Koden MDC-2900 User manual

MDC-2900 Series Revision History
0092629012-07 i
MDC-2900 Series Installation Manual
Doc No: 0092629012
Document Revision History
No. Doc. No-Rev. No. Revised Date
(Y/M/D)
Revised Content
0 0092629012-00 2009/02/28 First edition
1 0092629012-01 2009/06/05 Full revision
2 0092629012-02 2009/08/04 Full revision
3 0092629012-03 2010/02/03 Configuration Equipment, Chaptr 4, Chapter 6
4 0092629012-04 2011/04/25 Configuration Equipment, Chapter 1, Chapter 2,
Chapter 4, Chapter 6
5 0092629012-05 2011/11/15 Important Notice, Configuration Equipment,
Chapter 4, TT(ATA)TT(ARPA)
6 0092629012-06 2013/01/17 System Configuration, Configuration Equipment,
Chapter 3, Chapter 4, Chapter 6
7 0092629012-07 2013/08/22 Chapter 4
8
9
10
Document No. Revised Version Norm
When part of the document needs to be revised, the document has advanced revision number.
The document No. is indicated at the lower right side on the cover and at the left or right side of the
footer region of each page.
© 2009-2013 Koden Electronics Co., Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, translated in any from by any means
without the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in
this publication are subject to change without notice. Koden assumes no responsibility for any errors,
incidental or consequential damages caused by misinterpretation of the descriptions contained in this
publication.

Important Notice MDC-2900 Series
ii 0092629012-07
Important Notice
For copy and transcription of this Installation Manual (hereinafter referred to as this manual),
permission from Koden is needed. Koden prohibits the un-authorized copy and transcription of
this manual.
If this manual is lost or damaged, consult a dealer of Koden or Koden.
The specification of the products and the contents in this manual are subject to change without
notice.
The contents displayed on the menu of product may be different from the expression of this
manual. The fonts and shapes of the keys and menus in the illustration may differ from the actual
ones, and some parts may be omitted.
Koden is not liable for damages and troubles arisen from misunderstanding of the contents in this
manual.
Koden is not liable for any damages caused by earthquake, lightning, wind and flood damage and
fire for which Koden is not responsible, and actions by third parties, other accidents, customer’s
unintended error/abuse and the use under other abnormal conditions.
Koden is not liable for damages of accompaniment (change/loss of memorized content, loss of
business profit, stop of business) arisen from use or failure of our products.
If the stored data are changed or lost, irrespective of causes of troubles and damages, Koden is
not liable for them.
Koden is not liable for any damages arisen from malfunction caused by combination of software
and connected equipment in which Koden is not engaged.

MDC-2900 Series For Your Safe Operation
0092629012-07 iii
For Your Safe Operation
Symbol used in this Installation Manual
This manual uses the following symbols. Understand the meaning of each symbol and implement the
maintenance and inspection.
Symbol Meaning
Mark for warning
This symbol denotes that there is a risk of death or serious injury when not
dealing with it correctly.
Mark for danger high voltage
This symbol denotes that there is a risk of death or serious injury caused by
electric shock when not dealing with it correctly.
Mark for caution
This symbol denotes that there is a risk of slight injury or damage of device
when not dealing with it correctly.
Mark for prohibition
This symbol denotes prohibition of the specified conduct. Description of the
prohibition is displayed near the mark.
IMPORTANT
Mark for important matters
This mark denotes that there is a possibility that data loss may interfere
the operation or that the expected result may not be obtained when the
radar is not dealt correctly.
Mark for reference
This mark shows the part to be referred to concerning this description.

For Your Safe Operation MDC-2900 Series
iv 0092629012-07
Caution Item on Equipment
Caution on a high voltage inside.
A high voltage, which may risk your life, is used. This high voltage remains
in the circuit after you have powered off switch. To prevent touching the high
voltage circuit inadvertently, the protective cover is provided to the high
voltage circuit and the high voltage caution label is affixed. Ensure to power
off switch for your safety and discharge the electricity remaining in the
capacitor before starting to check. An engineer authorized by our company
should inspect and maintain the circuit.
Be sure to switch off the power in the boat.
If the power switch is inadvertently powered on during work, you will be
electrified. To prevent such accident from occurring, ensure to switch off the
power in the boat and the power of equipment. Furthermore, it is safer to
hang the caution tag with description of [Under Work] near the power switch
of equipment.
Caution on dust
Inhaling dust may cause A respiratory disease. When cleaning the inside of
equipment, be careful not to inhale dust. Wearing a safety mask is
recommended.
Caution on location of equipment
Do not install the equipment where it is excessively damp and suffers from
excessive water drops.
Caution on static electricity
The static electricity may be generated from the carpet on the floor in the
cabin or clothes made of synthetic fiber. The static electricity may destroy
the electronic parts on the circuit board. Handle the circuit board, taking the
suitable anti-static measures.

MDC-2900 Series For Your Safe Operation
0092629012-07 v
Caution Item on Handling
Caution on the rotating aerial
The radar antenna may start to rotate without notice. Please stand clear
from the antenna for your safety.
Caution on electromagnetic disturbance
The operating Antenna & Scanner unit radiates high-energy
electromagnetic wave. It may cause harmful effect for human body due to
its continuous irradiation. As International regulation says,
electromagnetic waves less than 100 watt/m2does not have a harmful
effect on human bodies, but some kind of medical devices such as heart
pacemakers are sensitive even under the low energy electromagnetic
wave. Any personnel with such a device should keep away from the
electromagnetic wave generating position at all times.
Specified power density and distance from the radar (in accordance with
the provision as specified in IEC 60945)
Model name Xmit power/
Antenna length
100W/m250W/m210W/m2
MDC-2960
MDC-2960BB
6kW / 4 feet Antenna 1.09m 1.55m 3.46m
6kW / 6 feet Antenna 1.30m 1.84m 4.11m
MDC-2910
MDC-2910BB
12kW / 4 feet Antenna 1.55m 2.19m 4.89m
12kW / 6 feet Antenna 1.84m 2.60m 5.81m
MDC-2920
MDC-2920BB
25kW / 4 feet Antenna 2.37m 3.36m 7.50m
25kW / 6 feet Antenna 2.82m 3.99m 8.91m

For Your Safe Operation MDC-2900 Series
vi 0092629012-07
Do not disassemble or modify. It may lead to trouble, fire, smoking or
electric shock. In case of trouble, contact our dealer or our company.
In case of smoke or fire, switch off the power in the boat and the power of
equipment. It may cause fire, electric shock or damage.
Caution on the remaining high voltage.
A high voltage may remain in the capacitor for several minutes after you
have powered off. Before inspecting inside, wait at least 5 minutes after
powering off or discharging the remaining electricity in an appropriate
manner. Then, start the work.
The information displayed in this unit is not provided directly for your
navigation. For your navigation, be sure to see the specified material.
Use the specified fuse. If un-specified fuse is used, it may cause a fire,
smoke or damage.

MDC-2900 Series Disposal of used cell and this radar
0092629012-07 vii
Disposal of used cell and this radar
Treatment of the used lithium ion cell
To dispose of built-in lithium ion cell (CR-2032) in this radar, insulate each terminal with scotch
tape, etc. and wrap in plastic bag, etc.
The disposal and collection rules may be different depending on each municipal district. Obey the
directions of each district.
Disposal of this radar
This radar shall be disposed according to the municipal regulations or rules.
A high-energy density lithium ion cell is built in this radar.
Improper disposal of a lithium ion cell is discouraged as the cell has a
possibility of short-circuiting. If it gets wet, the generation of heat,
explosion or ignition may occur resulting in an injury or a fire.

Contents MDC-2900 Series
viii 0092629012-07
Contents
Document Revision History...................................................................................................... i
Important Notice...................................................................................................................... ii
For Your Safe Operation..........................................................................................................iii
Symbol used in this Installation Manual ..................................................................................iii
Caution Item on Equipment.................................................................................................... iv
Caution Item on Handling........................................................................................................ v
Disposal of used cell and this radar .......................................................................................vii
Contents................................................................................................................................viii
System Configuration.............................................................................................................xii
Configuration Equipment.......................................................................................................xiv
Chapter 1 Prior to installation ......................................................................................................1-1
1.1 Installation precautions...................................................................................................1-1
1.2 Unpacking of components..............................................................................................1-1
1.3 Appearance verification of each unit and accessories....................................................1-1
1.4 Selection of location for installation ................................................................................1-1
1.4.1 Antenna-Scanner unit..................................................................................................1-1
1.4.2 Display unit and Operation unit ...................................................................................1-3
1.5 Cable wiring and interconnection ...................................................................................1-3
1.5.1 Antenna-Scanner unit..................................................................................................1-3
1.5.2 Display unit..................................................................................................................1-3
Chapter 2 Method of installation..................................................................................................2-1
2.1 How to install the Antenna-Scanner unit.........................................................................2-1
2.1.1 Installation of the Antenna-Scanner unit......................................................................2-1
2.1.2 Mounting Antenna .......................................................................................................2-2
2.1.3 Connecting the cables.................................................................................................2-3
2.2 Interconnection diagram of cable ...................................................................................2-5
2.3 Installation of the Display unit.........................................................................................2-6
2.3.1 Installation of MRD-105...............................................................................................2-6
2.3.1.1 Table mounting of MRD-105.....................................................................................2-6
2.3.1.2 Flush Mounting of MRD-105 ....................................................................................2-8
2.3.2 Installation of MRM-105 ..............................................................................................2-9
2.3.3 Installation of MRO-105.............................................................................................2-10
2.3.3.1 Installation of Operation unit MRO-105 ..................................................................2-10
2.3.3.2 Installation of Flush mounting the Operation unit MRO-105...................................2-12
2.4 Cable connection to a Display unit ...............................................................................2-13
2.4.1 Cable connection for MRD-105 Display unit..............................................................2-13
2.4.2 Cable connection for MRM-105 Processor unit.........................................................2-14

MDC-2900 Series Contents
0092629012-07 ix
2.4.3 Connecting the Display unit to GPS Compass (KGC-1) ........................................... 2-15
2.4.4 Connecting the KGC-1 or GTD-110/150 to a Display unit......................................... 2-16
2.4.5 Connecting the Display unit to KGC-1, GTD-110/150 and KGB-3 ............................ 2-17
2.4.6 Connecting the 2nd monitor with MRD-105 .............................................................. 2-18
2.4.7 Connecting the VDR or the 2nd Monitor (MRM-105) and the Alarm output .............. 2-18
2.4.8 Connecting the Gyro converter unit or THD.............................................................. 2-19
2.4.9 AIS cable connection ................................................................................................ 2-19
2.4.10 Cable connection for NAV, EPFS and SDME or Log .............................................. 2-20
2.4.11 Cable connection for interswitch ............................................................................. 2-21
2.4.11.1 Cable connection for cross, dual and independent connection............................ 2-21
2.4.11.2 Cable connection for secondary Display unit used as a monitor.......................... 2-22
Chapter 3 Setup after installation................................................................................................ 3-1
3.1 The execution order of the STARTUP menu.................................................................. 3-1
3.1.1 Set up Antenna installation height from sea level ....................................................... 3-1
3.1.2 Setup antenna cable length ........................................................................................ 3-1
3.1.3 Adjustment of automatic tune ..................................................................................... 3-1
3.1.4 Adjustment of transmitting delay time (Trigger Delay) ................................................ 3-2
3.1.5 Display bearing adjustment ........................................................................................ 3-3
3.1.6 Setup of MBS value (Main Bang Suppression)........................................................... 3-3
3.1.7 Function key usage .................................................................................................... 3-4
3.2 Setup Interface .............................................................................................................. 3-5
3.2.1 Setup TIME................................................................................................................. 3-6
3.2.2 Use without connection of HDG, SPD, LAT/LON and Way Point, etc. ........................ 3-6
3.2.3 Set up heading interfaces........................................................................................... 3-7
3.2.3.1 Connection of KGC-1 for obtaining ship’s bearing signal......................................... 3-7
3.2.3.2 Connection of NSK unit to obtain ship’s bearing signal ........................................... 3-7
3.2.3.3 Connection of output device of ship’s bearing (THD) such as gyro to obtain ship’s
bearing signal ...................................................................................................................... 3-8
3.2.4 Setting of STW to be used for SEA STAB................................................................... 3-8
3.2.5 Setting of COG/SOG to be used for GROUND STAB................................................. 3-9
3.2.6 Select SET/DRIFT input ............................................................................................. 3-9
3.2.7 Setting of sentences for input of latitude and longitude .............................................. 3-9
3.2.8 Setting of output of NAV and EPFS .......................................................................... 3-10
3.2.9 TLL output................................................................................................................. 3-10
3.2.10 ALR output...............................................................................................................3-11
3.2.11 Limiting of type of signal to input port.......................................................................3-11
3.2.12 Changing of formats of input/output ports of navigation devices, position and ship
speed (IEC 61162)............................................................................................................. 3-12
3.3 Setting of [PRESET] menu .......................................................................................... 3-12
3.3.1 Change of maximum adjustable range of [GAIN] knob............................................. 3-12

Contents MDC-2900 Series
x 0092629012-07
3.3.2 Setting when there is difference in GAIN at changeover of range.............................3-12
3.3.3 Preset of SEA AUTO level.........................................................................................3-13
3.3.4 Change of maximum value of [SEA] knob.................................................................3-14
3.3.5 Use of PRE-SEA suppression under the Manual SEA ..............................................3-14
3.3.6 When there is difference in the effect in Manual SEA suppression at changeover of
ranges ................................................................................................................................3-15
3.3.7 Switching over of FTC or CFAR in anti-rain clutter suppression mode......................3-15
3.3.8 Changing of the maximum of anti-rain clutter suppression knob at FTC...................3-15
3.3.9 Set preset DIFF (FTC)...............................................................................................3-16
3.3.10 Change of maximum value of Anti-rain clutter suppression at [CFAR] ....................3-16
3.3.11 Setting of preset CFAR............................................................................................3-16
3.3.12 Setting of signal detection threshold of TT(ARPA) ..................................................3-16
3.3.13 Change of background noise and target signal gradation .......................................3-17
3.3.13.1 Change of background noise ...............................................................................3-17
3.3.13.2 Change of Signal gradation..................................................................................3-17
3.4 Setting of CCRP (common reference position) and own ship profile............................3-18
3.5 Stopping of transmission to certain angle.....................................................................3-18
3.6 Backup of set values ....................................................................................................3-19
3.6.1 Internal storage .........................................................................................................3-19
3.6.2 External storage ........................................................................................................3-19
3.7 Use of interswitch function ...........................................................................................3-20
3.7.1 Cross connection.......................................................................................................3-20
3.7.2 DUAL connection ......................................................................................................3-20
3.7.3 MASTER/SLAVE connection.....................................................................................3-21
3.7.4 Connection of monitor ...............................................................................................3-22
3.7.5 Setup of Antenna location information.......................................................................3-23
Chapter 4 Troubleshooting and on-board repair..........................................................................4-1
4.1 Necessary information at the time of repair request.......................................................4-1
4.2 Provided self diagnostic tools.........................................................................................4-1
4.2.1 Alarm display and how to cancel .................................................................................4-1
4.2.1.1 Alarm display list.......................................................................................................4-2
4.2.1.2 Warning display list ..................................................................................................4-4
4.2.2 Status indicator lamp ...................................................................................................4-6
4.3 Malfunction diagnostics..................................................................................................4-7
4.3.1 Malfunction detection step...........................................................................................4-7
4.3.2 Malfunction diagnostics flow chart...............................................................................4-8
4.3.2.1 Initial malfunction diagnostics 1................................................................................4-8
4.3.2.2 Initial malfunction diagnostics 2................................................................................4-9
4.3.2.3 Other faults (Display unit).......................................................................................4-10
4.3.2.4 Abnormal display.................................................................................................... 4-11

MDC-2900 Series Contents
0092629012-07 xi
4.3.2.5 No response from the Antenna Scanner unit ......................................................... 4-12
4.3.2.6 Sensitivity failure.................................................................................................... 4-13
4.3.2.7 No display of ship’s bearing, speed and latitude/longitude .................................... 4-14
4.3.2.8 Operation unit abnormality..................................................................................... 4-15
4.3.2.9 Antenna Scanner unit abnormality......................................................................... 4-16
4.3.2.10 Synchronization of screen abnormality................................................................ 4-17
4.3.2.11 High voltage abnormality ..................................................................................... 4-17
4.3.2.12 Pulse length control failure .................................................................................. 4-18
4.3.2.13 Rotary abnormality............................................................................................... 4-19
4.3.2.14 Heading line and Azimuth abnormality................................................................. 4-20
4.3.2.15 TT (ARPA) abnormality ........................................................................................ 4-21
4.3.2.16 Map display abnormality...................................................................................... 4-22
4.3.2.17 No display of AIS ................................................................................................. 4-23
4.3.2.18 Other faults (Antenna Scanner unit) .................................................................... 4-24
4.4 Repair.......................................................................................................................... 4-26
4.4.1 Replacement of fuse................................................................................................. 4-26
4.4.2 Replacement of Internal Battery ............................................................................... 4-27
Chapter 5 Maintenance .............................................................................................................. 5-1
5.1 Regular service and cleaning up ................................................................................... 5-1
5.1.1 Monthly inspection...................................................................................................... 5-1
5.1.2 Annual inspection ....................................................................................................... 5-1
Chapter 6 Input/output data ........................................................................................................ 6-1
6.1 Input data....................................................................................................................... 6-1
6.1.1 Details of the data input format................................................................................... 6-1
6.1.2 Priority of received data .............................................................................................. 6-6
6.2 Details of TT(ARPA) tracking data output ...................................................................... 6-6
6.3 Details of the radar data output ..................................................................................... 6-7
6.3.1 Radar system data...................................................................................................... 6-7
6.4 Interface specification.................................................................................................... 6-8
6.4.1 NAV (J4), EPFS (J5) and SDME (J6) serial data input/output specification................ 6-8
6.4.2 VDR (external monitor) and Alarm output signal specification .................................... 6-9
6.4.3 AIS input/output specification (J2) .............................................................................6-11
6.4.4 Radar input/output signal specification ..................................................................... 6-12
6.4.5 Gyro input signal specification .................................................................................. 6-12
6.4.6 Talker device code of the data output devices .......................................................... 6-13

System Configuration MDC-2900 Series
xii 0092629012-07
System Configuration
MDC-2960/2910/2920 series system configuration
Display unit
MRD-105
Scanner unit
RB717A
RB718A
RB719A
Power cable
CW-259-2M
Rectifier
PS-010
or
VL-PGS001
Onboard DC power supply
21.6 - 41.6VDC Onboard AC power supply
100/115VAC
200/230VAC
A
C power cable
VV-2D8-3M
A
larm out
Operation unit
MRO-105.E
GPS Compass
S2N Gyro converter
A
IS
CW-376-5M
CW-376-5M
CW-406-5M
CW-406-5M
CW-387-5M
CW-576-0.5M
Slave display
MRD-105/105P
+MRO-105
CW-373-10M
CW-561-10M
External monitor
A
nalog SXGA
CW-560-2M
J9
10P J1
8P J2
12P J3
VDR
CW-560-2M
GYRO SYNCHRO
or step signal
LOG pulse
GYRO NMEA
signal
CW-406-5M
NAV
J5
J6 L1N Log pulse NMEA
converter
Antenna
RW701A-04
RW701A-06
CW-376-5M
ATA Board
E56-7010
AIS Board
E59-7100
C-MAP Card
Connecting cable
242J159098B-15M (Standard)
242J159098C-20M
242J159098D-30M
242J159098E-**M (100m Max.)
Inter switch
J4
NAV
GYRO
8P
6P
6P
15P D-Sub
EPFS
(Electric position
Fixing System)
SDME
(Speed and Distance
Measuring Equipment)
6P
CW-376-5M
Standard
Option
Owner supplied

MDC-2900 Series System Configuration
0092629012-07 xiii
MDC-2960BB/2910BB/2920BB series system configuration
Processor unit
MRM-105
Connecting cable
242J159098B-15M (Standard)
242J159098C-20M
242J159098D-30M
242J159098E-**M (100m Max.)
Antenna
RW701A-04
RW701A-06
Scanner unit
RB717A
RB718A
RB719A
Power cable
CW-259-2M
Rectifier
PS-010
or
VL-PGS001
Onboard DC power supply
21.6 - 41.6VDC
Onboard AC power supply
100/115VAC
200/230VAC
A
C power cable
VV-2D8-3M
GPS Compass
S2N Gyro converter
A
IS
CW-376-5M
CW-376-5M
CW-406-5M
CW-406-5M
CW-387-5M
CW-576-0.5M
Slave display
MRD-105/105P
+MRO-105
CW-373-10M
CW-561-10M
External monitor
A
nalog SXGA
CW-560-2M
J9
VDR
CW-560-2M
A
larm out
GYRO SYNCHRO
or step signal
LOG pulse
Operation unit
MRO-105.E
6P
SXGA
Monitor Display
GYRO NMEA
signal
CW-406-5M
NAV
J5 EPFS
(Electric position
Fixing System)
J6 L1N Log pulse NMEA
converter
SDME
(Speed and Distance
Measuring Equipment)
CW-376-5M
CW-376-5M
D-Sub 15P
10P J1
8P J2
12P J3
Inter switch
J4
NAV
ATA Board
E56-7010
AIS Board
E59-7100
C-MAP Card
8P
6P
6P
15P D-Sub
GYRO
Standard
Option
Owner supplied

Configuration Equipment MDC-2900 Series
xiv 0092629012-07
Configuration Equipment
Standard configuration list
MDC-2960
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6 kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB717A 6 kW 17 kg 1
3 Display unit MRD-105 15 kg 1
4 Operation unit MRO-105 1.8 kg 1
5 Connecting cable 242J159098B-15M With connectors on the
both sides
15 m 1
6 Power cable CW-259-2M With a connector on the
single side
2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material list 1 set
9 Cover E59MC11160 Hard cover 0.5 kg 1
10 Document MDC-2900.SER.OM.E Operation manual 1
11 Document MDC-2900.SER.IM.E Installation manual 1
12 Document MDC-2900.SER.QR.E Quick Reference 1
MDC-2910
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6 kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB718A 12 kW 17 kg 1
3 Display unit MRD-105 15 kg 1
4 Operation unit MRO-105 1.8 kg 1
5 Connecting cable 242J159098B-15M With connectors on the
both sides
15 m 1
6 Power cable CW-259-2M With a connector on the
single side
2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material list 1 set
9 Cover E59MC11160 Hard cover 0.5 kg 1
10 Document MDC-2900.SER.OM.E Operation manual 1
11 Document MDC-2900.SER.IM.E Installation manual 1
12 Document MDC-2900.SER.QR.E Quick Reference 1

MDC-2900 Series Configuration Equipment
0092629012-07 xv
MDC-2920
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB719A 25 kW 21 kg 1
3 Display unit MRD-105 15 kg 1
4 Operation unit MRO-105 1.8 kg
5 Connecting cable 242J159098B-15M With connectors on the
both sides
15 m 1
6 Power cable CW-259-2M With a connector on the
single side
2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material list 1 set
9 Cover E59MC11160 Hard cover 0.5 kg 1
10 Document MDC-2900.SER.OM.E Operation manual 1
11 Document MDC-2900.SER.IM.E Installation manual 1
12 Document MDC-2900.SER.QR.E Quick Reference 1
MDC-2960BB
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6 kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB717A 6 kW 17 kg 1
3 Processor unit MRM-105 12.4 kg 1
4 Operation unit MRO-105 1.8 kg
5 Connecting cable 242J159098B-15M With connectors on the
both sides 15 m 1
6 Power cable CW-259-2M With a connector on the
single side 2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material
list
1 set
9 Document MDC-2900.SER.OM.E Operation manual 1
10 Document MDC-2900.SER.IM.E Installation manual 1
11 Document MDC-2900.SER.QR.E Quick Reference 1

Configuration Equipment MDC-2900 Series
xvi 0092629012-07
MDC-2910BB
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6 kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB718A 12 kW 17 kg 1
3 Processor unit MRM-105 12.4 kg 1
4 Operation unit MRO-105 1.8 kg
5 Connecting cable 242J159098B-15M With connectors on the
both sides 15 m 1
6 Power cable CW-259-2M With a connector on the
single side 2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material
list
1 set
9 Document MDC-2900.SER.OM.E Operation manual 1
10 Document MDC-2900.SER.IM.E Installation manual 1
11 Document MDC-2900.SER.QR.E Quick Reference 1
MDC-2920BB
No. Name Type Comment Weight/
Length
Quantity
1 Antenna RW701A-04 4 ft 6 kg 1
RW701A-06 6 ft 8 kg
2 Scanner unit RB719A 25 kW 21 kg 1
3 Processor unit MRM-105 12.4 kg 1
4 Operation unit MRO-105 1.8 kg
5 Connecting cable 242J159098B-15M With connectors on the
both sides 15 m 1
6 Power cable CW-259-2M With a connector on the
single side 2 m 1
7 Spare parts SP-100 See spare parts list 1 set
8 Installation material M12-BOLT.KIT See installation material
list
1 set
9 Document MDC-2900.SER.OM.E Operation manual 1
10 Document MDC-2900.SER.IM.E Installation manual 1
11 Document MDC-2900.SER.QR.E Quick Reference 1

MDC-2900 Series Configuration Equipment
0092629012-07 xvii
Spare parts list
SP-100
No. Name Specification Comment Type
(Dimension)
Quantity Usage
1 Fuse F-1065-15A Normal
type
Tubular
(·6.4 x 30)
1 Main power
2 Fuse MF51NN250V5A Normal
type
Tubular
(·5.2 x 20)
1 Motor power
3 Fuse FGMB-A 250V0.5A Normal
type
Tubular
(·5.2 x 20)
1 High voltage
power supply
4 Carbon brush 24Z125209B 1 set Antenna motor
Installation material list
M12-BOLT.KIT
No. Name Specification Quantity Usage
1 Hexagon bolt B12X55U 4 Antenna unit
2 Nut N12U 8 Antenna unit
3 Plain washer 2W12U 8 Antenna unit
4 Spring washer SW12U 4 Antenna unit

Configuration Equipment MDC-2900 Series
xviii 0092629012-07
Options
(Common)
No. Name Specification Comment Weight
/Dimension
/Quantity
1 Gyro converter S2N, U/N 9028C qwerty-electronik
2 Log pulse NMEA
converter
L1N, U/N 9181A qwerty-electronik
200pulse/NM only
3 Power rectifier unit PS-010 5A fuse attached 3.5 kg
VL-PGS001 VEINLAND GmbH
20A fuse attached
4.5kg
4 AC power cable VV-2D8-3M Without connectors on the
both sides
3 m
5 Connecting cable
CW-373-
select 5M or 10M,30M
With 6-pin water resistant
connectors at both ends
(cable for data)
5 m or 10 m,
30 m
CW-374-5M With a 6-pin connector and
a 6-pin water resistant
connector (cable for data)
5 m
CW-406-5M With a 8-pin water resistant
connector and one end
plain (cable for THD)
5 m
CW-376-5M With a 6-pin water resistant
connector and one end
plain (cable for data)
5 m
CW-387-5M With a 8-pin water resistant
connector and one end
plain (cable for AIS)
5 m
CW-561-
select 10M or 30M
With 12-pin water resistant
connectors at both ends
(connector for slave
display)
10 m or 30 m
CW-576-0.5M With a 10-pin water
resistant connector and
D-Sub connector (RGB)
+Alarm out
0.5 m
CW-560-2M With 15-pin water resistant
D-Sub conectors at both
ends
(Cable for external display
unit)
2m
6 Antenna-Scanner unit
and Display unit
connecting cable
242J159098C-20M With connectors on the
both sides
20 m
242J159098D-30M With connectors on the
both sides
30 m
242J159098E-XM With connectors on the
both sides
65 m Max.
(Designated)

MDC-2900 Series Chapter 1 Prior to installation
0092629012-07 1-1
Chapter 1 Prior to installation
1.1 Installation precautions
In order to obtain the maximum performance of radar systems, this radar system should be
installed by qualified engineers in charge of installation and maintenance. Installation procedures
include the following:
(1) Unpacking of components;
(2) Inspection of composition units, spare parts, accessories and installation materials;
(3) Checking of supply voltage and current capacity;
(4) Selection of the location for installation;
(5) Installation of the Antenna-Scanner unit;
(6) Installation of the Display unit;
(7) Attachment of accessories;
(8) Planning and implementation of cable laying and connection;
(9) Coordination after installation.
1.2 Unpacking of components
Unpack components and check that all items correspond with the description of the packing list.
When a discrepancy or damage has been found, please contact the transportation/insurance firm,
and follow procedures for searching for loss items and claim of expense.
1.3 Appearance verification of each unit and accessories
Please check the appearance of each unit carefully, confirm that any dent and crack free.
Moreover, please also check the interior of each unit and confirm that there is no electric or
mechanical damage.
The illumination panel (back light) of the LCD module is made of glass. If the unit is dropped,
damage may occur. Since the presence of damage might not be found by checking of the
appearance, please confirm in the display screen after power turning on.
1.4 Selection of location for installation
In order to obtain the maximum performance of the units, it is necessary to install them in
consideration of matters as described below.
1.4.1 Antenna-Scanner unit
(1) Blind sectors shall be kept to a minimum, and shall not be placed in an arc of the horizon from
the right ahead direction to 22.5° abaft the beam and especially shall avoid the right ahead
direction (relative bearing 000°). The installation of the Antenna shall be in such a manner that
the performance of the radar system is not substantially degraded. The Antenna shall be
mounted clear of any structure that may cause signal reflections, including other Antenna and
deck structure or cargo. In addition, the height of the Antenna shall take account of target
detection performance relating to range of first detection and target visibility in sea clutter.
