INSTALLATION & MAINTENANCE MANUAL
HBLR
HBLR INSTRUCTIONS_WEB.indd 1 17/11/2017 09:49

2
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
HBLR1 / HBLR2
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this product should only be carried out by a qualified electrician or competent person
to the current Building and IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Remove the 4 screws as indicated in Fig 1
• Line up the 4 round screw holes on the reflector with the screw holes on the luminaire
• Using the 12mm screws provided with the reflector, fasten down the 4 screws to secure the
reflector to the luminaire
• This will modify the beam angle of HBL high bay units from 120 ° to 80°
•
•
•
Fig 1
HBLR INSTRUCTIONS_WEB.indd 2 17/11/2017 09:49

3
WARNING
GENERAL
WARRANTY
Only 4 screws (as indicated) should be removed to install this reflector
The unit should be recycled in the correct manner when it reaches the end of its life. Check local
authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the product.
This product has a warranty of 1 year from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of the
batch codes will invalidate the warranty. If this product should fail within its warranty period it should
be returned to the place of purchase for a free of charge replacement. ML Accessories does not accept
responsibility for any installation costs associated with the replacement product. Your statutory rights
are not affected. ML Accessories reserve the right to alter product specification without prior notice.
