Kohler K-856-M Assembly instructions

Homeowners Guide
Bath Whirlpool
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page ″Français-1″
Español, página ″Español-1″
K-856
1023274-5-B

Important Information
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRICAL SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
DANGER: Risk of personal injury. To reduce the risk of injury, do not permit children to use this
unit unless they are closely supervised at all times.
WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the
whirlpool.
WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,
telephone, radio, or television) within 5’ (1.5 m) of this whirlpool.
WARNING: Risk of hyperthermia. People using medications and/or having an adverse medical
history should consult a physician before using a whirlpool equipped with a heater.
Use this whirlpool only for its intended purpose as described in this manual. Do not use attachments not
recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not operate this unit without the guard (cover) over the suction fitting.
The whirlpool must be connected only to a supply circuit that is protected by a Ground-Fault
Circuit-Interrupter (GFCI) or Residual Current Device (RCD). Such a GFCI or RCD should be provided by
the installer and should be tested on a routine basis. To test the GFCI or RCD, press the test button. The
GFCI or RCD should interrupt power. Press the reset button. Power should be restored. If the GFCI or RCD
fails to operate in this manner, the GFCI or RCD is defective. If the GFCI or RCD interrupts power to the
bath without the test button being pressed, a ground current is flowing, indicating the possibility of an
electric shock. Do not use this whirlpool bath. Disconnect the whirlpool and have the problem corrected by a
qualified service representative before using.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs
when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia
include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c)
unawareness of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to
exit the bath, and (f) unconsciousness resulting in the danger of drowning.
IMPORTANT! Flush your whirlpool system twice a month or more depending upon usage, as described
in the ″Flushing Your Whirlpool System″section of this manual.
Do not allow the water temperature in the whirlpool to exceed 104°F (40°C).
Keep small objects such as bath toys and bathing accessories out of the whirlpool while the unit is running.
Repeated use of personal care products containing oils can damage plastic whirlpool components. Do not use
heavy, vegetable-based shampoos or bath oils.
Whirlpool hydro-massage action can cause even a small amount of bubble bath, bath soap, shampoo, or bath
oil to foam excessively. For this reason, please don’t use these products during whirlpool operation.
1023274-5-B 2 Kohler Co.

Table of Contents
Important Information .............................................................. 2
Thank You For Choosing Kohler Company .............................................. 3
Your Kohler Whirlpool ............................................................. 3
User Keypad and Whirlpool Modes/Features ............................................. 4
Operating Your Whirlpool ........................................................... 5
Neckjet and Backjet Operation (if equipped) ............................................. 5
Effervescence Operation (if equipped) ................................................. 6
Chromatherapy Operation (if equipped) ................................................ 6
Remote Control .................................................................. 7
Programming Your Remote Control .................................................... 7
FCC Compliance ................................................................. 8
Care and Cleaning ................................................................ 8
Flushing Your Whirlpool System ...................................................... 8
One-Year Limited Warranty ......................................................... 8
Lifetime Limited Warranty ........................................................... 9
One-Year Warranty ............................................................... 9
Troubleshooting Procedures ........................................................ 11
Service Parts ................................................................... 15
Thank You For Choosing Kohler Company
Thank you for choosing Kohler Company. Your Kohler Company product reflects the true passion for design,
craftsmanship, artistry, and innovation Kohler Company stands for. We are confident its dependability and
beauty will surpass your highest expectations, satisfying you for years to come.
All information in this guide is based upon the latest product information available at the time of
publication. At Kohler Company, we strive to fulfill our mission of improving the level of gracious living for
each person who is touched by our products and services. We reserve the right to make changes in product
characteristics, packaging, or availability at any time without notice.
Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.
Your Kohler Whirlpool
Your new whirlpool is designed to stimulate, invigorate, and energize your body with comforting
hydro-massage therapy. The whirlpool consists of the following components:
Bath - Acts as a reservoir for water, and provides a location for the hydro-massage action.
User Keypad - Located within easy reach, the keypad allows you to turn the whirlpool on and off.
It also allows you to access all the whirlpool modes and regulate the water flow or pulse speed.
Pump Motor - Provides quiet, variable speed power to circulate the water and create the soothing
hydro-massage action.
Adjustable Jets - Positioned to optimize their hydro-massage effect, the jets allow you to adjust the
air and water flow and control the flow direction as you desire.
Heater - Designed to automatically help maintain the temperature of the water up to 104°F (40°C) to
enhance your hydro-massage experience. The heater turns on automatically when the whirlpool is
operating, and turns off when the pump motor is turned off. The heater may be turned off, through
the keypad, at any time while the pump is operating.
Neckjets and Pillow - Delivers massaging water to the back of your neck. The pillow provides a
comfortable place to rest your head as you relax. To prevent water spills, a built-in switch stops the
neckjet action if the pillow is removed during operation. Neckjet operation is controlled through the
user keypad.
Backjets - Delivers massaging water to your back. The backjets pulse from the bottom of the
whirlpool toward the top, with water flow and pulse action occurring from two backjets at a time.
Kohler Co. 3 1023274-5-B

User Keypad and Whirlpool Modes/Features
Power - Turns the whirlpool pump on and off. Symbols illuminated in blue indicate available
modes/features. Modes which are operating will be illuminated in green.
Outer Ring - Rotate the outer ring to the desired mode. The selected mode will flash (blue).
Activate Button - Press ″OK″to activate the desired mode.
Up Arrow - Increases the water flow when the Flexjet mode is active. Increases the pulse speed
when the neckjet or backjet mode is active.
Down Arrow - Decreases the water flow when the Flexjet mode is active. Decreases the pulse speed
when the neckjet or backjet mode is active.
Flexjet Mode - When illuminated, this mode allows you to adjust the water flow by pressing the up
or down arrows.
Neckjet Mode - When illuminated, the neckjets are operating and you may adjust the pulsing speed
by pressing the up or down arrows.
Backjet Mode - When illuminated, the backjets are operating and you may adjust the pulsing speed
by pressing the up or down arrows.
Heater - The heater automatically engages when the whirlpool is turned on. To turn the heater off,
rotate the outer ring until the heater mode is flashing and press ″OK.″Press ″OK″again to turn the
heater back on. The heater will help to maintain the water temperature up to 104°F (40°C).
Indicator Bar - Shows the water flow volume in the Flexjet mode. Shows the pulse speed in the
neckjet or backjet mode.
Effervescence Mode - Effervescence ports activate to provide a gentle, soothing bubbling action. The
Flexjet mode, backjets and neckjets will automatically turn off when the effervescence mode is
activated.
Chromatherapy Cycle - Chromatherapy lights will automatically and continuously cycle through
the eight colors: white, violet, indigo blue, aqua blue, green, yellow, orange, and red. One cycle
through all eight colors takes approximately one minute.
Chromatherapy Specific Color Selection - When this mode is selected, you may choose a specific
color for the bath.
Flexjet Flow Mode
Activates Mode Selected
Backjet Mode -
Adjust Pulse
Rotate outer
ring to access
desired mode
Power On/Off
Chromatherapy -
Specific Color Heater
Chromatherapy Cycle
Decreases Flow
Effervescence Mode
Indicator Bar - Shows
water flow volume or
pulse speed
Increases Flow or Pulse
Neckjet Mode - Adjust Pulse
Lighted User Keypad
NOTE: Keypad shows all
features available.Your
keypad may vary based
on your whirlpool model.
1023274-5-B 4 Kohler Co.

Operating Your Whirlpool
Turn the jet trim fully counterclockwise. Position the jet nozzles so they face down toward the basin.
NOTE: The water temperature in the whirlpool should never exceed 104°F (40°C). A built-in heater
automatically maintains the water temperature when the whirlpool is running, as long as the water
temperature does not exceed 104°F (40°C). The heater will disengage at higher temperatures.
Close the drain, and fill the whirlpool to a level at least 2″(5.1 cm) above the top of the highest jet.
Use your hand to test the water temperature for comfort and safety, then carefully enter the bath.
Press Power to turn on the whirlpool. The whirlpool will start at medium volume. The heater will
also turn on and the heater icon will illuminate.
Increase or decrease the water flow by pressing the up or down arrows on the keypad. An indicator
bar in the center of the keypad shows the water flow volume.
Adjust the jets for optimum air/water mixture. Turn the jet trim clockwise to reduce the flow, and
counterclockwise to increase the flow. Position the jet nozzles to direct the water flow as desired to
maximize your hydro-massage experience.
The heater turns on automatically when the whirlpool is operating, and turns off when the pump
motor is turned off. The heater may be turned off, through the keypad, at anytime while the pump
is operating.
Press Power a second time to turn off the whirlpool.
NOTE: Your whirlpool will automatically stop after approximately 20 minutes of continuous operation.
You can restart the whirlpool, if you desire, by pressing Power.
Carefully exit the bath, and open the drain to empty the whirlpool.
NOTE: Consult the ″Troubleshooting″section of this manual before calling a qualified service
representative.
Neckjet and Backjet Operation (if equipped)
Make sure the slip cover is in place on the pillow, and the pillow is attached to the neckjet body.
NOTE: If the pillow is not properly installed the neckjets will stop. The neckjet icon and indicator bar on
the user keypad will flash. The neckjets will automatically restart when the pillow is properly installed.
With the whirlpool operating, rotate the outer ring until the neckjet icon is flashing. Press ″OK″to
activate the neckjets. The neckjet pulsing action will start at medium speed.
To increase or decrease the neckjet pulsing action, press either the up or down arrow buttons on the
keypad, while the neckjet mode is active.
Fill with water at least 2" (5.1 cm)
above the highest jet.
Turn the jet trim ring
clockwise to
decrease the flow. Position the jet
nozzles to direct
the water flow as
desired.
Turn the jet trim ring counterclockwise
to increase the flow.
Kohler Co. 5 1023274-5-B

Neckjet and Backjet Operation (if equipped) (cont.)
To increase or decrease the flow volume to the neckjets, rotate the outer ring to the Flexjet mode,
press ″OK″to activate the mode, and press either the up or down arrows on the keypad. This also
increases or decreases the flow to all modes.
Rotate the outer ring until the backjet icon is flashing and press ″OK.″The backjet pulsing action
will start at medium speed. The backjets pulse from the bottom of the whirlpool toward the top,
with water flow and pulse action occuring from two backjets at a time.
NOTE: If the water level falls below the water level sensors, the backjets will stop. The backjet icon and
indicator bar on the user keypad will flash. The backjets will automatically restart when the water level
covers the sensors.
To increase or decrease the backjet pulsing action, press either the up or down arrow buttons on the
keypad, while the backjet mode is active.
To increase or decrease the flow volume to the backjets, rotate the outer ring to the Flexjet mode,
press ″OK″to activate the mode, and press either the up or down arrows on the keypad. This also
increases or decreases the flow to all modes.
NOTE: To activate or deactivate functions while the neckjets and/or backjets are operating, rotate the
outer ring until the desired function is flashing and press ″OK.″(Example: To turn the heater off, rotate the
outer ring until the heater icon is flashing and press ″OK.″)
Press ″OK″while the neckjet mode is active, to turn off the neckjets.
Press ″OK″while the backjet mode is active, to turn off the backjets.
Effervescence Operation (if equipped)
With the whirlpool operating, rotate the outer ring until the effervescence icon is flashing. Press
″OK″to activate the effervescence ports. The effervescence action will start at the flow volume last
set in the Flexjet flow mode.
Increase or decrease the flow volume by pressing either the up or down arrow buttons on the
keypad.
NOTE: The effervescence mode is intended to be a relaxing, soothing experience. The Flexjet mode,
backjets and neckjets will automatically turn off when the effervescence mode is activated. Chromatherapy
may be used with this and all modes of operation.
Press ″OK″while the effervescence mode is flashing, to turn off the effervescence ports.
Chromatherapy Operation (if equipped)
NOTE: Chromatherapy may be used with all modes of operation. Chromatherapy may also be used when
the pump is not operating.
Chromatherapy Cycle - When this mode is activated, the chromatherapy lights will automatically
and continuously cycle through the eight colors; white, violet, indigo blue, aqua blue, green, yellow,
orange and red. One cycle through all eight colors takes approximately one minute. Rotate the outer
ring to select this mode and press ″OK″to activate it. Press ″OK″while the chromatherapy mode is
active, to turn off the lights.
Chromatherapy Specific Color Selection - When this mode is activated, you may choose a specific
color for the bath. Rotate the outer ring to select this mode, press ″OK″to activate and use the
up/down arrows to reach the desired color. Press ″OK″while the chromatherapy mode is active, to
turn off the lights.
1023274-5-B 6 Kohler Co.

Remote Control
The remote control places the whirlpool functions at your fingertips to further enhance your bathing
experience.
The functions of the remote are identical to the user keypad. You may turn the whirlpool on and off, turn the
heater on and off, and access/modify all whirlpool functions.
The mode selector button functions in the same way as the outer ring. When ″M″is pressed, one of the
modes will flash on the user keypad. If ″M″is pressed again, the next mode in clockwise order will flash.
When the desired mode is flashing, press ″OK″to activate it.
When the Flexjets mode is active, the arrows will increase or decrease the water flow volume.
The waterproof remote control is designed to be used in the bath and will float in the water.
Two AAA batteries are used in the remote control. To replace, simply unscrew the end cap and insert the
batteries, as shown above. Tighten the end cap securely, making sure the end cap makes contact with the
seal.
Programming Your Remote Control
IMPORTANT! Programming the remote control is required. Your whirlpool will not respond to any
remote control until you program the remote. If you replace the remote control or replace the pump
control, it will be necessary to program the remote control.
Turn the whirlpool power on.
Turn off all modes of operation. Wait approximately one minute until the keypad darkens
completely (Sleep mode).
On the user keypad, press the UP arrow, DOWN arrow, and the ″OK″buttons simultaneously. The
bottom LED on the keypad’s indicator bar will begin flashing.
While the LED is flashing, press the ″OK″button on the keypad. A light sequence will illuminate up
and down the indicator bar.
While the indicator bar light sequence is active, press any button on the remote control. The keypad
will stop the light sequence, perform a download, and then darken. This user keypad will only
respond to this remote.
NOTE: If you do not press any of the buttons on the remote within two minutes the whirlpool will not
respond to the remote control.
Activates Mode
Selected
Power
Increases Flow
or Pulse
Mode Selector Decreases Flow
or Pulse
Kohler Co. 7 1023274-5-B

FCC Compliance
FCC ID : N82-KOHLER001
Canada ID : 4554A-KOHLER001
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party responsible for compliance could void the
users’ authority to operate the equipment.
Care and Cleaning
For best results, keep the following in mind when caring for your KOHLER product:
•Use a mild detergent such as liquid dishwashing soap and warm water for cleaning. Do not use
abrasive cleaners that may scratch or dull the surface.
•Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Do not allow cleaners to sit or soak on the surface.
•Wipe surfaces clean and rinse completely with water immediately after cleaner application. Rinse
and dry any overspray that lands on nearby surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537 and press 1 for Kohler Products and then 3 for Literature.
Flushing Your Whirlpool System
Flush your whirlpool system twice a month or more, depending upon usage. Use the following
sequence:
•Turn the jet trim rings fully clockwise to remove air induction.
•Fill the whirlpool with warm water to a level at least 2″(5.1 cm) above the highest jets, or leave
water in the whirlpool after using.
•Add 2 tablespoons (30 ml) of a low-foaming dishwasher detergent and 20 ounces (590 ml) of
household bleach (5% - 6% sodium hypochlorite) to the water.
•Run the whirlpool for 5 to 10 minutes. Turn off the whirlpool and drain.
•If desired, rinse the bath surfaces with water.
•Rinse the surfaces of the jets, faucet, handrails, drain, etc. and wipe them dry with a soft cloth.
One-Year Limited Warranty
KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year
from date of installation.
Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection
discloses any such defects occurring in normal usage within one (1) year after installation. Kohler Co. is not
responsible for removal or installation costs. Use of in-tank toilet cleaners will void the warranty.
To obtain warranty service contact Kohler Co. either through your Dealer, Plumbing Contractor, Home
Center or E-tailer, or by writing Kohler Co., Attn.: Customer Service Department, 444 Highland Drive,
1023274-5-B 8 Kohler Co.

One-Year Limited Warranty (cont.)
Kohler, WI 53044, USA, or by calling 1-800-4-KOHLER from within the USA, 1-800-964-5590 from within
Canada and 001-877-680-1310 from within Mexico.
Implied warranties including that of merchantability and fitness for a particular purpose are expressly
limited in duration to the duration of this warranty. Kohler Co. and/or seller disclaims any liability for
special, incidental or consequential damages.
Some states/provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of special, incidental or consequential damages so these limitations and exclusions may not apply
to you. This warranty gives you specific legal rights. You may also have other rights which vary from
state/province to state/province.
This is Kohler Co.’s exclusive written warranty.
Lifetime Limited Warranty
Kohler Co. warrants the cast iron components of products manufactured after February 10, 2000, to be free of
defects in material and workmanship during normal residential use for as long as the original consumer
purchaser owns his or her home. Gloss reduction, scratching, staining and alkaline etching of the finish over
time due to use, cleaning practices or water or atmospheric conditions, are not manufacturing defects but are
indicative of normal wear and tear. This warranty applies only for KOHLER Cast Iron products installed in
the United States of America, Canada or Mexico (North America).
If a defect is found in normal residential use, Kohler Co. will, at its election, repair, replace or make
appropriate adjustment. Damage caused by accident, misuse, or abuse is not covered by this warranty.
Improper care and cleaning will void the warranty. Proof of purchase (original sales receipt) must be
provided to Kohler Co. with all warranty claims. Kohler Co. is not responsible for labor charges, installation,
or other incidental or consequential costs. In no event shall the liability of Kohler Co. exceed the purchase
price of the product.
If the cast iron product is used commercially or is installed outside of North America, Kohler Co. warrants
the cast iron product to be free from defects in material and workmanship for one (1) year from the date the
product is installed, with all other terms of this warranty applying except duration. All other components
other than the enameled cast iron carry Kohler Co.’s one-year limited warranty unless otherwise specified.
If you believe that you have a warranty claim, contact Kohler Co., either through your Dealer, Plumbing
Contractor, Home Center or E-tailer, or by writing: Kohler Co., Attn.: Customer Service Department, 444
Highland Drive, Kohler, WI 53044, USA. Please be sure to provide all pertinent information regarding your
claim, including a complete description of the problem, the product, model number, color, finish, the date the
product was purchased and from whom the product was purchased. Also include your original invoice. For
other information, or to obtain the name and address of the service and repair facility nearest you call
1-800-4-KOHLER from within the USA, 1-800-964-5590 from within Canada, and 001-877-680-1310 from
within Mexico.
Kohler Co. and/or seller are providing this warranty in lieu of all other warranties, expressed or implied,
including but not limited to the implied warranties of merchantability and fitness for a particular
purpose. Kohler Co. and/or seller disclaims any liability for special, incidental or consequential damages.
Some states/provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or
limitation of special, incidental or consequential damages, so these limitations and exclusions may not apply
to you. This warranty gives the consumer specific legal rights. You may also have other rights, which vary,
from state/province to state/province. This warranty is to the original consumer purchaser only, and
excludes product damage due to installation error, product abuse, or product misuse, whether performed by
a contractor, service company or the consumer.
This is Kohler Co.’s exclusive written warranty.
One-Year Warranty
KOHLER CO.
It is recommended that at the time of purchase, you verify that all accessories and components are complete
in this package.
Kohler Co. 9 1023274-5-B

One-Year Warranty (cont.)
This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the
date of purchase as shown on the invoice or receipt.
1. Kohler Co. will only service its commercialized products through its authorized distributors.
2. To obtain warranty service, please present the invoice and corresponding warranty.
3. Through its authorized distributors, Kohler Co. promises to repair the defective product or provide a new
replacement or an equivalent model (in those cases that the model has been discontinued) when the product
is beyond repair, without any charge to the consumer.
4. The time of repair will not exceed six (6) weeks commencing on the date the product is received.
5. It is recommended that the consumer save the invoice or receipt as additional protection, as it may
substitute the warranty in the case that there is a discrepancy in the validity of the warranty.
EXCEPTIONS AND RESTRICTIONS
The Warranty will not be valid in the following cases:
1. When the product is not operated in accordance with the instructions concerning use and operation set
forth in the owner’s manual or installation instructions, and when the recommendations and warnings
included are not observed.
2. When the product has been modified or dismantled partially or totally; or has been used in a negligent
fashion and as a consequence has suffered damages attributable to the consumer, individual, or hardware not
authorized by Kohler Co.
3. This warranty does not cover the damages as a result of disaster such as fire or acts of God, including
flooding, earthquake, or electric storms, etc. To obtain a list of distributors in your area where you can
exercise your rights under this warranty, please call 001-877-680-1310.
KOHLER CO., KOHLER, WI 53044 U.S.A.
IMPORTER:
INTERNACIONAL DE CERÁMICA, S.A.B. DE C.V.
AV. CARLOS PACHECO NO. 7200
CHIHUAHUA, CHIH., MEXICO C.P. 31060
TEL: [phone]
1023274-5-B 10 Kohler Co.

Troubleshooting Procedures
Remove the Jets
NOTE: A special tool is provided with the jets that will allow you to remove them from the whirlpool.
This tool is also supplied with each trim kit.
Position the jet ball nozzle so it is pointing upward.
NOTE: The nozzle must remain pointed up or the tool will slip off.
Insert the removal tool, hooked end up, into the opening of the jet and hook the inside top of the
nozzle.
Grasp the tool firmly and place your thumb against the whirlpool wall. Pull steadily on the tool
until the jet assembly pulls free of the hole. Be careful not to lose the O-ring.
Reinstall the Jets
NOTE: The jet O-ring must be correctly positioned, must be lubricated, and must be in good condition to
permit easy rotation and proper operation of the jet.
Install the O-ring onto the first shoulder of the jet. Lubricate the O-ring with silicone lubricant to
prevent noisy operation of the jet.
Carefully insert the jet into the housing, and lightly push and rotate the jet until it snaps into
position. Do not force the jet.
NOTE: When installed correctly, the jet should turn smoothly both clockwise and counterclockwise.
Troubleshooting Guide
This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualified
electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale
distributor.
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
1. User keypad does not
illuminate when power
button is pressed or outer
ring is rotated.
A. No power to control. A. Check wiring and connect power. If
problem persists, refer to
installer/dealer.
Remove the Jets
Insert the tool hook as shown and pull the jet out of the
housing. The jet should be facing up when this is done.
Housing
Reinstall the Jets
Insert the jet into the housing, and lightly
push and rotate until it snaps in position.
Slide the O-ring
onto the first
shoulder of the jet.
Inspect and
lubricate the O-ring.
Kohler Co. 11 1023274-5-B

Troubleshooting Procedures (cont.)
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
B. GFCI or RCD circuit
breaker is tripped. B. Reset GFCI or RCD.
C. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
C. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
D. Keypad is not working. D. Replace user keypad. Refer to
installer/dealer.
E. Control is not working. E. Replace control. Refer to
installer/dealer.
2. Motor starts, but all jets are
not functioning. A. Jet is closed. A. Rotate jet trim ring counterclockwise to open.
B. Jet not installed correctly. B. Reinstall jet; check for O-ring damage.
C. Jets are blocked. C. Remove obstruction.
3. User keypad is illuminated
but does not respond to
buttons or ring.
A. Control program is locked. A. Reset GFCI or RCD.
B. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
B. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
C. Keypad is not working. C. Replace user keypad. Refer to
installer/dealer.
D. Control is not working. D. Replace control. Refer to
installer/dealer.
4. User keypad indicator bar
keeps scanning at
power-up.
A. Control program is locked. A. Reset GFCI or RCD.
B. Wiring harness from user
keypad to control is loose,
disconnected, or damaged.
B. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
C. Keypad is not working. C. Replace user keypad. Refer to
installer/dealer.
D. Control is not working. D. Replace control. Refer to
installer/dealer.
5. User keypad is illuminated,
but pump will not start. A. Power cord from pump to control is loose,
disconnected, or damaged.
A. Check wiring for proper connections.
If problem persists, refer to
installer/dealer.
B. Pump is not working. B. Replace pump. Refer to
installer/dealer.
C. Control is not working. C. Replace control. Refer to
installer/dealer.
6. Motor runs but pump will
not prime (cavitates). A. Pump is shimmed too high. A. Lower pump/control to subfloor level.
B. Small air leak at pump
inlet. B. Securely tighten nut(s) on intake side of pump.
C. Motor/pump is not
working. C. Replace motor/pump. Refer to installer/dealer.
D. Controller is not working. D. Replace control. Refer to
installer/dealer.
7. Pump stops before 18
minutes. A. GFCI or RCD tripped. A. Identify source of fault, and correct. Reset GFCI or RCD.
B. Suction is blocked. B. Remove obstruction.
C. Jets are blocked. C. Remove obstruction.
D. Motor overheated and
protection device activated. D. Check for blockage at suction and/or jets. Remove obstruction and allow
motor to cool.
8. Pump does not
automatically stop after 22
minutes.
A. 20-minute timer
inadvertently disabled. A. See Service Manual.
1023274-5-B 12 Kohler Co.

Troubleshooting Procedures (cont.)
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
9. Pump will not turn off
when the power button on
user keypad is pressed.
A. Keypad is not working. A. Replace user keypad. Refer to
installer/dealer.
B. Control is not working. B. Replace control. Refer to
installer/dealer.
10. Pump operates but variable
speed feature does not
work.
A. Motor/pump is not
working. A. Replace motor/pump. Refer to installer/dealer.
B. Control is not working. B. Replace control. Refer to
installer/dealer.
11. Bath water cools while
pump is operating. A. Water temperature is above 104°F (40°C). A. Allow bath water to cool.
B. Heater is turned off on
user keypad. B. Turn heater on.
C. Wiring from heater to
control is loose,
disconnected, or damaged.
C. Check wiring for proper connections.
Refer to installer/dealer.
D. Heater is not working. D. Replace heater. Refer to
installer/dealer.
E. Control is not working. E. Replace control. Refer to
installer/dealer.
12. Noisy operation. A. Pump banding straps have
not been cut. A. Cut pump banding straps with tin snips.
B. Dry or dislodged jet O-ring
(squeal). B. Remove jet, replace and lubricate O-ring, and reinstall jet.
13. Remote control (if
equipped) does not work. A. Batteries improperly installed or dead. A. Replace batteries.
B. Antenna on wiring harness
is damaged. B. Replace wiring harness. Refer to installer/dealer.
C. Remote control not
programmed correctly. C. See remote control Homeowners Guide or Service Manual.
D. Remote control is not
working. D. Replace remote control.
E. Control is not working. E. Replace control. Refer to
installer/dealer.
14. Keypad does not respond
when neckjet mode is
selected.
A. Keypad is not working. A. Replace user keypad. Refer to
installer/dealer.
15. Pump operates but neckjets
do not turn on. Indicator
bar on user keypad is
flashing.
A. Pillow is not installed. A. Make sure the pillow is properly
attached to the neckjet body.
B. Reed switch does not
work. B. Check reed switch wiring and replace if necessary.
C. Wiring harness from
neckjet to control is loose,
disconnected or damaged.
C. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
16. Pump operates but neckjets
do not turn on. Indicator
bar on user keypad is NOT
flashing.
A. Neckjet line is blocked. A. Disconnect neckjet hoses and remove
obstruction.
B. Wiring harness from
neckjet to control is loose,
disconnected or damaged.
B. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
C. Butterfly valve is not
working. C. Replace butterfly valve. Refer to installer/dealer.
D. Control is not working. D. Replace control. Refer to
installer/dealer.
Kohler Co. 13 1023274-5-B

Troubleshooting Procedures (cont.)
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
17. Water flows from neckjets,
but neckjets do not pulse. A. Wiring harness from neckjet pulse canister to
control is loose,
disconnected or damaged.
A. Check wiring for proper connections.
Replace wiring harness if necessary.
Refer to installer/dealer.
B. Pulse canister does not
work. B. Replace pulse canister. Refer to installer/dealer.
C. Control is not working. C. Replace control. Refer to
installer/dealer.
18. Backjets do not operate. A. Whirlpool pump is not
operating. A. Turn on pump.
B. Backjet butterfly valve does
not open. B. Check for loose connections or wires leading from backjet pulse canister to
control. Replace backjet pulse canister
or control if necessary. Refer to
installer/dealer.
C. Not enough water in
whirlpool. C. Fill whirlpool so water level sensors are covered.
D. Actuator switch does not
work. D. Replace actuator switch. Refer to installer/dealer.
E. Power from pump motor
to control is off. E. Check for loose connections or wires leading from pump motor to control.
Refer to installer/dealer.
F. Backjet pipe is blocked. F. Remove obstruction.
G. Switch wire from switch to
control is disconnected. G. Reconnect or replace switch wires that use modular plug. Refer to
installer/dealer.
19. Backjets do not pulse. A. Pulse canister does not
work. A. Check for loose connections or wires leading from pulse canister to control.
Replace pulse canister or control if
necessary. Refer to installer/dealer.
B. Switch does not work. B. Replace switch. Refer to
installer/dealer.
C. Switch wire from switch to
control is disconnected. C. Reconnect or replace switch wires that use modular plug. Refer to
installer/dealer.
20. Effervescence ports do not
work. A. Whirlpool pump is not working. A. Turn on pump.
B. Butterfly valve is not
working. B. Replace butterfly valve. Refer to installer/dealer.
C. Pump does not work. C. Refer to the Service Manual to
troubleshoot the system. Refer to
installer/dealer.
D. Control does not work. D. Replace control. Refer to
installer/dealer.
21. Effervescence ports do not
bubble. A. Air intake on suction line is blocked. A. Remove blockage.
B. Water flow is too low. B. Increase water flow.
22. Chromatherapy lights do
not work. A. Loose, disconnected or damaged
wiring/connections.
A. Check wiring for proper connections.
Replace wiring if necessary. Refer to
installer/dealer.
B. Control does not work. B. Replace control. Refer to
installer/dealer.
1023274-5-B 14 Kohler Co.

Service Parts
C
C
Acrylic Shell Neck
Valve Hardware
Cast Iron Shell Neck
Valve Hardware
**Finish/color code must be specified when ordering
Nut
93823
Sensor
1019439
Screw
93931
Cover
93511**
94726-A
Cover
94726-B (White) (Black)
94496
Pillow Kit
94497 (Curved) (Flat)
94377
Pillow
94495 (Curved) (Flat)
94318-A2
94318-C2
94318-B2
94318-D2
[16-1/2" (41.9 cm)]
[15-1/2" (39.4 cm)]
[13-1/2" (34.3 cm)]
[7-1/2" (19.1 cm)]
94318-E2 [5-1/2" (14 cm)]
94318-F2 [18-1/4" (46.4 cm)]
94318-G2 [10-1/2" (26.7 cm)]
Hose
93948-A1
93948-B1 [8-3/8" (21.3 cm)]
[9-7/8" (25.1 cm)]
93948-C1 [6-7/8" (17.5 cm)]
93948-D1 [6" (15.2 cm)]
93948-E1 [4-5/8" (11.7 cm)]
Hose
1016534 (Ports Facing Left)
1016536 (Ports Facing Right)
1016535 (K-1339, K-1375, K-1418, K-1457 Models)
Neck Valve Assy.
Manifold
93590-A
Washer
63270
Screw
1000054
94387-A
Plate
94387-B [6" (15.2 cm)] [4-3/8" (11.1 cm)] Nut
90153
Washer
64212
Grommet
91819
Grommet
91819
Sleeve
91820
Screw
95045
Adapter
1018965
Tee
1010029
O-Ring
94821
Screw
50506
Butterfly
96956
Motor
1016466 Screw
63149
94275-B (K-812)
94275-A
Butterfly Valve
Screw
60982
Sleeve
91820
Nut
60170
Gasket
93542
Elbow
93848
Port
Kohler Co. 15 1023274-5-B

34353
O-Ring
67429
Flange
65885 (Acrylic and FRP)
67668 (Cast Iron)
Gasket
67889
Jet Housing
91967
Check Valve
88532** (Colored Finishes)
88531** (Metal Finishes)
Jet
30739
Jet Tool
1045715-P
67665
Plug
88530** (Colored Finishes)
88529** (Metal Finishes)
Jet
93685
Housing
96708
Flange
96895** (Colored Finishes)
65061** (Metal Finishes)
Cover
65886 (Acrylic and FRP)
60050 (Cast Iron)
Gasket
65054**
Screw
65226**
Suction Cover Plug
73518
Plug
1086350
Flange Removal Wrench
1003065
**Finish/color code must be specified when ordering.
Silicone Lube
Packet Single Jet For Whirlpools
With 6 or More Jets
Single Jet For Whirlpools
With 5 or Less Jets
SuctionFlange
Removal Tool
93836(1/2")
93837(3/4")
93838 (1")
93839(1-1/4")
94853(1-1/2")
Tube (w/Couplings)
1023274-5-B 16 Kohler Co.

1016957
2 HP Pump 1016958
Motor
1010548
Volute
1010673
Seal
1010677
Screw
1010675
O-Ring
1016960
Impeller
1010676
Cover
1018661 (One Outlet)
1018663 (Two Outlets)
Control
94821
O-Ring
61845-K
Copper Grounding Wire
1019719
Connector
1005363
Nut
60320
Screw
67065
Ground Lug
1018964
Bracket
1019432
CarriageBolt
90153
Locknut
90154
Nut
**Finish/color code must be specified when ordering.
1019445-A [1-3/4" (4.4 cm)]
1019445-B [2-3/4" (7 cm)]
1019445-C [3" (7.6 cm)]
1019445-D [2-1/2" (6.4 cm)]
1019445-E [2" (5.1 cm)]
1019445-F [2-1/4" (5.7 cm)]
1019445-G [3-1/4" (8.3 cm)]
1019445-H [3-1/2" (8.9 cm)]
1019445-J [3-3/4" (9.5 cm)]
1019445-K [4" (10.2 cm)]
1019445-L [1-1/2" (3.8 cm)]
1019445-M [1-1/4" (3.2 cm)]
Stud
1019444-A [3/4" (1.9 cm)]
1019444-B [1-3/4" (4.4 cm)]
1019444-C [2" (5.1 cm)]
1019444-D [1-1/2" (3.8 cm)]
1019444-E [1" (2.5 cm)]
1019444-F [1-1/4" (3.2 cm)]
1019444-G [2-1/4" (5.7 cm)]
1019444-H [2-1/2" (6.4 cm)]
1019444-J [2-3/4" (7 cm)]
1019444-K [3" (7.6 cm)]
1019444-L [1/2" (1.3 cm)]
1019444-M [1/4" (6 mm)]
Spacer
1019447-A [1/4" (6 mm)]
1019447-B [1/2" (1.3 cm)]
1019447-C [3/4" (1.9 cm)]
Isolation Mount
Outlet
1034673
Connector
To Tee Heater
To In-line Heater
93893
Cover
60320
Screw
93892-A
Electrical Box 67065
Ground Lug
61776
Lock Washer
1033678
Screw
93003
Strain Relief
94821
O-Ring
1005363
Nut
61776
Lock Washer
1010029
Pump Tee
Kohler Co. 17 1023274-5-B

1016953
1.5 HP Pump 1016954
Motor
1010548
Volute
1010673
Seal
1010677
Screw
1010675
O-Ring
1013755
Impeller
1010676
Cover
94821
O-Ring
61845-K
Copper Grounding Wire
1019719
Connector
1005363
Nut
1019447-A [1/4" (6 mm)]
1019447-B [1/2" (1.3 cm)]
1019447-C [3/4" (1.9 cm)]
Isolation Mount
1018964
Bracket
1019433
Carriage Bolt
1001794
Locknut
90153
Nut
1019446-A [1-3/4" (4.4 cm)]
1019446-B [2-3/4" (7 cm)]
1019446-C [3" (7.6 cm)]
1019446-D [2-1/2" (6.4 cm)]
1019446-E [2" (5.1 cm)]
1019446-F [2-1/4" (5.7 cm)]
1019446-G [3-1/4" (8.3 cm)]
1019446-H [3-1/2" (8.9 cm)]
1019446-J [3-3/4" (9.5 cm)]
1019446-K [4" (10.2 cm)]
1019446-L [1-1/2" (3.8 cm)]
1019446-M [1-1/4" (3.2 cm)]
Stud
1019444-A [3/4" (1.9 cm)]
1019444-B [1-3/4" (4.4 cm)]
1019444-C [2" (5.1 cm)]
1019444-D [1-1/2" (3.8 cm)]
1019444-E [1" (2.5 cm)]
1019444-F [1-1/4" (3.2 cm)]
1019444-G [2-1/4" (5.7 cm)]
1019444-H [2-1/2" (6.4 cm)]
1019444-J [2-3/4" (7 cm)]
1019444-K [3" (7.6 cm)]
1019444-L [1/2" (1.3 cm)]
1019444-M [1/4" (6 mm)]
Spacer
**Finish/color code must be specified when ordering.
1018660 (One Outlet)
1018662 (Two Outlets)
Control
Outlet
1034673
Connector
To Tee Heater
60320
Screw
93892-A
Electrical Box 67065
Ground Lug
61776
Lock Washer
1033678
Screw
93003
Strain Relief
94821
O-Ring
1005363
Nut
93893
Cover
60320
Screw
67065
Ground Lug
61776
Lock Washer
1010029
Pump Tee
To In-line Heater
1023274-5-B 18 Kohler Co.

1018710
Tee Heater
94821
O-Ring
94821
O-Ring
1012977
Adapter
1012916
Nut with Screws
1011679
Gasket
1012977
Adapter
1011679
Gasket
**Finish/color code must be specified when ordering.
94821
O-Ring
1012653
Adapter
1012653
Adapter
1012916
Nut w/Screws
1022408
In-line Heater
94821
O-Ring
1032545
Housing
Kohler Co. 19 1023274-5-B

65157
Nut
1020677
Gasket
1013499
Housing
1013453
Spring
91639
O-Ring
1013452**
Dial Trim
1013497-A
Decal 1013497-B
Decal
1013497-C
Decal 1013497-D
Decal
1013497-E
Decal
1020678-A
1023381
Wrench
1020678-B
1020678-D
1020678-C
1020678-E
**Finish/color code must be specified when ordering.
Cover/CircuitBoard
(w/Wrench)
1013497-M
Decal
1020678-M
Cover/CircuitBoard
(w/Wrench)
1013497-N
Decal
1020678-N
Cover/CircuitBoard
(w/Wrench)
1013497-P
Decal
1020678-P
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Cover/CircuitBoard
(w/Wrench)
Carefully study decal and cover
detail below for proper service
part identification.
91639
O-Ring
91639
O-Ring 91639
O-Ring
91639
O-Ring
91639
O-Ring
91639
O-Ring 91639 O-Ring
91639
O-Ring
1023274-5-B 20 Kohler Co.
