Kitronik MOVE mini User manual

:MOVE Mini
TIPPER TRAILER ADD-ON
GET TIPPING WITH THE

BUILD INSTRUCTIONS
1
Take the :MOVE mini and remove the front ‘:MOVE’ piece, followed
by the SERVO:LITE board, and then the pen mounting plate above
the servos. Put these aside for now, you will need them later.
1x
Tow Panel
& Connector
Exterior Side
Panels & Wheels
Servo &
Gear
Front, Base & Rear
Bucket Panels
Side Bucket
Panel
Servo
Connectors
M3x10 Countersunk
Screw
M3x6 Screw
M3 Washer
M2x16mm
Screw
M2x6mm
Screw
M2 Nuts
SUPPLIED WITH THIS KIT: 2x
2x 5x
8x
NOTE: If not done already, the SERVO:LITE board
will need to be converted for use of three servos
with the pin header provided.
Visit kitronik.co.uk/3servo for the online guide.
Base Panel
Pin Header

2Install the tow panel at the rear of the :Move mini using two
M3x10mm countersunk screws, passing through the hole in the
base and threading into the connector below. Thread an M2x16mm
screw halfway through the small hole. This will be the tow-bar to
connect the trailer.
3
NOTE: There will
be a small amount
of movement of
this part.
To begin building the trailer, use two M2x16mm
screws to assemble the exterior sides of the
trailer: thread the M2 nuts partially onto the
ends by approximately 3mm.
Use an M2X6mm bolt to attach the wheel
to the outside. Thread the screw into the
perspex, making sure the wheel is loose
enough to allow the wheel to spin freely.
4
5Use one of the M3x6mm screws
to attach the tipper bucket side
panel. A washer should be inserted
between the panels. Thread the
screw into the perspex, making
sure to leave this loose enough to
rotate freely.

Place the servo onto the base panel and
slot the connectors into the base from
below with the flat edge facing inwards.
Screw the servo into place with the
M2x6mm bolts: these should pass through
the servo and thread into the perspex.
8Press the servo gear onto the servo to fit firmly in
place and rotate fully clockwise.
7
NOTE: Ensure the servo is fitted with
the axle lined up with the cut-out in the
base panel as shown.
6Repeat steps 3-5 for the opposite
side, making sure components
are in reverse order.

9Slot the exterior side panel onto the base on the same
side as the servo gear. Place the tipper bucket panel
in the fully down position. Fit the nuts threaded on
previously into the slots in the base panel from below
and fit components together. Tighten the screws to
secure in place.
10
NOTE: Alternatively, using a
piece of tape to hold the nut in
place can help with this step.
NOTE: Before you continue,
check that the bucket side panel
rotates back and forth correctly.
Connect the rear panel of the tipper
bucket onto the trailer as shown
using an M2x6mm screw and M2
nut. Keep the nut in place while
inserting the screw by placing a
finger behind the slot in the panel.

Rotate the tipper
backwards and slot
the base panel of
the tipper bucket
into place, followed
by the front panel.
12
Repeat step 9 to attach the second exterior panel on the
opposite side. Make sure to slot the rear panel in as shown and
tighten the screws in the base. Then insert the second M2x6mm
screw into the rear panel with another M2 nut as shown using
the previous method.
Install the two remaining
M2x6mm screws at the
front of the tipper and
secure in place with the
M2 nuts.
NOTE: The front panel
will only fit in one way.
11
13

Thread the servo wires under the bucket and through the holes
in the base panel, then up through the tow panel connected to the
:Move mini - you may need to loosen the tow panel to allow the
wires to pass through the hole. Hook the tipper trailer under the
tow hook. Reconnect the servo wires and replace the SERVO:LITE
board and pen mounting plate in the :Move mini, followed by the
:MOVE piece at the front. Tuck the loose wires under the pen
mounting plate.
15 GET CODING!
Visit kitronik.co.uk/5624-TT for help.
NOTE: With the back of the
board facing you - the third
servo attaches to uppermost,
right, set of pins.
14

For more information on RoHs and CE please visit kitronik.co.uk/rohs-ce.
Children assembling this product should be supervised by a competent
adult. The product contains small parts so should be kept out of reach of
children under 3 years old.
TOOLS REQUIRED: STOCK CODE
5624-TT
:
• Small Phillips Screwdriver
• Soldering Iron
• Knife
This accessory requires modification to the Servo:Lite board and
disables the on board ZIP LEDs. Visit kitronik.co.uk/3servo for the
online guide.
