Kohler K-1111-VLN Assembly instructions

Homeowners Guide
Bath Whirlpool
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página ″Español-1”
K-1111-VLN
1042760-5-D

Operating Instructions
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRICAL SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
DANGER: Risk of personal injury. To reduce the risk of injury, do not permit children to use this
unit unless they are closely supervised at all times.
WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the
whirlpool.
WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,
telephone, radio, or television) within 5’ (1.5 m) of this whirlpool.
WARNING: Risk of hyperthermia. People using medications and/or having an adverse medical
history should consult a physician before using a whirlpool equipped with a heater.
WARNING: Risk of scalding. Do not allow the water temperature in the whirlpool to exceed
104°F (40°C).
Use this whirlpool only for its intended purpose as described in this manual. Do not use attachments not
recommended by the manufacturer.
Never drop or insert any object into any opening. Keep small objects such as bath toys and bathing
accessories out of the whirlpool while the unit is running.
Do not operate this unit without the guard (cover) over the suction fitting.
The whirlpool must be connected only to a supply circuit that is protected by a Ground-Fault
Circuit-Interrupter (GFCI) or Residual Current Device (RCD). Such a GFCI or RCD should be provided by
the installer and should be tested on a routine basis. To test the GFCI or RCD, press the test button. The
GFCI or RCD should interrupt power. Press the reset button. Power should be restored. If the GFCI or RCD
fails to operate in this manner, the GFCI or RCD is defective. If the GFCI or RCD interrupts power to the
bath without the test button being pressed, a ground current is flowing, indicating the possibility of an
electric shock. Do not use this whirlpool bath. Disconnect the whirlpool and have the problem corrected by a
qualified service representative before using.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs
when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia
include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c)
unawareness of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to
exit the bath, and (f) unconsciousness resulting in the danger of drowning.
Flush your whirlpool system twice a month or more depending upon usage, as described in the ″Flush
System″section.
Repeated use of personal care products containing oils can damage plastic whirlpool components. Do not use
heavy, vegetable-based shampoos or bath oils.
Whirlpool hydro-massage action can cause even a small amount of bubble bath, bath soap, shampoo, or bath
oil to foam excessively. For this reason, please don’t use these products during whirlpool operation.
1042760-5-D 2 Kohler Co.

Thank You For Choosing Kohler Company
Thank you for choosing Kohler Company. Your Kohler Company product reflects the true passion for design,
craftsmanship, artistry, and innovation Kohler Company stands for. We are confident its dependability and
beauty will surpass your highest expectations, satisfying you for years to come.
All information in this guide is based upon the latest product information available at the time of
publication. At Kohler Company, we strive to fulfill our mission of improving the level of gracious living for
each person who is touched by our products and services. We reserve the right to make changes in product
characteristics, packaging, or availability at any time without notice.
Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.
Kohler Co. 3 1042760-5-D

Your Kohler Whirlpool
The whirlpool is equipped with the following components:
•Bath - The bath acts as a reservoir for water and provides a location for the hydro-massage action.
•User Keypads (2) - Located within easy reach, the keypads allow you to turn the whirlpool on and
off, access all the whirlpool modes, and regulate the water flow or pulse speed. Available modes
will be illuminated in blue. Active modes will be illuminated in green.
•Pump Motors (2) - The pump motors provide quiet, variable speed power to circulate the water and
create the soothing hydro-massage action.
•Adjustable Jets - The adjustable jets may be positioned to optimize their hydro-massage effect. The
trim on the adjustable jets allow you to adjust the air and water flow.
•Heaters (2) - The heaters are designed to automatically help maintain the temperature of the water
up to 104°F (40°C) to enhance your hydro-massage experience. The heaters turn on automatically
when the whirlpool is operating and turn off when the pump motors are turned off. The heaters
may be turned off through the keypad at any time while the pump motors are operating.
•Pillows - The pillows provide a comfortable place to rest your head as you relax.
•Remote Controls (2) - The waterproof remote controls bring all the whirlpool features to your
fingertips.
•Chromatherapy - Add ambience to your bath with lights that automatically and continuously cycle
through the eight colors, or select just one color: white, violet, indigo blue, aqua blue, green, yellow,
orange, and red. One cycle through all eight colors takes approximately one minute. This mode may
be used with all modes of operation and also when the pumps are not operating.
•LED Lights (3) - The LED lights illuminate the ledge separating the two bath spaces.
•Effervescence Ports - The effervescence ports are intended to be a relaxing, soothing experience. The
Flexjets and backjets will automatically turn off when the effervescence mode is activated.
•Backjets - This mode delivers massaging water to your back. The backjets pulse from the bottom to
the top of the whirlpool. Water flow and pulse action occur from two backjets at a time.
The user keypad (2 provided) allows
you to turn the whirlpool and heater on
and off and regulate the water flow.
Adjustable jets allow you to
adjust the air and water
flow and direction.
The bath provides a reservoir
for the hydro-massage action.
Backjets
The pump motor (2 provided)
provides quiet, variable speed
power to circulate the water.
The heater (2 provided)
helps maintain the water
temperature up to 104˚F
(40˚C).
NOTE: Bath shown for illustrative
purposes. Your bath
model may vary.
1042760-5-D 4 Kohler Co.

User Keypads
Available modes will be illuminated in blue. Active modes will be illuminated in green.
Power Icon Turns the whirlpool pump on and off. Icons illuminated in blue indicate available
modes/features. Modes which are operating will be illuminated in green.
Chromatherapy
Specific Color Rotate the outer ring to select this mode. Press OK, press the up or down arrow to select a color, then press OK again. Only one of the two keypads controls this mode.
Outer Ring Rotate the outer ring to the desired mode. The selected mode will flash blue.
Backjet Mode Rotate the outer ring to select this mode. Press OK, then press the up or down arrow to
increase or decrease the pulsing action. Rotate the outer ring to the Flexjet mode, press OK
to activate the mode, then press the up or down arrow on the keypad to increase or
decrease water flow to the backjets and all other active modes.
OK Activates the desired mode.
Flexjet Flow
Mode Rotate the outer ring to select this mode. Press OK, then press the up or down arrow to increase or decrease the jet water flow.
Up Arrow Increases the water flow when the Flexjet flow mode is active. Increases the pulse speed
when the neckjet or backjet mode is active.
Effervescence
Mode Rotate the outer ring to select this mode, then press OK. The effervescence action will start at the water flow volume last set in the Flexjet flow mode. Press the up or down arrow to
increase or decrease the water flow. Press OK while the effervescence mode is flashing to
turn off the effervescence ports.
Indicator Bar Displays the water flow volume in the Flexjet flow mode. Displays the pulse speed in the
neckjet or backjet mode.
Chromatherapy
Cycle Rotate the outer ring to select this mode, then press OK. The chromatherapy lights will automatically and continuously cycle through eight colors. One cycle through all eight
colors takes approximately one minute. Only one of the two keypads controls this mode.
Down Arrow Decreases the water flow when the Flexjet flow mode is active. Decreases the pulse speed
when the neckjet or backjet mode is active.
Heater Automatically engages when the power icon is selected. Rotate the outer ring until the
heater mode is flashing, then press OK to turn the heater off. Press OK again to turn the
heater back on.
Flexjet Flow Mode
Activates Mode
Selected
Rotate outer
ring to access
desired mode.
Chromatherapy -
Specific Color
Power
On/Off Heater On/Off
Chromatherapy
Cycle
Decreases
Flow
Indicator Bar - Shows
Water Flow Volume or
Pulse Rate
Increases Flow
or Pulse Rate
Effervescence
Mode
Backjet Mode-
Adjust Pulse
Lighted User Keypad
Keypad above shows all features
available. Your keypad may vary
based on your whirlpool model.
Note:
Kohler Co. 5 1042760-5-D

Operation
NOTE: Please read these steps carefully before operating your whirlpool.
NOTE: The water temperature in the whirlpool should not exceed 104°F (40°C). The heater will
automatically turn off as the water temperature approaches 104°F (40°C) and will remain off until the
water cools.
Turn the jet trim fully counterclockwise. Position the jet nozzles so they face down toward the basin.
Close the drain and fill the bath above the backjet level probes.
Place your hand in the bath to test the water temperature for comfort and safety, then carefully
enter the bath.
Press the power icon. The heater will turn on and the whirlpool will start at a medium water flow
volume. The chromatherapy cycle icon will illuminate on the keypad and three small lights near the
whirlpool floor will illuminate until the keypad goes into sleep mode.
Press the up or down arrow to increase or decrease the water flow volume. The indicator bar in the
center of the keypad will display the current water flow volume.
Rotate the jet trim clockwise to reduce the air/water flow or counterclockwise to increase the
air/water flow.
Position the Flexjet nozzles to direct the water flow to maximize your hydro-massage experience.
Rotate the outer ring until the heater mode is flashing, then press OK. The heater will turn off. Press
OK again to turn the heater back on.
NOTE: In backjet mode, if the water level is lower than the backjet level probes, this mode will stop. The
backjet icon and indicator bar on the user keypad will flash. The backjet mode will automatically restart
when the water level reaches the backjet level probes.
Rotate the outer ring until the backjet mode is flashing, then press OK. Press the up or down arrow
to increase or decrease the pulsing action. Rotate the outer ring to the Flexjet mode, press OK to
activate the mode, then press the up or down arrow on the keypad to increase or decrease water
flow to the backjets and all other active modes.
Rotate the outer ring until the chromatherapy cycle is flashing, then press OK to activate it. Press
OK while the chromatherapy mode is active to turn off this mode.
Rotate the outer ring to the chromatherapy specific color. When flashing, press OK to activate it.
Press the up or down arrow to reach the desired color, then press OK to activate the desired color.
Press the power icon to turn the whirlpool off. The three small lights near the whirlpool floor will
remain illuminated until the keypad goes into sleep mode.
Turn the Flexjet
trim clockwise to
decrease the flow.
Turn the Flexjet trim
counterclockwise to
increase the flow.
Position the jet nozzles
to direct the water flow
as desired.
Fill with water until the backjet level
probes are covered with water.
Level
Probes
1042760-5-D 6 Kohler Co.

Operation (cont.)
Repeat the steps above to verify the second keypad is operating properly, less the chromatherapy
functions.
NOTE: The whirlpool will automatically shut off approximately 20 minutes after continuous operation. If
desired, press the power icon to reactivate the whirlpool.
Care and Cleaning
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537.
Flush System
NOTE: Flush your whirlpool system twice a month or more, depending upon usage.
Turn the jet trim rings fully clockwise to remove air induction.
Fill the whirlpool with warm water above the backjet level probes or leave water in the whirlpool
after using.
Add 2 teaspoons (10 ml) of a low-foaming, powder automatic dishwasher detergent and 20 ounces
(590 ml) of household bleach (5% - 6% sodium hypochlorite) to the water.
Run the whirlpool for 5 to 10 minutes. Turn off the whirlpool and drain the water.
If desired, rinse the bath surfaces with water.
Rinse the surfaces of the jets, faucet, handrails, and drain, and wipe them dry with a soft cloth.
Warranty
ONE-YEAR LIMITED WARRANTY
KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year
from date of installation.
Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection
discloses any such defects occurring in normal usage within one (1) year after installation. Kohler Co. is not
responsible for removal or installation costs. Use of in-tank toilet cleaners will void the warranty.
To obtain warranty service contact Kohler Co. either through your Dealer, Plumbing Contractor, Home
Center or E-tailer, or by writing Kohler Co., Attn.: Customer Care Center, 444 Highland Drive, Kohler, WI
53044, USA, or by calling 1-800-4KOHLER (1-800-456-4537) from within the USA and Canada, and
001-877-680-1310 from within Mexico.
IMPLIED WARRANTIES INCLUDING THAT OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXPRESSLY LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY. KOHLER CO. AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states/provinces do not allow limitations on how
long an implied warranty lasts, or the exclusion or limitation of special, incidental or consequential damages,
so these limitations and exclusions may not apply to you. This warranty gives you specific legal rights. You
may also have other rights which vary from state/province to state/province.
This is Kohler Co.’s exclusive written warranty.
Kohler Co. 7 1042760-5-D

Warranty
KOHLER CO.
It is recommended that at the time of purchase, you verify that all accessories and components are complete
in this package.
This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the
date of purchase as shown on the invoice or receipt.
1. Kohler Co. will only service its commercialized products through its authorized distributors.
2. To obtain warranty service, please present the invoice and corresponding warranty.
3. Through its authorized distributors, Kohler Co. promises to repair the defective product or provide a new
replacement or an equivalent model (in those cases that the model has been discontinued) when the product
is beyond repair, without any charge to the consumer.
4. The time of repair will not exceed six (6) weeks commencing on the date the product is received.
5. It is recommended that the consumer save the invoice or receipt as additional protection, as it may
substitute the warranty in the case that there is a discrepancy in the validity of the warranty.
EXCEPTIONS AND RESTRICTIONS
The Warranty will not be valid in the following cases:
1. When the product is not operated in accordance with the instructions concerning use and operation set
forth in the owner’s manual or installation instructions, and when the recommendations and warnings
included are not observed.
2. When the product has been modified or dismantled partially or totally; or has been used in a negligent
fashion and as a consequence has suffered damages attributable to the consumer, individual, or hardware not
authorized by Kohler Co.
3. This warranty does not cover the damages as a result of disaster such as fire or acts of God, including
flooding, earthquake, or electric storms, etc. To obtain a list of distributors in your area where you can
exercise your rights under this warranty, please call 001-877-680-1310.
KOHLER CO., KOHLER, WI 53044 U.S.A.
IMPORTER:
INTERNACIONAL DE CERÁMICA, S.A.B. DE C.V.
AV. CARLOS PACHECO NO. 7200
CHIHUAHUA, CHIH., MEXICO C.P. 31060
TEL: [phone]
Troubleshooting
This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualified
electrician should correct all electrical problems. For warranty service, contact your dealer or wholesale
distributor.
1042760-5-D 8 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
1. User keypad does not
illuminate when power
button is pressed or outer
ring is rotated.
A. No power to control. A. Check wiring and connect power. If
problem persists, Refer to the
installer/dealer.
B. GFCI or RCD tripped. B. Reset GFCI or RCD.
C. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
C. Check wiring for proper
connections. Replace wiring
harness if necessary. Refer to the
installer/dealer.
D. User keypad does not work. D. Replace user keypad. Refer to the
installer/dealer.
E. Control does not work. E. Replace control. Refer to the
installer/dealer.
2. Motor starts, but all jets
are not functioning. A. Jet is closed. A. Rotate jet trim counterclockwise to open.
B. Jet not installed correctly. B. Reinstall jet; check for O-ring
damage.
C. Jets are blocked. C. Remove blockage.
3. User keypad is
illuminated, but does not
respond to buttons or
outer ring.
A. Control program is locked. A. Reset GFCI or RCD.
B. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
B. Check wiring for proper
connections. Replace wiring
harness if necessary. Refer to the
installer/dealer.
C. User keypad does not work. C. Replace user keypad. Refer to the
installer/dealer.
D. Control does not work. D. Replace control. Refer to the
installer/dealer.
4. User keypad indicator bar
keeps scanning at
power-up.
A. Control program is locked. A. Reset GFCI or RCD.
B. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
B. Check wiring for proper
connections. Replace wiring
harness if necessary. Refer to the
installer/dealer.
C. User keypad does not work. C. Replace user keypad. Refer to the
installer/dealer.
D. Control does not work. D. Replace control. Refer to the
installer/dealer.
5. User keypad is
illuminated, but pump
will not start.
A. Power cord from pump to
control is loose, disconnected, or
damaged.
A. Check wiring for proper
connections. If problem persists,
Refer to the installer/dealer.
B. Pump does not work. B. Replace pump. Refer to the
installer/dealer.
C. Control does not work. C. Replace control. Refer to the
installer/dealer.
6. Motor runs but pump will
not prime (cavitates). A. Motor/Pump is shimmed too high. A. Lower pump/control to subfloor level.
B. Small air leak at pump inlet. B. Securely tighten nut(s) on intake
side of pump.
C. Motor/pump does not work. C. Replace motor/pump. Refer to the
installer/dealer.
D. Control does not work. D. Replace control. Refer to the
installer/dealer.
Kohler Co. 9 1042760-5-D

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
7. Pump stops before 18
minutes. A. GFCI or RCD tripped. A. Identify source of fault, and correct. Reset GFCI or RCD.
B. Suction is blocked. B. Remove obstruction.
C. Jets are blocked. C. Remove blockage.
D. Motor overheated and
protection device activated. D. Check for blockage at suction and/or jets. Remove blockage and
allow motor to cool.
8. Pump does not
automatically stop after 22
minutes.
A. 20-minute timer inadvertently
disabled. A. See Service Manual.
9. Pump will not turn off
when the power button
on user keypad is
pressed.
A. User keypad does not work. A. Replace user keypad. Refer to the
installer/dealer.
B. Control does not work. B. Replace control. Refer to the
installer/dealer.
10. Pump operates but
variable speed feature
does not work.
A. Motor/pump does not work. A. Replace motor/pump. Refer to the
installer/dealer.
B. Control does not work. B. Replace control. Refer to the
installer/dealer.
11. Bath water cools while
pump is operating. A. Water temperature above 104°F (40°C). A. Allow bath water to cool.
B. Heater is turned off on user
keypad. B. Turn heater on.
C. Wiring from heater to control is
loose, disconnected, or
damaged.
C. Check wiring for proper
connections. Refer to the
installer/dealer.
D. Heater does not work. D. Replace heater. Refer to the
installer/dealer.
E. Control does not work. E. Replace control. Refer to the
installer/dealer.
12. Noisy operation. A. Pump banding straps have not
been cut. A. Cut pump banding straps with tin snips.
B. Dry or dislodged jet O-ring
(squeal). B. Remove jet, replace and lubricate O-ring, and reinstall jet.
13. Remote control does not
work or operates both
pumps.
A. Batteries improperly installed or
dead. A. Replace batteries.
B. Antenna on wiring harness is
damaged. B. Replace wiring harness. Refer to the installer/dealer.
C. Remote control not
programmed correctly. C. See Homeowners Guide or Service Manual.
D. Remote control does not work. D. Replace remote control.
E. Control does not work. E. Replace control. Refer to the
installer/dealer.
14. Lights near whirlpool
floor do not work. A. Wiring damage. A. Check for loose or damaged wires. Repair or replace as needed.
Chromatherapy Lights
Symptoms Probable Causes Recommended Action
1. Chromatherapy lights do
not work. A. Loose, disconnected, or damaged wiring/connections. A. Check wiring for proper connections. Replace wiring if
necessary. Refer to the
installer/dealer.
B. Control does not work. B. Replace control. Refer to the
installer/dealer.
Backjet System
1042760-5-D 10 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
1. Backjets do not operate. A. Whirlpool pump is not
operating. A. Turn on pump.
B. Backjet butterfly valve does not
open. B. Check for loose connections or wires leading from the backjet
pulse canister to the control.
Replace the backjet pulse canister
or control if necessary. Refer to the
installer/dealer.
C. Not enough water in whirlpool. C. Fill whirlpool so water level
sensors.
D. Actuator switch does not work. D. Replace the actuator switch. Refer
to the installer/dealer.
E. Power from the pump motor to
the control is off. E. Check for loose connections or wires leading from the pump
motor to the control. Refer to the
installer/dealer.
F. Backjet pipe is blocked. F. Remove blockage.
G. Switch wire from switch to
control is disconnected. G. Reconnect or replace switch wires that use a modular plug. Refer to
the installer/dealer.
2. Backjets do not pulse. A. Pulse canister does not work. A. Check for loose connections or
wires leading from the pulse
canister control. Replace the pulse
canister or control if necessary.
Refer to the installer/dealer.
B. Switch does not work. B. Replace the switch. Refer to the
installer/dealer.
C. Switch wire from the switch to
the control is disconnected. C. Reconnect or replace the switch wires that the modular plug. Refer
to the installer/dealer.
Effervescence Ports
Symptoms Probable Causes Recommended Action
1. Effervescence ports do not
work. A. Whirlpool pump is not operating. A. Turn on pump.
B. Butterfly valve does not open. B. Replace the butterfly valve. Refer
to the installer/dealer.
C. Pump does not work. C. Refer to the Service Manual to
troubleshoot the system. Refer to
the installer/dealer.
D. Control does not work. D. Replace the control. Refer to the
installer/dealer.
2. Effervescence ports do not
bubble. A. Air intake on the suction line is blocked. A. Remove blockage.
B. Water flow is too low. B. Increase the water flow.
Kohler Co. 11 1042760-5-D

Service Parts
**Finish/color code must be specified when ordering.
A
B
1042760-5-D 12 Kohler Co.

**Finish/color code must be specified when ordering.
1-1/2" Tubing
1-1/2" Tubing
1-1/2" Tubing
1/2" Tubing
1/2" Tubing
1-1/2" Tubing
3/4" Tubing
1/2" Tubing
1/2" Tubing
In-line Heater
1-1/4" Tubing
1-1/4" Tubing
*Note: All tubing 1" unless otherwise noted.
95462**
Pillow
A
1015019
Plug/Wire Assembly
1048232
Plug/Wire Assembly
1023292
Cap
1048233
1049953
Lens
1049954
Nut
LED Lighting
Harness
94528
Check Valve
Kohler Co. 13 1042760-5-D

**Finish/color code must be specified when ordering.
*Note: All tubing 1" unless otherwise noted.
1-1/2" Tubing 3/4" Tubing
1-1/2" Tubing
1-1/4" Tubing
1-1/4" Tubing
1-1/4" Tubing
1-1/4" Tubing
In-line Heater
1-1/2" Tubing
1/2" Tubing
1/2" Tubing
1/2" Tubing
1/2" Tubing
B
1015019
Plug/Wire Assembly
94528
Check Valve
1015012
Plug/Wire Assembly
1023292
Cap
1042760-5-D 14 Kohler Co.

34353
O-Ring
67429
Flange
Gasket
67889
91967
Jet
30739
1045715-P
67665
Plug
93685
Housing
96708
Flange
Cover
Gasket
65054**
Screw
65226**
73518
Plug
1086350
1003065
Suction Flange
Removal Tool
Suction Cover Plug
96895**
65061**
65886
60050
93836 (1/2")
93837 (3/4")
93838 (1")
93839 (1-1/4")
94853 (1-1/2")
Tube (w/Couplings)
Flange Removal Wrench
Check Valve
Jet Housing
65885 (Acrylic and FRP)
67668 (Cast Iron)
Single Jet For Whirlpools
With 5 or Less Jets
Single Jet For Whirlpools
With 6 or More Jets
88532**
88531**
Jet
88530**
88529**
Silicone Lube
Packet
Jet Tool
(Colored Finishes)
(Metal Finishes)
(Colored Finishes)
(Metal Finishes)
(Colored Finishes)
(Metal Finishes)
(Acrylic and FRP)
(Cast Iron)
**Finish/color code must be specified when ordering.
Kohler Co. 15 1042760-5-D

1016957
Pump 1016958
Motor
1010548
Volute
1010673
Seal
1010677
Screw
1010675
O-Ring
1016960
Impeller
1010676
Cover
Control
94821
O-Ring
61845-K
1019719
Connector
1012855
Nut
60320
Screw
67065 1018964
Bracket
1019432
90153
Locknut
90154
Locknut
1019445-A [1-3/4" (4.4 cm)]
1019445-B [2-3/4" (7 cm)]
1019445-C [3" (7.6 cm)]
1019445-D [2-1/2" (6.4 cm)]
1019445-E [2" (5.1 cm)]
1019445-F [2-1/4" (5.7 cm)]
1019445-G [3-1/4" (8.3 cm)]
1019445-H [3-1/2" (8.9 cm)]
1019445-J [3-3/4" (9.5 cm)]
1019445-K [4" (10.2 cm)]
1019445-L [1-1/2" (3.8 cm)]
1019445-M [1-1/4" (3.2 cm)]
Stud
1019444-A [3/4" (1.9 cm)]
1019444-B [1-3/4" (4.4 cm)]
1019444-C [2" (5.1 cm)]
1019444-D [1-1/2" (3.8 cm)]
1019444-E [1" (2.5 cm)]
1019444-F [1-1/4" (3.2 cm)]
1019444-G [2-1/4" (5.7 cm)]
1019444-H [2-1/2" (6.4 cm)]
1019444-J [2-3/4" (7 cm)]
1019444-K [3" (7.6 cm)]
1019444-L [1/2" (1.3 cm)]
1019444-M [1/4" (6 mm)]
Spacer
1019447-A [1/4" (6 mm)]
1019447-B [1/2" (1.3 cm)]
1019447-C [3/4" (1.9 cm)]
Isolation Mount
Outlet
To Tee Heater
To In-line Heater
93893
Cover
60320
Screw
93892-A
Electrical Box 67065
Ground Lug
61776
Lock Washer
1033678
Screw
93003
Strain Relief
94821
O-Ring
61776
Lock Washer
1080775
Pump Tee 94821
O-Ring
1080774
Union Assy
Ground Lug
Copper Grounding Wire
Carriage Bolt
1018661
1018663
**Finish/color code must be specified when ordering.
(One Outlet)
(Two Outlets)
1042760-5-D 16 Kohler Co.

1018710
Tee Heater
94821
O-Ring
94821
O-Ring
1012977
Adapter
1012916
Nut with Screws
1011679
Gasket
1012977
Adapter
1011679
Gasket
**Finish/color code must be specified when ordering.
94821
O-Ring
1012653
Adapter
1012653
Adapter
1012916
Nut w/Screws
1022408
In-line Heater
94821
O-Ring
1032545
Housing
Kohler Co. 17 1042760-5-D

**Finish/color code must be specified when ordering
93552**
Flange Cap
96744
Flange Removal Tool
1010618
Elbow
93315
Gasket
1035480**
Flange
1001878
Effervescence Ports
Housing
1012821
Light Housing
93841
Screw
1019933
Chromatherapy Lights
1042760-5-D 18 Kohler Co.

1016466
Motor
63149
Screw
50506
Screw
96956
Butterfly Kit
1023753
1080774
Union Assy
94821
O-Ring
94821
O-Ring
**Finish/color code must be specified when ordering.
1080774
Union Assy
Butterfly Valve
Kohler Co. 19 1042760-5-D

65157
Nut
1020677
Gasket
1013499
Housing
1013453
Spring
91639
O-Ring
1013452**
Dial Trim
1013497-A
Decal 1013497-B
Decal
1013497-C
Decal 1013497-D
Decal
1013497-E
Decal
1020678-A
1023381
Wrench
1020678-B
1020678-D
1020678-C
1020678-E
**Finish/color code must be specified when ordering.
Cover/CircuitBoard
(w/Wrench)
1013497-M
Decal
1020678-M
Cover/CircuitBoard
(w/Wrench)
1013497-N
Decal
1020678-N
Cover/CircuitBoard
(w/Wrench)
1013497-P
Decal
1020678-P
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Carefully study decal and cover
detail below for proper service
part identification.
91639
O-Ring
91639
O-Ring 91639
O-Ring
91639
O-Ring
91639
O-Ring
91639
O-Ring 91639 O-Ring
91639
O-Ring
1042760-5-D 20 Kohler Co.
