Kogan KA7LSTEFRYA User manual

7L DIGITAL 1700W AIR
FRYER & STEAMER
KA7LSTEFRYA

•Read all instructions before using the appliance and retain this guide for reference.
•Do not operate the air fryer in flammable or heat-sensitive areas. Do not operate the air
fryer within an enclosed space, such as a cabinet.
•Be sure to use on a heat resistant and even surface, such as a heatproof mat. Do not
place directly on a benchtop. Keep the appliance at least 30cm away from the wall,
furniture or other flammables
•Do not insert foreign objects into the air inlet or outlet, as this may result in electric
shock or injury. If a foreign object accidentally enters these sections, please unplug the
power cord immediately and contact Kogan.com.
•Do not disassemble or attempt to modify the unit.
•Do not force the power cord to bend or stretch. If the power cord is damaged, stop using
the appliance immediately and replace the cord before the appliance is used again.
•When unplugging the appliance, please hold the plug and pull it out of the socket. If
you unplug it by pulling the cord directly, the cord may be damaged, resulting in
leakage or fire. When not in use for an extended period, please unplug the appliance
from the wall socket.
•Do not use loose electrical sockets as this may result in fire, electric shock or injury.
•Do not use an extension cord unless completely necessary with this product. If an
extension cord is used please ensure that it has a rating equal or exceeding the rating of
this appliance.
•Do not pull or carry by cord, use cord as a handle, close a door on the cord or pull cord
around sharp edges or comers. Keep cord� from heated surfaces.
•Do not bend or damage the power cord.
•Always unplug the appliance when not in use. To disconnect from the power supply, grip
the plug and pull from wall outlet. Never pull by the cord. The plug must be removed
from wall outlet before cleaning, servicing, maintenance or moving the appliance.
•Do not place the appliance near a hot gas or electric burner.
•Do not cover the appliance while in use. If it is covered, there is a risk of fire.
•Vigorously opening and closing the door will cause deformation of door panel.
•If the appliance emits excessive amounts of smoke, turn off the appliance or unplug the
power cord and keep the door closed to prevent any flames from spreading. The
appliance cannot be operated by an external timer or an independent remote-control
system.
Please handle this product with care and inspect it regularly to ensure it is in good
working order.
If the product, power supply cord or plug shows any signs of damage: stop use,
unplug and contact Kogan.com support.
SAFETY & WARNINGS

•Never immerse the appliance in water.
•Remove all packaging materials (including plastic bags, protective film, accessories,
etc.) before use. Keep away from infants and young children to prevent suffocation by
misusing.
•Do not clean the appliance until it is unplugged and cooled, to avoid accidents such as
electric shock and burns.
•Do not use the appliance if the water tank is damaged.
•The water in the water tank must be replaced before each use. After cooking, the
remaining water must be poured out to avoid the spread of viral bacteria.
•Steam fryers heat up during use. Avoid contacting hot surfaces on the steam fryer.
•Do not place your hands inside the unit immediately after cooking to avoid burns. Allow
the appliance to cool completely before opening the door.
•During operation of the fryer, there may be a small amount of smoke. Ensure nearby
windows are open to assist with air circulation. Infants and pets are especially
susceptible to smoke; place them in other rooms while the appliance is in use. If you
need to frequently cook foods which easily produce smoke, please ensure that the
steam fryer used is in a well-ventilated place.
•Thoroughly clean the steam fryer after every use once the machine has cooled,
including wiping up remaining water and removing any food residue.
WARNING:
•Do not use broken gloves to pick up hot food, as warm water and oil can easily cause
burns.
•Please be careful when opening the door during cooking, as steam will emit from within.
•Children should only use steam fryers if they adequately understand the proper use
instructions and can be allowed to use the steam fryer without supervision if they
understand that incorrect use will cause dangers. When the appliance is operated in a
combined mode, the child must be used under the supervision of an adult due to the
high temperature. Older people need to use steam fryers with their family members.
•Any component with the “High Temperature Surface ” mark will become hot during
use. Avoid contact with this part of the device.
•If the steam fryer door or door seal is damaged, cease usage immediately and contact
Kogan.com.
•It is dangerous for untrained users to open or attempt to repair the product. If you
encounter any problems during use, please contact Kogan.com

Initial inspection
Upon opening the package, inspect the unit to ensure that:
•There is no deformation of the outer cover of the machine due to impact or heavy
pressure.
•The pot door and the control panel are flat, and the door can be opened smoothly.
•The power cord is not loose or damaged.
•The voltage noted on the steam fryer rating plate matches the local voltages.
Always consider the following factors when positioning the fryer for use:
•Whether the fryer is level and stable on the chosen surface.
•The appliance’s proximity to high temperatures or moisture.
•The grounding of the electrical plug and socket.
In order to avoid causing damage to or dirtying the surrounding environment with oil, smoke
or steam, keep the appliance at a reasonable distance from nearby walls and cabinets.
Water Tank
Attention
•Clean the water tank if it is unused for an extended period. Residual water and
other liquids are prone to mildew.
•Do not put anything except the water into water tank to avoid malfunctions. In
order to maintain high heating efficiency and food hygiene, it is recommended to
use distilled or purified water.
•Ensure that the water tank is securely in place to avoid affecting normal use.
•Do not to use the appliance in an environment below 5°C. The time for producing
steam will be slower if the temperature is too low. When the environment
temperature reaches 0°C, the water will start to freeze and no steam will be
produced.
Attention
•During operation, the cooking time can be adjusted with the “+” and “-” buttons.
•The steam fryer will not operate if the door has not been closed securely.
•Ensure ample water is in the tank and that is has been inserted securely before use.
INSTRUCTIONS

Button 1 - Steam
Water will pump into the steam generator, and hot steam vapour will spray out through
steam drain holes, effectively cooking the food contained within.
When this program is active, the air fryer function is shut off.
Operation:
1. Press the steam function icon (button 1);
2. Set the timer using the “+” and “-” keys surrounding the timer icon.
3. Press the ON/OFF button to start the program.
The steam function will then commence.
Note: The temperature and steam quantity cannot be altered when using the steam
cooking function. The vapour quantity during steam function is fixed to ensure a constant
bowl temperature between 95°C-100°C. Yo u can set different cooking times for different food
and different food size.
OPERATION
3. Air
Fryer
1. Steam
4. Water scale
indicator
5. Water
scale
cleaning
2. Water shortage
indicator
12. Running
Icon
6. ON/OFF
9. Broccoli
8. Chicken
Wings
7. French
Fries
10. Steak
11. Prawns

Button 2 - Water shortage indicator
This light indicates that insufficient water is contained in the tank.
1. The water tank has a capacity of 600ml; once completely filled, it will allow up to
40 minutes of continuous steam function.
2. The steam function will produce condensation where the hot steam meets a colder
surface temperature. The collection tray at the bottom of the appliance will gather
this excess moisture.

Button 3 - Air Fryer
Taking advantage of fast cooking times and hot temperature circulation without oil, the air
fryer function can be very versatile through setting different temperatures and times for
many cooking purposes.
When this program is active, the steam function is shut off.
Operation:
1. Press the Air fryer icon ,
2. Set the temperature and timer using the “+” and “-” keys surrounding the
appropriate icon.
3. Press the ON/OFF button to start the program.
The air fryer function will then commence.
Button 4 - Water scale indicator
When the machine has operated in steam mode for a cumulative 20 hours, the machine's
lime scale removal prompt light will automatically turn on and blink, indicating that the
machine should be checked and cleaned of any lime scale that has appeared.
Tip: It is recommended to use pure water and distilled water as much as possible when
using the machine to cook food so as to prevent the build-up of lime scale on the heating
elements.
Button 5 - Water scale cleaning button
Press this button to clean the machine when the water scale indicator begins blinking.
Operation:
•Take 500ml purified water, add 10g edible citric acid and stir evenly until the citric
acid is melted.
•Put the water tank on the machine and press the "clean function" button to remove
scale.
•After the scale is removed, the lime scale prompt light will automatically turn off.
•Remove the pot cavity from the appliance and dump the wastewater within.
Tip: When you are not using the appliance on a regular basis, perform the water scale
cleaning cycle before using the unit again.
Button 6 - Power ON/OFF
Once plugged in, the full panel will be illuminated after pushing the ON/OFF button once.
Pushing the ON/OFF button a second time will start the cooking process with a default
temperature of 180°C and a cooking time of 15 minutes. During the cooking cycle, pressing
the Power Button will turn the unit off. All lights will turn off and the running light will
continue to blink for 20 seconds to allow the unit to cool down.

Button 7–11 - Cooking Presets
Selecting any of these will set the Time and Temperature to a default setting for that
particular food. You may override these presets with Time and Temperature Buttons. The
details for each preset are shown in the table below:
Temp.
range
°C
Time
range
MIN
Medium (°C-Min)
Preset Steam Air
fryer
French
fries
Chicken
Wings Broccoli Steak Shrimp
Preset
200 80 60 1 180-150 100-20 180-15
200-18
only air
fryer
200-20
only air
fryer
100-12
for
steam
100-6
for
steam
100-4
for
steam
180-2 for
air fryer
180-9
for air
fryer
180-5
for air
fryer
Button 12- Running Icon
These lights will blink in sequence while cooking is in progress and continues blinking up to
20 seconds.

•After using, please unplug the appliance. Do not place the power cord or plug directly
on the hot outer casing to prevent damage to the power cord.
•Clean the steam fryer once it has cooled adequately. The steam fryer should be
cleaned regularly and all food residue inside should be removed.
Note: Do not rinse the appliance directly with water when cleaning; wipe it with a damp
dish cloth. Dirt will cause the eventual degradation of the appliance’s surfaces, which
can affect the life of the appliance and can lead to other dangerous conditions.
•Wipe the steam fryer housing by a cloth with a soft detergent. Then wipe it off with a
damp cloth and dry it with a dry cloth. Do not use a scrubbing utensil such as a wire
brush to clean the steam fryer.
•Clean door seals, cavities and adjacent parts
WARNING: Do not use a rough scrubber or a sharp metal scraper to clean the door of the
steam fryer, as this can damage the seals.
•Do not clean the door safety lock system. Use the cavity cleaning function to clean the
pot cavity before use if the appliance has not been in use for some time.
•Clean the pot cavity soon after use to avoid inconvenience in cleaning in the future. The
oil produced during cooking will corrode the pot cavity, affect the heating of the
appliance and even change the taste of the food when left for an extended period.
•Do not wipe the appliance housing with a harsh detergent or any corrosive/volatile
chemical solvents to avoid damage to the unit.
CLEANING & CARE
Note
The steam fryer needs to be cleaned and maintained frequently.

Food container bowl 7L
Disassemble water tank capacity 600ml
Power of Air Fryer (heating
element) 220-240V, 1700W
Steam function Power 220-240V, 900W
Display LED display with touch screen
Functions Air Fryer, Steamer, Steam Air Fryer
Programs French fries, Chicken Wings, Broccoli, Steak, Shrimp
Panel type Full screen panel
Temperature 80-200°C
Timer 1-60min
Unit size 397 x 324 x 389mm
SPECIFICATIONS
389
324
397

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
