Kohler Underscore K-1822-G User manual

Features
•End drain.
•Slotted overflow for deep soaking.
•Integral lumbar support.
•66" (1676 mm) x 32" (813 mm) x 22" (559 mm)
Material
•Acrylic
Hydrotherapy
•122 BubbleMassage™airjets. 18 levels of massage intensity.
•Zones of Control feature allows you to target massage to back,
midsection, or feet.
•Automatic purge cycles remove residual water from air channels
after use.
•Built-in 300 W heater.
•Lighted keypad control.
Installation Codes/Standards
•Drop-in or under-mount. ASME A112.19.7/CSA B45.10
Required Accessories
K-7271 Brass Slotted Overflow Bath Drain
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
or
K-7272 PVC Slotted Overflow Bath Drain UL 1795
Greenguard UL 2818 - Gold
Recommended Accessories
K-1491 Bath/Whirlpool Pillow KOHLER®One-Year Limited Warranty
K-1601 Bath/Whirlpool Footstop See website for detailed warranty information.
K-1703 Whirlpool Remote Control
K-550 Under-mount Installation Kit
Available Color/Finishes
K-9498 3" Keypad Trim
K-24916 Wireless Music Kit Color tiles intended for reference only.
K-1705 Whirlpool/BubbleMassage™Remote Control
DescriptionCodeColor
White0
Biscuit96
Almond47
DuneNY
Ice™Grey95
SandbarG9
Mexican Sand™33
CashmereK4
Thunder™Grey58
Black Black™7
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
3-7-2017 06:08
Underscore®
5.5' BubbleMassage™Bath
K-1822-G

1"
Notes
Required Electrical Service Measure your actual product for rough-in details.
One dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device
(RCD).
Install this product according to the installation
instructions.
The hot water supply should be 70% of the
capacity of the bath or greater. Installations will
vary.
240 V, 15 A, 50/60 HzBlower:
Technical Information
All product dimensions are nominal. If relocating the blower motor, do not relocate or
alter the PVC tee or coiled flexible tubing
Drop-in, Under-mountInstallation:
EndDrain location: connected to the blower. Follow the blower
44-1/2" x 22-5/16" (1130 mm x 567 mm)Basin area, bottom: relocation instructions exactly. Provide access
for servicing the blower.
59-5/8" x 25-1/2" (1514 mm x 648 mm)Basin area, top:
111 lbs (50.3 kg)Weight:
50 lbs/ft²(244.1 kg/m²)Minimum floor load:
18" (457 mm)Water depth:
85.8 gal (324.8 L)Water capacity:
Drop-in, 64-1/2" x 30-1/2" (1638 mm x
775 mm)
Cutout:
Blower: 240 V, 5 A, 50/60 Hz, 300 WElectrical component
rating:
2-1/2" (64 mm)Minimum flat for door:
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
3-7-2017 06:08
Underscore®
5.5' BubbleMassage™Bath
K-1822-G
