Krabat Jockey Lite User manual

1
Krabat Jockey Lite
User manual

2
Safety
All Krabat products are CE marked according to MDR 2017/745 and 93/42 / EØF, Class 1 of 14 June
1993 - Medical Device Directive. This certifies that it meets all relevant European safety
requirements. This manual is approved according to these standards. The shelf life of the product
corresponds to a lifespan of about 5 years under normal use. After about 5 years the product should
be renovated by Krabat AS or an approved partner to extend the product’s service life. All service
must be performed by Krabat or an authorized partner.
Products with electrical components must be submitted to Krabat for a technical review / overhaul
before it is sent out to use again.
The CE-label is to be removed if the product is modified, or non-original parts are used!
Adjustments not described in Krabat user manuals shall only be carried out by Krabat, or by
personnel approved by Krabat.
Krabat products are not toys! Improper use may cause damage to both user and/ or the product.
Warranty
Krabat provide a guarantee of 2 years for all products. This guarantee is aimed at defects in
workmanship or materials. The guarantee may be reduced or waive if service or daily maintenance
are not observed. It is the customer’s responsibility to ensure that maintenance is carried out.
The warranty does not cover accidental damage, including damage caused by improper use or lack of
maintenance. The warranty does not cover normal wear or wear parts.
The warranty is void if non-original parts are used, or if the product is repaired or modified by
personnel not approved by Krabat.

3
Executed by:
Author:
A.L. Sørensen
Signature:
Date:
10.10.2016
Approved by:
CEO:
Fredrik Brodtkorb
Signature:
Date:
10.10.2016
Revision history:
Revision:
Date:
Author:
Notes:
1.0
10.10.2016
A.L. Sørensen
Etablished
2.0
29.04.2021
J.Sørensen
Major layout changed, warnings, technical data and revision
table added
2.1
22.06.2021
A. Simensen
05.0 –Info on cushions and cleaning instructions added

4
Jockey & Jockey Plus
01.0. General....................................................................................... s. 05
02.0. Main components.............................................................. s. 06
03.0. Use................................................................................................. s. 07
04.0. Optional equipment........................................................ s. 09
05.0. Maintenance......................................................................... s. 09
06.0. Individual adjustments….............................................. s. 09
07.0. Technical data………………………………………………..………………..s. 10
08.0. Warnings and definitions........................................... s. 11
09.0. Warranty.................................................................................. s. 13

5

6
01 - General
This user manual gives an overview of the
Krabat Jockey Lite with manual elevation
of the sitting unit. Krabat Jockey Lite
comes in three different sizes. Many
configurations are possible with different
accessories.
Krabat Jockey Lite is an active chair for children
between the age 2 –16 years of age (3 sizes).
The chair is height adjustable and can be
adjusted from floor level to the height of a
kitchen worktop. The sitting position can be
adapted to the individual child. Seat tilt and
backrest height positions can be set infinitely.
An occupational therapist or a physiotherapist
should determine the use of this chair.
The excellent sitting position provided by the
Krabat Jockey Lite is due to both the saddle
seat, which promotes a neutral position in the
pelvis and abduction in the hips. The footrests
supports the feet in an optimal position.
The chair promotes good stability in the lower
body and gives the spinal column natural
curves. This provides a good base for balance
and activity in the trunk and upper body. The
saddle seat enhances an active sitting position
rather than a slumped and passive position.
The upright and active position will also benefit
speech, swallowing and respiration.
To ensure an optimal sitting position it is
important to try out and adjust the chair before
use. Do not use the chair unless an individual
trial has been carried out. Furthermore, do not
let other children use the chair without an
individual trial.
As children grow they change their movement
and sitting pattern on a regular basis. It is likely
that the child will need another size of the
sitting unit or other adjustments. Contact your
local physiotherapist or occupational therapist
if the product is not optimal or if adjustments
are needed.

7
02 - Main components -Jockey Lite w/ manual elevation
Krabat Jockey Lite with manual elevation has the following main components:
01 Saddle seat with adjustable angle of the sitting unit
02 Adjustable backrest
03 Adjustable individual footrests or footrest-in-one
04 Undercarriage
05 Wheels with individual brakes
06 Central bail
01
03
02
04
05
06

8
03.0 - Use
To obtain the optimal sitting position the angles of the seat, backrest and
footrest need to be adjusted. This should be done by a therapist who has
received training from Krabat AS, or a representative for Krabat AS.
All angles can be adjusted infinitely. The individual footrests can be adjusted by loosening the 4 screws
shown in fig. 05. The footrest-in-one can be adjusted using two screws shown in fig. 06. The sitting unit
can be adjusted using the turnbuckle shown in fig. 07. The angleof the backrest can be fixed in different
positions using the locking lever shown in fig. 08.
The use of the chair should be discussed with your therapist or someone who knows the child well. It
is important to establish in which situations the child should use the chair, how long they should use
it and when to progress the time spell. This needs to be evaluated continuously as the child gets
familiar with the chair.

9
03.1 - Adjustments
Fold down back rest: Loosen handle (01), loosen the 2 grip knobs (02), fold down back rest
Back rest height adjustment: Loosen handle (01), adjust height, tighten handle (01)
Seat adjustment: Pull lever upwards (03), adjust height, release lever (03)
Seat tilt angle adjustment: Pull lever (04), adjust tilt angle, release handle (04)
Foot rest adjustment: Loosen grip knob (05), adjust foot rest, tighten grip knob (05)
Lock wheels: Push down lever (06)
Max user weight:
Size 1 and Size 2: 80 kg / Size 3: 100 kg
02
03
01
05
06
04

10
04 –Accessories
There are a variety of different harnesses available. See www.krabat.com for an updated list of
accessories.
All accessories come with their own user manual.
If you need accessories or other equipment for your Krabat Jockey chair, please contact a Krabat
representative, or a Krabat-approved therapist for installation and adjustment.
05 - Maintenance
All metal and plastic parts can be cleaned using mild soapy water. The seat and backrest is covered
with different types of upholstery, either an “all-in-one” cushion or a cushion with separate seat cover.
The “all-in-one” cushion may be cleaned using a cloth and soapy water or machine washed at 40
degrees Celsius. The separate seat cover may be machine washed at 40 degrees Celsius. None of the
cushions or seat covers can be tumble dried.
This is a personal product, individually customized according to medical requirements and demands
from each user. No regular maintenance is required.
Wash the chair’s components when needed. Follow normal hygiene advice and keep the chair clean
and tidy at all times.
The textile is fastened to the chair with Velcro. Advice about spot removal is given at www.krabat.com.
Bearings and other movable parts are maintenance free and should not be lubricated.
To prevent injury, no part of the product shall be serviced or maintained while in use.
NOTE: If any part should break or is obviously damaged, please stop using the chair and contact
authorized personnel for service or appropriate corrective measures.
06 - Individual adjustments and adaptations
If the sitting unit for some reason needs adjustment please contact a physiotherapist or an
occupational therapist. Adaptations of the sitting unit must be made by qualified personnel or Krabat
AS.
Do not under any circumstances make any modifications by yourself.

11
07 - Technical data
Size 1
Size 2
Size 3
Depth of seat
28 cm
34 cm
42 cm
Angle of backrest
Fixed 90°
Fixed 90°
Fixed 90°
Angle of seat
-15° forward / 0°
backwards
15° forward / 0°
backwards
-15° forward / 0°
backwards
Seat height above floor
45 - 57 cm
45 - 57 cm
57 - 75 cm
Footrest height
14 - 23 cm
14 - 23 cm
14 - 30 cm
Total height (in use)
87 cm
96 cm
120 cm
Total width
68 cm
68 cm
68 cm
Width of backrest
25 cm
32 cm
32 cm
Height of backrest
33 or 38 cm
38 or 43 cm
41 - 46 cm
Gross weight
10 kg
10 kg
11,3 kg
Age of user
Ca. 2-7 yrs
Ca. 7-14 yrs
Ca. 14 yrs and older
Max. user weight
80 kg
80 kg
110 kg

12
08.0 –Warnings and definitions
General warnings:
Suffocation/ strangulation:
In normal use, when Intended user is seated and secured, there are no strangulation- or entrapment
hazards. If the Intended user is not seated and is located near the hand control and its cable, there is
a possibility of suffocation. To avoid possible suffocation hazard, never leave a child unattended with
the Krabat Jockey.
Entrapment/ pinching:
If someone should be located close to the main column when in use, there is a possibility of
entrapment or pinching. To reduce the possibility of incidents regarding entrapment or pinching,
make sure no one is located close to the main column when in use. To further prevent the possibility
of incidents, never leave the chair unattended. To avoid possible entrapment hazard, the battery can
be removed as a second control measure.
Danger of tipping:
There is always a real danger that a product may tip, as long as you do not comply with
restrictions set by a therapist with training from Krabat, information that accompanied the
product or information available on Krabat.no. A general rule is that any movement outside
the "footprint" of the product towards the surface can pose a risk of tipping. The higher the
user, will also affect the possibility of tipping. The same applies to additional components
fitted, such as tables, communication tools and sacks / bags. To prevent the possibility of
such incidents, one must avoid this, and never leave the child in the chair without
supervision.
Applied parts definition:
Applied parts are defined as parts of the product that come in contact with the USER during normal
use / to perform its function.
Applied parts are defined as: Seat and backrest including cushions, foot support(s) including hip belt
if applied: foot straps and head rest.

13
Transport and storage
During transport and / or storage, Krabat Jockey Lite should remain operational in normal use
within its specifications after transport or storage in the following temperature ranges:
•-25 ° C to +5 ° C, and
•+ 5 ° C to +35 ° C at relative humidity up to 90%, non-condensing;
•35 ° C to 70 ° C at water vapor pressures up to 5o hPa
after the product has been removed from packaging and then between uses.
Note: Krabat Jockey Lite should be kept indoors.
Environmental impacts during use
When the Krabat Jockey Lite is to be used, it must be used under the following environmental
conditions:
•In temperatures between + 5 ° C to + 40 ° C;
•At relative humidity of 15% to 93%, non-condensing
•At an atmospheric pressure between 700 hPa to 1,060 hPa
This product is classified for non-continuous operation.
Normal operating cycle for use - 10% or 2 minutes of operation followed by 18 minutes of
standstill.
Use after storage:
If Krabat Jockey Lite is stored cold (below 0 degrees Celsius), wait 20 minutes before using the
chair.
If the Krabat Jockey Lite is stored in a warm place (above 50 degrees Celsius), all surfaces must
be allowed to cool to ambient temperature before placing the child in the chair. Wait 20
minutes before using the chair.
Tip: To avoid that the surfaces become too hot, the Krabat Jockey can be covered with a blanket to
shield surfaces of the chair from direct sunlight.

14
Explanations of symbols
Explanation of the various symbols used on the product and in this manual:
Symbol
Importance
Importance
Expanations
Symbol for use worth marking medical
equipment.
Producer
Indicates the manufacturer of medical devices
Medical electrical equipment - Part 1: General
requirements for basic safety and essential
performance
See instructions
for use
Indicates the need for the user to see the
user manual
Medical electrical equipment - Part 1: General
requirements for basic safety and essential
performance
See instructions
for use
See instructions for use
General warning sign
Warning: read all
warnings and
safety rules in the
operating
instructions
When a user is sitting in the chair and the
chair is to be moved, e.g. from room to room,
it is NOT recommended to do this with the
seating unit in the highest position.
To prevent accidental tipping, never move the
chair when the seat is in the highest position.
Medical electrical equipment
Type BF applied
part
Identification of type BF applied part
according to IEC 60601-1.
Medical electrical equipment - Part 1: General
requirements for basic safety and essential
performance
Degree of water
and dust
penetration
Manufacturer-determined degree of particle
and water ingress protection.
Symbol for use In marking electrical appliances
Kun til innendørs
bruk
To identify electrical equipment designed
primarily for indoor use.
Symbols for use in the labelling of electrical
devices.
Risk class 2
To identify electrical equipment designed
primarily for indoor use
The requirements for accreditation and market
surveillance relating to the marketing of products;
Medical Device Directive
CE marking
Signifies European technical conformity.
Symbol for use in the labelling of electrical
devices.
Do not throw in
general waste
Highlights that you should not place the
electrical item in the general waste (it should
be taken to a local recycling centre)
Symbol from the certified body that performed
tests
Certification mark
Certification mark that signifies that this
product is certified to meet requirements of
US and Canadian electrical safety standards.
Safety sign to prohibit sitting on a surface.
No sitting on
surface
To identify surfaces/ parts that are unsuitable
to sit on.
Safety sign to prohibit stepping onto a surface.
No stepping on
surface
To identify surfaces/ parts that are unsuitable
to step on.

15
9 - Warranty
Manufacturer of the Krabat products, Krabat AS –hereinafter referred to as KRABAT - having its
place of business at Ravnsborgveien 56, 1395 Hvalstad, Asker, Norway –gives the purchaser of a
KRABAT product the following product warranty, hereinafter referred to as the “WARRANTY”:
1. This WARRANTY is given upon the strict condition that the purchaser and any person that the
purchaser gives access to the KRABAT product observe and adhere to the following SAFETY
PRECAUTIONS:
I. Always make sure to have read and understood the relevant user manual for the actual
KRABAT product before taking into it use.
II. The KRABAT product is only meant to be used for its intended purpose in accordance
with the KRABAT user manual for the relevant KRABAT product.
III. Never leave a child, or any other user, using the KRABAT product without proper adult
supervision.
IV. Always make sure that safety belts are properly fit and fastened and do not
malfunction, as well as recheck the foresaid at regular intervals when the KRABAT
product is in use.
V. Always use the KRABAT product with due regard to the advice of your physiotherapist
or occupational therapist.
VI. Always remember that the KRABAT product is NOT a toy, and hence, never let a child,
or any one else, play with the KRABAT product, as it can harm both persons and the
product as well as causing damage.
VII. Always –when not in use - store the KRABAT product in a safe manner in order for it
not to be misused by anyone, and furthermore for the purpose of not exposing the
KRABAT product to conditions that may harm it and/or its functions.
2. Subject to the terms and conditions of the WARRANTY, KRABAT warrants that the KRABAT
product for a period of one (1) year (“the Warranty Period”) from the purchase of the KRABAT
product, shall function in accordance with its intended purpose as set out in the KRABAT user
manual following the actual KRABAT product purchased.
3. KRABAT will at its own cost either itself, or by assistance of a third party, within reasonable
time offer assistance in order to remedy any defect of substance to the KRABAT product which
occurs within the said Warranty Period, either by taking the unit in question for repair or by
forwarding spares for replacement, provided, however, the purchaser of the KRABAT product
without undue delay after having become aware of the defect(s), in writing has notified
KRABAT or a representative authorized by KRABAT of the discovered defect(s). However,
KRABAT retains the right at its sole discretion in lieu of performing remedial work to forward
a new unit in lieu of the unit having defects or being defective. In respect of forwarding spare
or replacement parts, or a new unit, KRABAT or its authorized representative, shall be deemed
to have fulfilled its obligation in so far the part(s) or unit(s) in question are made available for
collection at the offices from where the initial KRABAT product was sold.
4. In the event where a defect has not been successfully remedied,
I. I The purchaser shall be entitled to a reduction of the purchase price in proportion to
the reduced value of the KRABAT product, provided that under no circumstances shall
such reduction exceed fifteen per cent (15 %) of the purchase price for the said
KRABAT product, or

16
II. II Where the defect is so material as to significantly deprive the purchaser of the
benefit of the purpose of the purchase, the purchaser may terminate the purchase in
respect of the defective KRABAT product. The purchaser shall then be entitled to
actual loss suffered, if any, however, limited to a maximum of fifteen per cent (15 %)
of the purchase price for the said KRABAT product.
5. This WARRANTY does not give any guarantees apart from those expressly given under this
WARRANTY.
6. For avoidance of doubt This WARRANTY does not extend to any liability of KRABAT or its
authorized representatives in respect of any indirect or consequential loss or damage suffered
by the purchaser or any person the purchaser, either deliberately or undeliberately, gives
access to the KRABAT product.
7. This WARRANTY does not apply in so far that the KRABAT product is supplemented with or
there are changed parts of the KRABAT product with parts not manufactured by KRABAT or
with parts manufactured or provided by others and the use thereof is of not authorized in
writing by KRABAT.
8. KRABAT shall only be liable for defects which appear under conditions of operation or use
provided for in the relevant user manual following the KRABAT product.
9. KRABAT shall not be liable for defects which are caused by faulty maintenance, incorrect
adjustments or faulty repair by any other person than KRABAT or representative authorized
by KRABAT, or any alterations to the KRABAT product carried out without the prior written
consent from KRABAT.
10. This WARRANTY does not cover normal wear and tear.
11. KRABAT shall not under any circumstances be liable fordefects in any part of a KRABAT product
for more than two (2) years from delivery.
12. Save as set out above under this WARRANTY, KRABAT, as well as its authorized
representatives, shall not be liable for any defects of the KRABAT product. This applies to any
loss the defect may cause including loss of production, loss of profit and other indirect loss.
Hepro AS, avd. Krabat
Ravnsborgveien 56
1395 Hvalstad
Norway
www.krabat.no
