Kohler K-5402 Assembly instructions

Homeowners Guide
Wall-Hung Toilet with Cleansing Seat
Français, page ″Français-1″
Español, página ″Español-1″
K-5402
1247364-5-B

IMPORTANT SAFEGUARDS
When using electrical products, especially when children are present, basic safety precautions should
always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI)*.
WARNING: Risk of personal injury. UV light emitted from this light can cause injury to skin or
eyes. Avoid exposure to unshielded lamp.
WARNING: Risk of personal injury. Replacement of the UV lamp must only be performed by
qualified service personnel.
CAUTION: Risk of personal injury. Do not remove the UV lamp protective cover. Eye damage
may result from viewing the UV light directly.
For Service Personnel:
WARNING: Risk of electric shock. Disconnect power before servicing.
WARNING: Risk of personal injury. The UV lamp cover has an interlock designed to reduce the
risk of excessive ultraviolet radiation. Do not bypass the interlock. Reinstall the interlock after
servicing.
*Outside North America, this device may be known as a Residual Current Device (RCD).
WARNING: To reduce the risk of burns, electrocution, fire, or injury to persons:
Close supervision is necessary when this product is used by or near children, the elderly, or
invalids. Adjust the temperature of the seat for the elderly, those who are incapacitated, or persons
with sensitive skin.
Use this product only for its intended use as described in this manual. Do not use attachments not
recommended by Kohler Co.
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return the product for examination and repair.
Keep the cord away from heated surfaces.
Never block the air openings of the product. Keep the air openings free of lint, hair, and the like.
Never use while sleeping or drowsy.
Never drop or insert any object into any opening or hose.
Do not use outdoors or operate where aerosol spray products are being used or where oxygen is
being administered.
This product should be connected to a grounded, metallic, permanent wiring system, or an
equipment-grounding conductor should be run with the circuit conductors and connected to the
equipment grounding terminal or lead on the product.
This product conforms to applicable provisions of US 21 CFR, Chapter 1, Subchapter J, Radiological
Health.
SAVE THESE INSTRUCTIONS
1247364-5-B 2 Kohler Co.

Manual Operation
NOTE: When the cleansing wash features are activated from the side control panel, they will default to
the middle temperature, pressure, and wand position settings.
″rear″-Press the icon to activate rear wash. Press again to stop rear wash.
″dryer″-Press the icon to activate the dryer. Press again to stop the dryer.
″stop″-Press the icon to stop an activated feature.
″front″-Press the icon to activate front wash. Press again to stop front wash.
″flush″-Press the icon to flush the toilet.
″lighting″-Press the icon to turn the night light off. Press again to turn on the night light on.
Low Light Sensor - Senses low light levels and turns the night light on.
Dual Flush Actuator
The dual flush actuator allows manual or touchless flush with a choice of full or reduced flush.
Large button - For touchless full flush, hold your hand in front of the large button for 1.6 gpf (6.1
lpf). For manual flush, push the button.
Small button - For touchless reduced flush, hold your hand in front of the small button for 0.8 gpf
(3 lpf). For manual flush, push the button.
Seat Sensor
Area
Spray
Wand
Side
Control
Panel
Low Light
Sensor
Rear Wash Power
Night
Light
Front
Wash
Dual Flush
Actuator
Kohler Co. 3 1247364-5-B

Remote Control – Setup
NOTE: The remote control must be charged to operate. The ″Stop″icon will blink when the remote needs
to be charged.
Charging the Remote
Verify that the docking station has batteries installed. Refer to the ″Replacing the Batteries″section.
Place the remote control on docking station.
The remote is fully charged when the ″Stop″icon stops blinking.
Pairing to the Toilet
IMPORTANT! The remote control cannot be paired to the toilet while the toilet is occupied.
NOTE: The icons on the bottom row of the remote control will flash when the remote is not paired or is
out of range of the toilet.
Press the power button to turn on the remote control.
Move the remote control within close proximity to the toilet. The bottom row of icons should be
flashing.
Press and hold the ″lighting″icon on the side control panel. Release the icon after the night light
blinks three times.
Press and hold the ″Dryer″icon on the remote control.
While holding the ″Dryer″icon on the remote control, press and hold the ″rear″and ″front″icons
simultaneously on the side control.
When pairing is successful, the bottom icons will stop flashing.
Power Button
Docking Station
Side Control Panel
1247364-5-B 4 Kohler Co.

Remote Control – General Features
IMPORTANT! To activate features using the remote control, the remote must be paired with the toilet.
Refer to the ″Remote Control – Setup″section.
Power - Press the power button to turn the remote control on or off.
Seat Cover - With the seat unoccupied, press this ″Cover″icon to open or close the cover.
Seat - With the seat unoccupied, press the ″Seat″icon to open or close the seat.
Eco Flush - Press the ″Flush-eco″icon to flush the toilet with 0.8 gpf (3 lpf).
Full Flush- Press the ″Flush-full″icon to flush the toilet with 1.6 gpf (6 lpf).
Heated Seat Temperature - While seated, press the ″Seat temp″icon, then press again to increase or
decrease the temperature. The dots to the left of the icon indicate the temperature setting. There are
five settings.
Stop - Press the ″Stop″icon to stop the cleansing wash, dryer, deodorizer, and UV sterilization.
Press and hold to turn off the remote control.
Dryer - While seated, press the ″Dryer″icon to activate air flow. Press again to increase or decrease
air flow.
UV Disinfection - With the seat unoccupied, press the ″Clean″icon to initiate wand disinfection.
The feature is active when the icon is blinking.
Power Button
Docking Station
Kohler Co. 5 1247364-5-B

Remote Control – Cleansing Features
IMPORTANT! To activate features using the remote control, the remote must be paired with the toilet.
Refer to the ″Remote Control – Setup″section.
NOTE: Water temperature, water pressure, wand position, and massage action are adjustable while the
front or rear wash is in use. The dots to the left of the icons indicate the current setting.
Front Wash - Press the ″Front″icon to activate water spray from the front of the wand. Washing
will stop automatically after 5 minutes or can be stopped by pressing the ″Stop″icon.
Rear Wash - Press the ″Rear″icon to activate water spray from the back of the wand. Washing will
stop automatically after 5 minutes or can be stopped by pressing the ″Stop″icon.
Water Temperature - Press the ″Water temp″icon, then press again to increase or decrease the
temperature through five settings.
Massage - Press the ″Massage″icon to activate oscillating action. Press again to switch to pulsating
action. Press a third time for simultaneous oscillating and pulsating actions. Press a fourth time to
stop the action.
Spiral - Press the ″Spiral″icon to activate spiral action. This feature is only available while the rear
wash is in use. Press the icon again to stop the action.
Wand Position - Press the ″Wand″icon, then press again to adjust the wand position through five
settings.
Water Pressure - Press the ″Pressure″icon, then press again to increase or decrease water pressure
through five settings.
1247364-5-B 6 Kohler Co.

Enable/Disable Automatic Features
NOTE: Automatic features come enabled from the factory.
Cover Open/Close
When enabled, the seat cover automatically opens when the toilet is approached. The seat and seat
cover will automatically close 3 minutes after the toilet has been used.
Press and hold the ″lighting″icon on the side control panel until the night light blinks three times.
Press the ″Cover″icon on the remote control. The night light blinks once quickly when the sensor is
set to short distance, twice quickly for mid-distance, and three times quickly for long distance.
The night light blinks slowly when the feature is disabled.
Deodorizer
When enabled, the deodorizer automatically activates while the toilet is in use.
Press and hold the ″lighting″icon on the side control panel until the night light blinks three times.
Press the ″Seat″icon on the remote control.
The night light blinks once quickly when the feature is enabled, or blinks slowly when disabled.
Automatic Flush
When enabled, the toilet will automatically flush 60 seconds after the user stands up, lowers the
seat, or leaves the area.
Press and hold the ″lighting″icon on the side control panel until the night light blinks three times.
Press the ″Flush-full″icon on the remote control.
The night light blinks once quickly when the feature is enabled, or blinks slowly when disabled.
Energy Save Mode
When enabled, the toilet conserves energy by reducing the heated seat temperature when the toilet
is not in use.
Press and hold the ″lighting″icon on the side control panel until the night light blinks three times.
Side Control Panel
Kohler Co. 7 1247364-5-B

Enable/Disable Automatic Features (cont.)
Press the ″Seat temp″icon on the remote control.
The night light blinks once quickly when the feature is enabled, or blinks slowly when disabled.
UV Disinfection
When enabled, ultra violet rays and water sterilize the spray wand daily. This feature only operates
when the seat is closed.
Press and hold the ″lighting″icon on the side control panel until the night light blinks three times.
Press the ″UV″icon on the remote control.
The night light blinks once quickly when the feature is enabled, or blinks slowly when disabled.
Care and Cleaning
WARNING: Risk of property or product damage. Do not use in-tank cleaners in your toilet.
Products containing chlorine (calcium hypochlorite) can seriously damage fittings in the tank. This
damage can cause leakage and property damage.
Kohler Co. shall not be responsible or liable for any tank fitting damage caused by the use of cleaners
containing chlorine (calcium hypochlorite).
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
•For Artist Edition Toilets: Treat your decorative product just as you would treat your fine china.
DO NOT use bristle brushes or abrasive-backed sponges. They will scratch decorative surfaces. Use
only warm water to clean. Dry with a cotton cloth or soft sponge.
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537.
1247364-5-B 8 Kohler Co.

Servicing the Wand and Deodorizer
Cleaning the Spray Wand
On the remote control, press and hold the ″Wand″icon to extend the wand forward.
Clean the spray wand with a soft-bristled brush and hot water.
Press and hold the ″Wand″or ″Stop″icon to retract the wand.
Cleaning or Replacing the Deodorizer
Remove the filter cover.
Remove the filter from the housing and inspect it for damage.
If the filter is damaged, replace it.
If the filter is clogged, remove all debris.
Install the filter.
Reinstall the cover.
Spray
Wand
Kohler Co. 9 1247364-5-B

Servicing the Filters
Remove the right side panel.
Turn off the power to the toilet by flipping the internal switch.
Turn off the water by turning the handle to the closed position.
Remove the filters and inspect them for damage.
If the filters are damaged, replace them.
If the filters are clogged, remove all debris.
Install the filters.
Turn on the water by turning the handle to the open position.
Turn on the power to the toilet by flipping the internal switch.
Reattach the right side panel.
Filter
Filter
Internal
Switch
Handle
1247364-5-B 10 Kohler Co.

Replacing the Batteries
NOTE: The red light on the docking station will blink when the batteries are low. The ″Stop″icon on the
remote control will blink when it has a low charge and should be returned to the docking station.
If the remote control is secured to the docking station, remove it and set aside.
Remove the docking station from the wall by carefully lifting up and out.
Open the back compartment on the docking station by pushing both tabs outward at the same time.
Install four AA batteries, oriented as shown in the battery compartment.
Reinstall the cover.
Reinstall the docking station on the wall.
Troubleshooting
NOTE: For service parts information, visit the product page at www.kohler.com/serviceparts.
Small Children
The automatic flush and cleansing features are activated by a sensor located under the seat. Small
children may not be tall enough to be detected by the sensor.
General
Symptoms Probable Causes Recommended Action
1. The toilet has no power. A. The power is not turned on. A. Flip the switch on the junction box
behind the right side panel.
B. The power is not connected. B. Check the power connection inside
the junction box.
2. The toilet has power but
does not flush. A. No water being supplied to the toilet. A. Fully open the water supply stop.
3. No water sprays from the
wand or it has a weak
stream when activated.
A. The water supply stop is closed
or only partially open. A. Fully open the water supply stop.
Back of Docking Station
Kohler Co. 11 1247364-5-B

Troubleshooting (cont.)
General
Symptoms Probable Causes Recommended Action
B. The inlet hose from the water
supply stop to the toilet is
kinked or looped too tight.
B. Remove the kink in the hose or
make the loop wider.
C. The sensor does not detect the
user. C. Small children may not be detected. Adjust the sitting
position. The sensor may have
difficulty with fabric or other
objects. The sensor is designed to
sense skin.
D. The filters are blocked or
damaged. D. Service the filters. Refer to the ″Servicing the Filters″section.
4. The heated seat is not
working. A. The heated seat is not enabled. A. Activate the heated seat. Refer to the ″Enable/Disable Automatic
Features″section.
B. The temperature setting is too
low. B. Adjust the heated seat temperature using the remote control.
5. Water stops flowing from
the spray wand before
cleansing is complete.
A. Washing automatically stops 5
minutes after pressing a spray
icon.
A. Press the ″Front″or ″Rear″icon to
restart cleansing.
6. The deodorizer is not
working. A. The deodorizer is not activated. A. Activate the deodorizer using the remote control.
7. The UV disinfection
feature is not working. A. The UV disinfection feature is not activated. A. Activate the UV disinfection feature. Refer to the
″Enable/Disable Automatic
Features″section.
8. The toilet does not flush
automatically. A. The automatic flush feature is not enabled. A. Activate automatic flush. Refer to the ″Enable/Disable Automatic
Features″section.
B. The sensor does not detect the
user. B. If this issue occurs repeatedly, call the Customer Care Center using
the information on the back of this
manual.
9. The night light does not
turn on in low light
conditions.
A. The night light is not enabled. A. Press the ″lighting″icon on the side
control panel.
B. The low light sensor is not
working. B1. Clean the light sensor on the side control panel.
B2. Call the Customer Care Center
using the information on the back
of this manual.
Remote Control
Symptoms Probable Causes Recommended Action
1. The remote control is not
turning on. A. The batteries are not properly installed. A. Reinstall the batteries. Refer to the ″Replacing the Batteries″section.
B. The batteries are drained. B. Replace the batteries. Refer to the
″Replacing the Batteries″section.
2. The remote control is not
connecting with the toilet. A. The remote is too far from the toilet to receive a signal. A. Move the remote closer to the toilet to regain a connection.
B. The remote is not paired with
the toilet. B. Pair the remote to the toilet. Refer to the ″Remote Control – Setup″
section.
1247364-5-B 12 Kohler Co.

Remote Control Compliance
FCC ID: N82-KOHLER015, N82-KOHLER018
IFT: Certification Number RCPKO1215-2233 and RCPKO1215-2234.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning
This transmitter with its antenna complies with FCC’s RF exposure limits for general
population/uncontrolled exposure.
This device must not be co-located or operated in conjunction with any other antenna or transmitter.
This device should be operated with a minimum distance of at least 20 cm between the antenna and a
person’s body.
CANADA IC: 4554A-KOHLER015, 4554A-KOHLER018
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the
device.
This transmitter with its antenna complies with Industry Canada RF Exposure Limits for General
Population/Uncontrolled Exposure.
This Class B digital apparatus complies with Canadian ICES-003.
Warranty
KOHLER Intelligent Toilet and C3 Cleansing Seat Three-Year Limited Warranty
Kohler Co. warrants that its toilets with integrated cleansing functionality (″Intelligent Toilets″) and electric
cleansing seats will be free of defects in material and workmanship during normal residential use for three
years from the date the product is installed. This warranty applies only to intelligent toilets and electric
cleansing seats installed in the United States of America, Canada and Mexico (″North America″).
If a defect is found in normal residential use, Kohler Co. will, at its election, repair, provide a replacement
Kohler Co. 13 1247364-5-B

Warranty (cont.)
part or product, or make appropriate adjustment where Kohler Co.’s inspection discloses any such defect.
Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning
will void the warranty*. Proof of purchase (original sales receipt) must be provided to Kohler Co. with all
warranty claims. Kohler Co. is not responsible for labor charges, installation, or other incidental or
consequential costs other than those noted above. In no event shall the liability of Kohler Co. exceed the
purchase price of the intelligent toilet or electric cleansing seat.
If the intelligent toilets or electric cleansing seats are used commercially or are installed outside of North
America, Kohler Co. warrants that the intelligent toilet or electric cleansing seat will be free from defects in
material and workmanship for one (1) year from the date the product is installed, with all other terms of this
warranty applying except duration.
If you believe that you have a warranty claim, contact your Home Center, Dealer, Plumbing Contractor or
E-tailer. Please be sure to provide all pertinent information regarding your claim, including a complete
description of the problem, the product, model number, the date the product was purchased, from whom the
product was purchased and the installation date. Also include your original invoice. For other information,
or to obtain the name and address of the service and repair facility nearest you, write Kohler Co., Attn:
Customer Care Center, Kohler, Wisconsin 53044 USA, or by calling 1-800-4-KOHLER (1-800-456-4537) from
within the USA and Canada, and 001-800-456-4537 from within Mexico, or visit www.kohler.com within the
USA, www.ca.kohler.com from within Canada, or www.mx.kohler.com in Mexico.
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KOHLER CO. AND/OR SELLER
DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states/provinces do not allow limitations of how long an implied warranty lasts or the exclusion or
limitation of such damages, so these limitations and exclusions may not apply to you. This warranty gives
the consumer specific legal rights. You may also have other rights that vary from state/province to
state/province. This warranty is to the original consumer purchaser only, and excludes product damage
due to installation error, product abuse, or product misuse, whether performed by a contractor, service
company, or the consumer.
This is Kohler Co.’s exclusive written warranty.
* Never use cleaners containing abrasive cleansers, ammonia, bleach, acids, waxes, alcohol, solvents or other
products not recommended for stainless steel or polypropylene plastic. This will void the warranty.
1247364-5-B 14 Kohler Co.

Guide du propriétaire
Toilette fixée au mur avec siège de nettoyage
MESURES DE SÉCURITÉ IMPORTANTES
Lors de l’utilisation de produits électriques, et en particulier en présence d’enfants, toujours observer les
mesures de sécurité fondamentales, notamment:
LIRE TOUTES LES INSTRUCTIONS AVANT UTILISATION
DANGER: Risque de choc électrique. Raccorder uniquement à un circuit protégé par un
disjoncteur de fuite de terre (GFCI)*.
AVERTISSEMENT: Risque de blessures. La lumière ultraviolette émise par cette lampe peut créer
des lésions oculaires ou de la peau. Éviter toute exposition à une lampe non blindée.
AVERTISSEMENT: Risque de blessures. Le remplacement de la lampe UV peut seulement être
effectué par un personnel d’entretien qualifié.
ATTENTION: Risque de blessures. Ne pas retirer le couvercle de protection de la lampe UV. Les
yeux pourraient subir des lésions lorsque l’on regarde directement dans la lumière UV.
Pour le personnel préposé à l’entretien:
AVERTISSEMENT: Risque de choc électrique. Déconnecter l’alimentation électrique avant
d’effectuer un entretien.
AVERTISSEMENT: Risque de blessures. Ce couvercle de lampe UV est doté d’un système de
verrouillage conçu pour réduire le risque d’un rayonnement ultraviolet excessif. Ne pas annuler le
verrouillage. Réinstaller le verrouillage après l’entretien.
* Hors de l’Amérique du Nord, ce dispositif peut être connu sous le nom de dispositif à courant résiduel
(RCD).
AVERTISSEMENT: Pour réduire le risque de brûlures, d’électrocution, d’incendie ou de
blessures personnelles:
Il est nécessaire de superviser de près lorsque ce produit est utilisé par de jeunes enfants, des
personnes âgées ou invalides, ou lorsqu’il se trouve dans leur proximité. Ajuster la température du
siège pour les personnes âgées, les personnes frappées d’incapacité, ou les personnes dont la peau
est sensible.
Utiliser ce produit uniquement pour l’usage pour lequel il est destiné, tel que décrit dans ce manuel.
Ne pas utiliser de dispositifs d’attache non recommandés par Kohler Co.
Ne jamais faire fonctionner ce produit si son cordon ou sa prise sont endommagés, s’il ne fonctionne
pas correctement, s’il est tombé ou s’il est endommagé, ou s’il est tombé dans de l’eau. Retourner le
produit pour le faire examiner et réparer.
Tenir le cordon à distance de surfaces chauffées.
Ne jamais bloquer les ouvertures d’air du produit. S’assurer de l’absence de peluches, de cheveux
ou d’autres éléments similaires sur les ouvertures d’air.
Ne jamais utiliser ce dispositif lorsque l’on dort ou si l’on se sent somnolent.
Ne jamais faire tomber ou insérer un objet quelconque dans une ouverture ou un tuyau.
Kohler Co. Français-1 1247364-5-B

MESURES DE SÉCURITÉ IMPORTANTES (cont.)
Ne pas utiliser ce dispositif à l’extérieur et ne pas le faire fonctionner en présence de produits
aérosols ou si l’on administre de l’oxygène.
Ce produit doit être connecté à un système de câblage métallique permanent et mis à la terre, ou un
conducteur de mise à la terre de l’équipement doit être acheminé avec les conducteurs du circuit et
connecté à la borne ou au fil de mise à la terre de l’équipement sur le produit.
Ce produit est conforme aux conditions applicables de l’US 21 CFR, Chapitre 1, Sous-chapitre J,
Hygiène radiologique.
CONSERVER CES INSTRUCTIONS
1247364-5-B Français-2 Kohler Co.

Fonctionnement manuel
REMARQUE: Lorsque les fonctions de nettoyage et de lavage sont activées à partir du panneau de
commande latéral, elles se mettent par défaut aux réglages moyens de température, de pression et de
position de baguette.
″rear″(arrière) - Appuyer sur l’icône pour activer le lavage arrière. Appuyer de nouveau pour
arrêter le lavage arrière.
″dryer″(séchoir) - Appuyer sur l’icône pour activer le séchoir. Appuyer de nouveau pour arrêter le
séchoir.
″stop″(arrêter) - Appuyer sur l’icône pour arrêter une fonction activée.
″front″(avant) - Appuyer sur l’icône pour activer le lavage avant. Appuyer de nouveau pour arrêter
le lavage avant.
″flush″(chasse) - Appuyer sur l’icône pour rincer la toilette.
″lighting″(éclairage) - Appuyer sur l’icône pour éteindre la veilleuse. Appuyer de nouveau pour
allumer la veilleuse.
Capteur d’éclairage faible - Détecte les niveaux d’éclairage faible et allume la veilleuse.
Actionneur de chasse double
L’actionneur de chasse double permet une chasse sans contact avec un choix de chasse complète ou
réduite.
Grand bouton - Pour une chasse complète sans contact, tenir la main devant le grand bouton pour
1,6 gpf (6,1 lpf). Pour une chasse manuelle, appuyer sur le bouton.
Petit bouton - Pour une chasse réduite sans contact, tenir la main devant le petit bouton pour
0,8 gpf (3 lpf). Pour une chasse manuelle, appuyer sur le bouton.
Zone de capteur
de siège
Baguette de
vaporisation
Lavage arrière Mise en
marche/arrêt
Veilleuse
Lavage
avant
Panneau de
commande latéral
Capteur
d'éclairage
faible
Actionneur
de chasse
double
Kohler Co. Français-3 1247364-5-B

Télécommande – Configuration
REMARQUE: La télécommande doit être chargée pour fonctionner. L’icône ″Stop″clignotera lorsque la
télécommande doit être chargée.
Chargement de la télécommande
Vérifier que des piles ont été installées dans la station d’accueil. Se référer à la section ″Remplacer
les piles″.
Placer la télécommande sur la station d’accueil.
La télécommande est entièrement chargée lorsque l’icône ″Stop″s’arrête de clignoter.
Appariement de la toilette
IMPORTANT! La télécommande ne peut pas être appariée à la toilette lorsque celle-ci est occupée.
REMARQUE: Les icônes qui se trouvent dans la rangée du bas de la télécommande clignoteront lorsque
la télécommande n’est pas appariée ou si elle est hors de portée de la toilette.
Appuyer sur le bouton Marche/Arrêt pour activer la télécommande.
Rapprocher la télécommande dans un rayon proche de la toilette. La rangée d’icônes inférieure
devrait clignoter.
Appuyer et continuer à appuyer sur l’icône ″lighting″sur le panneau de commande latéral.
Relâcher l’icône lorsque la veilleuse a clignoté trois fois.
Appuyer et continuer à appuyer sur l’icône ″Dryer″sur la télécommande.
Tout en maintenant l’icône ″Dryer″enfoncée sur la télécommande, appuyer simultanément et
continuer à appuyer sur les icônes ″rear″et ″front″sur le panneau de commande latéral.
Lorsque l’appariement est réussi, les icônes du bas s’arrêtent de clignoter.
Bouton
Marche/Arrêt
Station d'accueil
Panneau de commande latéral
1247364-5-B Français-4 Kohler Co.

Télécommande – Fonctions générales
IMPORTANT! La télécommande doit être appariée avec la toilette pour que les fonctions puissent être
activées à l’aide de la télécommande. Se référer à la section ″Télécommande – Configuration″.
Marche/Arrêt - Appuyer sur le bouton Marche/Arrêt pour activer ou désactiver la télécommande.
Couvercle de siège - Avec le siège non occupé, Appuyer sur l’icône ″Cover″pour ouvrir ou fermer
le couvercle.
Siège - Avec le siège non occupé, appuyer sur l’icône ″Seat″pour ouvrir ou fermer le siège.
Chasse Éco - Appuyer sur l’icône ″Flush-eco″pour rincer la toilette avec 0,8 gpf (3 lpf).
Chasse complète- Appuyer sur l’icône ″Flush-full″pour rincer la toilette avec 1,6 gpf (6 lpf).
Température de siège chauffé - Tout en étant assis, appuyer sur l’icône ″Seat temp″, puis appuyer
de nouveau pour augmenter ou diminuer la température. Les points situés à gauche de l’icône
indiquent le réglage de la température. Cinq réglages sont possibles.
Arrêt - Appuyer sur l’icône ″Stop″pour arrêter le lavage et nettoyage, le séchoir, le désodorisant et
la stérilisation par UV. Appuyer et continuer à appuyer pour éteindre la télécommande.
Séchoir - Tout en étant assis, appuyer sur l’icône ″Dryer″pour activer le débit d’air. Appuyer de
nouveau pour augmenter ou diminuer le débit d’air.
Désinfection par UV - Avec le siège non occupé, appuyer sur l’icône ″Clean″pour lancer la
désinfection de la baguette. La fonction est activée lorsque l’icône clignote.
Bouton Marche/Arrêt
Station d'accueil
Kohler Co. Français-5 1247364-5-B

Télécommande – Fonctions de nettoyage
IMPORTANT! La télécommande doit être appariée avec la toilette pour que les fonctions puissent être
activées à l’aide de la télécommande. Se référer à la section ″Télécommande – Configuration″.
REMARQUE: La température de l’eau, la pression de l’eau, la position de la baguette, et l’action de
massage sont réglables pendant que le lavage avant ou arrière est en cours d’utilisation. Les points situés à
gauche des icônes indiquent le réglage actuel.
Lavage avant - Appuyer sur l’icône ″Front″pour activer la vaporisation d’eau à partir de l’avant de
la baguette. Le lavage s’arrête automatiquement au bout de 5 minutes, ou il peut être arrêté en
appuyant sur l’icône ″Arrêt″.
Lavage arrière - Appuyer sur l’icône ″Rear″pour activer la vaporisation d’eau à partir de l’arrière
de la baguette. Le lavage s’arrête automatiquement au bout de 5 minutes, ou il peut être arrêté en
appuyant sur l’icône ″Arrêt″.
Température de l’eau - Appuyer sur l’icône ″Water temp″, puis appuyer de nouveau pour
augmenter ou diminuer la température au moyen de cinq réglages.
Massage - Appuyer sur l’icône ″Massage″pour activer l’action d’oscillation. Appuyer de nouveau
pour passer à une action de pulsation. Appuyer une troisième fois pour obtenir des actions
simultanées d’oscillation et de pulsation. Appuyer sur l’icône une quatrième fois pour arrêter
l’action.
Spiral - Appuyer sur l’icône ″Spiral″pour activer l’action de spirale. Cette fonction est seulement
disponible pendant que le lavage arrière est en cours d’utilisation. Appuyer de nouveau sur l’icône
pour arrêter l’action.
Position de la baguette - Appuyer sur l’icône ″Wand″, puis appuyer de nouveau pour ajuster la
position de la baguette au moyen de cinq réglages.
Pression de l’eau - Appuyer sur l’icône ″Pressure″, puis appuyer de nouveau pour augmenter ou
diminuer la pression de l’eau au moyen de cinq réglages.
1247364-5-B Français-6 Kohler Co.
