Klutch 114923 User manual

SAVE THESE INSTRUCTIONS
25ft. COMBO HOSE REEL/CORD REEL
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item # 114923

Page 2 of 16
Thank you very much for choosing a Klutch product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This dual hose reel is designed for certain applications only. Northern
Tool and Equipment cannot be responsible for issues arising from
modification or use of this product in an application for which it was not
designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 16
Table of Contents
Intended Use..........................................................................................................................................4
Technical Specifications ......................................................................................................................4
Important Safety Information...............................................................................................................5
Specific Operation Warnings...............................................................................................................8
Assembly ...............................................................................................................................................9
Operating Instructions........................................................................................................................10
Maintenance ........................................................................................................................................10
Parts Diagram......................................................................................................................................11
Parts List..............................................................................................................................................12
Troubleshooting..................................................................................................................................14
Replacement Parts..............................................................................................................................14
Limited Warranty.................................................................................................................................15

Page 4 of 16
Intended Use
Dual air and electric reels feature steel construction with corrosion resistant powder-coat finish. Full
flow solid swivel joint; multi-position release ratchet spring is fully enclosed. Four direction non-snog
rollers reduce hose wear abrasion. Can be mounted to a wall, ceiling or floor.
Technical Specifications
Property
Specification
Specification of Cord
3C / 125V
AWG
12
Amps (A）
13
Type
SJTOW
Outlet
S1
Length (ft)
25
Specification of Hose
3/8in. / 180 PSI
Material
NBR/SBR
Length (ft)
25

Page 5 of 16
Important Safety Information
•Read and understand all instructions. Failure to follow all instructions may result in serious injury.
•The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this reel. Always be
aware of the environment and ensure that the reel is used in a safe and responsible manner.
•DO NOT allow persons to operate or assemble the reel until they have read this manual and have
developed a thorough understanding of how it works.
•DO NOT modify the reel in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the reel.
•Use the right tool for the job. DO NOT attempt to force a small equipment to do the work of larger
industrial equipment. There are certain applications for which the reel was designed. It will do the
job better and more safely at the capacity for which it was intended. DO NOT use the reel for a
purpose for which it was not intended.
•Industrial or commercial applications must follow OSHA requirements.
WORK AREA SAFETY
•Inspect the work area before each use. Keep the work area clean, dry, free of clutter, and well lit.
Cluttered, wet, or dark work areas can result in injury. Using the reel in a confined work area may
put you dangerously close to other cutting tools and rotating parts.
•Do not use the reel when there is a risk of causing a fire or an explosion; e.g., in the presence of
flammable liquids, gases, or dust. The reel can create sparks, which may ignite the dust or fumes.
•Keep children and bystanders away from the work area while operating the reel. Do not allow
children to operate the reel.
•Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be below the work surface hidden from your view and
may cause personal harm or property damage if unintentionally contacted.
•Do not allow the reel to come into contact with an electrical source. The reel is not insulated and
contact will cause electrical shock.
PERSONAL SAFETY
•Stay alert, watch what you are doing, and use common sense when operating the reel. Do not
use the reel while you are tired or under the influence of drugs, alcohol, or medication. A moment
of inattention may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts.
•Use ANSI compliant safety goggles or safety glasses with side shields, or when needed, a face
shield. Use a dust mask in dusty work conditions. Also use non-skid safety shoes, hardhat,
gloves, dust collection systems, and hearing protection when appropriate.
•Do not overreach. Keep proper footing and balance at all times.

Page 6 of 16
•Secure the work with clamps or a vise instead of your hand when practical. This safety precaution
allows for proper tool operation using both hands.
DANGER
ELECTRICAL SAFETY
•Shock Hazard: Misuse can result in fire or death by electric shock.
•For indoor use in a dry location only.
•Do not use the reel in damp or wet conditions. Keep the work area is clean.
•Ensure that only the qualified electrician can installs/services this cord reel. Not for use by
children or unskilled persons.
•Do not plug in more than the specified Watts, Amps or Voltage on the cord reel.
•Ensure that reel is properly installed before connecting to power supply.
•Fully insert the plug into outlet.
•Ensure appliances are off before connecting to cord.
•Do not use excessive force to make connections.
•Ensure that all electrical power is removed from reel before servicing.
•Check for frayed and broken wires before each use. Do not use if damaged.
•Do not remove, bend, or modify any metal prongs or pins of cord.
•Do not connect a three-prong plug into a two-prong cord.
•Do not plug one extension cord into another.
•When pull electrical cord from the reel always grasp the electrical cord itself, not the work device.
•Do not drive, drag, or place objects over cord. Do not walk on cord.
•Remove power from the reel immediately when any malfunction occurs.
•Never remove, tamper with or cut out the safety devices installed by the manufacturer.
•Hold the hose/cord while rewinding.
•Always unplug when not in use. Grasp plug to remove from outlet. Do not unplug by pulling on
cord.
HOSE REEL USE AND CARE
•Check for damaged parts before each use. Carefully check that the reel will operate properly and
perform its intended function. Replace damaged or worn parts immediately. Never operate the
reel with a damaged part.
•Disconnect the air supply from the hose reel before making any adjustments, changing
accessories, or storing the reel.
•Use only accessories that are recommended by the manufacturer for use with your reel.
Accessories that may be suitable for one reel may create a risk of injury when used with another
reel. Never use an accessory that has a higher operating pressure than the reel itself.
•Inspect the reel, hose, and accessories for damage or excessive wear before each use. If you find
damage do not use the reel.

Page 7 of 16

Page 8 of 16
Specific Operation Warnings
•Wear ANSI Z87.1 compliant safety goggles or safety glasses with side shields when assembling
and using the hose reel.
•Assemble the hose reel on a clean workbench.
•Keep children away from the work area. If not in use, store out of the reach of children.
•Ensure that reel is properly installed before connecting input and output hoses.
•Make sure incoming pressure does not exceed the rated pressure (300 PSI) for reel.
•Before connecting a pressure source, ensure that supply pressure does not exceed maximum
working pressure rating of reel.
•Never attach any tool or accessory to the hose unless it is capable of safely operating at a
pressure greater than the supply pressure.
•If a leak occurs in the hose or reel, remove system pressure immediately.
•If reel ceases to unwind or rewind, remove system pressure immediately.
•Do not kink the hose. Do not step on the hose or drive or drag objects over the hose. Do not
place any objects on the hose or hose reel.
•Pull the hose from the reel by grasping the hose itself, not the valve. Do not pull or jerk on hose.
•Bleed fluid/gas pressure from reel before servicing it.
•Use soap and water when checking for air leaks. Exposure of skin directly to pressurized air or
fluids could result in severe bodily injury.
•Remember, even low pressure is very dangerous and can cause personal injury or death.
•Ensure that reel, hose, and equipment being service are properly grounded.
This product may contain chemicals known to the State of California to cause cancer, birth defects or
other reproductive harm.

Page 9 of 16
Assembly
Exposure to even low-pressure air or fluids is dangerous and can cause personal injury or death.
1）The reel must be installed in a location that conforms to current regulations and standards
covering electrical systems and work environments.
2）Secure the reel to the wall or the ceiling according to the installation diagrams. Use screw
anchors or suitable screws which must be fitted in the holes in the brackets.
3）If hose or bumper block adjustment is required, pull out some hose or cable from reel and allow to
latch at desired length. Loosen bumper bolts and slide bumper block to a position close to the
hose or cable guide. Tighten bumper bolts, and unlatch the reel.
4）The reel is supplied with a hose guide roller bracket. The bracket position may be changed
depending on the reel mounting position. Figure 2 shows “Typical Mounting Positions.” If bracket
position needs to be changed, do the following:
(1) Pull out some hose or cable and let reel latch.
(2) Remove the bolts that attach the guide roller bracket to the support post.
(3) Rotate guide roller bracket to correct position, replace bolts and tighten.
Floor Wall
Ceiling

Page 10 of 16
Operating Instructions
1. Check reel for correct operation by slowly pulling out hose or cable. A “clicking” noise will be
heard every half revolution of the drum.
2. To latch the reel, pull out the hose or cable and allow it to retract after hearing the first, second or
third “click.”
3. To unlatch, slowly pull out the hose or cable until the “clicking” noise stops, and then let hose or
cable retract until the hose or bumper block rests against the cable guide.
4. If overloaded, the current protector will cut off automatically, unplug all appliances from the cord
and push the button to restore power.
5. Periodically check the hose condition for wear or damage, and check the swivel fitting for leakage.
Replace any worn, damaged, or leaking parts.
Note: To avoid damage to the reel, always hold on to the cable while it is rewinding.
Do not allow the hose to automatically retract in an uncontrolled way as the hose may whip
around and cause damage to property or personal injury.
Maintenance
Do not open the spring cover. Behind these covers are the main rewind springs. Removal of this
cover by untrained persons can be very dangerous as the spring may come loose, unwind violently,
and cause serious personal injury.
Maintain your tool. It is recommended that the general condition of any tool be examined before it is
used. Keep your tool in good repair by adopting a program of conscientious repair and maintenance in
accordance with the recommended procedures found in this manual. Keep all cutting tools sharp and
clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier
to control. Keep handles dry, clean, and free from oil and grease.
1. Make sure the cable is in proper working order and that the insulation is not cut or worn as this
could represent a hazard and jeopardize operation.
2. Clean the cable with a cloth dipped in warm water to remove dirt or deposits and ensure correct
rewinding.
3. Do not use detergents or solvents, which could damage the reel.
4. If it is necessary to perform maintenance on the electrical, mechanical parts of the reel, or to
replace the cable, contact an authorized service center.
