CHIRP 3212 SERVICE MANUAL
D101-05192
Knudsen Engineering Limited
10 Industrial Road
Perth, Ontario, Canada
K7H 3P2
Phone: [phone]
Fax: [phone]
www.knudsenengineering.com

D101-05192 2 of 7
[e-mail]
CONTENTS
1 INTRODUCTION ................................................................. 3
1.1 Aboutthismanual .......................................................... 3
1.2 TechnicalSupport .......................................................... 3
1.3 Warranty ................................................................. 3
1.4 RevisionHistory............................................................ 3
2 SERVICE ....................................................................... 4
2.1 SystemAccess ............................................................. 4
3 PartsLists ....................................................................... 5

D101-05192 3 of 7
1 INTRODUCTION
1.1 About this manual
This manual provides identification of the Chirp 3212 Echosounder (Part number D229-04405) modules and cable
assemblies for servicing.
1.2 Technical Support
For technical support or to report problems please contact your local representative or:
Technical Support
Knudsen Engineering Limited
10 Industrial Road
Perth, Ontario
K7H 3P2
Voice: [phone] 8:30 am to 5:00 pm E.S.T. Core Hours
Fax: [phone]
E-Mail: [e-mail]
WebSite: http://knudsenengineering.com/
1.3 Warranty
If the warranty period on the Chirp 3212 has not expired, please contact Technical Support prior to opening or
servicing the unit.
1.4 Revision History
Revision Description Date Initial
1 First Release 10-09-17 DKG

D101-05192 4 of 7
2 SERVICE
Please ensure that all power to the system is shut off and all external cables have been disconnected. Also if the
system has recently been powered on, please wait a few minutes before servicing to ensure capacitor drain.
Please note that the modules in the Chirp 3212 contain static sensitive components and any removal or handling of
these modules will require proper ESD procedures be followed.
2.1 System Access
Please ensure that all power to the system is shut off and all external cables have been disconnected. Also if the
system has recently been powered on, please wait a few minutes before servicing to ensure capacitor drain.
Open the outer lid of the case and remove the eighteen (18) screws on the Chirp 3212 cover plate. Lift the cover
plate from the left side and position ninety (90) degrees to the chassis as shown below. Secure the cover plate in
this position (tiewrap, etc).
FIGURE 1 - COVER OPEN

D101-05192 5 of 7
3 Parts Lists
The following tables contains the modules and cable assemblies located inside the Chirp 3212 Echosounder.
Hardware (mechanicals, screws, fasteners, etc) are not listed.
Cable Part Number Description Qty
1D219-04572 Transmit Output Cable 2
2D219-04573 Drive Signal Cable 2
3D219-04574 Receive Signal Cable 2
4D219-04575 DC Input Cable 1
5D219-04576 Circuit Breaker Assembly 1
6D219-04577 Power Switch Assembly 1
7D219-04579 Module Power Cable 4
8D219-04581 Aux BNC Cable 4
9D219-04582 Module USB Cable 2
10 D219-05019 USB Input Cable 1
The following table list all of the modules found inside the Chirp 3212 Echosounder. The module locations inside
the unit are shown on Figure 2.
Module Part Number Description Qty
1D309-04375 Long Pulse Transmitter Module 1
2D309-04412 USB Processor Module - 5509 2
3D309-04413 Short Pulse Transmitter 1
4D309-04414 Power Distribution Module 1
5D309-04495 USB Hub Module 1

D101-05192 6 of 7
FIGURE 2 - MODULE LOCATIONS
