Kodak 805 User manual

User’s Guide
805 Photo Printer

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
Contents
User’s Guide
SEARCH
Introduction
Printer Features
About This Manual
Safety Precautions
Power Requirement
Protective Measures
Connecting Cables
WEEE Statement
China RoHS
Installation Locations
For Long Operating Life
Other Cautions
Paper and Image Sizes
Printer Driver
Interfaces
Setting up the Printer
Finding a Location for the Printer
Unpacking the Printer
Loading the Ribbon
Handling Ribbon Spools
Storing Ribbons

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS HELP
SEARCH
Loading the Ribbon in the Printer
Connecting the USB Cable
Handling Paper
Storing Paper
Loading the Paper Tray
Installing the Dust Cover
About Printer Initialization
If the Printer Does Not Initialize
Making a Test Print
Calibrating the Printer
Operating the Printer
Buttons and Lights
Working with Paper
Handling and Storing Prints
Keeping the Printer in Good Working Condition
Cleaning the Printer
Troubleshooting
Light Indications and How to Resolve Them
If the Printer Does Not Operate Correctly
Clearing a Paper Jam
Clearing a Paper Jam from the Front Area
Clearing a Paper Jam from the Ribbon Area
Clearing a Paper Jam from the Back Area
Repairing a Torn Ribbon

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS HELP
SEARCH
Cleaning the Thermal Head
Repacking the Printer
Getting Additional Help
ERROR Light Off, MEDIA Light Red
ERROR Light Red, MEDIA Light Off
ERROR Light Red, MEDIA Light Red
Printer does Not Turn On
Printing Takes Much Longer than Usual
Nothing Happens when a Job is Sent
White or Colored Lines and Scratches
White or Multicolored Spots
Smudges, Smears, and Fingerprints
Paper does not Feed
Printer does not Respond when you Press Buttons
Invalid Ribbon Type
Site Specifications
Printer Specifications
Space Requirements
Operating Environment
Power Requirements
Accessories and Supplies
Search
Help

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS HELP
SEARCH
Navigating
Printing
Magnifying

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Introduction
Thank you for purchasing the KODAK 805 Photo Printer (805 printer). The 805
printer is a dye-sublimination device with superior printing speed. Printed
images are high-contrast and long lasting. The ribbon applies a coating that
protects images from fingerprints.
The 805 printer is the latest model of the Kodak page size dye-sublimination
printers. These printers produce superb photographic prints and proofs. The
805 printer is easy to install and set up. The interface is compatible with
virtually all computer environments.
Printer Features
The 805 printer includes the following features:
Paper Sizes: The 805 printer prints on two paper sizes. 3-color YMC
ribbons can be used in the 805 printer.
Resolution: The 805 printer has a resolution of 301 pixels per inch (ppi),
and prints a page in about 90 seconds.
Printer Driver: The printer driver supports the WINDOWS 2000 or
WINDOWS XP Operating Systems.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
About This Manual
This manual consists of the following sections:
• Introduction—describes the printer, available papers, printer drivers and
interfaces.
• Setting up the printer—describes how to set up the printer.
• Operating the printer—contains information on maintaining the printer
and working with the paper and ribbon.
• Troubleshooting—describes possible problems and how to resolve them.
• Site specifications—describes the printer specifications, space
requirements and operating conditions.
• Accessories and supplies—lists the accessories and supplies for the
printer.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Safety Precautions
The lightning flash symbol within an equilateral triangle is intended to
alert you to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute the risk of
electric shock.
The explanation point within an equilateral triangle is intended to alert
you to the presence of important operating and maintenance instructions in the
literature accompanying the appliance.
The hot surfaces symbol within an equilateral triangle is intended to
alert you to the presence of a hot surface. Do not touch. This symbol appears
next to the print head.
CAUTION:
RISK OF ELECTRIC SHOCK. DO NOT OPEN
To reduce the risk of electric shock, do not remove cover or back.
There are no user-serviceable parts inside. Refer servicing to
qualified service personnel.
There are no user or field serviceable components. Do not open
covers under any circumstances.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
CAUTION:
HOT SURFACE
AVOID CONTACT WITH THE THERMAL HEAD. It becomes hot during
printing and may remain hot, causing injury. Touching the thermal
head or sensor may cause malfunctions due to static electricity. Oils,
salts, and moisture from your hands will contaminate the head and
may spoil the prints.
To prevent fire or shock hazard, do not expose this appliance to rain
or moisture.
Before connecting, read instructions.
IMPORTANT: This thermal printer contains lead. Disposal of lead may be
regulated due to environmental considerations. For disposal or
recycling information, please contact your local authorities or the
Electronics Industry Alliance: www.eiae.org.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
CAUTION:
Use the included AC power cord so as not to interfere with radio and
television reception.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. To determine
if this equipment causes harmful interference to radio or television
reception, turn the equipment off and on. To correct the interference,try
one or more of these measures:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a different circuit than the
receiver
• Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
This digital photo printer complies with the requirements of the EC Directive
89/336/EEC, 73/23/EEC, and 93/68/EEC.
The electromagnetic susceptibility has been chosen at a level that gains proper
operation in residential areas, on business and light industrial premises, and on
small-scale enterprises, inside as well as outside of the buildings. All places of
operation are characterized by their connection to the public low voltage power
supply system.
In the interest of safety, please observe the following precautions:
Power Requirement
This product is designed for operation on 100V - 240V AC, 50 / 60Hz. Never
connect to any outlet or power supply having a different voltage or frequency.
CAUTION:
This apparatus must be grounded.
Avertissement: Cet appereil doit etre mis a la terre.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Protective Measures
If abnormalities arise:
If the printer emits smoke or abnormal sounds, immediately unplug the
power cord from the printer or power outlet. Continued use is hazardous.
Contact your dealer about having the printer checked and serviced.
Never insert any object into the unit.
Nothing other than supplies for this printer should ever be inserted into the
printer. Other items can cause a safety hazard and extensive damage to the
mechanism and electronics.
Do not set heavy objects on top of the unit.
Heavy objects can damage the unit and cause misoperation.
Avoid damaging the power cord.
Do not set anything heavy on the power cord or allow it to become pinched,
or cut. If the power cord becomes damaged, replace it immediately to avoid
shock hazard or electrical fire.
When the power cord is replaced, use the same type as originally supplied;
it is designed to reduce interference to radio & TV reception.
When unplugging the power cord, hold the plug, and remove it carefully.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Keep the unit dry. Do not place water or other liquid containers, flower
vases/pots on top of the unit.
Liquids that get into the unit can cause serious damage to the unit and
potential shock or fire danger. If liquid is spilled into or seeps into the unit,
unplug the Power Cord immediately and seek service as soon as possible
to avoid additional or possible damage due to corrosion.
Avoid handling liquids near the unit.
Do not remove the cabinet. There are no user-serviceable parts inside
and you will expose yourself to hazardous voltages and/or you may
cause damage to the unit.
Touching internal parts is dangerous and may expose you to an electrical
shock or cause a printer malfunction. Contact your dealer to carry out
internal checks and adjustments. Disconnect the power cord before
opening the cover to clear a paper jam, etc.
Unplug the power cord during a long absence or during an electrical
storm.
Turn off the Main Power switch and unplug the power cord during a long
absence or during an electrical storm.
Do not insert your fingers or any object into the paper exit when the
printer is on.
There is a roller inside the paper exit. If you insert your fingers when the
printer is on, you may get injured.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Be careful with the printing mechanism.
Do not move the printer while the top cover is open. This may cause injury.
Be careful not to catch your fingers in the printing mechanism.
Connecting Cables
Use the power cord supplied with the printer.
WEEE Statement
In the European Union, this symbol indicates
that when the last user wishes to discard this
product, it must be sent to appropriate facilities
for recovery and recycling. Contact your local
Kodak representative or refer to
www.kodak.com/go/recycle for additional
information on the collection and recovery
programs available for this product.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
China RoHS
Environmental Protection Use Period (EPUP)
In China, this number indicates the time period (in years) within which any
hazardous substances present in the product are not expected to be released
such that there is risk tohumanhealth, property, or theenvironment. This value
is assigned based on normal use of the product as described in the operating
instructions.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Installation Locations
Maintain good ventilation.
Ventilation slots and holes are provided on the top and rear of this unit.
Place the unit on a hard, level surface. Allow the following minimum space
around the printer to ensure proper ventilation:
Top: 2 in. (5.08 cm)
Sides: 0.5 in. (1.27 cm)
Rear: 2 in. (5.08 cm) - If the rear dust cover is in place (recommended)
then no additional space is required at the rear.
When installing the unit in a system rack, leave space between the unit and
the back of the rack.
Unsuitable locations:
Locations with high humidity and dust:
Do not place the unit in locations with high humidity and dust. They can
cause extensive damage. Avoid locations where the unit is likely to be
exposed to oily fumes and vapors.
Locations likely to be extremely hot:
Locations exposed to direct sunlight or near heating appliances can
attain extremely high temperatures which may deform the cabinet or
cause other damage.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Place the unit on a horizontal surface.
The unit is likely to be affected if it is operated when tilted, inclined or in
unstable places.
Protect against dew formation.
When the unit is moved from a cold area into a warm area, moisture can
condense inside the unit and prevent operation. Allow the temperature to
stabilize before use.
Operating ambient temperature range:
The operating temperature range is 59 - 86°F (15 to 30°C) and humidity of
10% - 85%. When using the unit in a system rack, make sure that the
temperature inside the rack does not exceed this range.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
For Long Operating Life
Unsuitable materials for cleaning the printer
Paint coat flaking and plastic deformation are likely to occur if the unit is
wiped with chemical dusters, benzine, thinner or any other solvent, if rubber
or PVC items are left in contact with the unit for a extended period, or if the
unit is sprayed with insecticide.
Care of the cabinet
Unplug and clean with a soft cloth slightly moistened with a mild soap and
water solution. Allow to dry completely before operating. Never use
petroleum-base solutions or abrasive cleaners.
Head abrasion
The thermal print head, like a video head, wears out. When it is worn, fine
details of the picture are not printed, requiring replacement of the thermal
head. Consult your dealer about having the head replaced.
Connecting devices
Read thoroughly the Safety Notices, Cautions, and Operating Precautions
of the instruction booklets for the other devices connected with the unit.
Caution on relocating
When transporting this unit, make sure to avoid impacts. Before moving the
unit, make sure to disconnect the power cord from the power outlet and the
cables from the connected devices. Remove the paper tray and ribbon.

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Other Cautions
Dust or other foreign matter adhering to the print paper or the sheet cartridge,
or deformation resulting from exposure to extremely low or high temperatures
could cause loss of color, uneven color or lines, or wrinkles in the print images.
Paper and Image Sizes
The 805 printer can print on the following sizes and types of Kodak Paper.
Paper Size Maximum Image Size
216 x 305 mm (8.5 x 12 in.)
A (long) paper 203 x 254 mm (8.0 x 10.0 in.)
216 x 356 mm (8.5 x 14 in.)
Legal paper 210 x 305 mm (8.27 x 12.0 in.)

Setting up the Printer
Introduction
Troubleshooting
Site Specifications
Operating the Printer
Accessories and
Supplies
CONTENTS
HELP
SEARCH
Printer Driver
The printer driver developed for the 805 printer is based on high-quality Kodak
photographic printing methods. The printer driver allows you to access printing
options based on Kodak color science.
The printer driver is provided for use with the WINDOWS 2000 or WINDOWS
XP Operating Systems.
Download the printer driver from the Service and Support page at
www.kodak.com.
Interfaces
The 805 printer has a standard USB 2.0 interface.
