Konquest KDT-2106v2 Instruction manual

QUICK USER GUIDE
KONQUEST KDT-2106v2
DIGITAL INFRARED THERMOMETER
KDT-2106v2

1
[1] Power button / Measure button
[2] LCD display screen
[3]Probe cover (keep it when measuring forehead temperature)
[4] Memory button / Unit switch button
[5] Probe cover (remove it when measuring ear temperature)
[6] Battery cover
[7] Mode button
[8] Sound switch
[1] Object temperature mode
[2] Forehead temperature mode
[3] Ear temperature mode
[4] Low battery
[5] Mute / Un-mute
[6] Fahrenheit / Celsius degrees
[7] Memory recall
[8] Temperature value
DISPLAY DESCRIPTION
PRODUCT STRUCTURE
M
1 2 3 4 5
6
7
8
MODE
MEM
1

2
2 EAR MODE TEMPERATURE MEASURE
1FOREHEAD MODE TEMPERATURE MEASURE
[1] Take off probe cover.
[2] Press and release the POWER/MEASURE[ ]
button for one second.
[3] Press the MODE [ ]button and select EAR.
The symbol EAR [ ] is displayed in the screen.
[4] Insert the probe in the ear canal.
[5] Press the POWER/MEASURE [ ] button to
start measurment.
[6] After the beep temperature will appear
in the LCD screen.
MODE
[1] Put the cover on the probe.
[2] Press and release the POWER/MEASURE [ ]
button for one second.
[3] Press the MODE [ ]button.
Select FOREHEAD. The symbol HEAD [ ]
is displayed in the screen.
[4] Place the probe with de cover on the
forehead between the eyesbrows.
[5] Press the POWER/MEASURE [ ] button
to start measurment.
[6] After the beep temperature will appear
in the LCD screen.
MODE

3
3OBJECT MODE TEMPERATURE MEASURE
4 SWITCH FAHRENHEIT TO CELSIUS DEGREES
5 MUTING THE THERMOMETER
READ INSTRUCTION MANUAL THOROUGHLY BEFORE USE
[1] Press and release the POWER/MEASURE [ ]
button for one second.
[2] Press and hold the MEMORY/UNIT [ ]button
for more than 4 seconds. ˚For ˚Care flashing.
[3] Press the MEMORY/UNIT [ ]button to switch
between ˚For ˚C.
[4] The thermometer shuts down after 10 second.
The setup is successful.
MEM
MEM
[1] Toggle the SOUND SWITCH [ ] to swicth
between MUTE and UN-MUTE.
[2] The [ ] symbol is displayed in MUTE MODE
and disappears in UN-MUTE MODE.
[1] Put the cover on the probe.
[2] Press and release the POWER/MEASURE [ ]
button for one second.
[3] Press the MODE [ ]button. Select OBJECT.
The symbol HOUSE [ ] is displayed in the screen.
[4] Point the thermometer to the center of the forehead
between the eyesbrows.
[5] Press the POWER/MEASURE [ ] button to start
measurment.
[6] After the beep temperature will appear in the LCD screen.
MODE
