Klimawent WPA-E-N/Ex Series User manual

1
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
Use and Maintenance Manual
Explosion proof stand fans
WPA-E-N/Ex
ATEX marking: II 2 G c Ex e II T3
Contents:
1. Introductory Remarks .........................................................................2
2. Application..........................................................................................3
3. Reservations of Producer.....................................................................3
4. Technical Data ....................................................................................4
5. Structure and Function .......................................................................6
6. Assembly and Start-up.........................................................................6
7. Operational Use...................................................................................9
8. Troubleshooting Guide ........................................................................10
9. Maintenance .......................................................................................10
10. Occupational Health and Safety...........................................................11
11. Transport and Storage .........................................................................11
12. Terms of warranty ...............................................................................11
13. Sample of the Declaration of Conformity .............................................12
888W01
WPA-3-E-N/Ex
04.06.2019/EN
888W02
WPA-5-E-N/Ex
04.06.2019/EN
888W03
WPA-6-E-N/Ex
04.06.2019/EN
888W04
WPA-7-E-N/Ex
04.06.2019/EN
888W05
WPA-8-E-N/Ex
04.06.2019/EN
888W06
WPA-9-E-N/Ex
04.06.2019/EN
888W07
WPA-10-E-N/Ex
04.06.2019/EN

2
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
1. Introductory Remarks
The purpose of the present Use and Maintenance Manual is to supply User with directions wi-
thin the range of application, installation, start-up and the use of the WPA-E-N/Ex explosion-
proof stand fans.
Installing, start up and operational use are exclusively admissible after getting acquaint-
ted with the contents of the Use and Maintenance Manual.
With regard to continuity of work carried on improvement of our products, we reserve for oursel-
ves the revision possibility of the draft and technological changes improving their functional fea-
tures and safety.
The construction of the WPA-E-N/Ex Explosion-proof stand fans meets the requirements of the
current state of technology as well as the safety and health assurances included in:

2006/42/EC Machinery Directive of the European Parliament and of the Council of May 17th,
2006 on machinery –amending the 95/16/EC (recast) /Journal of Laws EC L157 of 09.06.2006, page 24/

2014/35/EC Directive of the European Parliament and of the Council of February 26th, 2014
on the harmonisation of the laws of the Member States relating to the making available on the
market of electrical equipment designed for use within certain voltage limits.
/Journal of Laws EC L96 of 29.03.2014/

2014/34/EC ATEX Directive of the European Parliament and of the Council of February 26th,
2014 on the harmonisation of the laws of Member States relating to equipment and protective
systems intended for use in potentially explosive atmospheres.
/ Journal of Laws EC L96 of 29.03.2014 /
Additionally, the appliance meets following harmonized standard:
●
EN ISO-12100:2012
–
“Safety of machinery –Basic concepts, general principles
for design. Risk assessment and risk reduction”.
●
EN 60204-1:2018-2 ??????
–
“Safety of machinery –Electrical equipment of machines.
Part 1: General requirements”.
●
EN ISO 13857:2010
–
“Safety of machinery –Safe distances to prevent hazard
zones being reached by upper and lower limbs”.
●
EN 80079-0:2013/A11:2014
–
“Electrical appliances in areas of gas explosion risk. Part 0:
General requirements”.
●
EN 60079-7:2016-02
–
“Electrical appliances for areas of gas explosion hazard.
Part 7: Increased safety construction “e”.
●
EN 1127-1:2011
–
“Explosive atmospheres. Explosion prevention and protec-
tion. Basic terminology and methodology”.
●
EN ISO 80079-36:2016-07
–
“Explosive atmospheres –Part 36: Non-electrical equip-
ment for explosive atmospheres. Methodology and requi-
rements.
●
EN ISO 80079-37:2016-07
–
“Explosive atmospheres –Part 37: Non-electrical equip-
ment for explosive atmospheres. Non-electrical types of
protection. Constructional safety “c”, supervised ignition
“b”, immersion in a liquid “k”.
●
EN 14986:2017-02
–
“Designing of fans applied in areas of explosion hazard”
●
ISO 14694:2003+AMD1:2010
–
“Industrial fans – Guidelines on the quality of balancing
and the vibration level.
●
ISO 14695:2008/AC:2017-10
–
“Industrial fans –Methods of measurements of vibration
of fans.

3
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
2. Application
WPA-E-N/Ex explosion proof stand fans are intended for use in areas of explosion risk, where
where explosive atmosphere, (i.e. mixture of flammable substances in form of gas and vapour
with the air, whereby after ignition –in atmospheric conditions –the burning mass would expand
within the whole non-burning mixture) can occur.
Increased fan pressure of these devices allows their application in a system cooperating with
local exhausts, filtering units, as well as in a ventilation system of significant flow resistances.
The fans can work in temperature range -20C up to +40C. They are meant for forwarding the
dry air of dustiness not exceeding 0,3 g/m³, without viscous impurities.
Pursuant to the ATEX 2014/34/EC Directive and PN-EN 13463-1 the appliance features level
of protection: HIGH as appliance classified in group II, category 2; can work in areas where
explosive atmospheres are possible to occur. The device can be applied in zones 1, 2(G).
The appliance is marked on the Ex classification board:
II 2 G c Ex e II T3
Marking of the operational conditions of the device: group / category / hazard / class.

marking for explosion proof properties of the appliance,

group II –the device is designed for work on-ground, in factories in areas where explosi-
ve atmospheres occur, but this cannot be methane risk (firedamp) neither carbon dust
occurrence,

category 2 –the device is designed for application in areas where explosive atmosphe-
res are sporadically likely to occur,

gas hazard G,

“c” –signifies the constructional protection,

Ex –mark of the electrical device –constructed and tested according to the European Stan-
dards for work in areas of explosion hazard,

execution “e” –type of construction of the motor (a motor of increased safety)

gas explosion group II –occurring in factories of on-ground location –the fans are construc-
ted according to EN 14986:2009, whereby they can be applied for gas in explosion groups
II and hydrogen,

temperature class T3 –the surface temperature of any part of the appliance should not ex-
ceed 200ºC;the device can be used safely in explosive atmospheres belonging to classes
T1, T2, T3.
3. Reservations of Producer
A.
Manufacturer accepts no liability for any consequences following from the operational use
that is in contradiction to the purpose of application.
B.
Installing any additional elements not belonging to the normal device structure (or acces-
sory set) is not acceptable.
C.
Do not undertake any structural changes or constructional modifications on the device on
one’s own.
D.
Protect the appliance’s housing from mechanical damage.
E.
Before the installing check the load carrying capacity of the wall/building structure in points
where the stand fan shall be installed. Unsure mounting could cause hazard to personnel
/ people in the vicinity.
F.
Do not use the fan for conveying the air containing viscous impurities that
could deposit (build up)on the device surface, especially on the impeller.

4
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
G.
Neither use it for forwarding the air with aggressive pollutants which will
destructively effect the device structure.
H.
During operation,the maximum impeller rotations should not exceed the nominal rotations.
I.
Manufacturer is not responsible for wounds, injuries, body laceration experienced
by User or personnel during the incorrect operational use.
4. Technical Data
Table No.1
Type
Synchronous
rotations**
Supply
voltage
Motor
rate
Ingress
protection
Acoustic pressure
level
[dB(A)]
from distance
Maximum
volume low
Maximum
vacuum
Weight
[1/min]
[V]
[kW]
IP
1m
5m
[m3/h]
[Pa]
[kg]
WPA-3-E-N/Ex
3000
3 x 400
0,25
56
69/61*
55/47*
1020
990
12
WPA-5-E-N/Ex
3000
3 x 400
0,55
56
76/67*
62/53*
1900
1250
17
WPA-6-E-N/Ex
3000
3 x 400
0,75
56
83/75*
69/61*
2500
1700
20
WPA-7-E-N/Ex
3000
3 x 400
1,1
56
86/74*
72/60*
3100
1800
23
WPA-8-E-N/Ex
3000
3 x 400
1,5
56
88/78*
74/64*
3900
2050
31
WPA-9-E-N/Ex
3000
3 x 400
2,2
56
91/82*
77/68*
4500
2400
38
WPA-10-E-N/Ex
3000
3 x 400
4,0
56
91/81*
77/67*
7400
2600
66
*
Acoustic pressure levels have been measured with the TK L=500 silencer attached at the
at the fan inlet and outlet (in case of WPA-3-E-N/Ex apply the silencer TK L=370 mm).
1.
Maximum temperature of the conveyed air is +60ºC,whereas maximum temperature within
the work zone +40ºC.
2.
Maximum dustiness of the conveyed air should not exceed 0,3 g/m3.
Fig. No.1 –Flow chart WPA-3-E-N/Ex

5
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
Fig. No.2 –Flow chart WPA-E-N/Ex
Fig. No.3 –Dimensions –WPA-E-N/Ex

6
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
Table No.2 –Dimensions –WPA-E-N/Ex
Type
A
B
C
D
E
F
n
G
H
J
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[pcs]
[mm]
[mm]
[mm]
WPA-3-E-N/Ex
410
385
50
125
125
155
6
6,5
380
130
WPA-5-E-N/Ex
480
480
60
160
160
194
6
6,5
420
140
WPA-6-E-N/Ex
490
505
60
160
160
194
6
6,5
445
140
WPA-7-E-N/Ex
550
520
60
200
160
194
6
6,5
460
155
WPA-8-E-N/Ex
570
550
60
200
200
224
234
246
8
6
8
9,0
6,5
9,0
475
155
WPA-9-E-N/Ex
615
620
60
200
200
224
234
246
8
6
8
9,0
6,5
9,0
500
155
WPA-10-EN/Ex
645
625
100
250
250
274
8
9,0
670
232
5. Structure and Function
The fan consists of a steel spiral housing, motor with installed on its shaft aluminium radial im-
peller. The impeller blades remind the airplane wing cross-section and provide low acoustic
pressure level of the fan.
The fan inlet is equipped with a flange to install the fan on the wall bracket or on a filtering unit,
whereas, the fan outlet is ended with a round fitting piece, for a safe connection of the spiral
seam duct (rigid conduit) or flexible connectors.
For safety reasons, the inlet and outlet are equipped with protective grills. It is recommended
to install silencers type TK at the inlet and outlet of the fan (see acoustic data in Table No.1).
ADDITIONAL EQUIPMENT –delivery on separate order:
■
motor protective switches WS –with short-circuit- and overload protection
■
wall brackets
■
silencers
It is important to fasten a protective cable (at the fan housing)to conduct the electrostatic char-
ges away. Additionally, on the motor housing is located a clamp to attach the protective cable,
which should be connected to the grounding. On the motor housing is placed a terminal box of
electrical supply.
6. Assembly and Start-up
The fans are meant for application within the industrial rooms. It is recommended to mount them
them on wall brackets (as additional equipment according to separate documentation). The fan
outlet must be connected with the discharge duct through a flexible section (made of antistatic
material). The connections should be fastened according to the configuration of the ventilation
system and its technology, and they ought to be suitable, with reference to the condition clari-
fications at the installing place. It is recommended to use silencers at the inlet and outlet.
User, who is performing the assembly is responsible for the compatibility with the reso-
lutions of EN ISO 13857.
6.1. Guidelines of installing
a/
VENTILATION INSTALLATION –to which WPA-E-N/Ex fans are connected,
shall be designed according to regulations and standards, with reference to the
local explosion hazard.
b/
ELECTRICAL POWER SYSTEM –to which WPA-E-N/Ex fans are connected,
shall be designed according to regulations and standards, with reference to the
local explosion hazard.

7
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
–
Before connection, make sure if the parameters of the existing electrical installation comply
with the parameters on the nominal data plate. Otherwise, connection cannot be carried out.
–
Any steps of connection to the power supply system ought to be executed by a person with
confirmed qualifications, according to the being in force, valid regulations and standards.
–
The whole ventilation system should be fitted with properly prepared installation to conduct
(dissipate) the electrostatic charges away.The couplings between the ventilation ducts must
have electrostatic connections made of protective cable.
–
Check if the metal ducts are grounded correctly. Moreover, carry out the grounding of the
motor housing, joining the protective cable with the contact on the motor housing.
Fan
Motor rate
[kW]
Current
[A]
Motor type
Cable
W1, W2
G-Y Protective
cable W3, W4
WP-3-E-N/Ex
0,25
0,9
SKh 63-2B; 3x400V; 50 Hz;
2870 r.p.m.; BESEL
should be
selected
by User
H05V-K 1G6
WP-5-E-N/Ex
0,55
1,4
SKh 71-2B; 3x400V; 50 Hz
2720 r.p.m.; IMV1; BESEL
WP-6-E-N/Ex
0,75
1,8
SKh 80-2A; 3x400V; 50 Hz;
2760 r.p.m.; IMV1; BESEL
WP-7-E-N/Ex
1,1
2,4
SKh80-2B; 3x400V; 50 Hz;
2780 r.p.m.; IMV1; BESEL
WP-8-E-N/Ex
1,5
3,5
SKh 90S-2; 3x400V; 50 Hz;
2850 r.p.m.; IMV1; INDUKTA
WP-9-E-N/Ex
2,2
4,7
SKg 90L-2; 3x400V; 50 Hz;
2860 r.p.m.; IMV1; INDUKTA
WP-10-E-N/Ex
4,0
7,5
SKg 112M-2; 3x400V; 50 Hz
2875 r.p.m.; IMV1; INDUKTA
Caution: The steel plate for current-equilibrating connections
–as in the Fig. No 1012-017078 of mechanical documentation
–referring the fans WPA-10-D-N/Ex; WPA-10-E-N/Ex.
Caution:
1. Supply voltage: 3x400V; 50Hz
2. Continuous work S1
3. Ingress protection IP56
4. Ambient temperature: -20ºC up to +40ºC
5. Insulation class F
6. To the fan housing connect the grounding cable
of length 400mm, ended with a KOI terminal.
7. Installations and devices for use in areas of
explosion risk –should be executed according to
–arrangements of the 2014/34/EC ATEX Directive,
–valid regulations and standards.
*
S1 isolating switch –in Ex execution. It is suggested to install
it near the fan. The application of the isolating switch is not
obligatory and depends on the decision of Investor.
Cables W1, W2 have to be selected by Investor, with reference
to the fan motor rate, cable length, outline of the cable, voltage
drop.
W3, W4 are cables for local equilibrating connections of cross-
section 6mm2, length 300 mm, ended with adequately selected
eye terminals, designed for connection to the fan fitting pieces.
CAUTION: The motor windings must be connected according
to the data on the nominal data plate of the motor and the
connection diagram (placed on the terminal box of the motor).
Fig. No. 4 –Connection diagram of the fan WPA-E-N/Ex

8
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
Fig. No.5 –Placement of the protective cables

9
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
6.2. Safety examine before the start-up:
a/
Check if all the mechanical connections are carried out correctly.
b/
Check the correctness of electrical connections and phase sequence.
c/
Examine the correctness of the connection between the motor and PE protective cable.
After the device is started up –check if the impeller rotation sense is according to the arrow
on the fan housing.
Fig. No.6 –Placement of the nominal plates and arrow of the correct fan rotation sense
The overload motor protection must have current-time performance, providing motor dis-
connection (from the power supply)in a time shorter than tEat the current being equal
to the start-up current of the motor.
7. Operational Use
Construction of the device assures a reliable function without continuous technical supervision.
Periodically, check the mechanical and electrical connections, the state of grounding and also
to provide the efficient cooling for the motor.
For incorrect operational use is considered:
a)
forwarding the media of temperature exceeding the admissible temperature (+60C),
b)
conveying aggressive media,
c)
conveying the media of high dustiness or with high content of pollution particles,
d)
use of the fan in a place where the temperature exceeds +40Cwithin the ambient area of
the motor.
Consequences of incorrect use:
a)
damage of the bearings,
b)
damages caused by corrosion,
c)
loss in balance of the rotating elements,
d)
vibrations,
e)
deformations,
f)
damages caused by friction.

10
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
Hazards which can occur due to improper use –damages or other defects caused by:

burst of the impeller,

break of the shaft,

fatigue crack of the material,

ignition / fire and explosion caused by sparks.
In cases when any symptoms of incorrect device function (noise increase, vibrations,
lowered flow efficiency)are noticed, the device should be disconnected from the power
supply system,and thoroughly revised (with reference to the reason of disturbance du-
ring the operation).
In case of every repair or spare part replacement (according to ATEX
2014/34 Directive) it is important to apply the adequate information on
on an additional plate or in the enclosed documentation (a register log of repair activi-
ties, etc.). This is the duty of the operator!
A list of frequent functional disturbances and ways of their elimination (corrective actions), is
exposed below.
8. Troubleshooting Guide
Table No.3
Problem
Possible reason
Corrective action
1.
Significant and sudden
Obstacle objects, pollutants redu-
Clean the inlet grid / ventilation con-
decrease of the intake
cing the air flow got stuck at the
duits.
flow efficiency.
inlet grid.
2.
Sudden vibrations
Obstacle objects reducing the
Disconnect the fan from the power
of the fan occur.
air flow got stuck in the impeller.
system, and remove the obstacle.
Impeller is defective.
Replace the impeller and the motor
for new.
3.
It is not possible to start
Fade of one of the phases or
Adjust to gain the correct voltage.
the fan.
the voltage is too low.
The block of protections got
Adjust the correct settings of protec-
activated.
tions.
9. Maintenance
Chiefly, the construction and solid execution of the fan guarantees its operational use, without
constant routine maintenance. To obtain correct functional performances of the fan and to meet
the Occupational Health and Safety, it is recommended to carry out technical revisions of
the fan in regular periods.
Technical revisions on the fan must be executed by a qualified person with
adequate authorization. Additionally, the fan should be necessarily discon-
nected from the power supply system.
In the course of technical revisions, follow the recommendations included in the User’s
Manual of the motor, that constitute integral part of the main Use and Maintenance Ma-
nual of the fan.
Scope of the technical revision:
–
Systematically, keep clean the inlet grill.
–
Periodically, check the mechanical and electrical connections. Moreover, when defective
function is by noise or visually spotted –undertake technical revision of the assembly.
–
Execute the check of the fan (motor –according to instructions of motor producer). During
the revision, clean the fan of the accumulated impurities.

11
04.06.2019 explosion-proof stand fan WPA-E-N/Ex
Before the start-up, follow subsequent steps on the fan:
–
Disconnect the fan from the power supply. Exemption from this are ac-
tivities that must be executed at the running fan, i.e. vibration measu-
ring (especially here are important Occupational Health and Safety re-
gulations).
–
Wait until the fan impeller stops rotating.
The fan can be restarted after the control steps are carried out, strictly as described in Section
6 “Assembly and Start-up”.
10. Occupational Health and Safety
Start up and the operational use of the fan are admissible after getting acquainted with
the contents of the present Use and Maintenance Manual. The fan shall not cause any me-
chanical hazard when it is correctly and firmly mounted to the floor or another constructional
element of the building.
Any installation activities related to the power supply, have to be carried out strictly according
to the enclosed Connection Diagram and in accordance with the instructions given in Section
6 of the present User’s Manual.
Connection to the power supply system ought to be carried out by an au-
theorized person with electrical qualifications, according to the valid regulations. The fan
should be protected from short-circuit and overload effects. In the course of operational
use, examine the connection to the PE protective cable.
Any revision activity and repair must be executed after the fan is disconnec-
ted from the power supply system. Approaching in “loose garment/clothing”
or putting the hand into the open inlet of the running fan can cause risk of
accident and severe disability.
11. Transport and Storage
Fans: WPA-3-E-N/Ex,WPA-5-E-N/Ex, WPA-6-E-N/Ex,WPA-7-E-N/Ex,WPA-8-E-N/Ex and
WPA-9-E-N/Ex are wrapped in foil and in cardboard packages. On the package surface must
be placed their weight. Whereas, large fans as WPA-10-E-N/Ex are solely wrapped in foil and
placed on a pallet.
During loading, reloading and transport the device neither should be thrown nor knocked down
/ overturned. Do not put any load on top of the device. It is inadmissible to put one device on
top of another (no stacking). During the transport protect them from atmospheric factors and
from mechanical damage. The fan must be stored in dry rooms and of efficient ventilation.
12. Terms of warranty
The period of warranty for the purchased device is indicated in the “Card of Warranty”. The war-
ranty does not comprise:
●
mechanical damages and malfunctions caused by User,
●
device failures / malfunctions caused during use which was in contradiction with the purpose
of operational use and with the present Use and Maintenance Manual,
●
any damages being caused during improper transport, storage or incorrect maintenance.
Infringement of the Clause 8 Section 3 “Reservations of Producer” of the present Use and Main-
tenance Manual and especially modifications undertaken by User on one’s own or use in contra-
diction with the purpose of application –shall result in the loss of warranty validity.

12
explosion-proof stand fan WPA-E-N/Ex 04.06.2019
13. Sample of the Declaration of Conformity
Declaration of conformity EC No. ……………..
Manufacturer (eventually the authorized representative / importer):
name: KLIMAWENT S.A.
address: 81-571 Gdynia, Chwaszczyńska 194
A person, authorized for issuing the technical documentation: Teodor Świrbutowicz, KLIMAWENT S.A.
hereby declares that the appliance:
name: explosion-proof stand fans
type/model: WPA-E-N/Ex
serial number: …………………………….. year of production: ………………………..
meets the requirements of the subsequent European Directives:

2006/42/EC Machinery Directive of the European Parliament and of the Council of May 17th, 2006 on machinery –amen-
ding the 95/16/EC (recast) /Journal of Laws EC L157 of 09.06.2006, page 24/

2014/35/EC Directive of the European Parliament and of the Council of February 26th, 2014 on the harmonisation of the
laws of the Member States relating to the making available on the market of electrical equipment designed for use within
certain voltage limits. /Journal of Laws EC L96 of 29.03.2014/

2014/34/EC ATEX Directive of the European Parliament and of the Council of February 26th, 2014 on the harmonisation of
the laws of Member States relating to equipment and protective systems intended for use in potentially explosive atmosphe-
res. / Journal of Laws EC L96 of 29.03.2014 /
The appliance meets following harmonized standard:
●
EN ISO-12100:2012
–
“Safety of machinery – Basic concepts, general principles for design. Ha-
zard assessment and risk reduction”.
●
EN 60204-1:2018-12
–
“Safety of machinery –Electrical equipment of machines. Part 1: Gene-
ral requirements”.
●
EN ISO 13857:2010
–
“Safety of machinery –Safe distances to prevent hazard zones from be-
ing reached by upper and lower limbs”.
●
EN 80079-0:2013/A11:2014
–
“Electrical appliances in areas of gas explosion risk. Part 0: General re-
quirements”.
●
EN 60079-7:2016-02
–
“Electrical appliances for areas of gas explosion hazard. Part 7: Increased
safety construction “e”.
●
EN 1127-1:2011
–
“Explosive atmospheres – Explosion prevention and protection. Basic ter-
minology and methodology”.
●
EN ISO 80079-36:2016-07
–
“Explosive atmospheres – Part 36: Non-electrical equipment for explosi-
ve atmospheres. Methodology and requirements.
●
EN ISO 80079-37:2016-07
–
“Explosive atmospheres – Part 37: Non-electrical equipment for explosi-
ve atmospheres. Non-electrical types of protection. Constructional safety
“c”, supervised ignition “b”, immersion in a liquid “k”.
●
EN 14986:2017-02
–
“Designing of fans applied in areas of explosion hazard”
●
ISO 14694:2003+AMD1:2010
–
“Industrial fans –Guidelines on the quality of balancing and the vibration
level.
●
ISO 14695:2008/AC:2017-10
–
“Industrial fans – Methods of measurements of vibration of fans.
……………………………
……………………………
……………………………
place, date
signature of authorised person
name, surname, function
of the signatory
KLIMAWENT S.A.
District Court Gdańsk-Północ
NIP: 958 159 21 35
Supported Employment Enterprise
in Gdańsk, VII Wydział Gospodarczy
REGON: 220631262
81-571 Gdynia, ul. Chwaszczyńska 194
of the National Register of Court
Bank Account: Santander Bank Polska S.A.
phone: [phone]
KRS 0000308902 company stock
56 1500 1025 1210 2007 8845 0000
email: [e-mail]
13.779.200 zł paid in total
www.klimawent.com.pl
