Korg ElecTribe ES-1 MkII User manual

S
S
Se
e
er
r
rv
v
vi
i
ic
c
ce
e
e M
M
Ma
a
an
n
nu
u
ua
a
al
l
l
ES-1
Provisional Version
CONTENTS
1) Structural Diagram -----2
2) Block Diagram ---------6
3) Circuit Diagram --------7
4) Diagnostics -----------?
5) Parts List -------------17
Revision: 1.00
Issued date: July 18th, 2000
Issued by: KORG INC.

PART CODE PART NAME NOTE Q'TY
001219700 PCB ASSY KLM-2197 ES-1 ES-1 M.PART 1
001219800 PCB ASSY KLM-2198/2201 ES-1 ES-1 M.PART 1
001219900 PCB ASSY KLM-2199 ES-1 ES-1 M.PART 1
304000070 TR 2SA812-T1B (M5-7) (TS) KLM-2197 ES-1 1
304010020 TR 2SB1120-F/G (TS) KLM-2197 ES-1 1
304020230 TR 2SC3661-TA/TB(3K) (TS) KLM-2197 ES-1 4
304020380 DIGITAL TR FP12Q-T1B (TS) KLM-2198/2201 12
304050140 DIGITAL TR DTC114EKA T146 (TS) KLM-2198/2201 8
304060070 FET 2SK433-T12-1C (TS) KLM-2197 ES-1 2
304060250 FET CPH6302-TL(TS) KLM-2197 ES-1 1
312052000 LED LB603VF KLM-2198/2201 1
314001400 DIODE RLS-73 TE-11 (TS) KLM-2197 ES-1 1
314010340 LED SLZ-190B-02-T1(TR) KLM-2198/2201 13
314010350 LED SLZ-290B-02-T1(TR) KLM-2198/2201 5
314029500 DIODE SB040-G23(TA) KLM-2197 ES-1 1
314029700 DIODE RLR4004 TE-21 (TS) KLM-2197 ES-1 2
314029800 LED CL-200YG-C-TU (TS) KLM-2198/2201 2
314029900 LED SML-210JTT86 (TS) KLM-2198/2201 43
314030700 SCHOTTKY DIODE RB051L-40TE25 KLM-2197 ES-1 1
315000500 DOUBLE DIODE MC-2840-T12-1(TS) KLM-2197 ES-1 3
315000600 DOUBLE DIODE MC2838-T12-1 (TS) KLM-2198/2201 29
320004649 IC HD6412350(D12350F20) (S) KLM-2197 ES-1 1
320012260 IC MBM29F160BE70TN-K(X-829S):S KLM-2197 ES-1 1
320021156 IC TMS57070FFT (S) KLM-2197 ES-1 1
324003010 IC TC7WU04F TE12L (TS) KLM-2197 ES-1 1
324004168 IC HD74HC4053FPEL (TS) KLM-2197 ES-1 1
324004176 IC HD74HC05FPEL (TS) KLM-2197 ES-1 1
324007006 IC BA07FP-E2 (TS) KLM-2197 ES-1 1
324007009 IC BA033FP-E2 (TS) KLM-2197 ES-1 1
324009004 IC NJM78L05UA-TE1 (TS) KLM-2197 ES-1 1
324011004 IC M5216FP-600C (TS) KLM-2197 ES-1 1
324011012 IC M51953BFP-600C (TS) KLM-2197 ES-1 1
324017009 IC RN5RG33AA-TR (TS) KLM-2197 ES-1 1
324017015 IC EM614163A-50J(TS) KLM-2197 ES-1 1
324018006 IC AK4522-VF-E2(TS) KLM-2197 ES-1 1
324021014 IC SN74LV138ANS-EL (TS) KLM-2198/2201 3
324021022 IC SN74HC4040APWR(TS) KLM-2197 ES-1 1
324021025 IC SN74AHCT240PWR(TS) KLM-2197 ES-1 1
324021101 IC SN74LV04APWR (TS) KLM-2197 ES-1 1
324021102 IC SN74LV08APWR (TS) KLM-2197 ES-1 1
324021103 IC SN74LV32APWR (TS) KLM-2197 ES-1 1
324021104 IC SN74LV74APWR (TS) KLM-2197 ES-1 2
324021105 IC SN74LV245APWR (TS) KLM-2197 ES-1 3
324021106 IC SN74LV139APWR (TS) KLM-2197 ES-1 1
324021107 IC SN74LV125APWR (TS) KLM-2197 ES-1 1
324021108 IC SN74LV138APWR (TS) KLM-2197 ES-1 2
324021109 IC SN74LV244APWR (TS) KLM-2197 ES-1 2
324021110 IC SN74LV574APWR (TS) KLM-2197 ES-1 3

PART CODE PART NAME NOTE Q'TY
324023007 IC S-8520F50MC-B0J-T2(TS) KLM-2197 ES-1 1
324037006 IC HY51V65164ASLTC-50-TE1(TS) KLM-2197 ES-1 1
324038005 IC TDA1308T/N1 (TS) KLM-2197 ES-1 4
334000600 PHOTO COUPLER PC-410K (TS) KLM-2197 ES-1 1
335011000 X'TAL OSC CA-301 20.00MHZ KLM-2197 ES-1 1
335011800 X'TAL OSC CA-301 16.384MHZ KLM-2197 ES-1 1
362009005 VR RK0971110SOM KLM-2198/2201 1
362009016 VR RK09K1130CA6 KLM-2197 ES-1 6
362009017 VR RK09K1130D0K KLM-2197 ES-1 2
362009018 VR RK09K12C0D08 KLM-2197 ES-1 1
362009030 RK09K12A0D06(G3857335M)10KDX2 KLM-2197 ES-1 1
370004500 REC EC16B242041S KLM-2197 ES-1 1
373009700 SSW SAA120200(G4177036M) KLM-2197 ES-1 1
375014800 PSW SDKLA10200 KLM-2197 ES-1 1
402004600 COIL 2943-666673 KLM-2197 ES-1 2
402006200 COIL C10-FR/33331 22UH(TR) KLM-2197 ES-1 1
402400400 COIL C8-E/33331 10UH KLM-2197 ES-1 1
404001040 CHIP COIL BLM21A102FPT(TS) KLM-2198/2201 1
404001070 CHIP COIL BLM11B102SPT:TS KLM-2197 ES-1 39
405008000 AC ADAPTOR A30960J ES-1 JP M.PART 1
405008100 AC ADAPTOR A30950 ES-1 US M.PART 1
405008100 AC ADAPTOR A30950 ES-1 EX M.PART 1
405008100 AC ADAPTOR A30950 ES-1 CN M.PART 1
405008300 AC ADAPTOR A9600E ES-1 FR M.PART 1
405008300 AC ADAPTOR A9600E ES-1 WG M.PART 1
405008300 AC ADAPTOR A9600E ES-1 GE M.PART 1
405010500 AC ADAPTOR A9600B ES-1 UK M.PART 1
450003100 PHONE JACK LGR4609-7000 KLM-2197 ES-1 4
454012700 DC POWER JACK DJ32-2 KLM-2197 ES-1 1
472071301 CONNECTOR SIDE S13B-PH-K-S (U) KLM-2197 ES-1 1
472071501 CONNECTOR SIDE S15B-PH-K-S (U) KLM-2197 ES-1 1
474029500 CONNECTOR CN015R-3013-0 KLM-2199 ES-1 1
474030400 FFC CONNECTOR 52271-2690 (TS) KLM-2199 ES-1 1
474030400 FFC CONNECTOR 52271-2690 (TS) KLM-2197 ES-1 1
475002790 HARNESS HNS-2790 BOARD IN KLM-2198/2201 1
475002909 HARNESS HNS-2909 BOARD IN KLM-2198/2201 1
475002910 HARNESS HNS-2910 BOARD IN KLM-2198/2201 1
480010200 DIN SOCKET YKF51-5046 KLM-2197 ES-1 1
500018300 CASE LEG 3X22X3 KOC-F48035 ES-1 M.PART 4
540021900 PLASTIC SUPPORT PS-610 ES-1 M.PART 4
545050720 FLAT CABLE TFL100K-26-90 ES-1 M.PART 1
620018200 PSW KNOB KOC-E40224 ES-1 M.PART 1
620033900 KNOB P422-9OG(BK/L.GR) ES-1 M.PART 9
620035400 X-829P RUBBER KEY F(20KEYS) ES-1 M.PART 1
620035600 X-829P/B RUBBER KEY L(13KEYS) ES-1 M.PART 1
620036000 X-610 ENCODER KNOB(BLK)E40466- ES-1 M.PART 1
620036100 KNOB P82-90G (BK/L.GR) ES-1 M.PART 1
620036500 X-8410 VR KNOB KOC-E40487 ES-1 M.PART 1

PART CODE PART NAME NOTE Q'TY
620038700 X-829S RUBBER KEY S(19KEYS) ES-1 M.PART 1
630024300 X-514/7 8-SEG LED WINDOW ES-1 M.PART 1
630025703 X-829P/B SHIELD SHEET F40869 ES-1 M.PART 5
641041547 X-829P/B BOTTOM COVER C30525 ES-1 M.PART 1
641041575 X-829S SM BRACKET KOC-C41166 ES-1 M.PART 1
644007700 GND SPRING KOC-C46014 ES-1 M.PART 1
644009000 X-8510 GND SPRING(K) KOC-C4116 ES-1 M.PART 6
646073400 X-829S UPPER CASE KOC-E40163-3 ES-1 M.PART 1
