Kogan 6 Series User manual

32 6 6
QH

TV Buttons

Press MENU button to display the main menu.
Channel Menu
1. Press ▼ / ▲ button to select the option that you want to adjust in the CHANNEL menu.
2. Press Enter button to adjust.
3. After finishing your adjustment, Press Enter button to save and return to the previous
menu.
Auto Tuning
ATV Manual Tuning
Current CH
Set the channel number.
Color System
Select the color system.
(Available System: AUTO,PAL , SECAM )
Sound System
Select the Sound system.
Fine-Turn
Adjust the frequency of the channel finely.
Search
Start searching channel.

DTV Manual Tuning
Press ▼ / ▲ button to select DTV Manual Tuning, then press Enter button to enter sub-menu.
Press / button to select channel, then press Enter button to search program.
Program Edit
Press ▼ / ▲ button to select Program Edit, then press Enter button to enter
sub-menu.
The three colored key is the shortcut key for programming
the channel.
First press ▼ / ▲ to highlight the channel you want to select, then:
Press the button to delete the program in the list. Red
Press the button to move the channel in favorite list. Yellow
Press the button to skip the selected channel.Blue
Press Fav button to add or remote the channel to your favorite list.
(Your TV set will skip the channel automatically when using
CH+/- to view the channels.)
Schedule List
Press ▼ / ▲ button to select Schedule List, then press Enter button to enter sub-menu.
It is available in source.
Signal Information
Press ▼ / ▲ button to select Signal Information, press the Enter button to see the detail
information about the signal. Only available when there is signal in DTV.
below.

►
►
Picture Menu
Picture Mode
Press ▼ / ▲ button to select Picture Mode, then press OK button to enter sub-menu.
You can change the value of contrast, brightness, color, sharpness and tint when the picture is in
Personal mode.
TIPS: You can press PMODE button to change the Picture Mode directly.
Contrast/ Brightness/ Color/ Tint / Sharpness
Press ▼ / ▲ button to select option, then press / button to adjust.
Contrast Adjust the highlight intensity of the picture, but the shadow of the picture is invariable.
Brightness Adjust the optical fiber output of the entire picture, it will effect the dark region of the picture.
Color Adjust the saturation of the color based on your own like.
Tint Use in compensating color changed with the transmission in the NTSC code.
Sharpness Aadjust the peaking in the detail of the picture.
Noise Reduction
HDMI Mode

Sound Menu
Press MENU button to display the main menu.
Press / button to select SOUND in the main menu.
1. Press ▼ / ▲ button to select the option that you want to adjust in the SOUND menu.
2. Press Enter button to adjust.
3. After finishing your adjustment, Press Enter button to save and return to the previous menu.
Sound Mode
Press ▼ / ▲ button to select Sound Mode,
then press Enter button to enter sub-menu.
Press▼/▲ button to select.
Standard Produces a balanced sound in all environments.
Music Preserves the original sound.Good for musical programs.
Movie Enhances treble and bass for a rich sound experience.
Sports Enhances vocals for sports.
Personal Select to customize sound settings.
Note:The treble and bass are only available in Personal mode,you can adjust them as you like.
Balance
Press ▼ / ▲ button to select option, Press / button to adjust.
Auto Volume level
Press ▼ / ▲ button to select Auto Volume Level, then press / button to select On or Off.
SPDIF Mode
Press ▼ / ▲ button to select SPDIF Mode, then press / button to select Off / PCM / Auto.
NOTE:
Balance: This item can adjust the speaker’s output, it enables you to listen to best at your position.
Auto Volume: This item is used for reducing the difference between channel and program’s
volume automatically.
AD Switch
Press ▼ / ▲ button to select AD Switch, then press / button to select On or Off.
Amblyopia function for the blind, the tracks will be mixed describe the current screen .
It need codestream to support.
Time Menu
Press MENU button to display the main menu.
Press / button to select TIME in the main menu.
►
◄
1. Press ▼ / ▲ button to select the option that you want to adjust in the TIME menu.
2. Press Enter button l to adjust.
3. After finishing your adjustment, Press Enter button to save and return to the previous menu.
Time Zone
Press ▼ / ▲ button to select Time Zone, then press Enter button to enter sub-menu.
Press ▼ / ▲ / / button to select time zone.
◄ ►
Sleep Timer
Press ▼ / ▲ button to select Sleep Timer, then press Enter button
to enter sub-menu.
Press ▼ / ▲ button to select.
(Available options are:Off,10min,20min,30min,60min,90min,
120min,180min,240min).

Auto Standby
OSD Timer
Press ▼ / ▲ button to select OSD Timer,
then press Enter button to enter sub-menu.
Press / button to select.
Press ▼ / ▲ button to select Auto Standby, then press Enter button to
enter sub-menu.
Press ▼ / ▲ button to select.
Tips: The remote control does not make any operation in the hypothesis time,
it will close down automatically. If you do any operation, it will reset the time.
Lock Menu
Press MENU button to display the main menu.
Press / button to select Lock in the main menu.
◄ ►
◄ / ►
Press ▼ / ▲ button to select System Lock ,
then press Enter button to make the following 4 options valid.
and if forget what you set, Default password is 0000/8888,
please call the service center.
Press ▼ / ▲ button to select Set Password,
then press Enter button to enter sub-menu to set new password.
Set Password

Channel Lock
Press ▼ / ▲ button to select Channel Lock
then press Enter button to enter sub-menu to select.
Press button to lock or unlock the channel.Green
Parental Guidance
Press ▼ / ▲ button to select Parental Guidance,
then press Enter button to enter sub-menu to select the number of age
which is suitable for your children.
Key Lock
Press ▼ / ▲ button to select Key Lock, then press / button to select Off or On.
When Key Lock’s statue is on, you can’t use the Key panel button.
1. Press ▼ / ▲ button on the remote control to select hotel mode in the Lock menu.
2. Press Enter button on the remote control to enter the sub-menu.
3. After finishing your adjustment, Press MENU button to save and return back to the previous menu.

Setup Menu
Press MENU button to display the main menu.
Press button to select SETUP in the main menu.
◄ / ►
1. Press ▼ / ▲ button to select the option that you want to adjust in the SETUP menu.
2. Press Enter button to adjust.
3. After finishing your adjustment, Press Enter button to save and return to the previous menu.
▼ / ▲ / ◄ / ►
OSD Language
TT Language
Press ▼ / ▲ button to select TT Language, then press Enter button to enter sub-menu.
Press button to select TT language.
▼ / ▲ / ◄ / ►
PVR File System
Press ▼ / ▲ button to select PVR File System, then press Enter button to enter sub-menu.
Press ▼ / ▲ button to select Check PVR File System ,
then press Enter button to enter. Then it will check the USB speed.

Aspect Ratio
Press ▼ / ▲ button to select Aspect Ratio, then press Enter button to enter sub-menu.
Press ▼ / ▲ button to select aspect ratio. (Available options are: Auto, 4:3,16:9, Zoom1, Zoom2).
Blue Screen
Press ▼ / ▲ button to select Blue Screen, then press Enter button to select On or Off.
First Time Installation
Press ▼ / ▲ button to select First time installation, then press Enter button to enter.
Reset
Press ▼ / ▲ button to select Reset, then press Enter button to enter sub-menu.
Software Update(USB)
Press ▼ / ▲ button to select Software Update (USB), plug your USB device in the USB slot,
then press Enter button to update the right software.
HDMI CEC
Press ▼ / ▲ button to select HDMI CEC, then press Enter button to enter the sub-menu.
HDMI CEC Press button to turn the HDMI CEC On or Off.
HDMI ARC Press button to turn the HDMI ARC On or Off.
Auto Standby Press button to turn the Auto Standby On or Off.
Device List Press Enter button to open the main menu of device.
Screen Menu
Press MENU button to display the main menu.
Press button to select SCREEN in the main menu.
◄ / ►
Auto Adjust
Press Enter button to start adjusting H-Offset/V-Offset/Size/Phase automatically.
H-Offset.
Adjust the horizontal position of the picture.
Press ▼ / ▲ button to select H-Offset, then press Enter button to enter sub-menu.
V-Offset
Adjust the vertical position of the picture.
Press ▼ / ▲ button to select V-Offset, then press Enter button to enter sub-menu.
Size
Adjust the display size.
Press ▼ / ▲ button to select Size, then press Enter button to enter sub-menu.
Phase
Adjust the horizontal interfering lines.
Press ▼ / ▲ button to select Phase, then press Enter button to enter sub-menu.
Position Reset
Press ▼ / ▲ button to select Position Reset, then press Enter button to enter.
1. Press ▼ / ▲ button to select the option that you want to adjust in the SCREEN menu.
2. Press Enter button to adjust.
3. After finishing your adjustment, Press Enter button to save and return to the previous menu.
Notes:
1. Noise Reduction in PICTURE option is invalid.
2. AD Switch in SOUND option is invalid.
3. TIME menu and description are the same as that for mode.Air
4. Block Program and Parental Guidance in LOCK option is invalid.
5. Audio Languages, Subtitle Language, Hearing Impaired and PVR File System
in SETUP option is invalid.
6. mode has no CHANNEL menu. PC

Note: Before operating Media menu,Plug in USB device,then press INPUT button to set the Input Source to Media .
Press ▼ / ▲ button to select Media in the Source menu, then press Enter button to enter.
Press button to select the option you want to adjust in the main Media menu,
then press Enter button to enter.
◄ / ►
Press button to select PHOTO in the main menu, then press Enter button to enter.
Press Exit button to return to the previous menu and exit menu to quit.
Photo Menu

Music Menu
Press button to select drive disk you want to watch , then press Enter button to enter.
Press Exit button to return to the previous menu and exit menu to quit.
Movie Menu
Press Exit button to return to the previous menu and exit menu to quit.
Press button to select MOVIE in the main menu, then press Enter button to enter.
Press button to select MUSIC in the main menu, then press Enter button to enter.
◄ / ►

Press button to select TEXT in the main menu, then press Enter button to enter.
Press Exit button to return to the previous menu and exit menu to quit.
Text Menu
