Konica Minolta AccurioPress C3080 User manual

AccurioPress
C3080/C3080P/C3070
AccurioPrint C3070L
Colour produCtion printing system
Quick GuiDE

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L Contents-1
Contents
1Introduction
1.1 Welcome .......................................................................................................................................... 1-3
1.2 Notations and symbols used in this manual................................................................................. 1-3
1.3 Intended use of this machine......................................................................................................... 1-4
1.3.1 Intended use .......................................................................................................................................1-4
1.3.2 Impermissible operating conditions....................................................................................................1-4
1.3.3 Exclusion of liability.............................................................................................................................1-4
1.4 Target groups.................................................................................................................................. 1-4
1.5 Configuration and Usage of this Guide......................................................................................... 1-5
1.5.1 HTML User's Guide operating environment .......................................................................................1-5
1.5.2 How to display the top page of the HTML User's Guide....................................................................1-6
1.5.3 Conventions used in this guide...........................................................................................................1-6
2 Before Getting Started
2.1 Turning the Power ON/OFF............................................................................................................ 2-3
2.2 Available Operations in this Machine.......................................................................................... 2-12
2.2.1 Major functions of this machine........................................................................................................2-12
2.2.2 Application functions (Image Controller IC-605)...............................................................................2-15
2.2.3 Application functions (Image Controller IC-417 / Image Controller IC-313) .....................................2-15
2.2.4 Application functions (Image Controller IC-314)...............................................................................2-16
3 Let's Make Prints
3.1 Printing Flow.................................................................................................................................... 3-3
3.1.1 Step 1: Prepare the printer driver and applications ............................................................................3-3
3.1.2 Step 2: Load paper into a tray ............................................................................................................3-3
3.1.3 Step 3: Configure information of the paper loaded into a tray in this machine ..................................3-3
3.1.4 Step 4: Use the printer driver to print data .........................................................................................3-4
3.1.5 Step 5: Check the finishing.................................................................................................................3-4
4 Basic Operations
4.1 Loading Paper ................................................................................................................................. 4-3
4.1.1 Loading paper into the main body tray...............................................................................................4-3
4.1.2 Loading paper into the Paper Feeder Unit PF-602m..........................................................................4-5
4.1.3 Loading Paper in Post Inserter of Folding Unit FD-503......................................................................4-6
4.2 Paper Setting................................................................................................................................... 4-7
4.2.1 Specifying paper information for a tray...............................................................................................4-7
5 Troubleshooting
5.1 Replenish and Replace Consumables .......................................................................................... 5-3
5.2 Clearing Paper Jams ...................................................................................................................... 5-9
5.2.1 How to view the animation guide........................................................................................................5-9
5.3 If the Specified Paper is not Found ............................................................................................. 5-12
5.4 Cannot Send Data......................................................................................................................... 5-16
5.5 Hue Adjustment............................................................................................................................. 5-17
5.6 Image Position Adjustment.......................................................................................................... 5-17
5.7 If you forget the administrator password ................................................................................... 5-17

Contents-2 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
6 Appendix
6.1 Good Use of the [HTML User's Guide].......................................................................................... 6-3
6.2 Name of each Component ............................................................................................................. 6-4
6.2.1 External components ..........................................................................................................................6-4
6.2.2 Internal components ...........................................................................................................................6-9
6.2.3 Control Panel Layout ........................................................................................................................6-11

1Introduction

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 1-3
1.1 Welcome 1
1Introduction
1.1 Welcome
Thank you for purchasing this machine.
This [Quick Guide] describes basic operations, maintenance, troubleshooting for this machine.
This information will be useful to enable the full capabilities of this machine and to utilize such functionality
efficiently.
Please keep this manual in a safe place where you can access it easily.
1.2 Notations and symbols used in this manual
7WARNING
-This symbol indicates that negligence of the instructions may lead to death or serious injury.
7CAUTION
-This symbol indicates that negligence of the instructions may lead to mishandling that may cause injury
or property damage.
NOTICE
This symbol indicates a risk that may result in damage to this machine or originals.
Follow the instructions to avoid property damage.
Tips
This symbol indicates information that complements the topic or optional devices required to use a certain
function.
dReference
This symbol indicates a function or functions that are related to the topic.
The meaning of other notations and symbols are as follows.
Notation/Symbol Description
[ ] These brackets indicate the name of a key on the touch panel, or of a
button on a computer screen, or of a title of a manual.
Bold Words in bold type indicate the name of a part, an option, or a key on
the control panel.
0This check mark indicates a prerequisite of a procedural step.

1-4 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Intended use of this machine
11.3
1.3 Intended use of this machine
1.3.1 Intended use
This machine is designed to be used as a digital printing system for the following purposes:
-Print, copy, and scan documents.
-Use available finishing functions such as duplexing, stapling, hole-punching, multi-folding and booklet
creation if appropriate options are installed.
-Store documents to reprint on the HDD of this machine.
The intended use also requires that:
-The system is used within the limits of device specifications and specifications of optional components,
-All safety instructions in the related user's guides are observed,
-Legal restrictions on copying or printing are observed (refer to instruction booklet [Safety Information]),
-Inspection and maintenance instructions are adhered to,
-General, national and company safety provisions are observed.
1.3.2 Impermissible operating conditions
The system may not be operated if:
-Errors or damage have been discovered,
-Maintenance intervals have been exceeded,
-Mechanical or electrical functions do not work as they should.
1.3.3 Exclusion of liability
The manufacturer of the system assumes no liability for damages if the system was operated under imper-
missible conditions.
1.4 Target groups
The user's guides are intended for the following users of the system:
-Operator: Person who has been trained by Konica Minolta or authorized partner to operate the system
for its intended use as well as manage consumables, and perform the maintenance and troubleshooting
described in user's guides.
-Administrator: Person who has been trained by Konica Minolta or authorized partner to manage con-
sumables, adjust system settings, and establish network connections and security systems.
Everyone who uses this system must have read and understood the related user's guides.

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 1-5
1.5 Configuration and Usage of this Guide 1
1.5 Configuration and Usage of this Guide
The User's Guide for this machine consists of the manuals below.
When you want to learn about detailed functions or operation procedures, refer to the [HTML User's Guide].
For information about how to use the [HTML User's Guide], refer to "6 Appendix" in this guide.
Note that basic technical knowledge about the machine is required to enable users to perform maintenance
work or troubleshooting operations. Maintenance and troubleshooting operations should be carried out as
instructed in this guide and the [HTML User's Guide].
Should you experience any problems, contact your service representative.
1.5.1 HTML User's Guide operating environment
Supported Operating Systems/Browsers
This guide describes the operation verification in the operating systems and browsers shown below.
Tips
-Check that [JavaScript] of your Web browser is enabled. The [HTML User's Guide] uses [JavaScript] for
the page display or search function.
-Note that some of the functions may not work normally depending on your system environment. Please
be forewarned.
-Problems may be able to be solved by using the latest Web browser.
Display resolution
1,024 e768 pixels or more
Title of manual Overview
[Safety Information] This guide provides precautions and requests that should be fol-
lowed to ensure safe usage of this machine.
Read this guide before using the machine.
[HTML User's Guide] This manual describes the basic operations, functions that enable
operations to be more convenient, maintenance procedures, sim-
ple troubleshooting operations, and various setting methods of this
machine.
Operating system Web browser
Windows 7 (Service Pack 1) Internet Explorer 11.x
Firefox 55.x
Chrome 61.x
Windows 8.1 Internet Explorer 11.x
Firefox 55.x
Chrome 61.x
Windows 10 Internet Explorer 11.x
Microsoft Edge 40
Firefox 55.x
Chrome 61.x
Mac OS 10.8 Safari 6.x
Mac OS 10.9 Safari 7.x
Mac OS 10.10 Safari 8.x
Mac OS 10.11 Safari 9.x
Mac OS 10.12 Safari 10.x

1-6 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Configuration and Usage of this Guide
11.5
1.5.2 How to display the top page of the HTML User's Guide
Double-click [index.html] in the [HTML User's Guide] folder to display the top page.
1.5.3 Conventions used in this guide
This guide describes product names and system configurations as follows.
Optional products are described with no model number added as follows unless otherwise specified.
The convention above is also applied to other optional devices.
NOTICE
The Image Controller IC-313 / Image Controller IC-314 is not compatible with the AccurioPrint C3070L.
Product name Conventions used in this guide
AccurioPress C3080
AccurioPress C3080P
AccurioPress C3070
AccurioPrint C3070L
This machine: Indicates the entire system including options
and functions.
The main body: Indicates the main unit that provides print
functions in this machine.
The machine: Indicates a mechanical part related to the struc-
ture or mechanism.
AccurioPress C3080P Printer model
Microsoft Windows Windows
Product name Conventions used in this guide
Image Controller IC-605
Image Controller IC-417
Image Controller IC-313
Image Controller IC-314
Image controller
Dual Scan Document Feeder DF-706 ADF
Saddle Stitcher SD-506
Saddle Stitcher SD-510
Saddle Stitcher SD-513
Saddle Stitcher

2Before Getting Started

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 2-3
2.1 Turning the Power ON/OFF 2
2 Before Getting Started
2.1 Turning the Power ON/OFF
Power supply
This machine has two power switches: main power switch and sub power switch.
NOTICE
The main power switch is normally kept turned on.
The main power switch must be turned on or off only when you start this machine for the first time or when
you restart this machine.
Turning the power on
1Open the front door of the main body, then turn the main power switch on.
When the main power switch is turned on, the Power LED on the control panel lights up in orange.
2Turn on the sub power switch on the upper-right corner of the main body.
When the sub power switch is turned on, the Power LED on the control panel lights up in blue.
After the start screen has been displayed, the
default screen is displayed.
The default screen can be selected from Utili-
ty/Counter. For details, refer to the [HTML Us-
er's Guide].
When [Ready to print] is displayed on the [MA-
CHINE] screen, you can use this machine.
OFF OFF
ON
ON

2-4 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Turning the Power ON/OFF
22.1
3For Image Controller IC-417/Image Controller IC-313/Im-
age Controller IC-314, turn the image controller on.
NOTICE
After this machine has started completely, turn the image con-
troller on.
%For Image Controller IC-417, turn the power switch in the
rear side on ( ), then press the button on the top of the
power switch ( ).
%For Image Controller IC-313, turn the power switch in the
rear side on ( ), then press the power button in the front
side ( ).
OFF
ON
OFF
ON

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 2-5
2.1 Turning the Power ON/OFF 2
%For Image Controller IC-314, open the front door and
press the Power controller button.
[Windows] starts, and after a while, the [workspace] screen is
displayed.
Wait until the [workspace] screen is displayed.
Tips
-If [Machine is warming up] is displayed on the [MACHINE] screen, it indicates that this machine is in the
warm-up state. Warm-up processing takes approximately 6.5 minutes.
Turning the power off (Image Controller IC-605)
1Turn off the sub power switch.
The touch panel display is cleared, and the Power LED on
the control panel is changed from blue to orange.
NOTICE
While the following message is displayed, do not turn off the
main power switch. Otherwise, a problem such as a toner fix-
ation in the machine may occur.
[Cooling in progress / Power is turned off automatically]
[Power off in progress / Please do not turn the main power off]
2Turn off the main power switch.
NOTICE
When turning the main power switch off then on, be sure to
wait for 10 seconds or longer before turning the main power
switch on again. If the main power switch is turned on again
within 10 seconds, the machine may not function normally.
OFF
ON
OFFON

2-6 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Turning the Power ON/OFF
22.1
Turning the power off (Image Controller IC-417)
1On the [MACHINE] screen, press [Controller].
2Press [Login].
3Select [Administrator] or [Operator], enter the password, then press [Login].
The default password is "Fiery.1". If you select [Operator], you do not need to enter the password.
4Press [Waiting Jobs].
5Press the [Tools] tab.
6Press [Restart Server].
7Press [Shut Down System].
8Press [Exit].
NOTICE
While the following message is displayed, do not quit the system. Otherwise, a problem such as a toner
fixation in the machine may occur.
[Cooling in progress / Power is turned off automatically]
[Power off in progress / Please do not turn the main power off]
9After the system has quit, turn off the sub power switch.
The touch panel display goes off, and the Power LED on the
control panel is changed from blue to orange.
OFF
ON

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 2-7
2.1 Turning the Power ON/OFF 2
10 Turn off the main power switch.
NOTICE
When turning the main power switch off then on, be sure to
wait for 10 seconds or longer before turning the main power
switch on again. If the main power switch is turned on again
within 10 seconds, the machine may not function normally.
11 Turn the power switch in the rear side off.
NOTICE
After this machine has exited completely, turn Image Control-
ler IC-417 off.
OFFON
OFF
ON

2-8 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Turning the Power ON/OFF
22.1
Turning the power off (Image Controller IC-313)
1Turn off the sub power switch.
The touch panel display is cleared, and the Power LED on
the control panel is changed from blue to orange.
NOTICE
While the following message is displayed, do not turn off the
main power switch. Otherwise, a problem such as a toner fix-
ation in the machine may occur.
[Cooling in progress / Power is turned off automatically]
[Power off in progress / Please do not turn the main power off]
2Turn off the main power switch.
NOTICE
When turning the main power switch off then on, be sure to
wait for 10 seconds or longer before turning the main power
switch on again. If the main power switch is turned on again
within 10 seconds, the machine may not function normally.
3Press the Menu button on the control panel ( ), press row
selection button 4, then select [Shut Down System] ( ).
NOTICE
After this machine has exited completely, turn the Image Con-
troller system off.
4When the system has quit, turn the power switch in the rear
side off ( ).
OFF
ON
OFFON
OFF
ON

AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L 2-9
2.1 Turning the Power ON/OFF 2
Tips
The Image Controller IC-313 can reset Fiery software or restart the entire system as needed.
-To reset only the Fiery software, press the Menu button on the control panel, then use the row selection
button to select [Restart Server] - [Restart Server] in sequence. In this case, do not reboot the Windows
operating system.
-To reboot the entire system including the Windows operating system, press the Menu button on the
control panel, then use the row selection button to select [Restart Server] - [Reboot System] in se-
quence.
-You can set the Image Controller IC-313 to turn on or off at the same time when the power of the main
body is turned on or off. For details, refer to the User's Guide for the Fiery Color Server.
Turning the power off (Image Controller IC-314)
1Turn off the sub power switch.
The touch panel display is cleared, and the Power LED on
the control panel is changed from blue to orange.
NOTICE
While the following message is displayed, do not turn off the
main power switch. Otherwise, a problem such as a toner fix-
ation in the machine may occur.
[Cooling in progress / Power is turned off automatically]
[Power off in progress / Please do not turn the main power off]
2Turn off the main power switch.
NOTICE
When turning the main power switch off then on, be sure to
wait for 10 seconds or longer before turning the main power
switch on again. If the main power switch is turned on again
within 10 seconds, the machine may not function normally.
3From the [File] menu in [workspace], select [Exit].
4Click [Yes].
5Check that the [IC-314 print controller icon] has disappeared from the taskbar, and then shut down
[Windows].
OFF
ON
OFFON

2-10 AccurioPress C3080/C3080P/C3070, AccurioPrint C3070L
Turning the Power ON/OFF
22.1
Power-saving function
Using the following functions can reduce the power consumption of this machine and provide greater power-
saving effects.
Tips
-Utility/Counter - [Administrator Setting] - [System Setting] - [Power Save Setting] - [Power Save Func-
tion Setting] is the same as Utility/Counter - [User Setting] - [System Setting] - [Power Save Setting] -
[Power Save Function Setting], use either of the methods to configure a setting.
Function Description
Power Save
function
Auto Low Power Turns off the touch panel display to reduce the power con-
sumption of this machine. This machine is placed into the Auto
Low Power mode when:
• The specified period of time has elapsed with no print jobs
executed in the printable state
•Power Save on the control panel has been pressed for a
second or more
This mode is available when [Auto Low Power] is selected by
selecting Utility/Counter - [Administrator Setting] - [System
Setting] - [Power Save Setting] - [Power Save Function Set-
ting].
You can select from the following power-saving time periods:
--- min., 5 min., 10 min., 15 min., 30 min., 60 min.,90 min.,120
min., and 240 min.
Power-saving time periods, 90 min., 120 min., and 240 min.,
may not be displayed depending on regions.
Auto Shut OFF Turns off all LEDs except Power Save LED and Power LED
on the control panel, to reduce the power consumption of this
machine. This machine is placed into the Auto Shut OFF mode
when:
• The specified period of time has elapsed with no print jobs
executed in the printable state
•Power Save on the control panel has been pressed for a
second or more
If the Auto Shut OFF mode is kept for a long time, it may take
a while to warm up this machine upon restart.
This mode is available when [Auto Shut OFF] is selected by se-
lecting Utility/Counter - [Administrator Setting] - [System Set-
ting] - [Power Save Setting] - [Power Save Function Setting].
You can select from the following power-saving time periods:
--- min., 0 min., 1 min., 30 min., 60 min.,90 min.,120 min., and
240 min.
Auto Wake-up
Cond. (Displayed
only when the Im-
age Controller
IC-605 is in-
stalled.)
Specify conditions to automatically release the Shut OFF
mode and start printing when print jobs are received in the
Auto Shut OFF mode.
If you press [All Jobs] to highlight the button, the Shut Off
mode is automatically released even during Auto Shut OFF, al-
lowing all print jobs to be outputted.
If you unhighlight the button, the Shut Off mode is automatical-
ly released during Auto Shut OFF only when the machine re-
ceives print jobs from [PS Plug-in driver] or [AccurioPro Hot
Folder], allowing them to be outputted. To process other jobs,
use this machine after releasing the Shut OFF mode.
ErP Setting Turns the main power off after the Auto Low Power mode, Auto
Shut OFF mode, or the sub power switch is kept in the off
state for the specified period of time.
There are seven power-saving time periods available: Do Not
Switch,12 Hours, 24 Hours, 36 Hours, 48 Hours, 60 Hours, and
72 Hours, from which you can select the desired one.
If the Weekly Timer is set to [Weekly Timer ON], [ErP Setting]
appears dimmed and you cannot configure this setting.
Monochrome Energy-save Mode For monochrome printing, you can carry out it in energy-save
mode.
Weekly Timer Automatically turns the power of this machine on or off based
on the specified time or day of the week.
