Konica Minolta bizhub C364e/C284e/C224e
Specification & Installation Guide
1
bizhub C364e/C284e/C224e Specifications
Type Full Color Printer/Copier/Scanner
Document holder Stationary (mirror scanning)
Photoconductor OPC
Luminous source LED light-source illumination
Copying system Laser electrostatic copy method
Developing system Dry-2 component developing method
Fusing system Belt Fusing
Resolution Scanning: 600x600 dpi
Printing: 1200 x 1200 dpi
Document holder Types: Sheets, books (2-page spreads),
three-dimensional objects
Size: Maximum 11"x17"
Weight: 4.5 lb.
Paper Thin Paper (14 lb. to 15.5 lb.)*
Plain Paper (16 lb. to 24 lb.)
Thick Paper 1 (24.25 lb. to 32 lb.)
Thick Paper 1+ (32.25 lb. to 41.75 lb.)
Thick Paper 2 (42 lb. to 55.5 lb.)
Thick Paper 3 (55.75 lb. to 68 lb.)
Thick Paper 4 (68.25 lb. to 79.75 lb.)**
Recycled Paper (16 lb. to 24 lb.)
Special Paper (16 lb. to 24 lb.)
Letterhead (16 lb. to 24 lb.)
Color Paper (16 lb. to 24 lb.)
1-Sided Special Paper (16 lb.to 24 lb.)
Banner Paper** (34 lb. to 55.5 lb.)
OHP Transparencies**, envelopes**,
label sheets**, tabs**, postcards**
*Cannot be fed through the bypass tray.
**Can only be fed through the bypass tray; Monochrome
copying/printing on transparencies is supported. Color
copying/printing on transparencies is NOT supported.
Copy sizes 1st Tray:
11"x17" to 8.5"x11", 5.5"x8.5", 8"x13"*
2nd Tray:
12.25"x18" to 8.5"x11", 5.5"x8.5", 8"x13"*
Bypass Tray:
12"x18" to 5.5"x8.5", 12.25"x18", 4"x6",
8"x13"*, Banner Paper
*There are six Foolscap sizes: 220x330mm(L),
8.5"x13.5", 8.5"x13" (L), 8.25"x13 (L),
8.12"x13.25" (L) and 8"x13" (L). Any one of these
sizes can be selected. For details, please consult with
your authorized Konica Minolta Service representative.
Paper tray
capacity
1st Tray and 2nd Tray:
Thin Paper/Plain Paper/Recycled Paper/
Special Paper/Letterhead/Color Paper/
1-Sided Special Paper: 500 sheets;
Thick Paper 1/1+/2/3: 150 sheets
Paper tray
capacity (cont.)
Bypass Tray:
Plain Paper/Recycled Paper/Special Paper/
Letterhead/Color Paper/1-Sided Special
Paper: 150 sheets; Thick Paper 1/1+/2/3/4/
OHP Transparencies/Postcards/Tabs:20
sheets; Envelopes:10; BannerPaper/Label
Sheets: 10 sheets
Copy exit tray
capacity
Thin Paper: 100 sheets
Plain Paper: 250 sheets
Thick Paper: 10 sheets
Overhead Projection
Transparencies*: 1 sheet
*Can only be fed through the bypass tray; Monochrome
copying/printing on transparencies is supported. Color
copying printing on transparencies is NOT supported.
Warm-up time Color and BW less than 20 seconds
(at room temperature/73.4° F)
Image loss width Leading edge: 0.1875"
Trailing edge: 0.125"
Rear edge: 0.125"
Front edge: 0.125"
First copy C364e: Color: 6.9 sec. or less
B/W: 5.3 sec. or less
C284e: Color: 7.7 sec. or less
B/W: 5.9 sec or less
C224e: Color: 8.3 sec. or less
B/W: 6.9 sec or less
Print speed*:
(Full Color/B&W)
(Simplex/Duplex)
bizhub C364e:
Plain paper: 36 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
18 sheets/min.
bizhub C284e:
Plain paper: 28 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
14 sheets/min.
bizhub C224e:
Plain paper: 22 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
14 sheets/min.
Print speed (ppm)*: Color/B&W (single sided/plain paper):
Size C364e C284e C224e
11"x17" 18 14 14
8.5"x14" 20 16 16
8.5"x11"P36 28 22
8.5"x11"L26 20 20
5.5"x8.5"L36 28 22
8"x13"L20 16 16
*Using 1st Tray
continued
04/08/2013

2
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
bizhub C364e/C284e/C224e Specifications continued
Print speed (ppm)*:
continued
Color/B&W (double sided/plain paper):
Size C364e C284e C224e
11"x17" 18 14 14
8.5"x14" 20 16 16
8.5"x11"P36 28 22
8.5"x11"L25 20 20
5.5"x8.5"L36 28 22
8"x13"L20 16 16
*Using 1st Tray
Magnification
ratios
1.0 (full size: 1.00+_0.5% or less)
Enlarge: 121.4%, 129.4%, 154.5%, 200%
Reduce: 78.5%, 73.3%, 64.7%, 50.0%
Minimal: 93%
Stored Zoom Ratios: 3
"Minimal" zoom ratio (90% to 99.9%)
Multiple copies 1 to 9,999 sheets
Density control Copy Density: Manual Density Adjustment
(9 Levels); Background Density: Automatic
and Manual Density Adjustments (9 levels)
Power
requirements
120V, 12 A, 60 Hz
Power
consumption
1.5 kW or less
TEC Value C364e: 2.12 kWh
C284e: 1.65 kWh
C224e: 1.25 kWh
Dimensions
(with control panel)
24.2" (W)x27" (D) x31" (H)
Space requirements* 36.9" (W)x47.8" (D) x 30.7" (H)
Memory (available
hard disk space)
2 GB, (250 GB HDD) (std); 2 GB (opt).
Weight Approx. 185.18 lb.
* The indicated space requirements represent the space required to pull out
thepaper tray and the tray extension of the bypass tray and with the ADF open.
Duty Cycle
Up to C364e: 125,000, C284e: 100,000, C224e: 80,000.
Maximum monthly copy/print volume supported under
standard vendor supplied service. Defines the upper
end of the expected customer volume for the device.
Customers should consider multiple machines if average
monthly volume approaches duty cycle on continual basis.
Environmental Requirements
Temperature 50° F to 86° F
Humidity 15% to 85%
Noise during operation (BW/Color) C364e: 71.6 dB/71.8 dB
C284e: 68.8 dB/69.4 dB
C224e: 66.7 dB/67.6 dB
Noise during feeder operation
(FS-534/FS-533)
C364e: 69.2 dB or less
C284e: 68.0 dB or less
C224e: 67.6 dB or less
Noise during standby 40.5 dB or less
Ozone emission Color: 3.0 mg/h
Color: 1.5 mg/h
Electrical Requirements
Line Options Dedicated NEMA Diagram for 5-15R
Voltage: 110 V/120
to 127 V/220
to 240 V AC
Amperage 12 A
Cycles 60 Hz
NEMA Part No: 5-15R
Cord Length 6.6 ft.
Note: The main electrical outlet must be located within 6.6 feet from the right rear
corner of the bizhub C364e/C284e/C224e main unit.

3
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
bizhub C364e/C284e/C224e + DF-624 + PC-210 + FS-534 + SD-511
62.88" (1597)
26.00" (660) 36.88" (937)
Unit: inch (mm
)
48.81" (1240)
61.00" (1550)
35.69" (906)
15.69"
(398)
16.88"
(428) 31.94" (812)
9.69"
(246)
bizhub C364e/C284e/C224e + DF-624 + PC-210 + FS-533
6.69"
(170)
43.56" (1107)
Unit: inch (mm
)
bizhub C364e/C284e/C224e + DF-624 + PC-210 + JS-506 + MK-730
34.13" (867)
11.63"
(295)
45.75" (1162)
Unit: inch (mm)
NOTICE: Be sure to allow a clearance of 8 inches (200 mm) or more at the back of this machine for the ventilation duct.
48.81" (1240)
16.88"
(428) 31.94" (812)
48.81" (1240)
16.88"
(428) 31.94" (812)
36.88" (937)
61.00" (1550)
35.69" (906)
15.69"
(398)
9.69"
(246)
61.00" (1550)
35.69" (906)
15.69"
(398)
9.69"
(246)
Space Requirements

4
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
Component Considerations
Automatic Duplex Unit (Standard)
Support Paper Type Thin Paper (14 lb. to 15.5 lb.)
Plain Paper (16 lb. to 24 lb.)
Thick Paper 1 (24.25 lb. to 32 lb.)
Thick Paper 1+ (32.25 to 41.75 lb.)
Thick Paper 2 (42 lb. to 55.5 lb.)
Thick Paper 3 (55.75 lb. to 68 lb.)
Recycled Paper (16 lb. to 24 lb.)
Special Paper (16 lb. to 24 lb.)
Letterhead (16 lb. to 24 lb.)
Color Paper (16 lb. to 24 lb.)
Support Paper Size 12.25"x18" to 5.5"x8.5"; 4"x6"; SRA3; 8"x13"*;
Custom: (W) 3.9" to12.625" x (L) 5.8" to18"
Power Requirements Supplied from main unit
*There are six Foolscap sizes: 220x330mm (L), 8.5"x13.5", 8.5"x13" (L), 8.25"x13 (L), 8.12"x13.25" (L) and 8"x13" (L).
Any one of these sizes can be selected. For details, please consult with your authorized Konica Minolta Service
representative.
OC-511 Original Cover
Type Original Cover/Platen Cover
DF-701 Dual Scanner Document Feeder
Type Single Pass Duplex Document Feeder
Support Paper Size 1-Sided/2-Sided Originals/Mixed Originals: 11" x 17"Lto 5.5" x 8.5"P
Support Paper Weight Single-Sided/Double-Sided: 9.25 lb. bond to 44 lb. bond
Mixed Original: 13.5 lb. bond to 34 lb. bond
1-Sided Thin Paper (9.25 lb. to 13.063 lb.)
1-Sided Plain Paper (13.25 lb. to 44 lb.)
2-Sided Plain Paper (13.25 lb. to 44 lb.)
Mixed Original Plain Paper (13.25 lb. to 34 lb.)
Paper Capacity Max. 100 sheets (21.25 Ib.)(Single-Sided/Double-Sided Originals)
Paper Transfer Speed 80 image/min (one-sided @ 300 dpi) (B&W/CoIor)
160 image/min (two-sided @ 300 dpi) (B&W/CoIor)
Power Requirements Supplied from main unit.
Max. Power Consumption 74.5 W or less
Dimensions WxDxH 24.1" x 19.8" x 5.6"
Weight Approximately 26.5 lb.
AU-202H AU-204H
KP-101
AU-211P
AU-202H AU-204H
KP-101
AU-211P
AU-202H AU-204H
KP-101
AU-211P

Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
5
Component Considerations
DF-624 Reversing Automatic Document Feeder
Type Reversing Automatic Document Feeder
Support Paper Size 1-Sided/2-Sided Originals/Mixed Originals: 11" x 17"Lto 5.5" x 8.5"P
Support Paper Weight Single-Sided/Double-Sided: 9.25 lb. bond to 34 lb. bond
Mixed Original: 13.5 lb. bond to 34 lb. bond
1-Sided Thin Paper (9.25 lb. to 13.063 lb.)
1-Sided Plain Paper (13.25 lb. to 34 lb.)
2-Sided Plain Paper (13.25 lb. to 34 lb.)
Mixed Original Plain Paper (13.25 lb. to 34 lb.)
Paper Capacity Max. 100 sheets (21.25 Ib.)(Single-Sided/Double-Sided Originals)
Paper Transfer Speed 80 image/min (one-sided @ 300 dpi) (B&W/CoIor)
37 image/min (two-sided @ 300 dpi) (B&W/CoIor)
Power Requirements Supplied from main unit.
Max. Power Consumption 60.0 W or less
Dimensions WxDxH 24.1" x 19.8" x 5.6"
Weight Approximately 19.75 lb.
AU-202H AU-204H
KP-101
AU-211P

6
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
Component Considerations continued
FK-511 Fax Kit
Memory Size 2048 MB (Standard)
Number of Stored Pages 10,000 Pages (approx. 700 characters per page when 8.5" x 11"
document is stored using fine resolution)
Number of Fax Lines 1 Fax Line (Standard); Add second FK-511 Fax Kit for dual line
faxcapabilities.
Communication ECM/Super G3
Compatible Lines PSTN, PBX
Scanning Line Density Ultra Fine: 600 x 600 dpi
Super Fine: 16 dot/mm x 15.4 line/mm, 400 x 400 dpi
Fine: 8 dot/mm x 7.7 line/mm, 200 x 200 dpi
Normal: 8 dot/mm x 3.85 line/mm
Modem Speed 2.4 kbps-33.6 kbps
Compression MH/MR/MMR/JBIG
Scanning/(Sending) Original Glass: Max. 11"x17"
Paper Size ADF: 11" x 39" (Normal, Fine, Super Fine)
11" x 17" (Ultra Fine, Manual TX)
Recording Paper Size 11"x17" to 5.5"x8.5"
Transmission Speed Less than 3 sec. (V.34, 33.6 Kbps, JBIG)
Scan Speed 2 sec. (Letter/Fine Mode)
Number of Abbr. Dial 2000
Number of Program Dial 400
Number of Group Dial 100 (Up to 500 destinations per group)
Sequential Multiple Max. 600
Station Transmission
Transmitting Functions 2-in-1 TX, Mixed Original, F-Code Transmission, Frame Erase
Transmission, Sharpness, Header/Footer, Memory Transmission,
Quick Memory Transmission, Timer Transmission, Incomplete
Transmission Hold, Manual Transmission, Confidential Transmission,
Password Transmission, Polling Transmission, Bulletin Function,
Relay Transmission, Fax Forwarding Function, Overseas TX, V.34
OFF, ECM OFF
Receiving Functions Duplex Print (RX), Manual Reception, Confidential Reception, Memory
Reception, Polling Reception, Bulletin Function, Fax Forwarding (to
any destination stored in the Address Book), TSI Routing (to any
destination stored in the Address Book).
AU-202H AU-204H
KP-101
AU-211P

Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
7
Component Considerations
FS-534 Staple Finisher (50 sheets)
Type Staple Finisher
Output Trays Output Tray 1, Output Tray 2, Folding Output Tray (Top of RU unit)
Support Paper Type Output Tray 1 & Output Tray 2:
Thin Paper (14 lb. to 15 lb.), Plain Paper (16 lb. bond to 24lb. bond),
Recycled Paper (16 lb. to 24 lb.), Thick Paper 1/1+/2/3 (24.25 lb. bond
to 79.75 lb. bond), OHP Transparencies, Postcards*, Envelopes*,
LabelSheets*, Letterhead*, Tabs*, Banner Paper*.
Staple Settings: Thin Paper (14 lb. to 15 lb.), Plain Paper (16 lb. bond
to 23.94 lb. bond), Recycled Paper (16 lb. to 24 lb.), ThickPaper1
(24.25 lb. bond to 32 lb. bond), Thick Paper 1+ (32.25 lb. to 41.75lb.),
Thick Paper 2 (42 lb. to 55.5 lb.)
* Fed into Output Tray 1
Support Paper Size Output Tray 1: 12.25"x18", 11"x17" to 5.5" x 8.5"L/P
Output Tray 2: Group/Sort: 12.25"x18", 11"x17", 5.5" to 8.5"L/P
Offset Group/Offset Sort: 12.25"x18", 11" x 17" to 5.5" to 8.5", SRA3
Width: 7.188" to 12.625"; Length 5.875" to 18"
Staple: 11"x17" to 7.25" x 10.5"L/P
Width: 7.188" to 11.688"; Length 5.875" to 17"
Folding Output Tray:
12.25" x 18", 11" x 17" to 5.5" x 8.5"L/P
Width: 3.5" to 12.5"; Length 5.5" to 18"
Mode Non-Sort, Sort, Group, Sort/Offset, Group/Offset, Sort and Staple
Stacking Capacity Output Tray 1: Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 lb. to 24 lb.):
200 sheets. Thick Paper (24.25 to 79.75lb.), OHP Transparencies,
Postcards, Envelopes or Label Sheets, Letterheads, Tabs: 20 sheets
Output Tray 2 – Group/Sort Mode: Plain Paper (16 lb. to 24 lb.): 3,000
sheets of 8.5" x 11" or smaller, or 1,500 sheets of 8.5" x 14" orlarger;
or 500 sheets of 5.5" x 8.5" or smaller.
Thick Paper (24.25 to 79.75 lb.), OHP Transparencies, Postcards,
Envelopes, Labels, Letterheads, Tabs: 20 sheets
2nd Tray – Offset Group/Offset Sort:
3,000 sheets (8.5" x 11" or smaller); 1,500 sheets (8.5" x 14" orlarger);
500 sheets (5.5" x 8.5" or larger)
Thin Paper (14 lb. to 15 lb.)
Plain Paper (16 lb. to 24 lb.)
Recycled Paper (16 lb. to 24 lb.)
Thick Paper (24.25 lb. to 79.75 lb.), OHP Transparencies, Postcard,
Envelope, Label sheets, Letterhead, Tabs: 20 sheets
Staple
Thin Paper (14 lb. to 15 lb.): 50 sheets
Plain Paper (16 lb. to 24 lb.): 50 sheets
Recycled Paper (16 lb. to 24 lb.): 50 sheets
Thick Paper (24.25 lb. to 32 lb.): 30 sheets
Thick Paper 1+ (32.25 lb. to 41.75 lb.): 30 sheets
Thick Paper 2 (42 lb. to 55.5 lb.): 20 sheets
2–9 Sheets: 100 Sets
10–20 Sheets: 50 Sets
21–30 Sheets: 30 Sets
31–40 Sheets: 25 Sets
41–50 Sheets: 20 Sets
Folding Output Tray: 100 sheets
Thin Paper (14 lb. to 15.5 lb.)
Plain Paper (16 lb. to 24 lb.)
Recycled Paper (16 lb. to 24 lb.)
Thick Paper (24.25 lb. to 79.75 lb.): 20 sheets
Staple Mode Paper Sizes: 8.5" x 11" to 11" x 17"; Corner, 2 Position (Side, Top)
continued
AU-202H AU-204H
KP-101
AU-211P

8
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
Component Considerations continued
FS-534 Staple Finisher continued
Available Options PK-520 Punch Kit (2/3-hole Punch), Saddle Stitcher SD-511
Power Requirements Supplied from Main Unit
Max. Power Consumption Less than 56 W
Dimensions (W x D x H) 20.81" x 25.25" x 40.25" (When tray is pulled out 25.88" (W))
Weight Approx. 88.188 lb.
Consumables SK-602 Staples (5,000 Staples x 3)
NOTE: FS-534 supports banner printing when installed on C754/C654/C364e/C364/C284e/C284/C224e/C224/754/654.
FS-533 Inner Finisher (Staple Function only) (50 sheets)
Type Inner Staple Finisher
Output Trays Output Tray 1
Support Paper Types Group/Sort: Thin Paper (14 lb. to 15 lb.), Plain Paper (16 lb. bond to
24lb. bond), Recycled Paper (16 lb. to 24 lb.), Thick Paper (24.25 lb.
bond to 79.75 lb. bond), OHP Transparencies, Postcards, Envelopes,
LabelSheets, Letterhead, Tabs, Banner Paper.
Offset Group, Offset Sort: Thin Paper (14 lb. to 15 lb.), Plain Paper (16lb.
bond to 24lb. bond), Recycled Paper (16 lb. to 24 lb.), Thick Paper
(24.25 lb. bond to 79.75 lb. bond)
Staple Settings: Thin Paper (14 lb. to 15 lb.), Plain Paper (16 lb. bond to
23.94 lb. bond), Recycled Paper (16 lb. to 24 lb.), ThickPaper(24.25 lb.
bond to 55.25 lb. bond)
Mode Group, Sort, Offset Group, Offset Sort, Staple
Support Paper Size Group/Sort: 12.25"x18"L, 11"x17"Lto 5.5" x 8.5"L/P, 4" x 6"L,
SRA3L
Width: 3.56" to 12.625"; Length: 5.5" to 47.25"
Offset Group/Offset Sort: 12.25" x 18"L, 11" x 17"L, 8.5" x 11"L/P,
7.25" x 10.5"P
Width: 8.25" to 11.69"; Length: 7.17" x 17"
Staple: 11" x 17"L, 8.5" x 14"L, 8.5" x 11"L/P, 7.25" x 10.5"P
Width: 8.25" to 11.69"; Length: 7.17" x 17"
Stacking Capacity Group, Sort, Offset Group, Offset Sort: Thin Paper (14 lb. to 15 lb.),
PlainPaper (16 lb. bond to 24lb. bond), Recycled Paper (16 lb. to 24 lb.):
500 sheets of 8.5" x 11" or smaller; or250 sheets of 8.5" x 14" orlarger
Thick Paper (24.25 lb. bond to 79.75 lb. bond), OHP Transparencies,
Postcards, Envelopes, LabelSheets, Letterhead, Tabs, Banner Paper:
10 sheets
Staple: Thin Paper (14 lb. to 15 lb.), Plain Paper (16 lb. bond to 24lb. bond),
Recycled Paper (16 lb. to 24 lb.): 50 sheets of 8.5" x 11" or smaller;
or30sheets of 8.5" x 14" or larger
Thick Paper (24.25 lb. bond to 55.5 lb. bond): 2 sheets
Staple Mode Corner Front / Back 2-point
Available Options PK-519 Punch Kit (2-3-hole Punch)
Power Requirements Supplied from Main Unit
Max. Power Consumption Less than 40W
Dimensions (W x D x H) 18.6" x 23" x 7.7"
Weight Approx. 26.5 lb.
Consumables SK-602 Staples (5,000 Staples x 3)
AU-202H AU-204H
KP-101
AU-211P
AU-202H AU-204H
KP-101
AU-211P

Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
9
Component Considerations
PK-519 Punch Kit (For FS-533)
Applicable Finisher FS-533
Number of holes 2 or 3 holes
Support Paper Weight Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 lb. to 24 lb.),
Thick paper (24.25 lb. bond to 79.75 lb. bond)
Support Paper Size 2-hole Punch Setting: 11" x 17", 8.5" x 14", 8.5" x 11"
3-hole Punch Setting: 11" x 17", 8.5" x 11"
Power Requirements Supplied from Finisher FS-533
Dimensions (WxDXH) 4.33" x 19.03" x 8"
Weight Approx. Approx. 7 lb.
PK-520 Punch Kit (For FS-534)
Applicable FS-534
Number of holes 2 or 3 holes
Support Paper Weight Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 lb. bond to 24 lb. bond),
Recycled Paper (16 lb. to 24 lb.),
Support Paper Size 2-hole Punch Setting: 11" x 17", 8.5" x 14", 8.5" x 11"
3-hole Punch Setting: 11" x 17", 8.5" x 11"
Power Requirements Supplied from Finisher FS-534
Dimensions (W x D x H) 2.375"x 19.375" x 5.563"
Weight Approx. Approx. 3.938 lb.
SD-511 Saddle Stitcher (For FS-534)
Applicable FS-534
Number of bins 1 Tray
Paper types Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 to 24 lb),
Thick Paper 1/1+/2 (24.25 to 55.5 lb.)*
*Can only be used as a cover page.
Paper sizes 12.25" x 18"L, 11" x 17", 8.5" x 14" L, 8.5" x 11",
Number of Center Stapled Plain Paper (16 to 24 lb.)
or Half-Folded Sheets 1–3 Sheets: 20 Sets
4–10 Sheets: 10 Sets
11–20 Sheets: 5 Sets
Number of 1 Sheet: 30 Sets
Tri-Folded Sheets 2–3 Sheets: 10 Sets
Staple mode Booklet, 2-point staple
Maximum staple sheet 20 sheets: (19 sheets/14 to 24lb.) + (1 sheet/13 to 55.5 lb.)
Dimensions (W x D x H) 8.25" x 21.88" x 21.56"
Weight 52.94 lb.
Consumables SK-602 (5,000 x 3 pkg/case)
Power requirements Supplied from finisher
AU-202H AU-204H
KP-101
AU-211P
AU-202H AU-204H
KP-101
AU-211P
AU-202H AU-204H
KP-101
AU-211P

10
Konica Minolta bizhubC364e/C284e/C224e
Specification & Installation Guide
Component Considerations continued
JS-506 Job Separator Tray
Output tray Output Tray 1, Output Tray 2
Mode Group, Sort, Offset Group*, Offset Sort*
* Fed into Output Tray2
Support Paper Types Group/Sort: Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 lb. bond to
24lb. bond), Recycled Paper (16 lb. to 24 lb.), Thick Paper (24.25 lb.
bond to 79.75 lb. bond), OHP Transparencies, Postcards*, Envelopes,
LabelSheets, Letterhead, Tabs*, Banner Paper*.
Offset Group, Offset Sort: Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16
lb. bond to 24lb. bond), Recycled Paper (16 lb. to 24 lb.), Thick Paper
(24.25 lb. bond to 79.75 lb. bond)
* Fed into Output Tray 2
Support Paper Size Output Tray 1: 12.25"x18"L, 11"x17"L to 5.5" x 8.5"L/P, SRA3L
Width: 3.56" to 12.625"; Length: 5.5" to 18"
Output Tray 2: Group/Sort: 12.25"x18"L, 11"x17"Lto 5.5" x 8.5"L/P,
4" x 6"L, SRA3L
Width: 3.56" to 12.625"; Length: 5.5" to 47.25"
Offset Group/Offset Sort: 11" x 17"L, to 7.25" x 10.5"L/P
Width: 7.17" to 12.25"; Length: 5.8" to 18"
Stacking Capacity Output Tray 1: Thin Paper (14 lb. to 15.5 lb.), Plain Paper (16 lb. bond
to24lb. bond),
Recycled Paper (16 lb. to 24 lb.): 100 sheets
Output Tray 2: Group/Sort: Thin Paper (14 lb. to 15.5 lb.), Plain Paper
(16lb. bond to 24lb. bond),
Recycled Paper (16 lb. to 24 lb.): 150 sheets; Thick Paper (24.25lb.
bond to 79.75 lb. bond), Transparency, Postcard, Label sheets:
20Sheets; Envelope: 10 Sheets; Banner Paper: 1 Sheet
Offset Group/Offset Sort: Thin Paper (14 lb. to 15.5 lb.), Plain Paper
(16lb. bond to 24lb. bond),
Recycled Paper (16 lb. to 24 lb.): 150 sheets; Thick Paper (24.25 lb.
bond to 79.75 lb. bond): Not specified
Power Requirements Supplied from Main Unit
Max. Power Consumption Less than 24W
Dimensions (W x D x H) 19.4" x 18.5" x 8.9"
Weight Approx. 3.3 lb.
AU-202H AU-204H
KP-101
AU-211P
