All space requirements are minimum
finished dimensions.
Tolerances for space requirements .
Dimensions in cm.
EB (single platform) = 2 + 1 vehicles
+3
0
MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018
30
160
55
125
100 500 (520)
45
15°
6°13°
see table
Standard passenger cars:
Limousine, station wagon, SUV, van
according to clearance and maximal
surface load.
Clearance profile
width
weight
wheel load
190 cm
max. 2000 kg
max. 500 kg
Standard Special
190 cm
max. 2600 kg
max. 650 kg
Dimensions
Suitable for
If necessary, protective gratings are installed at the back area
The upper platform is a frame construction. Flooring can
be provided by the customer (e.g. soil/turf, sandbed/turfblock,
sandbed/marble, etc.). Maximum weight of customer coating
250 kg/m2.
The upper platform is at ground level and is traversible when in
lowered position (vehicle load: 2600 kg maximum, wheel load:
650 kg maximum). On special conditions the upper platform
may be used as parking space.
A separate maintenance manhole must be installed by the
customer (with manhole cover, ladder and a connecting
passage to the pit). A save maintenance access with a door
has to be provided by the customer – please contact KLAUS
Multiparking. The hydraulic power unit and ventilation system
are also housed in the maintenance manhole
Standard type
Special system: maximum load for extra charge.
To follow the minimum finished dimensions, make sure
to consider the tolerances according to VOB, part C
(DIN 18330 and 18331) and the DIN 18202.
Car width for platform width 230 cm. If wider platforms
are used it is also possible to park wider cars.
Potential equalization from foundation grounding connection
to system (provided by the customer).
Slope with drainage channel and sump see page 3.
In compliance with DIN EN 14010, 10 cm wide yellow-black
markings compliant to ISO 3864 must be applied by the
customer to the edge of the pit in the entry area to mark the
danger zone (see „load plan“ page 4).
At the transition section between pit floor and walls no hollow
mouldings/coves are possible. If hollow mouldings/coves are
required, the systems must be designed smaller or the pits
accordingly wider.
3
2
44
1
2
3
4
5
6
7
9
8
10
11
After operation, the system must always be run into the
lowest final position (key interlock).
2000 kg / 2600 kg
PRODUCT DATA
U20 EB
1 2
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description
530 for vehicle up to 5.00 m = 16’4’’ long
(550 for vehicle up to 5.20 m 17’ long)
Water drainage Grounding
Shaft for maintenance
x100
140230
75
11
56
7
109
8
U20 EB
H1 H2
Type
U20 EB-425
H1
425
H2
385
car height
165
U20 EB-495 495 455 200

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018
Wi th imensions
Top view close pit
Pit imensions
Single platform (EB) Serial system (with dividing walls)
Shaft covering
(performed by
the customer)
Top
platform
Entrance
EB
2x single platform (without dividing wall)
EB EBEB EBEB
275
285
295
305
315
Pit dimension B
230
240
250
260
270
Usable platform width
parking levels
270
280
290
300
310
Usable platform width
top platform
550
570
590
Pit dimension C
2 x 230
2 x 240
2 x 250
Usable platform width
parking levels
2 x 270
2 x 280
2 x 290
Usable platform width
top platform
610 2 x 260 2 x 300
630 2 x 270 2 x 310
Top edge
finished
floor
Top edge
finished
floor
Top edge
finished
floor
B
175175BB
B
175175
0,00
80 80
Passage
130
130
Door
(performed
by the
customer)
0,00
80 60 80 60
Shaft for
maintenance
0,00
80 60
C
75 75 75
20
20
Cutting
through
20
Cutting
through
Cutting
through
All sidewalls must be in a rectangular angel. Max. tolerances are 1 cm!
Warning: If the side or backside is freely accessible these areas must be safeguarded (safety fences, safety grids,
marking etc.). Measures to be taken according to project.
End parking spaces are generally more difficult to drive into. Therefore we recommended for end parking spaces
our wider platforms. Parking on standard width platforms with larger vehicles may make getting into and out of
the vehicle difficult. This depends on type of vehicle, approach and above all on the individual driver’s skill.
For vehicle widths larger 190 cm a platform width of 270 cm is required in order to enable the driver to
get in and out of the car on one side.
Page 2 of 7
For dividing walls: cutting through 15 x 15 cm.
12
121212
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018
usable platform width
EB 2000 kg
EB 2600 kg
F1 F2
+34
+37
+68
+74
Upper platform with sheet metal plates
usable platform width
EB 2000 kg
EB 2600 kg
F1 F2
+37
+40
+74
+80
Upper platform with stone layer
B
Marking
10
75
75
usable platform width
F1 F2
F1 F2
Entrance
min.18
F1 F2
Loa plan
Section
Top view
U20 EB
Page 3 of 7
Dimension B see page 2
Marking compliant to ISO 3864 (colors used in this illustration are not ISO 3864 compliant)
All forces in kN
The loading capacity of the base plate must be proved by a structural
engineer. Possibly stronger base plate could be necessary.
13
14
15
16
Units are dowelled to the floor. Drilling depth: approx. 15 cm.
Floor and walls below the drive-in level are to be made of concrete (quality minimum C20/25)!
13
14
15
16
Approach
The illustrated maximum approach angles must not be exceeded. Incorrect approach angles will cause serious
maneouvring & positioning problems on the parking system for which the local agency of KLAUS Multiparking
accepts no responsibility.
maximum
descending
slope 3 %
maximum
ascending
slope 10 %
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018 Page 4 of 7
Pit e ge/Drainage
140
Entrance
230
60 60
50
50
1-2%
1-2%
140 230
Floor drain
1-2% 1-2%
1-2%
1-2%
Base plate
Base plate Base
plate
Base
plate
Circular drainage
channel
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description
On-site coating of the uppermost platform
Maximum weight of customer coating 250 kg/m2.
Coating with asphalt or concrete
Coating with paving stones or turf gri s
Asphalt or concrete
8
100
Paving stones
or turf grids Ballast
100

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018 Page 5 of 7
Technical ata
Electrical installation
Installation iagram Electrical ata (to be performe by the customer)
120
0,00
7.2
9
13
1
2
3
4
12
116 14
8
7.1
5
10
Main fuse:
3 x fuse 25 A (slow)
or circuit breaker 3 x 25 A
(trigger characteristic K or C)
Supply line (3 PH + N + PE)
with marked wire and protective
conductor:
5 x 4 mm2
No. Qunatity Description Position Frequency
to main switch3 1 per unit1
in the supply
line
Electricity meter
11
in the supply
line
21 per unit1
Foundation earth connector corner pit
floor
5 every
10 m
Empty pipe DN 40
with taut wire
7.1 1 per
system
1
Separate supply line (230 V)
with lighting and power outlet
from supply
line into the
shaft
41 per
system
1
Equipotential bonding in accordance
with DIN EN 60204 from foundation
earth connector to the system
61 per
system
1
base pit to
operating
device
Empty pipe DN 40
with taut wire
supply line to
hydraulic unit
7.2 1 per
system
1
Stand for operating device8 1 per
system
1
Electrical ata (inclu e in elivery of KLAUS Multiparking)
Control box with lockable main switch
Control line 3 x 0.75 mm2(PH + N + PE)
Control line 7 x 1 mm2with marked wire and protective conductor
Operating device
Control line 4 x 2.5 mm2with marked wire and protective conductor
Hydraulic unit 7.5 kW with three-phase current, 230/400 V, 50 Hz
9
10
11
12
13
14
No. Description
Low-noise power units mounted to rubber-bonded-to metal
mountings are installed. Nevertheless we recommend that
parking system’s garage be built separately from the dwelling.
Units
– maintenance offer/contract
– declaration of conformity
Available ocuments
By default, the system can only be used for a fixed number of
users. If required, would you please contact us.
Fiel of application
If the permissible drop opening is exceeded, safety grids are to be
mounted on the systems. If there are traffic routes next to or
behind the installations, barriers compliant to DIN EN ISO 13857
must be installed by the customer. Barriers must also be in place
during construction.
Safety gri s
Environmental conditions for the area of multiparking systems:
Temperature range –10 to +40° C. Relative humidity 50% at a
maximum outside temperature of +40° C.
If lifting or lowering times are specified, they refer to an
environmental temperature of +10° C and with the system set
up directly next to the hydraulic unit. At lower temperatures or
with longer hydraulic lines, these times increase.
Environmental con itions
See separate sheet regarding corrosion protection.
Corrosion protection
To avoid damages resulting from corrosion, make sure to follow
our cleaning and care instructions and to provide good ventilation
of your garage.
Care
The systems offered correspond to DIN EN 14010 and the
EC Machinery Directive 2006/42/E .
CE Certification
According to LBO and aVo (garage regulations) the Multiparking
systems are subject to approval. For the building application please
submit this data sheet.
Buil ing application ocuments
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018
To be performe by the customer
Any constraints that may be necessary according to DIN EN ISO
13857 in order to provide protection for the park pits for pathways
directly in front, next to or behind the unit. This is also valid during
construction. Safety grids on the systems are, if necessary, optionally
available against surcharge.
Safety fences
Consecutive numbering of parking spaces.
Numbering of parking spaces
Any required lighting, ventilation, fire extinguishing and fire alarm
systems as well as clarification and compliance with the relevant
regulatory requirements.
Buil ing services
In the middle of the pit a floor drain with connection to the cable
network or a pump sump is to be provided. The water is to be
drained with a pump to be provided by the customer. From the
pit corners/bearing surface of the lifting columns an incline to the
floor drain/pump sump is necessary.
For reasons of environmental protection we recommend to paint
the pit floor, and to provide oil and petrol separators in the
connections to the public sewage network.
To divert large amounts of water from the court area, we
recommend that the customer install a water drainage channel
around the periphery of the pit.
Drainage
In compliance with DIN EN 14010, 10 cm wide yellow-black
markings compliant to ISO 3864 must be applied by the customer
to the edge of the pit in the entry area to mark the danger zone.
Marking
Suitable electrical supply to the main switch must be provided by
the customer during installation. The functionality can be monitored
on site by our fitters together with the electrician. If this cannot be
done during installation for some reason for which the customer
is responsible, the customer must commission an electrician at
their own expense and risk.
In accordance with DIN EN 60204 (Safety of Machinery. Electrical
Equipment), grounding of the steel structure is necessary, provided
by the customer (distance between grounding max. 10 m).
Electrical supply to the main switch / Foun ation earth connector
– Mounting of contactor and terminal box to the wall valve, complete
wiring of all elements in accordance with the circuit diagram
– Costs for final technical approval by an authorized body
– Main switch
– Control line from main switch to hydraulic unit
If the following are not inclu e in the quotation, they will
also have to be provi e / pai for by the customer:
The customer must provide a cable duct (Helfamin-tube) from
pit floor to operating device. The location of the control element
must be specified according to the project (control stand, house
wall, etc.).
Operating evice
In general, a crane must be supplied by the customer for
installation of the telescope columns.
Hook clearance min. 700 cm over access level, crane load
approx. 1400 kg.
Installing vertical columns
A separate maintenance manhole with manhole cover, ladder
and a connecting passage to the pit must be installed by the
customer. In multiple systems, a shared maintenance manhole
may be sufficient, depending on the project.
Maintenance manhole
The customer must comply with DIN 67528 »Artificial lighting
of parking areas and parking houses« for the parking structure
lighting. The intensity of illumination in the pit and in the
maintenance manhole must be min. 80 Lux.
Lighting
To achieve a constant exchange of air, reduce humidity, prevent
condensation, and reduce vehicle moisture (due to rain, snow, ice,
etc.), it is recommended that the customer consult specialized
engineers for heating, ventilation, and climate control and install
a ventilation system. This will reduce or prevent the hazard of
corrosion and its attendant failures.
Ventilation
Any necessary wall cuttings according to page 2.
Wall cuttings
Page 6 of 7
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description
Technical ata
According to DIN 4109 (Sound insulation in buildings), para. 4,
annotation 4, KLAUS Multiparkers are part of the building services
(garage systems).
Normal soun insulation:
DIN 4109, para. 4, Sound insulation against noises from building
services.
Table 4 in para. 4.1 contains the permissible sound level values
emitted from building services for personal living and working
areas. According to line 2 the maximum sound level in personal
living andworking areas must not exceed 30 dB (A).
Noises created by users are not subject to the requirements
(see table 4, DIN 4109).
The following measures are to be taken to comply with this value:
– Sound protection package according to offer/order
(KLAUS Multiparking mbH)
– Minimum sound insulation of building R’w= 57 dB
(to be provided by customer)
Increase soun insulation (special agreement):
Draft DIN 4109-10, Information on planning and execution,
proposals for increased sound insulation.
Agreement: Maximum sound level in personal living and working
areas 25 dB (A). Noises created by users are not subject to the
requirements (see table 4, DIN 4109).
The following measures are to be taken to comply with this value:
– Sound protection package according to offer/order
(KLAUS Multiparking mbH)
– Minimum sound insulation of building R’w= 62 dB
(to be provided by customer)
Note: User noises are noises created by individual users in our
Multiparking systems. These can be noises from accessing the
platforms, slamming of vehicle doors, motor and brake noises.
Soun insulation
On-site coating of the uppermost platform according to
sectional drawing on page 2 (maximum weight of customer
coating 250 kg/m2).
Coating on the uppermost platform

MultiBase U20 EB | Code number 588.51.740-002 | Version 03.2018
Description Single platform (EB)
We reserve the right to change this specification without further notice
Multiparking system providing independent parking spaces for
2 cars (EB) one on top of the other each. On special conditions
the upper platform may be used as parking space.
Dimensions are in accordance with the underlying dimensions of
parking pit, height and width.
The parking bays are accessed horinzotally (installation deviation ± 1 %).
Vehicles are positioned on each parking space using wheel stops on
the right side (adjust according to operating instructions).
Operation via operating device with key interlock using master keys.
Operating instructions are attached to each operator's stand.
General escription:
– 2 telescopic lifting columns at rear with hydraulic cylinder
(mounted to the floor)
– 2 telescopic lifting columns at front (mounted to the floor)
− 1 upper platform (for floor coating to be provided by the customer,
e.g. sand layer/stone layer, please KLAUS Multiparking).
Maximum weight of customer coating 250 kg/m2
Optional design with platform sheet metal plates from
KLAUS Multiparking, against surcharge.
− 2 lower platforms
− 1 mechanic synchronization control system (to ensure
synchronous operation of the hydraulic cylinders while lowering
and lifting the platform)
− 2 hydraulic cylinders
− Dowels, screws, connecting elements, bolts, etc.
− The platforms and parking spaces are end-to-end
accessible for parking!
Multiparking system consisting of:
– Platform base sections
– Adjustable wheel stops
– Canted access plates
– Side members
– Cross members
– Screws, nuts, washers, distance tubes, etc.
Lower platforms consisting of:
– Hydraulic cylinder
– Magnetic valve
– Hydraulic conduits
– Screwed joints
– High-pressure hoses
– Installation material
Hy raulic system consisting of:
– Operating device (Emergency Stop, lock, 1master key per
parking space)
– Control box with lockable main switch
Electric system consisting of:
– Hydraulic power unit (low-noise, installed onto a console with a
rubber-bonded-to-metal mounting)
– Hydraulic oil reservoir
– Oil filling
– Internal geared wheel pump
– Pump holder
– Clutch
– 3-phase-AC-motor
– Contactor (with thermal overcurrent relay and control fuse)
– Test manometer
– Pressure relief valve
– Hydraulic hoses (which reduce noise transmission onto the
hydraulic pipe
Hy raulic unit consisting of:
KLAUS Multiparking reserves the right in the course of technical progress to use newer or other technologies, systems, processes,
procedures or standards in the fulfillment of their obligations other than those originally offered provided the customer derives no
disadvantage from their so doing.
– Covering plates
– Side members
– Cross members
− Tray for customer coating, optional platform sheet metal plates
from KLAUS Multiparking
– Screws, nuts
Upper platform consisting of:
Page 7 of 7
Page 1
Section
Dimensions
Car data
Page 2
Width
dimensions
Page 3
Approach
Load plan
Page 4
Pit
Paving
Page 5
Electrical
installation
T
echnical
data
Page 6
Tec. data
To be perfor-
med by the
customer
Page 7
Description
