Konica Minolta magicolor 7450 User manual

magicolor 7450
User’s Guide
®
4039-9563-01A
1800806-001B

Trademarks
KONICA MINOLTA, the KONICA MINOLTA logo and PageScope are trademarks or registered
trademarks of KONICA MINOLTA HOLDINGS, INC.
magicolor is a trademark or registered trademark of KONICA MINOLTA PRINTING SOLU-
TIONS U.S.A., INC.
All other trademarks and registered trademarks are the property of their respective
owners.
Copyright Notice
Copyright © 2005 KONICA MINOLTA BUSINESS TECHNOLOGIES, INC., Marunouchi Center
Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005, Japan. All Rights Reserved. This
document may not be copied, in whole or part, nor transferred to any other media or language,
without written permission of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
Notice
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to make changes to
this guide and to the equipment described herein without notice. Considerable effort has been
made to ensure that this guide is free of inaccuracies and omissions. However, KONICA
MINOLTA BUSINESS TECHNOLOGIES, INC. makes no warranty of any kind including, but not
limited to, any implied warranties of merchantability and fitness for a particular purpose with
regard to this guide. KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no
responsibility for, or liability for, errors contained in this guide or for incidental, special, or conse-
quential damages arising out of the furnishing of this guide, or the use of this guide in operating
the equipment, or in connection with the performance of the equipment when so operated.

SOFTWARE LICENSE AGREEMENT
This package contains the following materials provided by Konica Minolta Business Technolo-
gies, Inc. (KMBT): software included as part of the printing system, the digitally-encoded
machine-readable outline data encoded in the special format and in the encrypted form (“Font
Programs”), other software which runs on a computer system for use in conjunction with the
Printing Software (“Host Software”), and related explanatory written materials (“Documenta-
tion”). The term “Software” shall be used to describe Printing Software, Font Programs and/or
Host Software and also include any upgrades, modified versions, additions, and copies of the
Software.
The Software is being licensed to you under the terms of this Agreement.
KMBT grants to you a non-exclusive sublicense to use the Software and Documentation, pro-
vided that you agree to the following:
1. You may use the Printing Software and accompanying Font Programs for imaging to the
licensed output device(s), solely for your own internal business purposes.
2. In addition to the license for Font Programs set forth in Section 1 (“Printing Software”)
above, you may use Roman Font Programs to reproduce weights, styles, and versions of
letters, numerals, characters and symbols (“Typefaces”) on the display or monitor for your
own internal business purposes.
3. You may make one backup copy of the Host Software, provided your backup copy is not
installed or used on any computer. Notwithstanding the above restrictions, you may install
the Host Software on any number of computers solely for use with one or more printing
systems running the Printing Software.
4. You may assign its rights under this Agreement to an assignee of all of Licensee’s right and
interest to such Software and Documentation (“Assignee”) provided you transfer to
Assignee all copies of such Software and Documentation Assignee agrees to be bound by
all of the terms and conditions of this Agreement.
5. You agree not to modify, adapt or translate the Software and Documentation.
6. You agree that you will not attempt to alter, disassemble, decrypt, reverse engineer or
decompile the Software.
7. Title to and ownership of the Software and Documentation and any reproductions thereof
shall remain with KMBT and its Licensor.
8. Trademarks shall be used in accordance with accepted trademark practice, including iden-
tification of the trademark owner’s name. Trademarks can only be used to identify printed
output produced by the Software. Such use of any trademark does not give you any rights
of ownership in that trademark.
9. You may not rent, lease, sublicense, lend or transfer versions or copies of the Software that
the Licensee does not use, or Software contained on any unused media, except as part of
the permanent transfer of all Software and Documentation as described above.
10. In no event will KMBT or its licensor be liable to you for any consequential, incidental INDI-
RECT, PUNITIVE or special damages, including any lost profits or lost saving, even if
KMBT has been advised of the possibility of such damages, or for any claim by any third
party. KMBT or its licensor disclaims all warranties with regard to the software, express or
implied, including, without limitation implied warranties of merchantability, fitness for a par-
ticular purpose, title and non-infringement of third party rights. Some states or jurisdictions
do not allow the exclusion or limitation of incidental, consequential or special damages, so
the above limitations may not apply to you.

11. Notice to Government End Users: The Software is a “commercial item,” as that term is
defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial
computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consis-
tent with 48 C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.7202-4, all U.S. Govern-
ment End Users acquire the Software with only those rights set forth herein.
12. You agree that you will not export the Software in any form in violation of any applicable
laws and regulations regarding export control of any countries.
About Adobe Color Profile
ADOBE SYSTEMS INCORPORATED
COLOR PROFILE LICENSE AGREEMENT
NOTICE TO USER: PLEASE READ THIS CONTRACT CAREFULLY. BY USING ALL OR ANY
PORTION OF THE SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF
THIS SOFTWARE YOU ACCEPT ALL THE TERMS AND CONDITIONS OF THIS AGREE-
MENT. IF YOU DO NOT AGREE WITH THE TERMS OF THIS AGREEMENT, DO NOT USE
THE SOFTWARE.
1. DEFINITIONS In this Agreement, “Adobe” means Adobe Systems Incorporated, a Dela-
ware corporation, located at 345 Park Avenue, San Jose, California 95110. "Software"
means the software and related items with which this Agreement is provided.
2. LICENSE Subject to the terms of this Agreement, Adobe hereby grants you the worldwide,
non-exclusive, nontransferable, royalty-free license to use, reproduce and publicly display
the Software. Adobe also grants you the rights to distribute the Software only (a) as embed-
ded within digital image files and (b) on a standalone basis. No other distribution of the
Software is allowed; including, without limitation, distribution of the Software when incorpo-
rated into or bundled with any application software. All individual profiles must be refer-
enced by their ICC Profile description string. You may not modify the Software. Adobe is
under no obligation to provide any support under this Agreement, including upgrades or
future versions of the Software or other items. No title to the intellectual property in the Soft-
ware is transferred to you under the terms of this Agreement. You do not acquire any rights
to the Software except as expressly set forth in this Agreement.
3. DISTRIBUTION If you choose to distribute the Software, you do so with the understanding
that you agree to defend, indemnify and hold harmless Adobe against any losses, dam-
ages or costs arising from any claims, lawsuits or other legal actions arising out of such dis-
tribution, including without limitation, your failure to comply with this Section 3. If you
distribute the Software on a standalone basis, you will do so under the terms of this Agree-
ment or your own license agreement which (a) complies with the terms and conditions of
this Agreement; (b) effectively disclaims all warranties and conditions, express or implied,
on behalf of Adobe; (c) effectively excludes all liability for damages on behalf of Adobe; (d)
states that any provisions that differ from this Agreement are offered by you alone and not
Adobe and (e) states that the Software is available from you or Adobe and informs licens-
ees how to obtain it in a reasonable manner on or through a medium customarily used for
software exchange. Any distributed Software will include the Adobe copyright notices as
included in the Software provided to you by Adobe.

4. DISCLAIMER OF WARRANTY Adobe licenses the Software to you on an “AS IS” basis.
Adobe makes no representation as to the adequacy of the Software for any particular pur-
pose or to produce any particular result. Adobe shall not be liable for loss or damage aris-
ing out of this Agreement or from the distribution or use of the Software or any other
materials. ADOBE AND ITS SUPPLIERS DO NOT AND CANNOT WARRANT THE PER-
FORMANCE OR RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE, EXCEPT
FOR ANY WARRANTY, CONDITION, REPRESENTATION OR TERM TO THE EXTENT
TO WHICH THE SAME CANNOT OR MAY NOT BE EXCLUDED OR LIMITED BY LAW
APPLICABLE TO YOU IN YOUR JURISDICTION, ADOBE AND ITS SUPPLIERS MAKE
NO WARRANTIES, CONDITIONS, REPRESENTATIONS OR TERMS, EXPRESS OR
IMPLIED, WHETHER BY STATUTE, COMMON LAW, CUSTOM, USAGE OR OTHER-
WISE AS TO ANY OTHER MATTERS, INCLUDING BUT NOT LIMITED TO NON-
INFRINGEMENT OF THIRD PARTY RIGHTS, INTEGRATION, SATISFACTORY QUALITY
OR FITNESS FOR ANY PARTICULAR PURPOSE. YOU MAY HAVE ADDITIONAL
RIGHTS WHICH VARY FROM JURISDICTION TO JURISDICTION. The provisions of Sec-
tions 4, 5 and 6 shall survive the termination of this Agreement, howsoever caused, but this
shall not imply or create any continued right to use the Software after termination of this
Agreement.
5. LIMITATION OF LIABILITY IN NO EVENT WILL ADOBE OR ITS SUPPLIERS BE LIABLE
TO YOU FOR ANY DAMAGES, CLAIMS OR COSTS WHATSOEVER OR ANY CONSE-
QUENTIAL, INDIRECT, INCIDENTAL DAMAGES, OR ANY LOST PROFITS OR LOST
SAVINGS, EVEN IF AN ADOBE REPRESENTATIVE HAS BEEN ADVISED OF THE POS-
SIBILITY OF SUCH LOSS, DAMAGES, CLAIMS OR COSTS OR FOR ANY CLAIM BY
ANY THIRD PARTY. THE FOREGOING LIMITATIONS AND EXCLUSIONS APPLY TO
THE EXTENT PERMITTED BY APPLICABLE LAW IN YOUR JURISDICTION. ADOBE'S
AGGREGATE LIABILITY AND THAT OF ITS SUPPLIERS UNDER OR IN CONNECTION
WITH THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT PAID FOR THE SOFT-
WARE. Nothing contained in this Agreement limits Adobe’s liability to you in the event of
death or personal injury resulting from Adobe’s negligence or for the tort of deceit (fraud).
Adobe is acting on behalf of its suppliers for the purpose of disclaiming, excluding and/or
limiting obligations, warranties and liability as provided in this Agreement, but in no other
respects and for no other purpose.
6. TRADEMARKS Adobe and the Adobe logo are the registered trademarks or trademarks of
Adobe in the United States and other countries. With the exception of referential use, you
will not use such trademarks or any other Adobe trademark or logo without separate prior
written permission granted by Adobe.
7. TERM This Agreement is effective until terminated. Adobe has the right to terminate this
Agreement immediately if you fail to comply with any term hereof. Upon any such termina-
tion, you must return to Adobe all full and partial copies of the Software in your possession
or control.
8. GOVERNMENT REGULATIONS If any part of the Software is identified as an export con-
trolled item under the United States Export Administration Act or any other export law,
restriction or regulation (the “Export Laws”), you represent and warrant that you are not a
citizen, or otherwise located within, an embargoed nation (including without limitation Iran,
Iraq, Syria, Sudan, Libya, Cuba, North Korea, and Serbia) and that you are not otherwise
prohibited under the Export Laws from receiving the Software. All rights to use the Software
are granted on condition that such rights are forfeited if you fail to comply with the terms of
this Agreement.

9. GOVERNING LAW This Agreement will be governed by and construed in accordance with
the substantive laws in force in the State of California as such laws are applied to agree-
ments entered into and to be performed entirely within California between California resi-
dents. This Agreement will not be governed by the conflict of law rules of any jurisdiction or
the United Nations Convention on Contracts for the International Sale of Goods, the appli-
cation of which is expressly excluded. All disputes arising out of, under or related to this
Agreement will be brought exclusively in the state Santa Clara County, California, USA.
10. GENERAL You may not assign your rights or obligations granted under this Agreement
without the prior written consent of Adobe. None of the provisions of this Agreement shall
be deemed to have been waived by any act or acquiescence on the part of Adobe, its
agents, or employees, but only by an instrument in writing signed by an authorized signa-
tory of Adobe. When conflicting language exists between this Agreement and any other
agreement included in the Software, the terms of such included agreement shall apply. If
either you or Adobe employs attorneys to enforce any rights arising out of or relating to this
Agreement, the prevailing party shall be entitled to recover reasonable attorneys’ fees. You
acknowledge that you have read this Agreement, understand it, and that it is the complete
and exclusive statement of your agreement with Adobe which supersedes any prior agree-
ment, oral or written, between Adobe and you with respect to the licensing to you of the
Software. No variation of the terms of this Agreement will be enforceable against Adobe
unless Adobe gives its express consent, in writing, signed by an authorized signatory of
Adobe.
ICC Profile for TOYO INK Standard Color on Coated paper
(TOYO Offset Coated 2.0)
This ICC Profile (TOYO Offset Coated 2.0) characterizes Japanese offset press on Coated
paper and is fully compatible with ICC profile format.
About “TOYO INK Standard Color on Coated paper”
This is the standard for color reproduction of sheet-fed offset press on Coated paper made by
TOYO INK MFG.CO., LTD. (“TOYO INK”).
This standard is made from printing test with using TOYO INK’s sheet-fed offset printing inks
and TOYO INK’s own printing conditions.
“TOYO INK Standard Color on Coated paper” is compatible with “JAPAN COLOR”.
Agreement
1. The reproduction of images on a printer or a monitor using this ICC Profile do not com-
pletely match the TOYO INK Standard Color on Coated paper.
2. Any and all copyrights of this ICC Profile shall remain in TOYO INK; therefore you shall not
transfer, provide, rent, distribute, disclose, or grant any rights in this ICC Profile to any third
party without the prior written consent of TOYO INK.
3. In no event will TOYO INK its directors, officers, employees or agents be liable to you for
any consequential or incidential, either direct or indirect, damages(including damages for
loss of business profits, business interruption, loss of business information, and the
like)arising out of the use or inability to use this ICC Profile.
4. TOYO INK shall not be responsible for answering any question related to this ICC Profile.

5. All company names and product names used in this document is the trademarks or regis-
tered trademarks of their respective holder.
This ICC Profile made by GretagMacbeth ProfileMaker and granted TOYO INK certain license
to distribute by GretagMacbeth AG.
TOYO Offset Coated 2.0 © TOYO INK MFG. CO., LTD. 2004
For EU member states only
This symbol means: Do not dispose of this product
together with your household waste!
Please contact the Local Authority for appropriate dis-
posal instructions. In the case of a new device being
purchased, the used one can also be given to our dealer
for appropriate disposal. Recycling of this product will
help to conserve natural resources and prevent potential
negative consequences for the environment and human
health caused by inappropriate waste handling.

Contents
Contents i
1 Introduction ....................................................................................................... 1
Getting Acquainted with Your Printer 2
Space Requirements 2
Printer Parts 3
Front View 3
Rear View 4
Front View with Options 4
2 About the Software ........................................................................................... 5
Software Utilities CD-ROM 6
PostScript Drivers 6
PCL Drivers 6
PPD Files 7
Utilities 7
System Requirements 9
Selecting Driver Options/Defaults (for Windows) 10
Windows Server 2003/XP/2000/NT 4.0 (PostScript and PCL6) 10
Windows Me/98SE (PCL6) 11
Windows Me/98SE (PPD) 12

Contentsii
Uninstalling the Windows Printer Driver 13
Displaying Windows Printer Driver Settings 14
Windows Server 2003/XP 14
Windows 2000/NT 4.0/Me/98SE 14
Using the Postscript and PCL Printer Drivers 15
Common Buttons 15
OK 15
Cancel 15
Apply 15
Help 15
Easy Set 15
Paper View 16
Printer View 16
Watermark View 16
Quality View 16
Default 16
Advanced Tab (PostScript Printer Driver Only) 16
Basic Tab 17
Layout Tab 17
Cover Page Tab 17
Overlay Tab 18
Watermark Tab 18
Quality Tab 18
Version Tab 19
Limitations on Printer Driver Functions Installed with Point and Print 19
Using the Windows Me/98SE PPD File 20
Common Buttons 20
OK 20
Cancel 20
Apply 20
Restore Defaults 20
Paper Tab 20
Graphics Tab 21
3 Using the Status Monitor (Windows Only) ....................................................23
Working with the Status Monitor 24
Introduction 24
Operating Environment 24
Opening the Status Monitor 24
Using the Status Monitor 24
Recognizing Status Monitor Alerts 25
Recovering from a Status Monitor Alert 25
Closing the Status Monitor 25

Contents iii
4 Printer Control Panel and Configuration Menu ............................................ 27
About the Control Panel 28
Control Panel Indicators and Keys 28
Message Window 30
Help Screens 31
Configuration Menu Overview 32
Main Menu 32
PROOF/PRINT MENU 33
Printing/Deleting a Stored Job 33
Entering a Password 34
PRINT MENU 36
PAPER MENU 38
QUALITY MENU 45
CAMERA DIRECT MENU 61
INTERFACE MENU 64
SYS DEFAULT MENU 67
MAINTENANCE MENU 77
SERVICE MENU 82
5 Camera Direct .................................................................................................. 83
Camera Direct 84
Printing Directly from a Digital Camera 84
6 Using Media ..................................................................................................... 87
Media Specifications 88
Media Types 89
Plain Paper (Recycled Paper) 89
Thick Stock 91
Envelopes 92
Labels 94
Letterhead 95
Postcards 95
Transparencies 96
Glossy Stock 97
What Is the Guaranteed Imageable (Printable) Area? 99
Imageable Area—Envelopes 99
Page Margins 99
Loading Media 100
Tray 1 (Manual Feed Tray) 100
Loading Plain Paper 100
Other Media 102
Loading Envelopes 103
Loading Label Sheets/Postcards/Thick Stock/Glossy Stock and Transpar-
encies 107
Loading the Banner Paper 109

Contentsiv
Tray 2 111
Loading Media 111
Printing on Envelopes 114
Tray 3/4/5 (Optional Lower Feeder Units) 117
Loading Plain Paper 117
Duplexing 120
Output Tray 122
Media Storage 123
7 Replacing Consumables ...............................................................................125
Replacing Consumables 126
About Toner Cartridges 126
Replacing a Toner Cartridge 128
Replacing a Imaging Unit 132
Replacing the Waste Toner Bottle 137
Replacing the Backup Battery 139
8 Maintaining the Printer ..................................................................................143
Maintaining the Printer 144
Cleaning the Printer 148
Exterior 148
Media Rollers 149
Cleaning the Media Feed Rollers (Manual Feed Tray) 149
Cleaning the Media Feed Rollers (Tray 2/3/4/5) 150
Cleaning the Duplex Option Feed Rollers 151
Cleaning the Media Transfer Rollers for Tray 3/4/5 152
Cleaning the Laser Lens 153
9 Troubleshooting ............................................................................................155
Introduction 156
Printing a Configuration Page 156
Preventing Media Misfeeds 157
Understanding the Media Path 158
Clearing Media Misfeeds 159
Media Misfeed Messages and Clearing Procedures 160
Clearing a Media Misfeed in Tray 2 161
Clearing a Media Misfeed in Tray 3/4/5 165
Clearing a Media Misfeed from the Duplex Option 167
Clearing a Media Misfeed from the Fuser Unit 168
Clearing a Media Misfeed from Tray 1 (Manual Feed Tray) and Transfer
Roller 172
Solving Problems with Media Misfeeds 175
Solving Other Problems 178
Solving Problems with Printing Quality 183
Status, Error, and Service Messages 189
Standard Status Messages 189

Contents v
Error Messages (Warning :) 190
Error Messages (Operator Call :) 195
Service Messages: 200
10 Installing Accessories .................................................................................. 201
Introduction 202
Antistatic Protection 203
Dual In-Line Memory Module (DIMM) 204
Installing a DIMM 204
Hard Disk 206
Installing a Hard Disk 206
CompactFlash 208
Installing the CompactFlash card 208
Duplex Option 211
Kit Contents 211
Installing the Duplex Option 211
Lower Feeder Unit 216
Kit Contents 216
Installing a Lower Feeder Unit 216
Caster Base 225
Kit Contents 225
Installing the Caster Base 226
Banner Tray 229
Installing the Banner Tray 229
A Appendix ........................................................................................................ 233
Safety Specifications 234
Technical Specifications 234
Printer 234
Consumable Life Expectancy Chart 238
Our Concern for Environmental Protection 239
What is an ENERGY STAR product? 239

1
Introduction

Getting Acquainted with Your Printer2
Getting Acquainted with Your Printer
Space Requirements
To ensure easy operation, consumable replacement and maintenance,
adhere to the recommended space requirements detailed below.
!" The options appear shaded in the above illustrations.
650 mm (25.6")
577 mm (22.7")
463 mm (18.2")
848 mm (33.4")
124 mm (4.9")
603 mm (23.7") 100 mm
(3.9")
Front View
Side View
124 mm (4.9")
124 mm (4.9")
437 mm (17.2")
907 mm (35.7")
535 mm (21.1")372 mm (14.6")
966 mm (38.0")
100 mm
(3.9")
100 mm
(3.9")
100 mm (3.9")
100 mm
(3.9")

Getting Acquainted with Your Printer 3
Printer Parts
The following drawings illustrate the parts of your printer referred to through-
out this guide, so please take some time to become familiar with them.
Front View
1—Control panel
2—Toner cartridge (Cyan, Magenta,
Yellow)
3—Toner cartridge (Black)
4—Output tray
5—Top cover
6—Fuser unit
7—Transfer belt unit
8—Filter 1 (Air filter)
9—Transfer roller
10—Right side cover
11—Tray 1 (Manual feed tray)
12—Tray 2
13—Grip
14—Imaging unit
15—Front cover
16—Laser lens cleaning tool
17— Waste toner bottle
18—Power switch
13567
11
9
10
13 1216
2 4
8
14
17
15
18
14
17
K
3
C M
Y
2
16

Getting Acquainted with Your Printer4
Rear View
1—Filter 2 (Dust filter)
2—Digital Camera Direct Print Port
3—10Base-T/100Base-TX/
1000Base-T ethernet interface
port
4—USB port
5—Parallel port
6—Filter 3 (Ozone filter)
7—Power connection
8—Option cassette connector
9—Ventilation grilles
Front View with Options
1—Duplex option
2—Lower feeder units (Tray 3/4/5)
12
3
7
5
8
4
6
9
2
1

2
About the
Software

Software Utilities CD-ROM6
Software Utilities CD-ROM
PostScript Drivers
!" When using Windows Me/98SE, use the PPD file for Windows Me/
98SE. See also “Displaying Windows Printer Driver Settings” on page
14.
!" A specific PPD file has been prepared for applications (such as Page-
Maker and CorelDRAW) that require that a PPD file be specified when
printing.
When specifying a PPD file while printing on Windows XP, Server
2003, 2000 and NT 4.0, use the specific PPD file provided on the Soft-
ware Utilities CD-ROM in drivers\<operating_system>\PPD.
PCL Drivers
Operating System Use/Benefit
Windows Server 2003/XP/2000 These drivers give you access to all of
the printer features, including finish-
ing and advanced layout. See also
“Displaying Windows Printer Driver
Settings” on page 14.
Windows NT 4.0
Operating System Use/Benefit
Windows Server 2003/XP/2000 These drivers give you access to all of
the printer features, including finish-
ing and advanced layout. See also
“Displaying Windows Printer Driver
Settings” on page 14.
Windows Me/98SE
Windows NT 4.0
