Kontron KTA75/Flex User manual

The pulse of innovation
PRELIMINARY
KTA75/Flex
KTD-N0876-0

Error! Use the Home tab to apply Überschrift 1 to the text that you want to appear here.
Table of Contents
KTA75/Flex Users Guide
» Table of Contents «
1Introduction ........................................ 5
2Installation Procedure .............................. 6
2.1 Installing the Board ................................................. 6
2.2 Requirements IEC60950 ................................................ 7
3System Specifications ............................... 8
3.1 Component main data .................................................. 8
3.2 KTA75/Flex Block Diagram ............................................ 14
3.3 USB ports overview .................................................. 15
4Connectors Locations ............................... 18
4.1 KTA75/Flex Topview .................................................. 18
5Connector Signal Definitions ....................... 19
6Rear IO Connectors ................................. 20
6.1 DisplayPort (DP0/DP1/DP2)( J3/J4/J44) ............................... 20
6.2 USB3.0 Connectors (USB10/USB11/USB12/USB13)(J15/J15/J14/J14) ........ 23
6.3 Ethernet Connectors (ETH1/ETH2) (J8) ................................ 25
6.4 USB x4 Stack Connector (USB6/USB7/USB8/USB9) (J20) .................. 26
6.5 Audio Interface (J40) ............................................... 28
7Pin Connectors ..................................... 29
7.3 Audio Header Connector (J41) ........................................ 31
7.4 USB4/5 Connector (J16) .............................................. 32
7.5 Jumper area (J34, J35, J36, J37) .................................... 34
7.6 SPI Connector (J21) ................................................. 35
7.7 COM1/COM2 (J23/J22) ................................................. 36
7.8 LPC Connector (J29) ................................................. 37
7.9 Front Panel Connector (J5) .......................................... 38
7.10 CPU/System Fan Connectors (J25, J24) ................................ 40
7.11 Feature Connector (J26) ............................................. 41
7.12 KBD/MSE (J27) ....................................................... 46
8Slot Connectors (PCI-Express, miniPCIe, PCI, SATA,
mSATA) .................................................. 47
8.1 PCIex16 (in x16 slot) (J7) .......................................... 47
8.2 PCIex4 (J6) ........................................................ 49
8.3 mPCIe connector (J38) ............................................... 51
8.4 mSATA/mPCIe Connector (J43) ......................................... 52

Error! Use the Home tab to apply Überschrift 1 to the text that you want to appear here.
Table of Contents
KTA75/Flex Users Guide
8.5 PCI slot connectors (J18 & J28) ..................................... 53
8.6 SATA0, SATA1, SATA2, SATA3, SATA4 & SATA5 (J12, J13, J9, J11, J10 &
J39) 57
Appendix: Mating Connectors ............................. 58
Appendix: OS Setup ...................................... 59

KTD-N0876-0 Page 1 General Information
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Document Revision History
Rev.
Date
By
Comment
0
Mar 21th 2013
MLA
Preliminary version ofKTA75/Flex.
Copyright Notice
Copyright 2013, KONTRON Technology A/S, ALL RIGHTS RESERVED.
No part of this document may be reproduced or transmitted in any form
or by any means, electronically or mechani- cally, for any purpose
without the express written permission of KONTRON Technology A/S.

KTD-N0876-0 Page 2 General Information
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of
their respective owners.
Disclaimer
KONTRON Technology A/S reserves the right to make changes without
notice to any product, including circuits and/or software described or
contained in this manual in order to improve design and/or
performance.
Specifications listed in this manual are subject to change without
notice. KONTRON Technology assumes no responsibility or liability for
the use of the described product(s), conveys no license or title under
any patent, copyright or mask work rights to these products and makes
no representations or warranties that these products are free from
patent, copyright or mask work right infringement unless otherwise
specified. Applications that are described in this manual are for
illustration purposes only. KONTRON Technology A/S makes no
representation or warranty that such application will be suitable for
the specified use without further testing or modification.
Life Support Policy
KONTRON Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS
IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT EXPRESS WRITTEN APPROVAL OF
THE GENERAL MANAGER OF KONTRON Technology A/S.
As used herein:
Life support devices or systems are devices or systems which (a) are
intended for surgical implant into body or (b) support or sustain life
and whose failure to perform when properly used in accordance with
instructions for use provided in the labelling can be reasonably
expected to result in significant injury to the user.
A critical component is any component of a life support device or
system whose failure to perform can be reasonably expected to cause
the failure of the life support device or system or to affect its
safety or effectiveness.

KTD-N0876-0 Page 3 General Information
KTA75/Flex Users Guide
KTA75/Flex Users Guide
KTA75/Flex P/N: 66110000
Prod.code:A4Q S/N: 01148401
KONTRON Technology Technical Support
If you have questions about installing or using your KONTRON
Technology Product, then check this User’s Manual first – you will
find answers to most questions here. To obtain support please contact
your local Kontron Sales Partner or Kontron Field Application Engineer
(FAE).
Before Contacting Support: Please be prepared to provide as much
information as possible:
CPU Board
1.Type and P/N (Part Number), find label like:
2.S/N (Serial Number), find label like:
Configuration (if relevant)
1.CPU Type and Clock speed
2.DRAM Type and Size.
3.BIOS Revision (find the version info in the BIOS Setup Menu).
4.BIOS Settings different than Default Settings.
System (if relevant)
1.OS (Operating System) Make and Version.
2.Driver Version numbers: Graphics, Network, and Audio etc.
3.Attached Hardware: Harddisks, CD-Rom, Display Panels etc.

KTD-N0876-0 Page 4 General Information
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Warranty
KONTRON Technology warrants its products to be free from defects in
material and workmanship during the warranty period. If a product
proves to be defective in material or workmanship during the warranty
period KONTRON Technology will, at its sole option, repair or replace
the product with a similar product.
Replacement Product or parts may include remanufactured or refurbished
parts or components.
The warranty does not cover:
1.Damage, deterioration or malfunction resulting from:
A. Accident, misuse, neglect, fire, water, lightning or other
acts of nature, unauthorized product modification or failure
to follow instructions supplied with the product.
B. Repair or attempted repair by anyone not authorized by
KONTRON Technology.
C. Causes external to the product, such as electric power
fluctuations or failure.
D. Normal wear and tear.
E. Any other causes which does not relate to a product defect.
2.Removal, installation and set-up service charges.
Exclusion of damages:
KONTRON TECHNOLOGY LIABILITY IS LIMITED TO THE COST OF REPAIR OR
REPLACEMENT OF THE PRODUCT. KONTRON TECHNOLOGY SHALL NOT BE LIABLE
FOR:
1.DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT,
DAMAGES BASED UPON INCON- VENIENCE, LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, LOSS OF PROFITS, LOSS OF BUSINESS OPPORTUNITY,
LOSS OF GOODWILL, INTERFERENCE WITH BUSINESS RELATIONSHIPS OR
OTHER COMMERCIAL LOSS, EVEN IF ADVISED OF THEIR POSSIBILITY OF
SUCH DAMAGES.
2.ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR
OTHERWISE.
3.ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.

KTD-N0876-0 Page 5 Introduction
KTA75/Flex Users Guide
KTA75/Flex Users Guide
1Introduction
This manual describes the KTA75/Flex family of boards made by KONTRON
Technology A/S. These board will also be denoted KTA75 within this
Users Guide.
The KTA75 is designed to support the listed APU variants (uPGA 722pin
processors) and AMD A75 Fusion Controller Hub (FCH) A75 on a Flex form
factor. See the chapter System Specifications for more specific
details.
APU variants
AMD PN
Processor data
R-464L
RE464LDEC44HJE
2.3 GHz –Quad Core –35W
R-460H
RE460HDEC44HJE
1.9 GHz –Quad Core –35W
R-272F
RE272FDEC23HJE
2.7 GHz –Dual Core –35W
R-268D
RE268DDEC23HJE
2.5 GHz –Dual Core –35W
The 4 versions have the same type of active CPU cooler (the cooler is
by default not premounted, but can be ordered with this obtion).
Use of this Users Guide implies a basic knowledge of PC-AT hard- and
software. This manual is focused on describing the KTA75 board’s
special features and is not intended to be a standard PC-AT textbook.
New users are recommended to study the Installation Procedure stated
in the following chapter before switching-on the power.
All configuration and setup of the CPU board is either done
automatically or manually by the user via the BIOS setup menus. Only
exceptions are the Clear CMOS jumper and the Always On jumper.

KTD-N0876-0 Page 6 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Warning: Turn off PSU (Power Supply Unit) befor configuring
the board and do not hot plug power supply, otherwise
components (RAM, LAN cards etc.) might get damaged.
!
!
Warning: please notice that the board contains components on
both sides of the PCB which can easily be damaged if board is
handled without reasonable care. A damaged component can
result in malfunction or no function at all. Do not use
washers with teeth as they can damage the PCB and may cause
2Installation Procedure
2.1 Installing the Board
To get the board running, follow these steps. If the board shipped
from KONTRON has already components like RAM mounted, then relevant
steps below can be skipped.
1. Turn off the PSU (Power Supply Unit)
2. Insert the DDR3 UDIMM 240 Pin module(s)
Be careful to push it in the slot(s) before locking the tabs.
3. Connecting Interfaces and PSU
Insert all external cables for hard disk, keyboard etc. A
display/monitor must be connected in order to be able to change
BIOS settings. Connect a standard ATX/BTX PSU to the board by the
inserting power cables into 24-pin ATX and the 4-pin ATX+12V PWR
plugs connectors.
4. Power Button
Turn on mains power to the PSU. If board doesn’t boot, then
PWRBTN_IN must be toggled; this is done by shorting pins 16
(PWRBTN_IN) and pin 18 (GND) on the FRONTPNL connector (see
Connector description), by use of a “normally open” switch etc.
5. BIOS Setup
Enter the BIOS setup by pressing the <Del> key during boot up. Enter
Exit Menu and Load Optimal Defaults. Refer to the “BIOS
Configuration / Setup“ section of this manual for details on BIOS
setup.
6. Mounting the board to chassis
It is recommended using screws with integrated washer and having
diameter of approx. 7mm.
Note: To clear all BIOS settings, including Password protection,
activate Clear CMOS Jumper for ~10 sec (without power connected).

KTD-N0876-0 Page 7 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
2.2 Requirements IEC60950
Users of KTA75 should take care when designing chassis interface
connectors in order to fulfil the IEC60950 standard.
Lithium battery precautions
CAUTION!
Danger of explosion if battery is
incorrectly re- placed. Replace only
with same or equivalent type
recommended by manufacturer. Dispose
of used batteries according to the
manufacturer’s instruc- tions.
VORSICHT!
Explosionsgefahr bei unsachgemäßem
Austausch der Batterie. Ersatz nur
durch den selben oder einen vom
Hersteller empfohlenen gleichwertigen
Typ. Entsorgung gebrauchter Batterien
nach Anga- ben des Herstellers.
ATTENTION!
Risque d'explosion avec l'échange
inadéquat de la batterie. Remplacement
seulement par le même ou un type
équivalent recommandé par le
producteur. L'évacuation des batteries
usagées conformément à des indications
du fabricant.
PRECAUCION!
Peligro de explosión si la batería se
sustituye incorrectamente. Sustituya
solamente por el mismo o tipo
equivalente recomendado por el
fabricante. Disponga las baterías
usadas según las instrucciones del
fabricante.
ADVARSEL!
Lithiumbatteri –Eksplosionsfare ved
fejlagtig håndtering. Udskiftning må
kun ske med batteri af samme fabrikat
og type. Levér det brugte batteri
tilbage til leverandøren.
ADVARSEL!
Eksplosjonsfare ved feilaktig skifte av
batteri. Benytt samme batteritype eller
en tilsvarende type anbefalt av
apparatfabrikanten. Brukte batterier
kasseres i henhold til fabrikantens
instruksjoner.
VARNING!
Explosionsfara vid felaktigt
batteribyte. Använd samma batterityp
eller en ekvivalent typ som
rekommenderas av apparattillverkaren.
Kassera använt batteri enligt
fabrikantens instruktion.
VAROITUS!
Paristo voi räjähtää, jos se on
virheellisesti asennettu. Vaihda
paristo ainoastaan lalteval- mistajan
suosittelemaan tyyppiln. Hävitä
käytetty paristo valmistajan ohjeiden
mukaisesti.
When an interface or connector has a VCC (or other power) pin which is
directly connected to a power plane like the VCC plane:
To protect the external power lines of the peripheral devices the
customer has to take care about:
•That the wires have suitable rating to withstand the maximum
available power.
•That the enclosure of the peripheral device fulfils the fire
protecting requirements of IEC60950.

KTD-N0876-0 Page 8 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
3System Specifications
3.1 Component main data
The table below summarizes the features of the KTA75/Flex embedded
motherboards.
Form
factor
Flex: 190,5 x 228,6 mm / 7,5 x 9,0”
ocessor
AMD eTrinity FP2 processor:
•Quad-Core 2.3 GHZ with R-464L APU 35W
•Quad Core 1.9 GHz with R-460H APU 35W
•Dual Core 2.7 GHz with R-272F APU 35W
•Dual Core 2.5 GHz with R-268D APU 35W
•Compatible with Existing 32-Bit x86 and 64-bit AMD64
Code Base
•AMD64 64-bit ISA
•High Performance Floating-Point Unit
•SSE 4.1 & 4.2, AVX 1.0 &1.1, AES, XOP, FMA4
•Secure advanced Virtualization Features
•64-bit DDR3 SDRAM Controller (1333MT/s,666MHz): PC3-
10600 / (1600MT/s,800MHz): PC3-12800
•Compliant with JEDEC DDR3 1.5V and LV-DDR3
1.35V/1.25V SDRAM specification. Note:LV-DDR3 modules
not validated
•PCIe® Technology
•Integrated Memory Controller
•Integrated Graphics AMD Radeon™ HD 7000G Series
graphics.
•Dedicated graphics memory controller
•2D Acceleration Features
•Open GL 4.2 & 2.0
•DirectX® 11 compliant 3D Acceleration Features
•Adaptive Anti Aliasing, Shader Model 5
•Motion Video Acceleration Features
•Dedicated hardware (UVD 3) for H.264
•VC-1, DivX and MPEG2 decode
•HDCP (High-bandwidth Digital Content Protection)
supported on DisplayPort Interface.
•Display Port 1.2
•Support DVI/HDMI via passive adapter.

KTD-N0876-0 Page 9 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Companion
Device
AMD A75 (Hudson)Fusion Controller Hub
•Unified Media Interface (UMI) (5.0 GT/s)
•PCI Express® 2.0 Controller
•PCI Host Bus Controller
•USB Controllers with up to 14 USB ports
•SMBus Controller
•SATA Controller with RAID 0,1,10 support
•High Definition Audio
•Real Time Clock (RTC)
•Integrated Clock controller
•ACPI 3.0 compliant
Memory
Memory controller is integrated in the AMD eTrinity FS1r2
uPGA 722pin processor.
Features are:
•Compliant with JEDEC DDR3 1.5V and (LV-DDR3 1.35V /
1.25 SDRAM, not verified) specifications
•Supports DDR3 UDIMM 240pin Using up to 8GB DRAM
technology
•DDR3 1333/1600MT/s (PC3-10600/PC3-12800)
•From 1GB to 2x 8GB maximum (16GB in total)
Notes: Less than 4GB displayed in System
Properties using 32bit OS
(Shared Video Memory/PCI
resources is subtracted)
ECC not supported
Flash
(BIOS)
32Mbit SPI Flash for dual System BIOS.
Security
Intel® Integrated TPM 1.2 support
Infineon TPM SLB9635TT1.2 (FW 3.17)
IT8516E
Embedded
Controlle
r
KT Feature Connector.
15 Multiplexed (GPIO, DAC, ADC, PWM & TIMER)
Possible 152 GPIO expansion.
Software Watchdog.
Audio
Codec
Audio, 7.1 Channel High Definition Audio Codec using the
VIA VT1708S codec
Seriel
ATA
6x SATA port J9 –J13 & J39, SATA 3.0
1x mSATA J39 (mechanically sharing space with mPCIe slot
J38), SATA 3.0
•RAID 0,1,10 support
Frontpane
l
2xUSB, HDD-LED, SYSRST#, SUSLED, PWRBTN#, AUDIO Line/MIC
output.
PCI
2x PCI slots (PCI Local Bus Specification revision 2.3
32bit/33MHz)

KTD-N0876-0 Page 10 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
PCIe
1x PCI Express x16 Slot
1x PCI Express x4 Slot (in mechanically x16 slot)
1x mPCIe Slot J38
1x mPCIe/mSATA J43 (mechanically sharing between mSATA and
mPCIe) The mSATA interface will be selected when a mSATA
card are inserted into the mPCIe socket (J43)
DisplayPo
rt
3x DisplayPort connector ( in REAR-IO area)
DP1 J43
DP2 J3
DP0 J4
Optionally Add-On card with 1x DisplayPort
LVDS
Optionally Add-On card (TBD)
Audio
Jack
3x Audiojacks stack J40 (in REAR-IO area)
Blue Line-In
Green Speaker
Pink Mic
Audio
Audio Pin header J41
Line-out
Line-in
Surround output: SIDE, LFE, CEN, BACK and FRONT
Microphone: MIC1
SPDIF-OUT (electrical Interface only)
LAN
Two RJ45 connectors J8 (in REAR-IO area)
2x 10/100/1000Mbits/s LAN (ETH1/ETH2) using Intel®
Pearsonville xGB PCI Express Ethernet controller
(WGI211ATSLJXZ).
PXE Netboot supported.
Wake On LAN (WOL) supported
USB
14x USB ports (9x USB2.0 & 4x USB2.0/USB3.0):
2x USB2.0 in Frontpanel Connector J5
2x USB2.0 in USB Internal USB Connector J16
4x USB2.0, USB stack J20 (in REAR-IO area)
2x USB 2.0/USB3.0, Right USB stack J14 ( in REAR-IO
area)
2x USB 2.0/USB3.0, left USB stack J15 (in REAR-IO
area)
1x USB 2.0 in mPCIe socket J38
1x USB 2.0 in mSATA/mPCIe socket J43
Serial
port
2x RS232 pin header (+12V, -12V supply generated by driver
circuit)
COM1 2x 5 Pin row J23
COM2 2x 5 Pin row J22
LPC
LPC connector J29

KTD-N0876-0 Page 11 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
FAN
CPUFAN 4 pin row J25 12V PWM
SYSFAN 4 pin row J24 12V PWM
PS2
Kbd/Mse
1x 6 Pin row Keyboard / Mouse PS2 cable kit interface J27
Power
Plug
1x 4 pole Internal connector J19 ATX core power
(+12V Single Supply , Max 260W)
1x 24 pole connector J17 ATX/BTX power
Battery
Exchangeable 3.0V Lithium battery for on-board Real Time
Clock and CMOS RAM.
Manufacturer Panasonic / Part-number CR-2032L/BN,
CR2032N/BN or CR-2032L/BE.
Approximate 6 years retention.
Current draw is 4 µA when PSU is disconnected and 0 µA in
S0 –S5.
CAUTION: Danger of explosion if the battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Speaker
On-board Speaker Piezo
On-board speaker (Electromagnetic Sound Generator like
Hycom HY-05LF)

KTD-N0876-0 Page 12 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Environme
ntal
Operating:
0C –60C operating temperature (forced cooling). It is
the customer’s responsibility to provide sufficient
airflow around each of the components to keep them within
allowed temperature range.
10% - 90% relative humidity (non-condensing)
Storage:
-20C –70C; lower limit of storage temperature is defined
by specification restriction of on-board CR2032 battery.
Board with battery has been verified for storage
temperature down to -40°C by Kontron.
5% - 95% relative humidity (non-condensing)
Electro Static Discharge (ESD) / Radiated Emissions (EMI):
All Peripheral interfaces intended for connection to
external equipment are ESD/ EMI protected.
EN 61000-4-2:2000 ESD Immunity
EN55022:1998 class B Generic Emission Standard.
Safety:
EN 60950-1: 2006/ A11:2009/ A1:2010/A12:2011
IEC 60950-1(ed.2)
CSA C22.2 No. 60950-1
Product Category: Information Technology Equipment
Including Electrical Business Equipment
Product Category CCN: NWGQ2, NWGQ8
File number: E194252 ( E194252-A21-CB-1)
Theoretical MTBF:
314.614 / 153.436 hours @ 40ºC / 60ºC
Restriction of Hazardous Substances (RoHS):
All boards in the KTA75 family are RoHS/RoHS-II compliant.
Capacitor utilization:
No Tantalum capacitors on board
Only Japanese brand Solid capacitors rated for 100 ºC used
on board
BIOS
AMI EFI
SPI Connector J21 (for BIOS Recovery)
Clear CMOS J34
Always On J37

KTD-N0876-0 Page 13 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
OS
(planned)
Windows 7 (32 and 64bit)
Windows 8 (32 and 64bit)
Windows XP (32 bit)
DOS
Windows Embedded 7

KTD-N0876-0 Page 14 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
3.2 KTA75/Flex Block Diagram
PCIe x16 (x16slot)
Graphics
eTrinity
APU
Processor
722pin
uPGA
1x PCIe x4 (x16
slot)
1x mPCIe w. USB
(USB2.0)
1x mPCIe/mSATA w.
USB (USB2.0)
2x PCI 32bit/33MHz
2x 10/100/Gbe
Intel
Pearsonville I211AT
6x SATA (SATA3.0,
RAID 0,1,10
1x mSATA (mSATA
shared with mPCIe
socket)
2x UDIMM DDR3
Dual Channel
( 1067/1333
3x DP (DisplayPort
1.2)
A75
FCH
4x USB3.0/USB2.0
10x USB2.0
VIA Audio Codec
SPI BIOS Flash
2x Fan (CPU/System)
TPM (Infineon)
Embedded
Controll
er
ITE8516
2x COM (RS232)
Feature connector:
SMBus/I2C
GPIO/DAC/ADC/PWM
GPIO expansion (up
to 152)
Intruder
6-pin PS/2
Keyboard/Mouse

KTD-N0876-0 Page 15 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
3.3 USB ports overview
The KTA75 board contains two pairs of EHCI (Enhanced Host Controller
Interface) and OHCI (Open Host Controller Interface) in order to
support up to 10 USB1.1/USB2.0 devices and further more two xHCI
(Extensible Host Controller Interface) to support up to 4 USB3.0
devices.
The OHCI controllers support USB1.1, Full-Speed (12Mbps) and Low-Speed
(1.5Mbps).
The EHCI controllers support USB2.0, High-Speed (480Mbps).
The xHCI controllers support USB3.0, USB2.0 and USB 1.1, Super-Speed
(5.0Gbps), High-Speed (480Mbps), Full-Speed (12Mbps) and Low-Speed
(1.5Mbps)
Legacy Keyboard/Mouse and wakeup from sleep states are supported.
Over-current detection on all USB ports except USB2.
USB
#
USB standard
Connector
location
HCI
Note
USB0
USB1
USB2.0 /USB1.1
Frontpanel (J5)
OHCI1/EHCI1
USB2
USB2.0 /USB1.1
mPCIe (J38)
OHCI1/EHCI1
No over
current
detection
USB3
USB2.0 /USB1.1
mSATA/mPCIe (J43)
OHCI1/EHCI1
No over
current
detection
USB4
USB2.0 /USB1.1
Pin row (J16)
OHCI1/EHCI1
USB5
USB2.0 /USB1.1
Pin row (J16)
OHCI2/EHCI2
USB6
USB7
USB8
USB9
USB2.0 /USB1.1
USB quad stack
(J20)
Rear IO
OHCI2/EHCI2
USB1
0
USB1
1
USB3.0/USB2.0/US
B1.1
USB3.0 dual stack
(J15)
Left - Rear IO
xHCI1
USB1
2
USB1
3
USB3.0/USB2.0/US
B1.1
USB3.0 dual stack
(J14)
Right - Rear IO
xHCI2
Notes: In order to meet the requirements of USB standard, the 5V input supply
must be at least 5.00V.
The contacts for USB devices are protected and suitable to supply USB devices
with a maximum input current of 1000mA.

KTD-N0876-0 Page 16 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
Do not supply external USB devices with higher power dissipation through these
pinsTo protect the external power lines of peripheral devices make sure that
- the wires have the right diameter to withstand the maximum available
current.
- to enclosure of the peripheral device fulfills the fire-protecting
conditions of IEC/EN 60950.

KTD-N0876-0 Page 17 System Specifications
KTA75/Flex Users Guide
KTA75/Flex Users Guide
For USB2.0 cabling it is required to use only HiSpeed USB cable,
specified in USB2.0 standard:
For USB3.0 cabling it is required to use only HiSpeed USB cable,
specified in USB3.0 standard:
