LITHIUM IRON PHOSPHATE
LIFEPO4 BATTERY PACK
INSTRUCTIONS FOR CONNECTION
THE BATTERY PACK TO DEYE INVERTERS
51,2V 100Ah
KT-LFPES512100
Before connecting the battery with inverter.make sure the following rules are complied.
1. The battery system discharge power/current is proper with the inverter power. It is recommended to congure the inverter
capacity with battery in 1: 2 proportion, for example. If you have a 5 kW rated inverter, connect at least 2 batteries (10kWh),
2. If the system is an off-grid system, make sure that conguration can manage to avoid overdischarging the battery. It is strongly
recommended to install a smart generator and MPPT modules (brands like Victron that support DC-coupled application).
3. Make sure that the installation environment, setting and sequence is following the User Manual.
1. PRECONDITIONS
2.1 DEVICE SUPPORT
2.1.1 CABLE CONNECTION
Deye/Sunsynk Hybrid inverter and Kon-TEC KT-LFPES512100 battery can be used for following system types
- Energy Storage Systems
- Grid Backup
- Off-grid
Compatible device:
SUN-SG04LP1-EU / SUN-SG03LP1-EU / SUN-SG05LP1-EU / SUN-SG04LP3-EU / SUN-SG01LP1-EU
1. Keep both inverter and battery completely off.
2. Connect the communication cable to the system according to the following schematic
2. COMMISSIONING WITH INVERTER
Kon-TEC Battery BMS CAN port Deye/Sunsynk inverter CAN
port
Pin 4 H Pin 4 H
Pin 5 L Pin 5 L
Pin 6 GND Pin 2 or Pin
6 (based on
model)
GND

KT-LFPES512100 https://www.kon-tec.eu/
2/3
Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów, Poland
T: [phone] E: [e-mail] W: www.kon-tec.eu
2.1.2 START SYSTEM
1 Set the Master battery (ONLY!!!) DIP address according to the User Manual (Picture above).
2 Press the Master battery reset button to switch on all the batteries and then close the battery breaker to start inverter.
3 Turn on inverter DC switch, then press “ON” button to power on the inverter. Then turn on AC input and output breaker.
INSTALACJA PV
PV INSTALLATION
PE
Deye BMS CAN port
Wyjście AC
AC out
LINK OUT - PORT OSTATNIEGO AKUMULATORA SLAVE WOLNY
LINK OUT - LAST SLAVE BATTERY PORT NOT CONNECTED
Wejście AC
AC in Sieć
energetyczna
GRID
Deye/Sunsynk Inverter
Ostatni akumulator Slave
Last Slave battery
Akumulator Master
Master battery
DIP: 0000010
n - równolegle
n - parallel
Rozłącznik DC
DC Breaker

Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów, Poland
T: [phone] E: [e-mail] W: www.kon-tec.eu
3/3
KT-LFPES512100 https://www.kon-tec.eu/
2.1.3 INVERTER SETUP
1 Check the inverter screen, if green LED is on, and there is no alarm LED, it means that everything is proper, otherwise please check
inverter manual for troubleshooting.
2 Click the setting icon on the screen top right and choose battery setting
3 Enter the Battery Setting and set the following values
If we congure the inverter with the battery connected via the CAN communication cable (inv. BMS CAN, Master battery Link In) we
set the following parameters (in each window, press the button to conrm the parameters, otherwise the settings will not be set):
Battery Setting:
Batt Mode: Lithium
Batt Capacity: 100Ah * N (N indicates the number of battery pack in parallel )
Max A charge: 50A * N (N indicates the number of battery pack in parallel )
Max A discharge: 50A * N (N indicates the number of battery pack in parallel )
Activate battery: enable
Lithium mode: 00
Shutdown: ≥ 10%
Low batt: ≥ 20%
Restart: ≥ 30%
Grid charge: enable
Gen charge: enable (if using Diesel generator)
However, if we congure the battery WITHOUT connection with a communication cable by the CAN port, enter the settings manually:
Batt mode: Use Batt V
Max A charge: 50A * N (N indicates the number of battery pack in parallel )
Max A discharge: 50A * N (N indicates the number of battery pack in parallel)
Activate battery: enable
Shutdown: ≥ 10%
Low batt: ≥ 20%
Restart: ≥ 30%
Grid charge: enable
Gen charge: enable (if using Diesel generator)
Float V: 54,6V
Absorption: 56,0V
Equalization V: 56V
Equalization Days: 15 days
Equalization Hours: 2.0 hours
>

KT-LFPES512100 https://www.kon-tec.eu/
4/3
Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów, Poland
T: [phone] E: [e-mail] W: www.kon-tec.eu
4 Back to the home screen and click the battery icon to check if communication and parameters are correct.
5 Conrm all the parameters and then nish other settings (TOU, Zero export etc.) on the inverter according to the inverter manual.
6 If parameters are set correct, you are ready to use the system.
