1. Vital information-READ NOW
For your child’s safety,please read these instructions carefully before use and keep
them for future reference.Failure to follow the instructions contained in this manual
could result in serious injury to your child.
This child safety seat can only be used with the harness for children 9kg to 18kg
in weight(group I:9 - 18 kg ; group I, 15-36 kg).
This instruction manual can be retained in the special space of the child seat for its
life period.
1.
2.
I III:
Do not use this child safety seat at the home. It has not been designed for home use
and should only be used in your car.
The child safety seat should be changed when it has been subject to violent stresses
in an accident.
3.
4.
5.
6.
Never leave your child unattended in the child restraint system even for a short time.
This child restraint should be securely belted in the vehicle even when not in use.
In a crash or sudden stop,an unsecured child safety seat may injure other occupants.
2

Do not use any load bearing contact points other than those described in the
instructions and marked in the child restraint,
Any luggage or other objects liable to cause injuries in the event of a collision
shall be properly secured.
The rigid items and plastic parts of a child restraint must be so located and installed
that they are not liable,during everyday use of the vehicle to become trapped by a
moveable seat or in a door of the vehicle.
To prevent from the risk of fall,your child should always be fastened.
7.
13.
14.
15.
16.
17.
18.
19.
20.Notice:
Always make sure that any straps holding the seat restraint to the vehicle shall
be tight,any straps restraining the child should be adjusted to the child’s body,and
check that the straps shall not be twisted.
when in doubt ,please contact the
child restraint manufacturer.
It is dangerous to make any alteration or additions to the device without the
approval of the competent authority,and a danger of not following closely the
installation instructions provided by the child restraint manufacturer.
This child safety seat is designed for children from 9 to 36 kg.Never overload
the child safety seat more than one child or with other loads.
The child restraint must not be used without the cover.
The seat cover should not be replaced with any other than the one recommended
by the manufacturer,because the cover constitutes an integral part of the restraint
performance.
Before you adjust any movable or adjustable parts of your child safety seat,you
must remove your baby from the child safety seat.
The child safety seat should be kept away from sunlight if the seat is not provided
with a textile,otherwise it may be too hot for the child’s skin.
Never use a second-hand product,as you can never be certain what was happened
to it.
8.
9.
10.
11.
12.
IMPORTANT!Ensuring that any lap straps is worn low down,so that the pelvis is
firmly engaged.
Do not use in any configuration not shown in the instructions.
34
2. Safety instruction
Only suitable if the approved vehicles are
fitted with 3 point safety-belts,approved
to U N/ECE Regul at i on No.1 6 o r other
equivalent standards.
3. Using safety seat in this way
Forward facing traffic direction
Back facing traffic direction Error
Vehicle is only fitted with 2-point safety belt Error
Vehicle is fitted with 3-point safety belt Correct
Seat beside the driver Correct
Rear seat Correct
Rear middle seats Three-point Belt Correct
Correct
3.1 Please carefully implement the Country Traffic Safety Regulations
●Do not install the child safaty seat at the front seat with airbag.
● Please read the instruction manual carefully that how to use the airbag.
NOTICE
You can install this position
Unable to install the position
Do not install the child safaty seat
at the front seat with air bag.
Only with the three point
safety belt,can this location.
DIAGONAL BELT DIAGONAL BELT
LAP BELT LAP BELT

5
Head belt guide
group II,III
Safety belt route slot
Looking clip
Height adjuster
4.Parts and interior equipment
Headrest
Backrest
Harness adjuster
strap
Base
Comfortable cushion
Chest pad
Comfortable cushion
Adjuster
(Under the cover)
Harness connector
Belt slot
Harness
Belt slot
Adult belt route slots
6.How to place the safety seat
5. Scope of application for children
!
GROUP I
GROUP II,III
It is suitable for the weight 9-18 kg,
given to children about 9months-4
years old.
It is suitable for the weight 15-36 kg,
given to children about 4-12 years old.
6
Note:In order to keep safety,please put the restraint system on the back seat,
and ensure that the backrest and the car seat nicely.
Buckle

A1
A2
7. Installing the safety group I
It is suitable for the weight 9-18 kg,given to children about 9months-4 years old.
7.1 Installing the safety car seat
CLICK
Step 1:Place the child safety seat on the
vehicles ' seat .Pull out the diagonal belt
together with lap belt, through the belt
route slot of backrest(A1、A2) .
Step 2:Insert into car seat belt buckle
Hear a“CLICK”.
78
A3
A4
A5
Step 3: Clip the diagonal belt into
the locking clip.(A3、A4) .
! Note!Please refer to the following
picture,clip the safety belt into the
locking clip in the right way(A5)

9
A6
A7
Step 4:Pull car seat belt follow
the direction of red arrow and
make sure the belt is tight
enough(A6、A7).
10
①
②
A8
A9
A10
Step 3: Put the child into the safety
car seat.
Step 2:Release the buckle
Step 1. Loosen the harness
7.2 Securing the child in the safety
car seat.

11
①
②
③
!
A11
A12
A13
Step 5.Align the left and right buckle
tongues to one tongue and insert into
the buckle until you hear a “Click”.
12
A14
Step 6:Pull the shoulder straps upwards to
remove the slack from the lap sections of
the harness then pull the adjuster strap
until the harness is fully tightened.
B1
B2
8. Installing the safety group II,III
It is suitable for the weight 15-36 kg,for children about 4-12 years old Approx.
8.1
seat pad.
Remove the buckle and car
Step 1. Loosen the harness
Step 2:Release the buckle
RightToo high
Too low
Step 4:
(A11).
Pull the height adjuster to adjust
the height of the harness and the headrest
according to the child's height
The height for the harness is
adjusted by lifting the headrest
Note!
(A12).
CLICK

13
B3
B4
B5
Step 3:Slide both of the harness
straps off the harness connector.
Step 4:Pull out the shoulder belt .
Step 5:
the slot which under the safety
car seat.
Pull out the harness from
14
B6
B8
B7
Step 6:
and accessories well.
Keep the removed cushion
Step 7:
from the safety car seat(B7、B8 .
Remove the shoulder straps
)

15
Too high Right
B12
B13
B14
Step 5:Fasten car seat belt and make
sure, it is tight enough.
Too low
Important:Ensuring that any lap straps is
worn low down,so that the pelvis is firmly
engaged,shall be stressed.
16
Step 4:Use the height adjuster to adjust
the height of the headrest according to
the child's height.The gap between head
belt guide and baby is 2 finger width.The
harness straps should be level with or just
above the child's shoulders(B12、B13).
B10
B11
8.2 Installing the safety car seat
Step 2:T
Step 3:
he diagonal belt go through
the belt guide on the side of the
headrest(B10).
Insert into car seat belt buckle
Hear a“CLICK”(B11).
Step 1:Let the lap belt go through
under the armrest(B9、B10).
CLICK
B9

C1
C2
C3
9. Remove the cover
Step 1. Loosen the harness
Step 2:Release the buckle
Step 3:Slide both of the harness
straps off the harness connector.
17
C4
C5
C6
Step 5:
the slot which under the safety
car seat.
Pull out the harness from
Step 4:Pull out the shoulder belt
forward.
Step 6:
and accessories well.
Keep the removed cushion
18

C7
C8
C9
Step 7:
from the safety car seat(C7、C8 .
Remove the shoulder straps
)
Step 8:Turn the seat to the back and
unlock the snap fastener.
19
C10
C11
Step 9:
cover
Pull all directions to take out the
(C10、C11).
※Follow in reverse order and repeat the procedure to put on the fabric cover
20

21
11. Maintenance and cleaning
11.1 Daily maintenance
1.In daily use,check periodically the child seat.The child seat should be replaced
after an accident.
2.Please keep this child seat in dry and ventilated place to avoid damp moldy.
3.If the child seat becomes dusty,clean the seat belt and the plastic pieces by
swiping them with a damp sponge and let it dry naturally.
4.If food or drink drop accidently on the buckle,disassemble the seat belt from
the child seat and rinse it gently by warm water.Leave it dry naturally.
5.For cleaning the entire child seat fabric cover,please refer to the 11.2 washing
instructions.
11.2 Washing instruction
Never use any solvant,chemical detergent or lubricant on any part of your
child seat.
Hand wash,
water
temperature
below 30℃
Do not bleach Dryclean,any
solvent except
trichloroethylene
Do not tumble dry Do not iron
11.3 Remove and assemble the fabric cover
1. Firstly,remove the crotch pad and buckle of the child seat(see part 9),and
then remove the shoulder straps and comfortable cushion.
2.Remove the fabric cover of the child seat.To install the fabric cover,please
operate follow the above instructions in reverse order.
21
10. Steps of backrest and base assembly
D1
D2
D3
Slot alignment
Slot alignment
Step 2:Align base and backrest in a
straight line.
Step 1:Slide seat out of box
Step 3:Place backrest hooks inside base
securely.
D4
Step 4:Gently keep pressure on hooks
as you lift backrest up.
WARNING:DO NOT FORCE MAY CAUSE
DAMAGE.
22
