1 Introduction
Welcome to Korenix JetNet 5428GRackmount Managed Ethernet Switch User Manual.
Following topics are covered in this chapter:
1.1 Overview
1.2 Major Features
1.3 Package Checklist
1.1 Overview
The JetNet 5428G Series, the 19-inch 24+4G Managed Ethernet Ring Switch includes
JetNet 5428G, JetNet 5428G-DC and JetNet 5428G-2G-2FX.
The JetNet 5428G/5428G-DC, is equipped with 24 10/100 Base-TX ports plus 4 Gigabit
RJ45 / MINI GBIC combo ports. The 5428G-2G-2FX is equipped with 24 10/100 Base-TX
ports, 2 100M/Gigabit SFP plus 2 Gigabit RJ45/SFP combo ports. JetNet 5428G Series is a
special design for control rooms where high-port density and performance are required. The
2/4 Gigabit Combo port design allows 10/100/1000 triple speed of copper ports, and the
SFP ports accept all types of Gigabit SFP transceivers, including Gigabit SX, LX, LHX, ZX
and XD for several connections and distances. Additionally, the last 2 SFP ports of JetNet
5428G-2G-2FX can support 100Base-FX and Gigabit SFP transceivers.
Model Name Description
JetNet 5428G
Rackmount Managed Ethernet Switch with 24 10/100Base-TX +
4 Gigabit Combo Ports, 90-264VAC input
JetNet 5428G-DC Rackmount Managed Ethernet Switch with 24 10/100Base-
TX +
4 Gigabit Combo Ports, 24V (12-48V) DC input
JetNet
5428G-2G-2FX
Rackmount Managed Ethernet Switch with 24 10/100Base-TX +
2 100Base-FX/1000Base-
X SFP + 2 Gigabit Combo Ports,
90-264VAC input
The device is mounted within the 19 inch rack, along with other 19 inch public servers or
other network devices. When the lower industrial switches are aggregated to the JetNet
5428G, the 24+4G design allows connecting up to 12 100M rings plus 2 Gigabit rings. Each
of the ring has its own ring redundancy protection. This is a unique and Korenix patent
protected ring technology.
JetNet 5428G is designed as a fan-less rackmount switch with low power consumption
and wide operating temperature. JetNet 5428G-DC, the DC input model, allows 24V

3
(12-48V) DC input. JetNet 5428G supports Jumbo frame featuring up to 9,216 bytes packet
size for large size file transmission. This is the trend for future industrial application
requests.
The embedded software supports RSTP and Multiple Super Ring technology for ring
redundancy protection. Full layer 2 management features include VLAN, IGMP Snooping,
LACP for network control, SNMP, LLDP for network management. Secured access is
protected by Port Security, 802.1x and flexible Layer 2/4 Access Control List. With JetNet
5428G, you can fulfill the technicians’ need of having best solution for the industrial Ethernet
infrastructure.
1.2 Major Features
Korenix JetNet 5428G has the following major features:
•24-port 10/100 Base-TX and 4-port Gigabit RJ-45/SFP combo ports (10/100/1000
Base-TX, 1000Base-X) (JetNet 5428G/5428G-DC)
•24-port 10/100 Base-TX, 2-port Gigabit RJ-45/SFP combo ports (10/100/1000
Base-TX, 1000Base-X) and 2-port 100Base-FX/1000Base-X SFP ports. (JetNet
5428G-2G-2FX)
•Non-Blocking Switching Performance, no collision or delay when wire-speed
transmission
•Supports Jumbo Frame up to 9,216 byte
•RSTP and Multiple Super Ring (Rapid Super Ring, Rapid Dual Homing, MultiRing,
TrunkRing)
•Maximum 12 x 100M Rings plus 2 Gigabit Rings aggregation capability
•VLAN, LACP, GVRP, QoS, IGMP Snooping, Rate Control, Online Multi Port Mirroring
•Link Layer Discovery Protocol (LLDP), SNMP V1/V2c/V3, RMON and JetView
Discovering and Management
•Advanced Security supports IP/Port Security, 802.1x and Access Control List
•Event Notification by E-mail, SNMP Trap, Syslog and Relay Output
•Rigid Aluminum Case complies with IP31
•90-264VAC or Dual 12-48VDC power input
Note: The detail spec is listed in latest datasheet. Please download the latest
datasheet in Korenix Web site.
1.3 Package List
Korenix JetNet 5428G Series products are shipped with following items:

4
JetNet 5428G 24+4G Rackmount Managed Ethernet Ring Switch
JetNet 5428G (no SFP transceivers)
Rack Mount Kit
Console Cable
Power Cord
Document CD
JetNet 5428G-DC 24+4G Rackmount Managed Ethernet Ring Switch with 12-48VDC
input
Includes:
JetNet 5428G-DC (no SFP transceivers)
Rack Mount Kit
Console Cable
Document CD
JetNet 5428G-2G-2FX 24+4G Rackmount Managed Ethernet Ring Switch
JetNet 5428G-2G-2FX (no SFP transceivers)
Rack Mount Kit
Console Cable
Power Cord
Document CD
Model Name Power Input 100M
Copper
100M&
Gigabit
Fiber
Gigabit
Combo
JetNet 5428G 90-264VAC 24 4
JetNet 5428G-2G-2FX 90-264VAC 24 2 SFP 2
JetNet 5428G-DC 24V(12-48V)DC 24 4
If any of the above items are missing or damaged, please contact your local sales
representative.

5
2 Hardware Installation
This chapter includes hardware introduction, installation and configuration information.
Following topics are covered in this chapter:
2.1 Hardware Introduction
Dimension
Panel Layout
Bottom View
2.2 Wiring Power Inputs
2.3 Wiring Earth Ground
2.4 Wiring Ethernet Ports
2.5 Wiring Fiber Ports
2.6 Wiring Gigabit Combo Ports
2.7 Wiring RS-232 console cable
2.8 Rack Mounting Installation
2.9 Safety Warming
2.1 Hardware Introduction
LED
System: Power (Green), Ring Master (Green)
10/100 RJ-45:
Link/Activity: Green = 100M, Yellow = 10M;
Duplex: On = Full, Off = Half
Gigabit Copper/SFP:
Link/Activity: Green = 1000M, Yellow = 10M or 100M;
Duplex: On = Full, Off = Half)
Gigabit SFP: Link/Activity (Green/Green Blinking)
Dimension
JetNet 5428G Industrial Modular Managed Ethernet Switch dimension (W x H x D) is
44mm(H) x 438mm (W) x 170mm (D)

6
Panel Layout
The front panel includes RS-232 Console Port, System & Port LEDs, Fast Ethernet Port
Interfaces and Gigabit Combo Port Interfaces.
The console port chooses RS-232 DB-9 types. The pin arrangement is “Pin2: TxD, Pin3:
RxD, Pin5:GND”. Korenix attached the console cable within the shipped box.
In the Rear panel, there are 2 types power input connector applied to JetNet 5428G and
JetNet 5428G-DC.
JetNet 5428G/5428G-2G-2FX chooses standard AC plug as power input socket.
JetNet 5428G-DC chooses 4-pin terminal block as power input socket. Follow the V+, V-
indication in the rear panel to screw the power source.
2.2 Wiring Power Inputs
JetNet 5428G provides 2 types power input, AC power input for JetNet 5428G and DC
power input for JetNet 5428G-DC. The front power switch can switch off all the power
input at the same time.
JetNet 5428G AC Power Input
Connect the attached power cord to the AC power input connector, the available AC
power input is range from 90-264VAC.
JetNet 5428G-DC DC Power Input
The suggested power input is 24VDC, the available range is from 12-48VDC.
Follow below steps to wire JetNet 5428G redundant DC power inputs.

7
1. Insert positive and negative wires into V+ and V-
contacts respectively of the terminal block
connector
2. Tighten the wire-clamp screws to prevent DC
wires from being loosened.
3. Power 1 and Power 2 support power redundancy,
one of it failed, the other recovered.
4. Positive and negative power system inputs are
both accepted, but Power 1 and Power 2 must
apply the same mode.
Note 1: It is a good practice to turn off input and load power, and to unplug power terminal
block before making wire connections. Otherwise, your screwdriver blade can
inadvertently short your terminal connections to the grounded enclosure.
Note 2: The range of the suitable DC electric wire is from 12 to 24 AWG.
Note 3: Please follow the V+ and V- indicator to wire. Incorrect wiring would not damage
the switch. Incorrect wiring can not power on the switch.
Note 4: The DC1 and DC2 power status will be shown as DC power status due to the
integrated DC power design.
2.3 Wiring Earth Ground
To ensure the system will not be damaged by noise or any electrical shock, we suggest
you to make exact connection with JetNet 5428G with Earth Ground.
For AC input, the 3 pin include V+, V- and GND. The GND pin must be connected to the
earth ground.
For DC input, loosen the earth ground screw by screw drive; then tighten the screw after
earth ground wire is connected.
2.4 Wiring Fast Ethernet Ports
JetNet 5428G includes 24 RJ-45 Fast Ethernet ports. The fast Ethernet ports support
10Base-T and 100Base-TX, full or half duplex modes. All the fast Ethernet ports will
auto-detect the signal from connected devices to negotiate the link speed and duplex
mode. Auto MDI/MDIX allows users to connect another switch, hub or workstation without
changing straight through or crossover cables.
Note that crossover cables simply cross-connect the transmit lines at each end to the
received lines at the opposite end.

8
Straight-through Cabling Schematic Cross-over Cabling Schematic
Note that Ethernet cables use pins 1, 2, 3, and 6 of an 8-pin RJ-45 connector. The signals
of these pins are converted by the automatic MDI-X function, as shown in the table below:
Pin MDI-X Signals MDI Signals
1 RD+ TD+
2 RD- TD-
3 TD+ RD+
6 TD- RD-
Connect one side of an Ethernet cable into any switch port and connect the other side to
your attached device. The LNK LED will light up when the cable is correctly connected.
Refer to the LED Indicators section for descriptions of each LED indicator. Always make
sure that the cables between the switches and attached devices (e.g. switch, hub, or
workstation) are less than 100 meters (328 feet).
The wiring cable types are as below.
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568 100-ohm (100m)
100 Base-TX: 2-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (100m)
1000 Base-TX: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (100m)
2.5 Wiring Fiber Ports
Small Form-factor Pluggable (SFP)
The SFP ports accept standard Gigabit MINI GBIC SFP transceiver. But, to ensure
system reliability, Korenix recommends using the Korenix certificated Gigabit SFP
Transceiver. The web UI will show Unknown vendor type when choosing the SFP which
is not certificated by Korenix. The certificated SFP transceiver includes 100Base-FX
single/multi mode, 100/Gigabit BIDI/WDM, 1000Base-SX/LX single/multi mode ranger
from 550m to 80KM.
The way to connect the SFP transceiver is to Plug in SFP fiber transceiver fist.
Cross-connect the transmit channel at each end to the receive channel at the opposite
end as illustrated in the figure below. The SPF cage is 2x1 design, check the
direction/angle of the fiber transceiver and fiber cable when
inserted.

9
Below figure is the SFP plug-in and SFP Fiber Cable Plug-in Example.
Note: This is a Class 1 Laser/LED product. Don’t stare at the Laser/LED Beam.
2.6 Wiring Gigabit Combo Ports
JetNet 5428G series includes 4 RJ-45 Gigabit Ethernet ports. The speed of the gigabit
Ethernet port supports 10Base-T, 100Base-TX and 1000Base-TX. JetNet
5428G/5428G-DC equips 4 Gigabit SFP ports combo with Gigabit Ethernet RJ-45 ports.
The speed of the SFP port supports 1000Full Duplex. The available gigabit SFP
supports Gigabit Single-mode, Multi-mode, BIDI/WDM single-mode SFP transceivers.
(The 100Base-FX is not supported in gigabit combo ports.)
The JetNet 5428G-2G-2FX equips 2 100M/Gigabit SFP ports plus 2 Gigabit SFP ports
combo with Gigabit Ethernet RJ-45 Ports. The 2 Combo ports’ capability is the same as
JetNet 5428G/5428G-DC.
While the SFP transceiver is plugged, the Fiber port has higher priority than copper
port and moved to the Fiber mode automatically.
2.7 Wiring RS-232 Console Cable
Korenix JetNet 5428G attaches one RS-232 DB-9 to DB-9 cable in the box. Connect the
DB-9 connector to the COM port of your PC, open Terminal tool and set up serial settings
to 9600, N,8,1. (Baud Rate: 9600 / Parity: None / Data Bit: 8 / Stop Bit: 1) Then you can
access CLI interface by console cable.
Note: If you lost the cable, please contact with your sales or follow the pin assignment to
buy a new one. The Pin assignment spec is listed in the appendix.
2.8 Rack Mounting Installation
The Rack Mount Kit is attached inside the package.
2.1.1 Attach the brackets to the device by using the screws provided in the Rack
Mount kit.

10
(The picture is JetNet 5628G, the mounting method is the same.)
2.2.2 Mount the device in the 19’ rack by using four rack-mounting screws provided by
the rack manufacturer.
(The picture is JetNet 5628G, the mounting method is the same.)
When installing multiple switches, mount them in the rack one below the other. It’s
requested to reserve 0.5U-1U free space for multiple switches installing in high
temperature environment.This is important to disperse the heat generated by the
switch.
Notice when installing:
Temperature: Check if the rack environment temperature conforms to the specified operating
temperature range.
Mechanical Loading: Do no place any equipment on top of the switch. In high vibration
environment, additional rack mounting protection is necessary, like the flat board under/above the
switch.
Grounding: Rack-mounted equipment should be properly grounded.

11
2.9 Safety Warming
2.2.1 The Equipment intended for installation in a Restricted Access
Location.
2.2.2 The warning test is provided in user manual. Below is the information:
”For tilslutning af de ovrige ledere, se medfolgende installationsvejledning”.
“Laite on liitettava suojamaadoitus-koskettimilla varustettuun pistorasiaan”
„Apparatet ma tilkoples jordet stikkontakt“
”Apparaten skall anslutas till jordat uttag”

12
3 Preparation for Management
JetNet 5428G Rackmount Managed Switch provides both in-band and out-band
configuration methods. You can configure the switch via RS232 console cable if you
don’t attach your admin PC to your network, or if you lose network connection to your
JetNet 5428G. This is so-called out-band management. It wouldn’t be affected by
network performance.
The in-band management means you can remotely manage the switch via the network.
You can choose Telnet or Web-based management. You just need to know the device’s
IP address and you can remotely connect to its embedded HTTP web pages or Telnet
console.
Following topics are covered in this chapter:
3.1 Preparation for Serial Console
3.2 Preparation for Web Interface
3.3 Preparation for Telnet console
3.1 Preparation for Serial Console
In JetNet 5428G package, Korenix attached one RS-232 DB-9 to DB-9 console cable.
Please attach RS-232 DB-9 connector to your PC COM port, connect the other end to
the Console port of the JetNet 5428G. If you lose the cable, please follow the console
cable PIN assignment to find one. (Refer to the appendix).
1. Go to Start -> Program -> Accessories -> Communication -> Hyper Terminal
2. Give a name to the new console connection.
3. Choose the COM name
4. Select correct serial settings. The serial settings of JetNet 5428G are as below:
Baud Rate: 9600 / Parity: None / Data Bit: 8 / Stop Bit: 1
5. After connected, you can see Switch login request.
6. Login the switch. The default username is “admin”, password, “admin”.
Booting...
Sun Jan 1 00:00:00 UTC 2006
Switch login: admin
Password:
JetNet5428G (version 0.2.25-20090414-11:04:13).
Copyright 2006-2008 Korenix Technology Co., Ltd.
Switch>

13
3.2 Preparation for Web Interface
JetNet 5428G provides HTTP Web Interface and Secured HTTPS Web Interface for
web management.
3.2.1 Web Interface
Korenix web management page is developed by JAVA. It allows you to use a standard
web-browser such as Microsoft Internet Explorer, or Mozila, to configure and interrogate
the switch from anywhere on the network.
Before you attempt to use the embedded web interface to manage switch operation,
verify that your JetNet 5428G Series Rackmount Ethernet Switch is properly installed on
your network and that every PC on this network can access the switch via the web
browser.
1. Verify that your network interface card (NIC) is operational, and that your operating
system supports TCP/IP protocol.
2. Wire DC power to the switch and connect your switch to your computer.
3. Make sure that the switch default IP address is 192.168.10.1.
4. Change your computer IP address to 192.168.10.2 or other IP address which is
located in the 192.168.10.x (Network Mask: 255.255.255.0) subnet.
5. Switch to DOS command mode and ping 192.168.10.1 to verify a normal response
time.
Launch the web browser and Login.
6. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC.
7. Type http://192.168.10.1 (or the IP address of the switch). And then press Enter.
8. The login screen will appear next.
9. Key in user name and the password. Default user name and password are both
admin.
Click on Enter or OK. Welcome page of the web-based management interface will then
appear.

14
Once you enter the web-based management interface, you can freely change the
JetNet’s IP address to fit your network environment.
Note 1: IE 5.0 or later versions do not allow Java applets to open sockets by default.
Users have to directly modify the browser settings to selectively enable Java applets to
use network ports.
Note 2: The Web UI connection session of JetNet 5428G will be logged out
automatically if you don’t give any input after 30 seconds. After logged out, you should
re-login and key in correct user name and password again.
3.2.2 Secured Web Interface
Korenix web management page also provides secured management HTTPS login. All
the configuration commands will be secured and will be hard for the hackers to sniff the
login password and configuration commands.
Launch the web browser and Login.
1. Launch the web browser (Internet Explorer or Mozila Firefox) on the PC.
2. Type https://192.168.10.1 (or the IP address of the switch). And then press Enter.
3. The popup screen will appear and request you to trust the secured HTTPS
connection distributed by JetNet 5428G first. Press Yes to trust it.
4. The login screen will appear next.

15
5. Key in the user name and the password. The default user name and password is
admin.
6. Click on Enter or OK.Welcome page of the web-based management interface will
then appear.
7. Once you enter the web-based management interface, all the commands you see
are the same as what you see by HTTP login.
3.3 Preparation for Telnet Console
3.3.1 Telnet
Korenix JetNet 5428G supports Telnet console. You can connect to the switch by Telnet
and the command lines are the same as what you see by RS232 console port. Below
are the steps to open Telnet connection to the switch.
1. Go to Start -> Run -> cmd. And then press Enter
2. Type the Telnet 192.168.10.1 (or the IP address of the switch). And then press
Enter
3.3.2 SSH (Secure Shell)
Korenix JetNet 5428G also support SSH console. You can remotely connect to the
switch by command line interface. The SSH connection can secure all the configuration
commands you sent to the switch.
SSH is a client/server architecture while JetNet 5428G is the SSH server. When you
want to make SSH connection with the switch, you should download the SSH client tool
first.
SSH Client
There are many free, sharewares, trials or charged SSH clients you can find on the
internet. Fox example, PuTTY is a free and popular Telnet/SSH client. We’ll use this
tool to demonstrate how to login JetNet by SSH. Note: PuTTY is copyright 1997-2006
Simon Tatham.

16
Download PuTTY: http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html
The copyright of PuTTY
Figure 0... Open SSH Client/PuTTY
In the Session configuration, enter the Host Name (IP Address of your JetNet 5428G)
and Port number (default = 22). Choose the “SSH” protocol. Then click on “Open” to
start the SSH session console.
Figure 0... After click on Open, then you can see the cipher information in the
popup screen. Press Yes to accept the Security Alert.
