KPM-11M Optical Power Meter User Manual
External and key function description
1 3
4
2
Ceramic ferrule
1
Silicone cap
2
USB charging port
LED lighting
3
4
1
2
3
13
8
4
56
7
9
11
10
12
Auto shutdown icon
5
13 LED light switch key: turn on/off the
flashlight, press any key to turn on the
backlight
Electricity
6
wavelength7
Absolute power value and unit8
Linear power value and unit9
λ key: 7 kinds of test wavelengths
that can switch the optical power
10
Power on/off key: turn on/off the device
11
REF/dB key: Short press the dB unit to
switch, long press until the screen displays
REF to enter the relative optical power test
mode
12
Optical power wavelength switching
(Dry battery type is not rechargeable)
Power/Off button
Short press the power button to turn on
the meter. The meter has automatic
startup and automatic shutdown functions.
The default automatic shutdown time is 15
minutes. If you want to cancel this function,
press and hold the power button when it is
turned on. After turning it on, the " " icon
on the screen disappears, indicating that
the automatic shutdown is canceled.
Power reference value setting
1.After booting, enter the optical power
meter interface, short press the "REF" key
to set the current power value as the
reference power, which can achieve relative
optical power test (insertion loss test) or
absolute power test, enter the relative power
test mode at the bottom of the screen.The
insertion loss (dB) is displayed, and the screen
displays the reference value; short press the
"dB" key to switch between linear power and
absolute power display.
2.The units of linear power, absolute power,
and relative power are nW, dBm, and dB
respectively.
P absolute power = 10lgP linear power / 1mW
P relative power = P absolute power-
P reference power
On the optical power meter interface, short
press the "λ" key to switch the measurement
wavelength, select 7 different test wavelengths,
850nm/980nm/1300nm/1310nm/1490nm/
1550nm, 850nm, 1625nm to ensure the accuracy
of the test, select the wavelength Must be
consistent with the wavelength of the measured
optical signal.
λ
850nm 980nm 1300nm
1310 1490 nm
1550
nm
nm 1625 nm

Product description
7
Product features
8
Accurate measurement, error less than 0.2dB
60 hours continuous use (only in optical power meter mode)
7 wavelengths (850/980/1300/1310/1490/1550/1625) nm
Back clip design, mini compact
Measuring range -70~+10dBm/-50~+26dBm
Universal interface design, adapt to SC, ST, FC interface
Optional lithium battery, USB charging, easy to use
Equipped with LED lights, it is more convenient to check
the line in the dark
Product parameter
9
KPM-11M Optical Power Meter User Manual
5LED flashlight
Flashlight switch: Short press the " "
button to turn on the flashlight, which
is convenient for use in a dark environment
and realize the lighting function; short press
the " " button to turn off the flashlight.
Key Function
REF/dB Increased by 0.1dB
λReduced by 0.1dB
save
Calibration function description
6
Press REF/dB first, and then press the +REF/dB keys simultaneously
to enter the calibration mode. The λ key is to adjust the value down, a
nd the REF/dB key is to adjust the value up. Press the power button to
save the value and exit the calibration procedure.
Wavelength (nm) 800~1700nm
Power measurement
range (dBm) -70～+10dBm / -50~+26dBm
Interface 2.5mm universal connector
Power supply Rechargeable lithium battery
1000mAh/7 AAA1.5V battery *2
Resolution (dB) 0.01
Working temperature -10~+60(℃）
Storage temperature -25~+70(℃）
Volume/weight
Probe type
Charging interface
127x36.5x28mm /61g
InGaAs
USB charging (only charging models)
Working time 20 hours with battery
Charge for 60 hours
This product uses a 650nm semiconductor laser as a light-emit-
ting device and is driven by a constant current source to emit a
stable red light; it enters a single-mode or multi-mode fiber after
being connected to an optical fiber interface to realize the
function of fiber fault detection. It is an optical fiber engineering
construction and optical fiber network. An indispensable tool for
maintenance, optical device production and research.
Tips
11
Operating environment altitude:
Area altitude below 2000m
Please read all instructions and warnings before
using this product. Irregular use will cause
damage to the product or personal safety.
Use environment
1) Do not store this product in high temperature, strong light
and strong magnetic fields, and do not place it in other harsh
environments such as fire sources.
2）Improper use of the product may easily cause the product
damage or may endanger personal and property safety.
3) If consumers violate the product manual and improperly
use it, the personal and property damage caused by it will
bearby yourselve, our company will not bear any legal
responsibility.
4) Non-professionals are strictly prohibited from
disassembling this product.
5) Avoid using electrical appliances or loads that exceed the
output current of this product (the circuit will be protected
and there will be no output).
6) Avoid strong physical effects, including knocking, throwing,
trampling, squeezing, etc.
Packing carton, optical power meter ,
certificate of conformity, instruction manual.
