Kohler Skyline Pivot Pentagon User manual

11180583-W2-B
These instructions must be left with the user
Installation Guide
Skyline Pentagon Enclosure

2
1180583-W2-B

31180583-W2-B
Safety Information
1. Careshouldbetakenwhendrillingintowallsandoorstoavoidanyhiddenpipesor
wires.
2. Westronglyrecommendthatallglasspanelsaremovedbyaminimumoftwopeople
andthatanyprotectivepackagingalongtheglassedgesiskeptinplaceforaslongas
possibletopreventdamagebeforeinstallation.
3. Duringinstallationwerecommendadditionalhelpinliftingheavydoorsandsidepanels.
4. Wearprotectivefootwearwhenliftingpanels.
5. Wear safety glasses when drilling.
Wall Preparation
GENERAL INFORMATION
The wall channels must
be installed onto a tiled or
waterproof finished flat and
evenwallsurface.Failuretodo
so will result in an unsatisfactory
seal,whichmaycauseproperty
damage.
INTRODUCTION
ThankyouforpurchasingaqualityKOHLER®product.Toenjoythefullpotentialofyournew
product,pleasetaketimetoreadthisguidethoroughly,havingdoneso,keepithandyfor
future reference.
Thefollowingpagesaimtoprovidecomprehensiveinstallationinstructions,plusadviceon
howtocareandmaintainyourproduct.
Werecommendthattheunitisinstalledbyaqualiedplumberorengineer.
General
1. Readalloftheseinstructionsandretainthisguideforlateruse.
2. Passonthisguideintheeventofchangeofownershipoftheinstallationsite.
3. Followallwarnings,cautionsandinstructionscontainedinthisguide.
4. Removeallprotectivetapefromtheenclosurebeforeinstallation.

4
1180583-W2-B
GUARANTEE
Fordomestic installations,yourenclosurehasthebenetofourlifetimeguaranteewhich
startsfromdateofpurchase.
Fornon-domestic installations,weguaranteetheproductagainstanydefectinmaterials
orworkmanshipforaperiodofoneyearfromthedateofpurchase.
Fortermsandconditionsrefertothebackcoverofthisguide.
RecommendedUsage
Domestic ü
LightCommercial ü
HeavyCommercial û
Healthcare û
6.0 mm
2.0 mm 3.0 mm
TOOLS REQUIRED

51180583-W2-B
PACK CONTENTS
x 2
Pack 1 Pack 2
X 1 q
X 1 q
X 1 q
X 1 q

6
1180583-W2-B
1
INSTALLATION
Note! Make sure that the
wallshavebeentileddown
to the tray.
Note!Coverthetraywastetopreventthelossofsmallparts.
Note! Protect the tray surface during enclosure installation.
Height of Enclosure (mm) 1900
Min/Max Frame Adjustment Enclosure Size Minimum (mm) Maximum (mm)
900 x 900 867 897
1200 x 900 1200 1167 1197
900 867 897
(a) Install the shower tray in accordance with the manufacturer’s instructions.
Caution!Makesurethattheshowertrayislevelandthatthewallsarevertical
andsquare.
± 0 mm
9 mm

71180583-W2-B
2
(a) Positiononeofthepanelwallchannels.Usingaspiritlevelmakesurethatit
isupright.
(b) Markthepositionofthexingholes,thenremovethewallchannel.
(c) Drillwitha6mmmasonrybit(notsupplied),andplugusingthewallplugs
(suppliedwiththedoor).
(d) Positionthewall-channelonthewallandinstallthexingscrews(suppliedwith
door).
(e) Fullytightenthexingscrews,makingsurethatthewallchannelisupright.
RH Panel Shown
9 mm
6 mm
x3
x3
x3
± 0 mm

8
1180583-W2-B
(a) Positionthesecondpanelwallchannelonthewall.Usingaspiritlevelmake
surethatitisupright.
(b) Markthepositionofthexingholes,thenremovethewallchannel.
(c) Drillwitha6mmmasonrybit(notsupplied),andplugusingthewallplugs
(suppliedwiththedoor).
(d) Positionthewallchannelonthewallandinstallthexingscrews(suppliedwith
thedoor).
(e) Fullytightenthexingscrews,makingsurethatthewallchannelisupright.
3LH Panel Shown
9 mm
6 mm
x3
x3
x3
± 0 mm

91180583-W2-B
4
(a) Installthesidepanelsoverthewallchannelsthathadbeensecuredtothewall
earlier.
(b) Adjustthesidepanelssothattheyareinthecorrectposition.

10
1180583-W2-B
5
(a) Installthedoorinposition.
(b) Pushthesidepanelandthedoorframetogetheruntiltheextrusionsengage
and lock together.
Side
Panel
Door
Panel
