magicolor®2350
PJL
Reference Guide
1800721-001A

Trademarks
KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered
trademarks of KONICA MINOLTA HOLDINGS, INC.
QCOLOR and magicolor are trademarks or registered trademarks of KONICA MINOLTA
PRINTING SOLUTIONS U.S.A., INC.
This product uses Software Developer Kit of Peerless Systems Corporation. Copyright
© 2001 Peerless Systems Corporation. All Rights Reserved.
This product uses NEST Office SDK of Novell, Inc. Copyright © 1999 Novell, Inc. NEST
is a trademark of Novell, Inc. in the United States and other countries.
Copyright Notice
Copyright © 2003 KONICA MINOLTA BUSINESS TECHNOLOGIES, INC., Marunouchi
Center Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005, Japan. All Rights
Reserved. This document may not be copied, in whole or part, nor transferred to any
other media or language, without written permission of KONICA MINOLTA BUSINESS
TECHNOLOGIES, INC.
Printer Job Language Technical Reference Manual, Hewlett-Packard Company. Printer
Job Language (PJL) was developed by Hewlett-Packard Company. Other product
names mentioned in this manual may also be trademarks or registered trademarks of
their respective owners.
Manual Notice
This guide provides an introduction to the PJL commands that the magicolor 2350
printer supports.
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. reserves the right to
make changes to this manual and to the equipment described herein without notice.
Considerable effort has been made to ensure that this manual is free of inaccuracies
and omissions. However, KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.
makes no warranty of any kind including, but not limited to, any implied warranties of
merchantability and fitness for a particular purpose with regard to this manual.
KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. assumes no responsibility
for, or liability for, errors contained in this manual or for incidental, special, or
consequential damages arising out of the furnishing of this manual, or the use of this
manual in operating the equipment, or in connection with the performance of the
equipment when so operated.


iii
SECTION 1: Using PJL Commands ...... 1
1.1 Introduction ...................................... 3
1.2 Conventions...................................... 9
1.3 Issuing PJL Commands................. 15
SECTION 2: PJL Commands ............... 19
2.1 PJL Commands .............................. 21
2.2 Status Codes .................................. 55
2.3 PJL/DOCMatrix...................................... 61
Index ...................................................... 67

Using PJL Commands
In Section 1...
Chapter 1.1 — Introduction
Describes PJL, features, and an overview of
the commands available for your printer.
Chapter 1.2 — Conventions
Describes the typographical and context con-
ventions that must be used when working with
the PJL command set. Also includes informa-
tion about variables and language
configuration.
Chapter 1.3 — Issuing PJL Commands
Identifies the methods that can be used to
send PJL commands to your printer.

Chapter Location
Chapter Title
Begins on
page...
1.1 Introduction 3
1.2 Conventions 9
1.3 Issuing PJL Commands 15

Introduction—

About PJL4
About PJL
Printer Job Language (PJL) enables advanced users and software applica-
tion developers to send commands to the printer and receive printer status.
This allows you to control the printer’s configuration for a print job and to
establish two-way communications with the printer. In addition, PJL com-
mands can be used to change the printer’s control panel settings and to
change the printing language from within applications.
In This Guide
This PJL Reference Guide contains information about the PJL commands
that are supported by your printer. Section 1 provides a general introduction
to PJL. Section 2 contains the full list of PJL commands supported by your
printer and describes the function of each command. If you have experience
using PJL commands, you can skip the remainder of this Section and begin
with Section 2.
 For customers who have older Crown printers, we’ve also included a
PJL/DOC (Document Option Command) equivalency matrix at the end
of Section 2. (DOC was supported by earlier Crown printers.) You can
use this matrix to find the PJL command that is most equivalent to a
DOC entry.
Online Benefits
If you’re viewing this document using Acrobat Reader, you can take advan-
tage of the hyperlinks that we’ve provided in the Contents and Index pages to
quickly jump to the topics that interest you. Just click on any Contents or
Index entry to open the linked page.
There are also other hyperlinks in this document available
for use. All references to page numbers and any text sur-
rounded by a green box contain a hyperlink to another page.
 See the Acrobat Reader online help for information
about the document navigation tools provided in the Reader.
 Visit our website (printer.konicaminolta.net/support) for product and
documentation updates for your printer.
Linked Text

Overview of PJL 5
Overview of PJL
Using PJL to configure or to communicate with your printer requires the use
of PJL commands, which may include the use of PJL environmental vari-
ables, modifiers, and parameter values to define the commands given.
Supported PJL Command Set
The following lists identify the PJL commands that are supported by your
KONICA MINOLTA printer.
 Additional information about each command is given in Section 2.
Kernel and Job Control Commands
Status or Information Request (Readback) Commands
COMMENT
DEFAULT
ENTER
EOJ
INITIALIZE
JOB
PJL
RESET
SET
UEL
DINQUIRE
ECHO
INFO
INQUIRE
USTATUS
USTATUSOFF

Overview of PJL6
Environmental Variables
Environmental variables are used with the PJL commands to provide
printer-specific controls and additional communication tools your printer can
understand.
The following lists identify the common PJL environmental variables that are
supported by your KONICA MINOLTA printer.
 The full list of PJL variables, with additional information about each
variable, is given in Section 2.
 Some PJL command variables may appear in more than one of the
following categories.
Accounting Information Variables
Document/Printer Control Variables
CHARGENUMBER
HOST
JOBNAME
USERNAME
CPLOCK
CUSTOMSIZEX
CUSTOMSIZEY
EMAILADDRESS
HELDJOBTIMEOUT
HOLD
HOLDKEY
HOLDTYPE
INTRAY1SIZE (read-only)
INTRAY2SIZE (read-only)*
JOB
JOBID
LANG
LOWTONER
MODELNAME (read-only)
NOTIFY

Overview of PJL 7
Document Formatting Variables
OUTBIN
OUTTONER
PASSWORD
PERSONALITY
POWERSAVE
POWERSAVETIME
REPRINT
TIMEOUT
TRAYMAPPING
USERNAME
Notes: *Optional lower feeder unit and Tray 2 required.
BINDING*
BITSPERPIXEL
COLORSEPARATION
COLORUCR
COPIES
DUPLEX*
FORMLINES
JOB
LANGUAGE
MEDIASOURCE
MEDIATYPE
ORIENTATION
PAPER
PLANESINUSE
PRINTQUALITY
QTY**
RESOLUTION
TRAYCHAIN
Notes: *With optional duplexer.
**With optional hard disk.

Overview of PJL8
PCL Variables
Lineprinter Variables
PostScript Variables

FONTNUMBER
FONTSOURCE
LINETERMINATION
OPTIMIZEFOR
PCLLINETERMINATION
PITCH
PTSIZE
SYMSET
AUTOWRAP
CHARMAP
FONTNAME
LINESPERPAGE
LPLINETERMINATION
LPORIENTATION
MARGINS
NUMBERLINES
TABS
PRTPSERRS
COLORMATCHING
DESTINATIONPROFILE
KPRESERVE
RGBBLACK
RGBSRCPROFILE
SIMULATIONPROFILE
SIMINRGBLINKS

Conventions—

Introduction10
Introduction
Conventions denotes two meanings: 1) How this manual uses character and
document formatting to define the PJL commands and variables (see Docu-
ment Conventions), and 2) How you should enter PJL command text in your
application to ensure the printer recognizes the commands correctly (see
“PJL Command Syntax”on page 11).
Document Conventions
The text describing the available PJL commands and variables in Section 2
appear in tables like the one shown below.
The first row identifies the PJL command or environmental variable
defined in the table.
The Syntax row displays the correct method of entering the command
and any required or optional arguments that are or can be associated
with the command. Unless otherwise noted, all of the text appearing in
this row must be entered on the same line of the PJL job. See the PJL
Command Syntax section for additional information.
Response Syntax identifies the syntax that the printer uses in its
responses to queries.
The Description row defines the command’s function.
Notes contains any additional information, tips, or cautions that may
help you when applying the defined command or its arguments.
Command
or Variable
Command (or variable) Name
Syntax Command Syntax
Response
Syntax
Response Syntax
Description Command description
Notes Notes about the command or its usage.

PJL Command Syntax 11
PJL Command Syntax
The characters and symbols used when identifying the syntax of PJL com-
mands is defined in the following table:
Control Character Definitions
This table defines the control characters used in PJL command syntax.
[ ] Square brackets enclose any optional arguments that
can be used in conjunction with the command. If you use
optional arguments, don’t type the brackets.
< > Angled brackets enclose control characters. When these
appear in the Syntax, enter the control code only (don’t
type the <> characters). See the next section for control
character definitions.
| Vertical bars appear in command syntax to indicate that
there are multiple optional parameters.
CAPS The complete @PJL command must be in uppercase.
Control
Char-
acter
Character
Descrip-
tion
Hex Code ASCII Code
<CR> Carriage
Return
0x0D 13
<ESC> Escape 0x1B 27
<FF> Form Feed 0x0C 12
<HT> Horizontal
Tab
0x09 9
<LF> Line Feed 0x0A 10
<SP> Space 0x20 32
<UEL> * Universal
Exit
Language
0x1B 25 2D 31 32 33 34 35 58 27 37 45 49 50 51 52 53 88
Notes: *See “Universal Exit Language (<UEL>) Usage”on page 12 for complete
UEL usage information.

Universal Exit Language
(<UEL>) Usage
12
Universal Exit Language (<UEL>) Usage
The <UEL> Kernel Command signals to the printer that a PJL job needs to be
processed or has completed processing. This allows the printer to switch
between PJL and its default printing language (for example, PostScript). The
following bullets identify the rules you should follow when using the <UEL>
Command:
Always start and end all PJL jobs with the <UEL> Command. The Syntax
for this command is
<ESC>%-12345X
The <UEL> Command at the beginning of the PJL job must be immedi-
ately followed by the @PJL prefix. No spaces or other characters can be
placed between the <UEL> and the @PJL characters. For example,
<ESC>%-12345X@PJL
 Following the text shown in the above example, you can continue
with a <CR> <LF> to begin another PJL command on the next line,
or you can use the @PJL on this line to start another PJL Com-
mand.
No characters should follow the <UEL> placed at the end of the PJL job.
Any character after the <UEL> is seen and handled as a new job.
Additional Syntax Rules
The <LF> (Line Feed) control code must be used at the end of each PJL
command to terminate the line.
 The only exception to this rule is the <UEL> command, which does
not require the <LF> control code.
The <CR> control character is optional, but can be useful when spacing is
needed between command lines (no blank lines are allowed in PJL jobs).
Always place the optional <CR> before the <LF>, which is used to termi-
nate the line.
A space (ASCII 32, Hex 0x20) or tab (ASCII 9, HEX 0x09) is required
between the @PJL prefix and the PJL command name.
A space (ASCII 32, Hex 0x20) is required between the PJL command
name and command arguments.

Language Configuration 13
Variables and Values
Many PJL commands require the use of variables to assign values to the
command parameters. PJL commands support the use of alphanumeric vari-
able characters when the following rules are applied:
Alpha Characters
All variables must begin with an alpha character.
Do not use spaces in variables.
Alpha characters must be Roman-8 uppercase (characters 65-90).
Numeric Characters
Do not begin variables with a numeric character.
If a decimal is used in a numeric value, a number must precede the deci-
mal point, and only one decimal point is allowed in a value.
Do not use commas in numeric values.
Numeric characters must be Roman-8 numbers 0-9 (characters 48-57).
Strings
Strings are not used in variables but may be used as values.
Strings can use any combination of the alpha and numeric characters that
follow the guidelines described above.
Strings must be placed within double quotation marks.
Quotation marks cannot be used as part of the string.
Control characters are not allowed in strings.
Language Configuration
In order for the printer to correctly interpret the PJL commands that are sent
to it, the printer must recognize or be told which language to use to process
the job. Three methods of language switching can be used.
Explicit Language Selection—This is the recommended method of
switching languages and involves the use of the ENTER LANGUAGE
command to notify the printer of the language to be used.
Implicit Language Selection—If the ENTER LANGUAGE command is
not used, the printer uses the language set as the default language. This
method works fine as long as the default language is the same language

Language Configuration14
as the job sent to the printer. If the PERSONALITY variable is set to
AUTO, and no ENTER command is received, Context Language Selec-
tion (described next) is used instead of Implicit Language Selection. This
variable can be set through PJL or user interface (operator control panel
[System Default/Emulations/Default menu], CrownView, and PageScope
Light).
Context Language Selection—When the printer is configured to auto-
matically select the language of incoming jobs and the ENTER LAN-
GUAGE command is not used to identify the job language, the printer
samples the incoming data and chooses a language based on its interpre-
tation of the sampled data.


Issuing PJL
Commands—

Introduction16
Introduction
The following chapters in this guide describe the PJL commands, their vari-
ables, and their functions. This chapter looks at the common methods of
sending the PJL command jobs to the printer and receiving readback
responses from the printer.
Sending PJL Commands to the Printer
The three most common methods used to send PJL commands to the printer
are
Creating an ASCII file containing the PJL commands and copying this file
to your printer. Use this method if you want to send configuration changes
to the printer and don’t require readback responses from the printer.
 You can also modify your Autoexec.bat file to copy the ASCII file to
the printer each time you boot your workstation.
Embedding PJL commands in an application during development. This
method allows application developers to take advantage of the com-
mands and readback status of the printer to customize application func-
tions that interact with the printer.
 Due to the extensive variations in application development, this
method is not documented in detail in this Guide.
Using a utility software application that handles the bidirectional communi-
cation necessary to send and receive information from the printer.
Copying ASCII Files to the Printer
This section describes one method of creating and sending an ASCII file con-
taining PJL commands to your printer from a workstation running a Windows
Operating System.
1From the Start menu, choose Run.
2Type edit and then select OK.
The MS-DOS Editor opens.
3Enter the following on the first line of the new file you are creating.
<ESC>%-12345X@PJL
To create the <ESC> character, hold down the CTRL key and select the P
key, and then press the Esc key.
