GUIDE
All speeds have the Soft Start®feature which automatically starts the Stand Mixer
at a lower speed to help avoid ingredient splash-out and “our puff” at start-up,
then quickly increases to the selected speed for optimal performance.
NOTE: The speed control can be set between the speeds listed in the chart to obtain
speeds 1, 3, 5, 7, and 9 if a finer adjustment is required. Do not exceed Speed 2 when
preparing yeast doughs as this may cause damage to the Stand Mixer.
SPEED ACCESSORY ACTION DESCRIPTION
STIR STIR For starting all mixing procedures, slow
stirring, combining, and mashing. Use to
add our and dry ingredients to batter,
and to add liquids to dry ingredients.
Do not use Speed 1 to mix or knead
yeast doughs.
1
2SLOW MIXING For slow mixing, mashing, and faster
stirring. Use to mix and knead yeast
doughs, heavy batters, and candies;
start mashing potatoes or other
vegetables; cut shortening into flour;
mix thin or splashy batters.
4MIXING,
BEATING For mixing semi-heavy batters, such
as cookies. Use to combine sugar and
shortening, and to add sugar to egg
whites for meringues. Medium speed
for cake mixes.
6BEATING,
CREAMING For medium-fast beating (creaming),
or whipping. Use to finish mixing cake,
doughnut, and other batters. High
speed for cake mixes.
8FAST BEATING,
WHIPPING For whipping cream, egg whites,
and boiled frostings.
10 FAST WHIPPING For whipping small amounts of cream,
or egg whites; for final whipping of
mashed potatoes.
NOTE: To move the speed control lever with ease, lift slightly up as you move it across
the settings in either direction.
W10882018A_EN_v05.indd 5 4/20/16 3:27 PM

6 | USING THE STAND MIXER
USING THE STAND MIXER
ASSEMBLING THE STAND MIXER
1Check to be sure that the Stand
Mixer is unplugged, and the speed
control is turned to “0”. 2
Raise the motor head: Slide the
locking lever to the unlock position
and lift the motor head. Once lifted,
slide the locking lever to the lock
position to keep the motor head up.
3
Attach the bowl: Place the bowl on
the bowl clamping plate and gently
turn it in a clockwise direction to
lock it into place.
4
Attach any accessory: Slip the
accessory onto the beater shaft and
press upward as far as possible. Turn
the accessory counterclockwise to
hook the accessory over the pin on
the shaft.
NOTE: To move the speed control lever
with ease, lift slightly up as you move it
across the settings in either direction.
W10882018A_EN_v05.indd 6 4/20/16 3:27 PM

ENGLISH
USING THE STAND MIXER | 7
USING THE STAND MIXER
IMPORTANT: Your Stand Mixer is adjusted at the factory so that the at beater just
clears the bottom of the bowl. If, for any reason, the at beater hits the bottom of
the bowl or is too far away from the bowl, you can easily correct the clearance.
NOTE: When properly adjusted, the flat beater will not strike on the bottom or sides
of the bowl. If the flat beater or the wire whip is so close that it strikes the bottom of
the bowl, coating may wear off the beater or wires on the whip may wear.
ASSEMBLING THE STAND MIXER
(OPTIONAL) To adjust beater to
bowl clearance: Tilt the motor head
back; then turn the screw slightly
counterclockwise (left) to raise the
beater, or clockwise (right) to lower the
beater. Adjust the beater so that it just
clears the surface of the bowl. If you
over adjust the screw, the bowl lock
lever may not lock into place.
(OPTIONAL) Place the pouring shield*:
Slide the pouring shield* from the
front of the Stand Mixer over the
bowl until the pouring shield* is
centered. The bottom rim of the
pouring shield* fits inside of the bowl.
The pouring chute will be just to the
right of the attachment hub as you face
the Stand Mixer.
5
Lower the motor head: Slide the
locking lever to the unlock position
and guide the motor head down.
Make sure motor head is completely
down, then slide the locking lever
to the lock position. Before mixing,
test lock by attempting to raise
motor head.
* Select models only and accessories sold separately.
W10882018A_EN_v05.indd 7 4/20/16 3:27 PM

8 | USING THE STAND MIXER
USING THE STAND MIXER
OPERATING THE STAND MIXER
NOTE: The Stand Mixer may warm up during use. Under heavy loads with extended
mixing time, the top of the unit may become hot. This is normal.
1
Plug the Stand Mixer into a
grounded 3 prong outlet. Always
set the speed control lever on
lowest speed to start, then gradually
increase speed to avoid splashing
ingredients. See the “Speed control
guide” to select the best speed for
your recipe.
2
Do not scrape the bowl while
the Stand Mixer is operating.
The bowl and beaters are designed
to provide thorough mixing without
frequent scraping. Scraping the
bowl once or twice during mixing
is usually sufficient.
NOTE: To move the speed control lever
with ease, lift slightly up as you move it
across the settings in either direction.
W10882018A_EN_v05.indd 8 4/20/16 3:27 PM

ENGLISH
USING THE STAND MIXER | 9
USING THE STAND MIXER
DISASSEMBLING THE STAND MIXER
NOTE: The pouring shield* can be
used to avoid ingredients splashing
out of the bowl when mixing as well
as to easily pour ingredients in the
bowl while mixing.
1
Raise the motor head: Check to
be sure that the Stand Mixer is
unplugged, and the speed control is
turned to “0”; then slide the locking
lever to the unlock position and lift
the motor head. Once lifted, slide
the locking lever to the lock position
to keep the motor head up.
(OPTIONAL) Remove the pouring
shield*: Lift the front of the pouring
shield* clear of the rim of the bowl,
and pull away from the Stand Mixer.
2
Remove the accessory: Turn the
speed control to “0”, unplug the
Stand Mixer, and tilt the motor head
back; then, press the accessory
upward as far as possible, turn the
accessory clockwise and pull it away
from the beater shaft.
3Remove the bowl: Gently turn
the bowl counterclockwise to release
it from the bowl clamping plate.
(OPTIONAL) Pour ingredients into the
bowl through the pouring chute.
* Select models only and accessories sold separately.
W10882018A_EN_v05.indd 9 4/20/16 3:27 PM

10 | USING THE STAND MIXER
USING THE STAND MIXER
OPTIONAL ATTACHMENTS
KitchenAid offers a wide range of optional attachments such as the spiralizer, pasta
cutters, or food grinder that may be attached to the Stand Mixer attachment power
hub as shown here.
1Check to be sure that the Stand
Mixer is unplugged, and the speed
control is turned to “0”. 2Turn the attachment knob
counterclockwise to remove
attachment hub cover.
3
Insert attachment into attachment
hub, making certain that attachment
power shaft ts into the square
attachment hub socket. It may be
necessary to rotate the attachment
back and forth. When it is in the
proper position, the pin on the
attachment will t into the notch
on the hub rim.
4
Tighten the attachment knob
by turning it clockwise until the
attachment is completely secured
to the Stand Mixer. See the
Instructions manual that came
with your attachment for detailed
directions on using the attachment.
