Kohler ENGLEFIELD Assembly instructions

©2017 Kohler Co. 1 1256365-X2-C



 


•


•
    
 
 

All information is based on the latest product information
available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics,
packaging, or availability at any time without notice.
IMPORTANT NOTICE TO INSTALLERS Please leave
these instructions for the consumer. They contain
important information.
NOTES
•Flush the water supply pipes thoroughly to remove debris.
•The highest working pressure for showerhead &
handshower is 0.5 MPa(5 bar). If it exceeds 0.5MPa
(5 bar), a pressure reducer is needed. The highest
water and environment temperature is 60°C.
Please keep handshower, showerhead and the shower
arm away from heater, or it may become damaged and
cause injury to the user.
Special model meets or exeeds the following at date of
manufacture: TIS
 ROUGH-IN DIMENSION
HANDSHOWER SET

INSTALLATION AND CARE GUIDE

 BEFORE YOU BEGIN
 CODE/STANDARDS APPLICABLE

 Dimensions are approximate.
Unit: mm.
Note: The recommended dimension for installation can be adjusted according to user preferences and layout.

Finished Wall
ผนัง
*From The Floor to Bracket
*ระยะจากพื�นถึงระดับหัวฝักบัว
1500 - 1800 mm/มม.
Bracket Level
ระดับของขอแขวน
1256365-X2-C 2 ©2017 Kohler Co.

 




 


 



 INSTALLATION
How To Install Handshower
Flush water supply for about one minute before install
the handshower.
Put the washer (6) and ow regulator (5, If provided) into
the shower hose connector (7). Connect the handshower
(4) to shower hose.
NOTE: Do not over tighten.
Connect another end of shower hose to the water supply.
How To Install Bracket
A. Position the bracket, then mark the center of a hole on
the wall.
B. Drill the hole as marked position.
C. For concrete wall, place anchor (1) into the wall.
D. Position the bracket (2) and tighten a screw (3) rmly.
1
2
3
1
2
3
Single Screw Bracket Double Screws Bracket
ขอแขวนแบบสกรู 2 ตัว
ขอแขวนแบบสกรู 1 ตัว
4
7
5
6
©2017 Kohler Co. 3 1256365-X2-C

 

 


How To Change the Water Function
NOTE: For multi-function handshower.
Lever Type:
Slide the lever left or right to change the water function.
Button Type:
Press the button and fully release to change the water
function.
All Finishes: Clean the nish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc, which could
adversely affect the nish and are not recommended for
cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and ttings.
 CARE AND CLEANING






 HANDSHOWER OPERATION
1256365-X2-C 4 ©2017 Kohler Co.






How To Operate The Hand Shower
Any debris or mineral build-up may cause the ow stream
to become distorted or reduce the ow rate. To remove
the debris or mineral build-up, run water through the
handshower, rmly press or rub your nger back and forth
across the rubber nozzles.
Remove and clean the screen washer.
1. The Company warrants the product during normal resident use.
It does not apply in the event of product damages caused by
accident,transportation,misuse,abuse,installationerror,orhasbeen
modied in a manner inconsistent with the products as shipped by
the Company. The warranty excludes damage due to aggressive air
or water conditions, or harsh or abrasive cleaners and/or materials.
Improper care and cleaning will void is warranty.
2. If a defect is found in normal resident use, within the warranty
period, the Company will, at its election, repair, replace or make
appropriate adjustment. The Company is not responsible for labor
charges, installation, or other incidental or consequential costs.
In no event shall the liability of the Company exceed the purchase
price of the product.
3. In the case that the product is not covered by this warranty, the
Company will inform the customer of the service charge and other
cost that may occurred. The Company will proceed further service
only upon receive the customer consent.
4. Proof of purchase: original sales receipt or other documents, if any,
from consumer must be made available to the Company with all
warranty claims.
Remarks:
•Please carefully review the installation instruction manual before you
install the product.
•The Company reserves the right to make changes of this Warranty at
any time without prior notice.
Warranty period:
1. Faucets
•Faucet body 1 year from the date of purchase
•Cartridge (leak and drip during normal use) - Lifetime
2. Other products (not include those Vitreous china, Vitreous china
-related and bathtub products) – 1 year from the date of purchase
To obtain warranty service, contact Kohler Co. either through your
Dealer, Plumbing Contractor, or by writing:
Call Center
KOHLER (Thailand) Public Company Limited
16th Floor, Jasmine City Building
2 Soi Sukhumvit 23, Sukhumvit Road
Wattana, Bangkok 10110
Tel: 0-2204-6222 Fax: 0-2204-6224
Email: [email protected]
 





 














 





•




•





 
•
•
 











 ENGLEFIELD PRODUCT WARRANTY
