Konica Minolta SL1000 Microfiche User manual

SL1000 Digital Film Scanner
User’s Guide

International ENERGY STAR® Compliance Statement
The purpose of the International ENERGY STAR® Program is to promote the
development and popularization of energy-efficient office equipment.

i
SAFETY INFORMATION
This section contains detailed instructions on the operation and maintenance of this machine. To
achieve optimum utility of this device, all operators should carefully read and follow the instructions
in this manual. Please keep this manual in a handy place near the machine.
Make sure you observe all of the precautions listed in this manual.
* Please NOTE that some parts of the contents of this section may not correspond with the purchased
product.
Warning and Precautions Symbols
WARNING:
Ignoring this warning could cause serious injury or even death.
CAUTION:
Ignoring this caution could cause injury or damage to property.
Meaning of Symbols
A triangle indicates a danger against which you should take precautions.
This symbol warns against possible burns.
A dialog line indicates a prohibited course of action.
This symbol warns against dismantling the device.
A Black circle indicates an imperative course of action.
This Symbol indicates you must unplug device.

SAFETY INFORMATION
ii
WARNING
●Do not modify this product, as a fire, electrical shock, or breakdown could result. If
the product employs a laser, the laser beam source could cause blindness.
●Do not attempt to remove the covers and panels which have been fixed to the product.
Some products have a high-voltage part or a laser beam source inside that could cause
an electrical shock or blindness.
●Do not remove or exchange the fuse of this product, as a fire, electrical shock, or
breakdown could result.
●Only use the power cord supplied in the package. If a power cord is not supplied,
only use the power cord and plug that is specified in POWER CORD
INSTRUCTION. Failure to use this cord could result in a fire or electrical shock.
●Use the power cord supplied in the package only for this machine and NEVER uses it
for any other product. Failure to observe this precaution could result in a fire or
electrical shock.
●Use only the specified power source voltage. Failure to do that could result in a fire or
electrical shock.
●Do not use a multiple outlet adapter to connect any other appliances or machines. Use
of a power outlet for more than the marked current value could result in a fire or
electrical shock.
●Do not unplug or plug in the power cord with a wet hand, as an electrical shock could
result.
●Plug the power cord all the way into the power outlet. Failure to do this could result
in a fire or electrical shock.
●Do not scratch, abrade, place a heavy object on, heat, twist, bend, pull on, or damage
the power cord. Use of a damaged power cord (exposed core wire, broken wire, etc.)
could result in a fire or breakdown.
Should any of these conditions be found, immediately turn OFF the Power Switch,
unplug the power cord from the power outlet, and then call your authorized service
representative.
●Do not use an extension cord, in principle. Use of an extension cord could cause a fire
or electrical shock. Contact your authorized service representative if an extension
cord is required.

SAFETY INFORMATION
iii
WARNING
●Do not place a flower vase or other container that contains water, or metal clips or
other small metallic objects on this product. Spilled water or metallic objects dropped
inside the product could result in a fire, electrical shock, or breakdown.
Should a piece of metal, water, or any other similar foreign matter get inside the
product, immediately turn OFF the Power Switch, unplug the power cord from the
power outlet, and then call your authorized service representative.
●Do not keep using this product if it becomes inordinately hot or emits smoke, or
unusual odor or noise. Immediately turn OFF the Power Switch, unplug the power
cord from the power outlet, and then call your authorized service representative. If you
keep on using it as is, a fire or electrical shock could result.
●Do not keep using this product, if this product has been dropped or its cover damaged.
Immediately turn OFF the Power Switch, unplug the power cord from the power
outlet, and then call your authorized service representative. If you keep on using it as
is, a fire or electrical shock could result.
●Connect the power cord to an electrical outlet that is equipped with a grounding
terminal.
CAUTION
●Do not use flammable sprays, liquids, or gases near this product, as a fire could result.
●Do not let any object plug the ventilation holes of this product.
Heat could accumulate inside the product, resulting in a fire or malfunction.
●Do not install this product at a site that is exposed to direct sunlight, or near an air
conditioner or heating apparatus. The resultant temperature changes inside the product
could cause a malfunction, fire, or electrical shock.
●Do not place the product in a dusty place, or a site exposed to soot or steam, near a
kitchen table, bath, or a humidifier. A fire, electrical shock, or breakdown could result.
●Do not place this product on an unstable or tilted bench, or in a location subject to a
lot of vibration and shock. It could drop or fall, causing personal injury or mechanical
breakdown.
●After installing this product, mount it on a secure base. If the unit moves or falls, it
may cause personal injury.

SAFETY INFORMATION
iv
CAUTION
●Do not place any objects around the power plug as the power plug may be difficult to
pull out when an emergency occurs.
●The socket-outlet shall be installed near the machine and shall be easily accessible as
the power plug may be difficult to pull out when an emergency occurs.
●Always use this product in a well ventilated location. Operating the product in a
poorly ventilated room for an extended period of time could injure your health.
Ventilate the room at regular intervals.
●Whenever moving this product, be sure to disconnect the power cord and other cables.
Failure to do this could damage the cord or cable, resulting in a fire, electrical shock,
or breakdown.
●When moving this product, always hold it by the locations specified in the User’s
Guide or other documents. If the unit falls it may cause severe personal injury. The
product may also be damaged or malfunction.
●Remove the power plug from the outlet more than one time a year and clean the area
between the plug terminals. Dust that accumulates between the plug terminals may
cause a fire.
●When unplugging the power cord, be sure to hold onto the plug. Pulling on the power
cord could damage the cord, resulting in a fire or electrical shock.
Precautions for Routine Use
●Do not use this product in an area where ammonia or other gases or chemicals are
present. Failure to do so may shorten the service life of the product, cause damage or
decrease performance.
●Do not use this product in an environment with a temperature outside the range
specified in the User’s Guide, as a breakdown or malfunction could result.

v
INFORMATIONS DE SÉCURITÉ
Cette section contient des instructions détaillées sur l'utilisation et l'entretien de cette machine. Pour
obtenir un rendement optimal de cette machine, il est imperative que toutes les personnes l'utilisant
lisent attentivement et observent scrupuleusement les consignes de ce manuel. Veuillez conserver ce
manuel en lieu sûr, à proximité de la machine.
Veuillez observer toutes les consignes de sécurité énumérées dans ce manuel.
Veuillez NOTE r que certaines informations contenues dans cette section pourraient ne pas
correspondre à votre produit.
Symboles d'avertissement et de précaution
WARNING:
Le non-respect de cet avertissement pourrait causer de graves blessures,
voire un accident mortel.
CAUTION:
Le non-respect de cette précaution pourrait causer des blessures ou des
dommages matériels.
Signification des symboles
Un triangle indique un danger potentiel requérant certaines précautions.
Ce symbole vous met en garde contre des risques de brûlures.
Une diagonale dans un cercle désigne une interdiction.
Ce symbole signifie qu'il est interdit de démonter l'appareil.
Un cercle noir désigne une procédure obligatoire.
Ce symbole signifie que vous devez débrancher l'appareil.

INFORMATIONS DE SÉCURITÉ
vi
WARNING
 Ne modifiez pas ce produit, car cela risquerait de causer un incendie, une
électrocution ou une panne de l'appareil. Si ce produit comporte un laser, sachez que
l'exposition au rayon laser pose un risque pour les yeux.
 N'essayez jamais de démonter les couvercles et panneaux montés sur le produit.
Certains produits renferment des composants de haute tension ou une source de
rayon laser qui risqueraient de causer une electrocution ou des lésions aux yeux.
 Ne pas retirer ou d'échanger le fusible de ce produit, comme un incendie,
d'électrocution ou une panne peut en résulter.
 Utilisez uniquement le cordon d'alimentation contenu dans l'emballage.
Si le cordon d'alimentation n'est pas fourni, veillez à vous procurer uniquement un
cordon avec fiches conformes aux INSTRUCTIONS POUR LE CORDON
D'ALIMENTATION. Le non-respect de cette consigne risquerait de provoquer un
incendie.
 Utilisez le cordon d'alimentation contenu dans l'emballage uniquement avec cette
machine; ne l'utilisez JAMAIS avec aucun autre appareil. Le non-respect de cette
consigne risquerait de provoquer un incendie ou une électrocution.
 Utilisez uniquement la tension d'alimentation spécifiée. Le non-respect de cette
consigne risquerait de provoquer un incendie ou une électrocution.
 N'utilisez jamais d'adaptateur multi-prise pour alimenter simultanément d'autres
appareils ou machines. Le branchement à une prise de courant délivrant une tension
supérieure aux spécifications risquerait de provoquer un incendie ou une
électrocution.
 Né branchez ni débranchez jamais le cordon d'alimentation avec des mains
mouillées car cela risquerait de provoquer une électrocution.
 Branchez le cordon d'alimentation à fond dans la prise de courant. Le non-respect de
cette consigne risquerait de provoquer un incendie ou une électrocution.
 Veillez à ne jamais entailler, user, chauffer, tordre, déformer ni placer d'objet lourd
sur le cordon d'alimentation. L'utilisation d'un cordon d'alimentation endommagé
(dont un fil est rompu ou à nu, etc.) risquerait de provoquer un incendie ou une
électrocution.
Si le cordon présente un de ces endommagements, mettez immédiatement l'appareil
HORS tension, débranchez son cordon d'alimentation et contactez un centre de SAV.
 N'utilisez pas de rallonge. L'utilisation d'une rallonge risquerait de provoquer un
incendie ou une électrocution. Contactez un centre de SAV si vous souhaitez un
cordon d'alimentation plus long.

INFORMATIONS DE SÉCURITÉ
vii
WARNING
 Ne posez jamais de vase ou tout autre récipient contenant de l’eau, ainsi que de petits
objets métalliques tels que des trombones sur l’appareil.
Si le récipient venait à être renversé ou des objets métalliques venaient à tomber dans
l’appareil, cela risquerait de provoquer un incendie, une électrocution ou une panne de
l’appareil.
En cas de pénétration de liquide, d’objet métallique ou de tout autre objet à l’intérieur
de l’appareil, mettez immédiatement l’appareil HORS tension avec son interrupteur
d’alimentation, débranchez son cordon d’alimentation de la prise de courant et
contactez un centre de SAV.
 Si cet appareil venait à chauffer anormalement ou dégageait de la fumée, une odeur ou
un bruit anormal, cessez immédiatement de l’utiliser. Mettez immédiatement
l’appareil HORS tension avec son interrupteur d’alimentation, débranchez son cordon
d’alimentation de la prise de courant et contactez un centre de SAV. Le non-respect de
cette consigne risquerait de provoquer un incendie ou une électrocution.
 En cas de chute de l’appareil ou d’endommagement de son boîtier, cessez
immédiatement d’utiliser l’appareil. Mettez immédiatement l’appareil HORS tension
avec son interrupteur d’alimentation, débranchez son cordon d’alimentation de la prise
de courant et contactez un centre de SAV. Le non-respect de cette consigne risquerait
de provoquer un incendie ou une électrocution.
 Branchez le cordon d’alimentation à une prise de courant pourvue d’une broche de
mise à la terre.
CAUTION
 Tenez toujours tout produit inflammable -liquide, gaz et vaporisateur- à l’écart de
l’appareil car ces produits posent un risqué d’incendie.
 N’obstruez jamais les orifices de ventilation de cet appareil avec quelque objet que ce
soit.
 La chaleur risquerait de s’accumuler à l’intérieur de l’appareil, provoquant un
incendie ou une panne.
 N’installez pas cet appareil dans un endroit directement exposé aux rayons du soleil,
ni à proximité d’un climatiseur ou d’un appareil de chauffage. Le changement de
température ainsi provoqué à l’intérieur de l’appareil risquerait de causer une panne,
un incendie ou une électrocution.
 N’installez pas cet appareil dans un endroit poussiéreux et évitez également les
endroits exposés à de la suie ou de la vapeur, à proximité d’une table de cuisine, d’une
baignoire ou d’un humidificateur. Cela risquerait de provoquer un incendie, une
électrocution ou une panne de l’appareil.
 N’installez pas cet appareil sur une surface instable ou inclinée, et évitez également
les endroits particulièrement exposés aux vibrations et chocs. L’appareil risquerait de
se renverser ou de tomber, causant des blessures ou une panne.
 Tenez les unités de toner et unités de tambour PC à l’écart des disquettes, montres et
autres objets sensibles aux champs magnétiques.
Cela risquerait de provoquer un fonctionnement erratique de ces appareils.

INFORMATIONS DE SÉCURITÉ
viii
CAUTION
 Ne posez aucun objet à proximité de la prise de courant alimentant le cordon car cela
risquerait de gêner l’accès au cordon et son retrait en cas d’urgence.
 Veillez à ce que la prise de courant alimentant l’appareil se trouve à proximité de ce
dernier et soit facile d’accès afin de permettre un retrait rapide du cordon
d’alimentation en cas d’urgence.
 Utilisez uniquement cet appareil dans un endroit bien ventilé. Une utilization
prolongée de l’appareil dans une pièce faiblement ventilée pourrait poser un risque
pour la santé de l’utilisateur. Veillez à aérer la pièce à intervalles réguliers.
 Veillez à toujours débrancher le cordon d’alimentation et tout autre câble avant de
déplacer l’appareil. Le non-respect de cette precaution risquerait d’endommager le
cordon d’alimentation ou le câble et de provoquer un incendie, une électrocution ou
une panne.
 Lorsque vous déplacez l’appareil, veillez à toujours le tenir aux endroits indiqués dans
le mode d’emploi ou toute autre documentation. Une chute de l’appareil risquerait de
causer de graves blessures. Cela pourrait en outre causer une panne et/ou un
endommagement de l’appareil.
 Veillez à débrancher la fiche du cordon d’alimentation de la prise de courant plusieurs
fois par an afin de nettoyer les broches de la fiche.
Toute accumulation de poussière entre les broches de la fiche risquerait de provoquer
un incendie.
 Quand vous débranchez le cordon d’alimentation, veillez à saisir le cordon par sa
fiche. Ne tirez jamais sur le cordon même car cela risquerait de l’endommager et de
provoquer un incendie ou une électrocution.
Precautions for Routine Use
 N’utilisez jamais cet appareil en présence d’ammoniaque ou d’autres produits
chimiques ou gaz. Le non-respect de cette précaution risquerait de réduire la durée de
vie de l’appareil, de causer des dommages ou de réduire ses performances.
 N’utilisez jamais cet appareil dans un endroit où la temperature ambiante sort de la
plage spécifiée dans le mode d’emploi, car cela risquerait de causer une panne et/ou
un endommagement de l’appareil.

ix
Welcome
Please follow the instructions given in this manual when operating the system and do not touch any
part of the system the manual does not cover.
NEVER attempt to disassemble or rebuild the system.
The contents of this manual are subject to change without notice.
No part of this manual may be quoted, reproduced or translated into any other language.

x
Introduction
Thank you for choosing our Digital Film Scanner “SL1000” (herein after referred to as “the Scanner”).
This User’s Guide includes precautions for installation/operation of the Scanner, a system outline, an
explanation of the Driver software, operation procedures for the Scanner, troubleshooting tips,
maintenance, and product specifications.
To ensure the best performance and effective use of your unit, read this manual carefully until you
familiarize yourself thoroughly with the unit's operation and features.
Please keep this manual and use it as a quick and handy reference tool for immediately clarifying any
questions that may arise.
Please also NOTE the following precautions.
Safety Information
All Areas
Use the USB Cable supplied with the equipment. Use of an unshielded cable invites radio frequency
interference.
Always refer to this manual when operating the Scanner and do not attempt to touch the Scanner parts
for which no explanations are given in the text.
NEVER attempt to disassemble or modify the Scanner, as it is very dangerous.
Call your authorized dealer when you want to move the Scanner, which has been installed.
FCC Part 15 - Radio Frequency Devices (For U.S.A. Users)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
WARNING
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at their own expense.
The design and production of this unit conform to FCC regulations, and any changes or modifications
must be registered with the FCC and are subject to FCC control. Any changes made by the purchaser
or user without first contacting the manufacturer will be subject to penalty under FCC regulations.

xi
Interference-Causing Equipment Standard (ICES-003 ISSUE 4) For Canada Users)
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
UL/UL Marking
This equipment has been tested and found to comply with UL60950-1.
CE Marking (Declaration of Conformity) (For European Users)
This product complies with the following EU directives:
2006/95/EC and 2004/108/EC directives.
This declaration is valid for the area of the European Union (EU) only.
This device must be used with shielded interface cable and shielded network cable.
The use of non-shielded cable is likely to result in interference with radio communications and is
prohibited under rules.
We declare under our sole responsibility that the Scanner and options to which this declaration relates
is in conformity with the specifications below.
This declaration is valid for the area of the European Union (EU) only.
Trademark Acknowledgments
IBM and IBM PC/AT are registered trademarks of International Business Machines Corporation.
Microsoft, Windows, Windows Vista and Windows 7 are registered trademarks of Microsoft
Corporation.
All other brand or product names are trademarks or registered trademarks of their respective
companies or organizations.

xii
Organization
This manual consists of the following seven chapters. Chapters 1 and 2 contain basic information
about the Scanner, including safety precautions for installation/operation, system configuration, and
features. Be sure to read these chapters before using the Scanner.
Chapter 1 Precautions for Installation and Operation
Provides safety precautions required to ensure correct installation and operation of the
Scanner.
Chapter 2 Overview
An overview of the features, system configuration, functions and part names of the
Scanner
Chapter 3 Application “SL-Touch for SL1000”
Describes the application “SL-Touch for SL1000”.
Chapter 4 Operation
Describes operation precautions and procedures, and settings for each function.
Chapter 5 Troubleshooting
Describes error and warning messages that appear on the Personal Computer, and
procedures for eliminating these problems.
Chapter 6 Maintenance
Describes daily maintenance required for satisfactory operation of the Scanner.
Chapter 7 Specifications
Complete specifications of the Scanner.
NOTE:
In this manual, important points requiring special attention are described in sections marked with
“NOTE ”. Items that appear on the menu screen in the Personal Computer are enclosed by double
quotation marks “ ”. Referenced chapters or their titles are shown in brackets [ ].

xiii
Contents
Chapter 1 Precautions for Installation & Operation.................1-1
1Precautions for Installation............................................................ 1-2
1.1 Installation Environment.............................................................. 1-2
1.2 Power Source ............................................................................. 1-2
1.3 Grounding ................................................................................... 1-2
1.4 Space Requirements................................................................... 1-3
2Precautions for Installation and Operation .................................... 1-5
2.1 Operating Environment ............................................................... 1-5
2.2 Precautions when operating the Scanner................................... 1-5
2.3 Precautions when operating the Personal Computer ................. 1-5
2.4 Moving the Scanner.................................................................... 1-6
Chapter 2 Overview ....................................................................2-1
1Features........................................................................................2-2
2Part Identification and Functions................................................... 2-3
2.1 Main Unit..................................................................................... 2-3
2.2 Roll Film Carrier (Option)............................................................ 2-4
Chapter 3 Application “SL-Touch for SL1000”.........................3-1
1SL-Touch for SL1000 Setup .......................................................... 3-2
1.1 Trademark Acknowledgments..................................................... 3-2
1.2 System environment ................................................................... 3-2
1.3 Installation the Application Software and the Driver Software .... 3-3
1.4 Update the Application Software and the Driver Software .......... 3-8
1.5 Uninstalling the Application Software and the Driver Software ..3-11
2Application Start-Up and Shutdown............................................. 3-13
2.1 Application Start-Up .................................................................. 3-13
2.2 Application Shutdown ............................................................... 3-14
3SCAN Mode Screen.................................................................... 3-15
3.1 Toolbar ...................................................................................... 3-17
3.2 Film Selection ........................................................................... 3-22
3.3 Image Adjustment ..................................................................... 3-25
3.4 Lamp Illuminance...................................................................... 3-29
3.5 Output Setting........................................................................... 3-30
3.6 Preferences .............................................................................. 3-35
3.7 Custom Setting ......................................................................... 3-38
3.8 Password Change .................................................................... 3-42
3.9 E-Mail Setting ........................................................................... 3-43
4VIEW Mode Screen..................................................................... 3-45
4.1 Toolbar ...................................................................................... 3-47
4.2 Image Adjustment ..................................................................... 3-49
4.3 Convert multi-page.................................................................... 3-51
4.4 OCR.......................................................................................... 3-53
4.5 E-Mail........................................................................................ 3-55

xiv
4.6 Delete File .................................................................................3-58
5Roll Film Carrier ..........................................................................3-59
5.1 Roll Film Carrier ........................................................................3-59
5.2 Multiple SCAN ...........................................................................3-61
5.3 Multiple SERACH ......................................................................3-63
Chapter 4 Operation....................................................................4-1
1Precautions for Operation .............................................................4-2
1.1 Main Unit .....................................................................................4-2
1.2 Roll Film Carrier (Option) ............................................................4-2
2Turning the Scanner ON/OFF .......................................................4-3
2.1 Turning ON the Power Switch .....................................................4-3
2.2 Turning OFF the Power Switch ...................................................4-3
2.3 Power Saving Features ...............................................................4-4
3Operating the Fiche Film...............................................................4-5
3.1 Film Selection..............................................................................4-5
3.2 Film Insertion...............................................................................4-5
4Operating the Roll Film .................................................................4-7
4.1 Film Selection..............................................................................4-7
4.2 Selecting the Film Width 16 mm/35 mm...................................... 4-8
4.3 Loading the Roll Film...................................................................4-9
4.4 Feeding the Film........................................................................ 4-13
4.5 Rewinding the Film....................................................................4-15
4.6 Operation of the A-Type Cartridge Adaptor (Option) .................4-16
4.7 Operation of the M-Type Cartridge Adaptor (Option).................4-18
Chapter 5 Troubleshooting.........................................................5-1
1Problems with the Scanner ...........................................................5-2
2Troubleshooting ............................................................................5-3
2.1 Flashing display of the Indicator Lamp........................................5-3
2.2 Attention display on the Personal Computer Screen................... 5-3
2.3 Errors shown on the Personal Computer Screen........................5-4
3Trouble when scanning an image .................................................5-6
4Trouble when the Film Rewinding and Winding ............................ 5-6
Chapter 6 Maintenance ...............................................................6-1
1Maintenance .................................................................................6-2
1.1 Daily checks ................................................................................6-2
1.2 Cleaning ......................................................................................6-3
Chapter 7 Product Specifications..............................................7-1
1Major Specifications ......................................................................7-2

Chapter 1
Precautions for Installation
& Operation

SL1000 User’s Guide
1-2
1 Precautions for Installation
1.1 Installation Environment
Install the Scanner in a location, which meets the following requirements to ensure safe
operation and utmost performance.
A well-ventilated place
An area which is free from ammonia or other organic gases.
A place which has easy access to a power outlet so that the unit may be easily plugged and
unplugged.
An area free from direct sunlight
A place which is out of the direct air stream of an air conditioner, heater or ventilator and is
not subject to extremely high or low temperatures or humidity.
A stable location with a flat surface that is not subject to undue vibration.
A place away from curtains or other objects that catch fire and burn easily
An area that is safe from spilled water or other liquids.
A dust-free location
1.2 Power Source
The Power Source Voltage Requirements are as follows.
Use a Power Source with little voltage/frequency fluctuations.
Power Source: 50 Hz – 60 Hz
Voltage Fluctuation: 120 VAC ±10%, 230 VAC ±10%
Frequency Fluctuation: 50 Hz ±3 Hz
60 Hz ±3 Hz
Be careful not to exceed the capacity of the outlet, especially when sharing other appliances
from the same outlet.
The outlet should be located near the unit and be easily accessible so that the Power Cord
can be unplugged immediately if necessary.
NEVER connect any other appliances or machines by means of a multiple socket to the
outlet being used for the unit.
If an Extension Cord is needed, use one with a capacity greater than the power consumption
of the unit.
Make sure that the Power Cord and extension cord do not become caught in any mechanism
of the system. Do not allow either the power or extension cord to become caught underneath
the weight of the unit.
1.3 Grounding
Be sure to connect the Ground Wire for the Power Cable to any of the following places to
prevent electrical shocks due to electrical leakage:
Ground Terminal of the outlet
Ground terminal that complies with local electrical standards
NOTE : NEVER connect the Ground Cable to a Gas Pipe, the Ground Wire for a Telephone
Line, or a Water Pipe.

Chapter 1 Precautions for Installation & Operation
1-3
1.4 Space Requirements
Secure the recommended space shown in the figure below to ensure easy operation and
maintenance of the Scanner.
[Standard: Fiche Carrier Model]

SL1000 User’s Guide
1-4
[Motorized Roll Film Carrier /Manual Roll Film Carrier Model]
