Kohler Memoirs K-1418-G User guide

Features
•122 airjets release thousands of bubbles that surround, support,
and massage the body.
•Variable-speed blower lets you adjust massage intensity to 18
levels.
•Zones of Control feature allows you to target massage to back,
midsection, or feet.
•Lighted keypad.
•Generous 6-foot length provides spacious bathing for up to two
people.
•Immediate and manual purge cycles remove residual water
from air channels after use.
•Coordinates with other products in the Memoirs collection.
Material Codes/Standards
ASME A112.19.7/CSA B45.10
•Acrylic
CSA B45.5/IAPMO Z124
Hydrotherapy ASTM E162
•BubbleMassage ASTM E662
Installation UL 1795
CSA C22.2 No. 218.2
•Drop-in
Additional Hydrotherapy Options KOHLER®Plastic Baths and Receptors
Lifetime Limited Warranty
•Soaking Bath - 1417-0
•Soaking Bath + Bask heated surface - 1417-W1 KOHLER®Hydrotherapy Components
Five-Year Limited Warranty
•BubbleMassage air bath - 1418-G
•BubbleMassage air bath + Bask heated surface - 1418-GW See website for detailed warranty information.
•VibrAcoustic - 1418-VB
•VibrAcoustic + Bask heated surface - 1418-VBW
Available Colors/Finishes
•Whirlpool - 1418-H2
•Effervescence Relax Package - 1418-CT Color tiles intended for reference only.
•Effervescence Spa Package - 1418-AH DescriptionCodeColor
•Whirlpool Massage Package - 1418-M
White0
•Spa Package + Massage Package - 1418-V
Biscuit96
Recommended Products/Accessories
K-1491 Bath/Whirlpool Pillow Almond47
DuneNY
K-1601 Bath/Whirlpool Footstop
K-1705 Whirlpool/BubbleMassage™Remote Control
K-7161-AF Bath Drain
SandbarG9
K-9498 3" Keypad Trim
K-24916 Wireless Music Kit
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-28-2019 04:34 - US/CA
Memoirs®
6' BubbleMassage™Bath
K-1418-G

1-1/2"
Notes
Required Electrical Service Measure your actual product for rough-in details.
One dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI). Outside North America,
this device may be known as a Residual Current Device (RCD).
Install this product according to the installation
instructions.
The hot water supply should be 70% of the
capacity of the bath or greater. Installations will
vary.
240 V, 15 A, 50/60 HzBlower:
Technical Information
All product dimensions are nominal. If relocating the blower motor, do not relocate or
alter the PVC tee or coiled flexible tubing
Drop-inInstallation:
CenterDrain location: connected to the blower. Follow the blower
relocation instructions exactly. Provide access
for servicing the blower.
48" x 27" (1219 mm x 686 mm)Basin area, bottom:
60" x 30" (1524 mm x 762 mm)Basin area, top:
If installing a rim-mount faucet, make sure there
is no interference above or below the deck before
drilling any holes.
150 lbs (68 kg)Weight:
54 lbs/ft²(263.7 kg/m²)Minimum floor load:
16" (406 mm)Water depth:
94 gal (355.8 L)Water capacity:
Drop-in, 70-1/2" x 40-1/2" (1791 mm x
1029 mm)
Cutout:
Blower: 240 V, 5 A, 50/60 HzElectrical component
rating:
VariableBlower speed:
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-28-2019 04:34 - US/CA
Memoirs®
6' BubbleMassage™Bath
K-1418-G
