Kodak Truper Series User manual

Exceptional.
Fast producing.
Ready for duty.
repu¯rT
Series Scanners

In addition to delivering outstanding scanning technology and bundled feature sets—including VRS
Professional, Ultrasonic Multi-feed Detection and Advanced Color Dropout—Tru¯per Scanners also deliver
choice for reducing the total cost of scanning.
Kodak Tr ¯ uper Series Scanners: speeding to the top of their
class
>Speedy prep time
Small footprint, easy to use
With its small footprint and rotary style paper
handling, the Tru¯per 3610 Scanner fits in small
spaces and delivers an easy-to-use capture
platform for any scanning application.
Handles fragile, bound, odd-size and long
documents
With its built-in flatbed, the Tru¯per 3210 Scanner
handles exception documents with ease.
Productive
Ultrasonic Multi-feed Detection
catches double-feeds automatically.
Minimize rescans
Auto Color Detect: no problem mixing color
and black-and-white documents
With Auto Color Detect, Tru¯per Scanners
color and black-and-white as documents are
scanned, and accurately capture the original
images. Auto Color Detect allows you to
eliminate sorting documents by color, saving
Auto Orientation: no problem mixing
landscape and portrait documents
Auto Orientation automatically displays
scanned images “right side up” as they are
normally read. Auto Orientation reduces
document preparation, scanning interruptions
and operator intervention.
Blank Page Deletion: save file size and money
With Blank Page Deletion, Tru¯per Scanners
automatically detect and delete blank pages
when scanning in duplex mode. Blank Page
Deletion reduces scanned file size and
document preparation.
User-replaceable parts: reduce service calls
With easy-to-change and easy-to-clean parts,
ongoing routine maintenance can be handled
by scanner users. This reduces the need for
service calls and allows you to boost scanning
Tru¯per models use the same
consumable kits, which eliminates the need to
stock multiple kits for multiple scanners.
Long and very long document scanning
The long document handling feature is end-
user selectable and requires no additional IT
support. It’s easy to switch between standard-
length and long-length document scanning.
Users can convert very long documents like
fetal monitoring strips and electrocardiogram
(EKG) strips into sharp, digitized images,
which are automatically rendered into image
segments that are 254 cm (100 in.) long.
process of cutting long documents into
measured sections or mounting them on
standard-size sheets prior to scanning.
Tru¯per 3610
Scanner
Tru¯per 3210
Scanner
Fast producing
High scanning speeds in color,
black-and-white and grayscale.
Up to 95 pages per minute
Exceptional
A duty cycle to meet your volume needs.
Up to 15,000 scans per day
Kodak Tr ¯ uper Series Scanners: speeding to the top of their class

>High-quality images
Tru¯per Series Scanners deliver great image quality that meets the
demands of modern document management solutions. Whether you
scan bar codes, forms, invoices, patient records or EKG strips, you can
be confident that Tru¯per Scanners will accurately capture your images
and increase your OCR/ICR read rates.
The LED lamps are designed to last for the life of the scanner, and their
VirtualReScan Professional:
a feature bundle that saves you a bundle
With VRS Professional, Tru¯per Series Scanners dramatically reduce
Tru¯per Scanners an obvious choice for today’s
With Auto Color Detect, Blank Page Deletion and Auto Orientation
included with VRS Professional, you can reduce manual steps and
savings and lower your total cost of scanning. The VRS application
includes all the image processing tools required for the production
Series Scanners: speeding to the top of their
class >>>>
>Fast producing
S
For color, black-and-white and grayscale
scanning, Tru¯per Scanners provide
accelerated throughput.
Duty cycle: volume when you need it
The daily duty cycle of 15,000 pages gives
you the capacity to handle all your volume
needs, from ad-hoc scanning to peak
USB 2.0: drives higher image transfer speed
Tru¯per Scanners have a USB 2.0 interface for
easy installation and accelerated transfer of
scanned images to the host computer.
Ultrasonic Multi-feed Detection with
Multi-feed Ignore: minimizes rescans
and catches double-feeds
Tru¯per Scanners feature Ultrasonic Multi-feed
Detection technology to catch unintentional
multi-feeds. For envelopes, or for documents
containing sticky notes, the Multi-feed Ignore
setting allows them to scan without triggering
rescans and document preparation time.
Automatic Document Feeder:
greater capacity for more documents
The ADF’s 200-sheet capacity increases your
batch scanning options and helps maximize
your productivity. In addition, the document
guides in the feeder area are lockable and can
be positioned independently, to maximize
feeding flexibility.
Flatbed plus rotary and rotary-only models
Two models are available to meet your
scanning needs—a rotary-only model, the
Tru¯per 3610 Scanner; and a flatbed plus
rotary model, the Tru¯per 3210 Scanner.
For applications requiring the scanning of
exception documents, choose the 3210 model.
In the absence of exception documents,
choose the 3610 model.
Wider ADF: accepts larger documents
The Tru¯per Scanners’ document feeding
capacity easily accommodates wider
documents and oversized documents. The
expanded feeder width also improves image
cropping and deskew in conjunction with the
included VRS application.
Very long documents—
Scans documents of
unlimited lengths.
With Kodak Tru¯per Series Scanners, the low-volume production scanner segment just got a
little faster. The Tru¯per Scanners’ unique combination of image quality, duty cycle and speed
businesses with exception document scanning needs. With flatbed plus rotary, or rotary-only
models, the Tru¯per Scanners can meet your diverse scanning needs.

Scanning Mode 3210: Simplex, Duplex and Flatbed
3610: Simplex and Duplex
Scanning Method CIS (Contact Image Sensor) with LED lamps
Scanning Speed
Black-and-White, Grayscale, Color
(Letter Size, Landscape, 200 dpi)
Simplex 95 ppm (pages per minute); Duplex 190 ipm (images per minute)
Daily Duty Cycle Up to 15,000 pages per day
Resolution Optical: 600 dpi
Black-and-White or Grayscale Output: 100–600 dpi
Color Output (with the VRS application): 100–400 dpi
Output Options Black-and-White, Grayscale (8 bit), and Color (24 bit)
Image Enhancement VRS Professional features include Auto Cropping, Deskew, Auto Brightness, Advanced
Clarity, Auto Color Detect, Auto Orientation, Bar Code Detection and Blank Page Deletion
Interface USB 2.0 enhanced (cable included)
Document Size Flatbed Approximately 297 x 432 mm (11.7 x 17 in.) for 3210 model only
ADF Scanning Size: Approximately 48 x 70 mm (1.9 x 2.8 in.) to 302 mm x unlimited (11.9 in. x unlimited*)
*screen images are appended to 254 cm (100 in.)
Paper Thickness (ADF) 0.05 to 0.15 mm (2.0 to 5.9 mils) Note: 1 mil = 1/1000 in.
Paper Weight (ADF) 40 to 127 g/m2(10.6 to 34 lbs.)
Feeder Capacity 200 Sheets of 64 g/m2(17 lb.) paper
Scanner Size 3210: 76 x 51 x 29 cm (30 x 20 x 11.4 in.)
3610: 48 x 44 x 29 cm (18.9 x 17.3 x 11.4 in.)
Scanner Weight 3210: 29 kg (64 lbs.)
3610: 21 kg (47 lbs.)
Power Requirements
and Consumption Scanning
Standby
Sleep Mode
100-120 VAC, 50/60 Hz
<90 W
<27 W
2.0 W
220-240 VAC, 50/60 Hz
<80 W
<27 W
<3.5 W
Environment Operating Temperature
and Humidity
Temperature 15°C to 30°C (59°F to 86°F)
Humidity: 30% to 80% RH non-condensing
Additional Features Advanced Color Dropout (up to six colors), Ultrasonic Multi-feed Detect with Multi-feed Ignore,
Long and Very Long Document Handling, Switchable Background, Bar Code Recognition,
End User Replaceable Feeder Rollers, MultiStream (Direct ISIS only), Direct TWAIN,
Independently Adjustable and Lockable Document Guides
Additional Contents Power Cord, USB 2.0 Cable, Roller Cleaning Kit, CD-ROM (Operator Manual, VRS Professional,
User Utility Software), Printed Documents (Quick Installation Checklist)
Bundled Software Kofax VCDemo, Kofax Scan Demo
Consumable and Accessory Options Roller Cleaning Kit, Roller Exchange Kit, Imprinter Kit, Imprinter Kit Cartridge,
Shading Paper, Blower Accessory, Memory Upgrade Kit,
NCR Paper Cleaning Kit, Long Document Productivity Weight Kit
Imprinter Features Pre-Scan, Front Page Imprinter, 62 Characters
To learn more:
Visit www.kodak.com/go/docimaging
Printed using Kodak Technologies.
©Kodak, 2012. Kodak and Tr¯uper are trademarks of Kodak.
Subject to technical change without notice.
