Simrad TP90
INSTALLATION
MANUAL

484238/A
March2023©KongsbergMaritimeAS
PUBLIC
SimradTP90
CatchMonitoringPositioningTransceiver
Unit
InstallationManual
Thepurposeofthismanualistoprovidethedescriptionsandprocedures
requiredtoinstalltheTP90CatchMonitoringPositioningTransceiver
UnitandsetituptointerfacetheTV80.

KongsbergMaritimeAS
www.kongsberg.com
Documentinformation
•Product:SimradTP90
•Document:InstallationManual
•Documentpartnumber:484238
•DocumentISBNnumber:N/A
•Revision:A
•Dateofissue:27March2023
Copyright
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsberg
MaritimeAS.Nopartofthisdocumentmaybecopiedorreproducedinanyformorbyany
means,andtheinformationcontainedwithinitisnottobecommunicatedtoathirdparty,
withoutthepriorwrittenconsentofKongsbergMaritimeAS.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhich
itwasdesigned.Improperuseormaintenancemaycausedamagetotheequipmentand/or
injurytopersonnel.Youmustbefamiliarwiththecontentsoftheappropriatemanuals
beforeattemptingtooperateorworkontheequipment.
KongsbergMaritimedisclaimsanyresponsibilityfordamageorinjurycausedbyimproper
installation,useormaintenanceoftheequipment.
Disclaimer
KongsbergMaritimeASendeavourstoensurethatallinformationinthisdocumentis
correctandfairlystated,butdoesnotacceptliabilityforanyerrorsoromissions.
Supportinformation
Ifyourequiremaintenanceorrepair,contactyourlocaldealer.Youcanalsocontactususing
thefollowingaddress:[email protected]g.com.Ifyouneedinformation
aboutourotherproducts,visithttps://www.kongsberg.com/simrad.Onthiswebsiteyouwill
alsondalistofourdealersanddistributors.

484238/A3
Tableofcontents
ABOUTTHISMANUAL..................................................................5
SIMRADTP90..............................................................................7
TP90CatchMonitoringPositioningTransceiver...................................................................7
Orderinformation...................................................................................................................8
Systemdiagram.......................................................................................................................9
Supportinformation...............................................................................................................11
INSTALLINGTHETP90USINGITSMOUNTINGBRACKETS.........14
CABLELAYOUTANDINTERCONNECTIONS.................................16
Cableplan.............................................................................................................................17
Listofcables.........................................................................................................................18
Connectingthetransducer.....................................................................................................19
InstallingthePowerSupplyUnit..........................................................................................22
SETTINGUPTHETRANSCEIVER................................................25
TECHNICALSPECIFICATIONS....................................................28
DRAWINGFILE..........................................................................30
Aboutthedrawingsinthedrawingle.................................................................................30
TP90outlinedimensions......................................................................................................32
OVERVIEWOFFREQUENCYSELECTION.....................................33
InstallationManual

4484238/A
SimradTP90

484238/A5
Aboutthismanual
Thepurposeofthispublicationistoprovidethedescriptionsandproceduresrequiredto
installtheTP90CatchMonitoringPositioningTransceiverUnit.
Targetaudience
Thepublicationisintendedfortechnicalpersonnelsuchasskilledshipyardworkers,
electricians,qualiedengineersandnavalarchitects.Itisassumedthatyouunderstand
thegeneralprinciplesofmarineelectronicequipment.Youmustalsobefamiliarwith
theinstallationofelectronicandmechanicalproducts.Youareexpectedtohavebasic
mechanicalskillsandfamiliaritywithhandlingsensitiveelectronicequipment.
Installationinstructions/Installationdrawings
Theinformationinthisdocumentmustberegardedasguidelinesandrecommendations.
Note
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationofthe
TP90systemmustbeapprovedbythevessel’ snationalregistryandcorresponding
maritimeauthorityand/orclassicationsociety.Suchapprovalmustbeobtainedbeforethe
installationcanbegin.Theshipownerandshipyarddoingtheinstallationareresponsible
forobtainingandpayingforsuchapproval.
KongsbergMaritimeASwillacceptnoresponsibilityforanydamageorinjurytothe
product,vesselorpersonnelcausedbyequipmentthathasbeenincorrectlyinstalledor
maintained,orbydrawings,instructionsorproceduresthathavenotbeenpreparedbyus.
TheoutlinedimensionsoftheTP90receiverfoundintherelevantchapterinthismanual.
Endusermanualsandsourcedrawings(normallyinAutoCadformat)canbedownloaded
fromourwebsite.
•https://www.kongsberg.com/tp90
Aboutthismanual

6484238/A
Registeredtrademarks
Observetheregisteredtrademarksthatapply.
Windows®isaregisteredtrademarkofMicrosoftCorporationintheUnitedStatesand
othercountries.
Simrad®,SIMRAD®andtheSimrad®logoareeitherregisteredtrademarks,ortrademarks
ofKongsbergMaritimeASinNorwayandothercountries.
SimradTP90InstallationManual

484238/A7
SimradTP90
TP90CatchMonitoringPositioningTransceiver
TheSimradTP90CatchMonitoringPositioningTransceiverisanoptionalpartofthe
SimradTV80catchmonitoringsystem.Bymeansofthistransceiver,theTV80canprovide
informationabouttherelativepositionoftheITIandPxPossensorsplacedonthetrawl.
Thetransceiverconnectstooneortwotransducers.Initially,onlysingletransducer
installationissupported.Thetransceivercanreceiveinformationfromarelevantselection
ofITIsensors,excepttheITITrawlEyeandtheITICatch.
Thetransceiverrequiresanexternalpowersupplyoffering12to15Vdc,minimum5A.A
suitablepowersupplyisprovidedwiththedelivery.AhighqualityEthernetcableconnects
thetransceivertothecomputer.Thedistancebetweenthecomputerandthetransceivercan
beextendeduptomaximum70meters.Ifalongercableisrequired,cutitinhalf,andinsert
anEthernetswitchtoprovidebufferamplication.
ATV80systemwithPxPossensorsandaTP90transceiverallowsyoutomeasuretherange
andbearingtoeachsensoronthetrawl.Themeasurementsofrangeandbearingprovidethe
positionofthesensorsrelativetothevessel,andthusthelocationofthetrawl.Whenthis
positionisknown,youcanavoidwrecksandotherobstaclesontheseabed.Thismeansthat
aTV80systemttedwithaTP90transceivercanreplaceanexistingITIsystem.
PositioninformationissenttoandfromthetransceiverviaNMEAsentences.For
moreinformation,refertotherelevantsoftwarereleasenoteandtheTV80end-user
documentation.
SimradTP90

8484238/A
Thetransceiversupportsthesecatchmonitoring
sensors:
•PxPossensor:measurementcombinations
–Depth
–Height1
–Height2
–Remote1
–Remote2
–SpreadCOM1
–SpreadCOM2
–Temperature/Depth(Liddependant)
–Temperature/Depth(Liddependant)+Remote1
–Temperature/Depth(Liddependant)+Remote2
ThePxPossensoroperatesbetween27kHzand33kHz.
Relatedtopics
Systemdiagram,page9
Orderinformation
ToordertheTP90transceiver,contactyourlocaldealer.Ifyoudonothavearegulardealer,
alistofallourdistributorsanddealerscanbefoundonourwebsite.Yourdealerwillalsobe
abletohelpyouwithadetailedquotationincludingpriceanddeliveryinformation.
Relevantorderinformationisprovidedonourwebsite.
•https://www.kongsberg.com/tp90
SimradTP90InstallationManual

484238/A9
Systemdiagram
ThesystemdiagrampresentsaTV80systemwithaTP90transceiver.
AbasicsystemconsistsofaTV80system,thetransceiver,onesingle-splitbeamtransducer,
andacomputer.TheTV80softwarecontrolstheoperationofthesystem.
ADisplay
Youcanuseoneortwodisplaysonyourcomputerdependingonpersonaland/or
operationalpreferences.
BComputer
CTP90CatchMonitoringPositioningTransceiver
DPowerSupplyUnit
ETransducer
FITIsensor/PxPossensor
GEthernetconnection
SimradTP90

10484238/A
Unlessotherwisespeciedinacontract,thedisplay,thecomputer,andthetransducersare
notincludedinthestandarddeliveryfromKongsbergMaritime.
Relatedtopics
TP90CatchMonitoringPositioningTransceiver,page7
SimradTP90InstallationManual

484238/A11
Supportinformation
IfyouneedtechnicalsupportforyourTP90systemyoumustcontactyourlocaldealer,or
oneofoursupportofces.Alistofallourofcesanddealersisavailableonourwebsite.
YoucanalsocontactourmainsupportofceinNorway.
Norway(mainofce)
•Companyname:KongsbergMaritimeAS/Simrad
•Address:Strandpromenaden50,N3190Horten,Norway
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Spain
•Companyname:KongsbergMaritimeSpainS.L.U
•Address:PartidaAtalayes20,03570Villajoyosa,Spain
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
France
•Companyname:SimradFrance
•Address:5ruedeMenMeur,29730Guilvinec,France
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
USA
•Companyname:KongsbergUnderwaterTechnologyLLC(KUTL)/SimradFisheries
•Address:1921033rdAveW,SuiteA,Lynnwood,WA98036,USA
•Telephone:[phone]
SimradTP90

12484238/A
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Canada
•Companyname:KongsbergMesotechLtd.
•Address:1598KebetWay,PortCoquitlam,BC,V3C5M5,Canada
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Malaysia
•Companyname:KongsbergMaritimeMalaysiaSdn.Bhd
•Address:Unit27-5SignatureOfces,TheBoulevard,MidValleyCity,
LingkaranSyedPutra,59200KualaLumpur,Malaysia
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Korea
•Companyname:KongsbergMaritimeKoreaLtd
•Address:#1101HarborTower,113-1,Nampodong6-Ga,Jung-Gu,Busan600-046,Korea
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
China
•Companyname:KongsbergMaritimeChinaLtd
•Address:555ChuanqiaoRoad,China(Shanghai)PilotFreeTradeZone,201206,China
•Telephone:[phone]
•Telefax:[phone]
SimradTP90InstallationManual

484238/A13
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
SimradTP90

14484238/A
InstallingtheTP90usingits
mountingbrackets
Thetransceivercanbeinstalledverticallyorhorizontallyusingtheintegratedmounting
brackets.
Prerequisites
AsuitablelocationfortheTP90mustbedenedpriortoinstallation.Theunitcanin
principlebemountedanywhereonboardtheshipprovidedthatthelocationisdryand
ventilated.Thephysicallengthofthecableslimitthedistancebetweeneachtransducer
andthetransceiver.
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethenormal
toolsforelectronicandelectromechanicaltasks.
Context
IfyoumounttheTP90onabulkhead,positiontheunitsothatalltheconnectorsarefacing
down.
Ensuremaximumphysicaldistancebetweenthetransceiverandthepowersupply.Thisis
importanttoreducenoise.
Procedure
1Observetheinstallationrequirements.
aThepositionmustbechosentottheavailablecablelengthsbetweenthe
transceiverandtheotherunitsitconnectsto.
bMakesurethatenoughspaceismadeavailableformaintenancepurposes.
cMakesurethatadequateventilationisavailabletoavoidoverheating.
dMakesurethattheinstallationmethodallowsforthephysicalvibration,
movementsandforcesnormallyexperiencedonavessel.
2Placetheunitintheselectedlocation.
SimradTP90InstallationManual

484238/A15
3Securetheunitusingfourboltsorscrews.
4Connectthecables.
Note
Whenyouconnectthecables,makesurethattheyareallproperlysecured,andable
towithstandthevibrationandmovementsofthevessel.
InstallingtheTP90usingitsmountingbrackets

16484238/A
Cablelayoutand
interconnections
Topics
Cableplan,page17
Listofcables,page18
Connectingthetransducer,page19
InstallingthePowerSupplyUnit,page22
SimradTP90InstallationManual

484238/A17
Cableplan
ThecablesareusedtoconnecttheTP90transceivertothecomputer,thePowerSupply
Unitandthetransducer(s).
ADisplay
BProcessorUnit
CTP90TransceiverUnit
DTransducer
EPowerSupplyUnit
Cablesidentiedwithanasterisk(*)aresystemorcommercialcables.Thesecablesare
providedinthedeliveryorwiththerelevantitem.
Cablelayoutandinterconnections

18484238/A
Listofcables
Asetofcablesisrequiredtoconnectthesystemunitstoeachother,andtotherelevant
powersource(s).AdditionalcablesarerequiredtoconnecttheTP90systemtoperipheral
devices.Cablenumbersnotshownarenotrelevantforthepurposeofthismanual.
Computercables
CableTypeFromToMinimumrequirements
C01ACPowercableComputerACpoweroutlet2x1.5mm2+1.5mm2Ground
C02ACPowercableDisplayACpoweroutlet2x1.5mm2+1.5mm2Ground
VideocableComputerDisplay C03
Thisisacommercialcable.Thedisplaycableisoftenphysicallyattachedtothedisplay,and
terminatedinthe“computerend”withamaleconnector.
C04SerialcableComputerExternaldevice(s)2x5x0.5mm2
C05EthernetcableComputerExternaldevice(s)Cat6STP(ShieldedTwisted
Pair)
C06EthernetcableComputerTP90Catch
Monitoring
Positioning
Transceiver
Cat6STP(ShieldedTwisted
Pair)
C07EthernetcableComputerSR70/SR75
ReceiverUnit
Cat6STP(ShieldedTwisted
Pair)
TP90CatchMonitoringPositioningTransceiverUnitcables
CableTypeFromToMinimumrequirements
C41SingleITI
transducercable
(380-109483)
TP90Catch
Monitoring
Positioning
Transceiver
Singletransducer
forTrawl
Positioning(TP)
C51DCPowercableTP90Catch
Monitoring
Positioning
Transceiver
PowerSupplyUnit
C52ACPowercablePowerSupplyUnitACpoweroutlet2x1.5mm2+1.5mm2Ground
SimradTP90InstallationManual
