KRAL W Series User manual

www.kral.at
Operating Instructions
KRAL Screw Pumps.
W Series
OIW 01en
Edition 2019-11
Original instructions
www.northridgepumps.com

2 OIW 01en Edition 2019-11 Operating Instructions
Table of contents
KRAL Screw Pumps – W Series
About this document
□General information 3
□Target groups 3
□Symbols 3
□Danger levels 4
□Associated documents 4
□General safety instructions 4
Labeling
□Type code 5
□Rating plate 5
Technical data
□Proper use 6
□Improper use 6
□Operational limits 6
□Required NPSH values 7
□Noise levels 8
□Weights 8
▪Weight of pump with free shaft end 8
▪Weight of the completion 8
Function description
□General drawing of a screw pump 10
□General drawing of screw pump with
coupling and motor 10
□Function description 11
□Shaft seal 11
▪Mechanical seal 11
▪Seal variants 11
□Back pressure valve 12
Transportation, storage and disposal
□Unpacking and checking the state of
delivery 13
□Raising the pump/motor-driven pump 13
□Storage 13
□Preservation 14
▪Preserving the internal surfaces of the
pump 14
▪Preserving the external surfaces of the
pump 14
▪Removing the preservative 14
□Safety instruction for disposal 14
□Disposing of the pump 14
Installation, removal and connection
□Installation 15
▪Installing the pump 15
▪Protect the pump against soiling 16
▪Connecting the pump to the piping
system 16
▪Aligning and checking the shaft coupling 17
□Electrical connection 18
▪Connecting the pump 18
□Removing the pump 18
▪Removing the pump 18
Operation
□Commissioning 20
▪Safety instructions for commissioning 20
▪Protect the pump against soiling 20
▪Cleaning the piping system 20
▪Filling and venting the pump 20
▪Checking the direction of rotation 21
▪Initial commissioning the pump 22
□During operation 23
▪Checking the operating pressure 23
□Switching off the pump 23
□Resuming pump operation 23
Repairs
□Maintenance 24
▪Required maintenance 24
▪Maintaining the ball bearing 24
□Replacing the coupling 24
▪General drawing 24
▪Removing the torsionally elastic
coupling 25
▪Installing the torsionally elastic coupling 26
□Replacing the mechanical seal and
ball bearing 27
▪Removal of mechanical seal and
ball bearing 28
▪Installation of mechanical seal and
ball bearing 28
□Replacing the screw set 29
▪Removing the screw set 29
▪Installing the screw set 30
□Replacing the Domsel type radial shaft
seal 31
▪Removing the radial shaft seal 32
▪Installing the radial shaft seal 32
Troubleshooting
□Information about faults 33
▪Possible faults 33
▪Troubleshooting 33
Spare parts
□Maintenance kits 36
▪W 15 – 118 36
□Accessories 37
▪Tool kits for LFI/LVI/LFT/LVT/LFM/WS 37
□Completions 37
Appendix
□Tightening torques 38
□Contents of the EC Declaration of
Conformity 38
□Notes 39
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 3
General information
About this document
About this doc ument General information
The operating instructions form part of the pump or motor-driven pump. The operating instructions must
be kept for future reference. Furthermore please observe the operating instructions for the drive motor.
Target groups
Symbols
Target group Tasks
Operator-owner □Keep these instructions available at the installation site for future
reference.
□Ensure that employees read and observe these instructions and
the associated documents, in particular the safety instructions
and warnings.
□Observe additional plant-specific directives and regulations.
Specialist personnel, fitters □Read, observe and follow these instructions and the associated
documents, in particular the safety instructions and warnings.
Symbol Meaning
Warning personal injury
Notice
Procedures mechanical installation
Procedures electrical installation
Check or fault table
Request for action
www.northridgepumps.com

4 OIW 01en Edition 2019-11 Operating Instructions
Danger levels
About this document
Danger levels
Associated documents
General safety instructions
Warning Danger level Consequences of non-observances
DANGER Immediate threat of danger Serious personal injury, death
WARNING Possible threat of danger Serious personal injury, invalidity
CAUTION Potentially dangerous situation Slight personal injury
CAUTION Potentially dangerous situation Material damage
ATEX supplementary instructions for operation in potentially explosive areas
Declaration of conformity according to EU Directive 2006/42/EC
Declaration of conformity according to EU Directive 2014/34/EU
Manufacturer's declaration according to EU Directive 2014/68/EU
Technical documentation for supplied components
The following general safety instructions must be observed:
□No liability is accepted for damage arising through non-observance of the operating
instructions.
▪Read the operating instructions carefully and observe them.
▪The operator-owner is responsible for the observance of the operating instructions.
▪Installation, removal and installation work may only be carried out by specialist personnel.
□Do not use KRAL pumps outside the performance limitations specified on the rating plate and
in the "Technical data" section. In the case of operating data that does not agree with the
specifications on the rating plate, please contact the manufacturer.
□In order for the warranty to remain valid, corrective maintenance carried out during the warranty
period requires the express permission of the manufacturer.
□Observe the general regulations for the prevention of accidents as well as the local safety and
operating instructions.
□Observe the valid national and international standards and specifications of the installation
location.
□In case of systems with an increased potential of danger to humans and/or machines the failure
of a pump may not lead to injuries or damage to property.
▪Always equip systems with an increased potential of danger with alarm equipment.
▪Maintain and check the protective/alarm equipment regularly.
□The pumped liquids can be dangerous (for example hot, dangerous to health, poisonous,
combustible). Observe the safety regulations for handling dangerous materials.
□Pumped liquids can be subject to high pressure and can cause damage and/or personal injury
should leaks occur.
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 5
Type code
Labeling
Labeling Type code
Rating plate
1Model
2Size
3Seal type
4Material
5Connecting part
6Completion
7Version index
Fig. 1 Type code
Item Designation Type
1Model WS: Pump with free shaft end /
motor-driven pump with pressure-side SAE flange
2Size Corresponds to flow rate in [l/min] at 1450 min-1
3Seal type A: Standard mechanical seal
B: Mechanical seal of hard material
C: Standard radial shaft seal
D: Magnetic coupling
F: Radial shaft seal, high-temperature model
X: Special heating system
4Material A: GJS Tenifer screw casing, standard screws
B: Plastic-coated screw casing, standard screws
5Connecting part
suction side
A: Pipe thread connection axial
X: Special Design
6Completion P: Pump with free shaft end
F: Motor-driven pump with pump bracket pedestal
V: Motor-driven pump without pump bracket pedestal
M: Motor-driven pump on motor base
7Version index For internal administration
1Construction year
2Max. operating overpressure suction-side /
Max. operating overpressure pressure-side
3Temperature range
4Serial number
5Type
6Article number
7Differential pressure
8Nominal delivery rate
9Rated speed
10 Nominal viscosity
11 Weight
Fig. 2 Rating plate
WS - 20.AAAP.00001
1
2
3
4
5
6
7
KRAL GmbH, 6890 Lustenau, Austria www.kral.at
pS max. / pDmax.
Ty p |Type
SN | Serial no.
Tmin. / Tmax. ºC
l/min
mm²/s
kg
min-¹
bar
bar
Δp
Jahr | Year Gewicht | Weight
n
Q
Art.-Nr. | Item no.
1
2
3
4
5
6
7
8
9
10
11
www.northridgepumps.com

6 OIW 01en Edition 2019-11 Operating Instructions
Proper use
Technical data
Technic al data Proper use
KRAL screw pumps of the W series are used to deliver lubricating liquids or cutting emulsions and
cutting oils. Both the concentration and the size of solid particles carried in the emulsion affect the
service life of the pump. The maximum size of the particles should not exceed 70 µm. It is always to your
advantage to use filters with a higher separation factor. The W pumps are not suitable for delivering
emulsions containing hard particles, e.g. hardened steel, corundum, hard metal or silicon carbide. The
pumps may only be used within the operational limits described within this chapter.
Improper use
The pump is not suitable for delivering gases or media with a high concentration of solids. Operating
data that deviates from the values on the rating plate and the operational limits can cause damage to the
pump. If there is any doubt whether deviating operating data can cause damage, inform the
manufacturer.
Operational limits
Tab. 1 Operational limits
Sizes
W 15 –
W 20
W 32 –
W 42
W 55 –
W 85
W 105 –
W 118
W 160 –
W 210
W 235 –
W 275
Operating pressure max. [bar] 120
Temperature max. [°C]
GJS screw casing
□Standard mechanical seal 150
□Mechanical seal of hard material 180
□Standard radial shaft seal 80
□Radial shaft seal
high-temperature model
150
□Magnetic coupling 250
Temperature max. [°C]
Plastic-coated screw casing
60
Temperature min. [°C]
for pump materials
-10
Viscosity [mm2/s]
min.–max.
1
10000
Rotating speed max. [1/min]
– at 50 Hz 2900
– at 60 Hz 3600
Inlet pressure max. [bar]
□Mechanical seal 6
□Radial shaft seal 2
□Magnetic coupling 6
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 7
Required NPSH values
Technical data
Required NPSH values
The following table shows the required NPSH values to ensure that the various pump sizes can be
operated without cavitation. These values are derived from the pump kinematics during operation with a
low-volatility pumped liquid such as lubricating oil or hydraulic liquid.
The following examples indicate that when pumped liquids have a readily volatile component content
the required NPSH values notably increase:
□Fuel oil requires an NPSH value of at least 6 mWC.
□When the pumped liquid contains water (e.g. heavy fuel oil), the values in the table have to be
increased by the vapor pressure of the water at the specified operating temperature.
The required NPSH values also needs to be increased if there are gas contents, regardless of whether it
is dissolved or not. In case of any doubt, contact the manufacturer.
Tab. 2 Required NPSH values
Size Viscosity Rotating speed [1/min] Size Viscosity Rotating speed [1/min]
[mm2/s] 1450 1750 2900 3500 [mm2/s] 1450 1750 2900 3500
NPSH value [mWC] NPSH value [mWC]
W 15 6 2 W 105 6 2 2.7 3.2
37 237 22.2 33.6
152 22.2 152 2.4 2.6 3.6 4.4
380 22.7 3380 2.8 3.1 4.4 5.4
W 20 6 2 W 118 6 2 3.1 3.9
37 237 2.2 3.5 4.4
152 22.4 2.7 152 2.5 2.8 4.3 5.4
380 2.2 2.4 3.2 3.8 380 33.3 5.3 6.8
W 32 6 2 W 160 6 2 2.9 3.6
37 237 23.3 4
152 22.3 2.6 152 2.5 2.7 3.9 5
380 2.2 2.4 3.1 3.7 380 2.9 3.2 4.9 6.2
W 42 6 2 2.3 W 210 62.1 45.2
37 22.1 2.6 37 2.4 2.7 4.5 6
152 22.8 3.5 152 2.8 3.2 5.5 —
380 2.5 2.7 44.8 380 3.5 46.9 —
W 55 6 2 W 235 6 2 3.5 4.5
37 22.7 37 2.3 2.5 45.1
152 2.1 2.8 3.3 152 2.7 34.9 —
380 2.5 2.7 3.5 4.0 380 3.2 3.6 —
W 74 6 2 2.6 3.0 W 275 62.3 4.5 6.1
37 22.9 3.4 37 2.5 2.9 5.1 7
152 2.3 2.5 3.3 4.1 152 33.5 6.3 —
380 2.7 3.0 4.4 5.0 380 3.6 4.2 —
W85 6 2 2.8 3.4
37 23.1 3.8
152 2.4 2.6 3.8 4.6
380 2.8 3.1 4.6 5.8
www.northridgepumps.com

8 OIW 01en Edition 2019-11 Operating Instructions
Noise levels
Technical data
Noise levels
Tab. 3 Noise levels
Weights
Weight of pump with free shaft end
Tab. 4 Weight table of W-pump with free shaft end
Weight of the completion
Tab. 5 Weight table of completion without pedestal
Max. noise level ± 3 dB(A) [dB(A)]
W 15-20 W 32-42 W 55-85 W 105-118 W 160-210 W 235-275
Pump
(at 2900 r.p.m.)
56 59 63 65 69 71
Motor max.
– at 40 bar 62 68 74 74 72 78
– at 80 bar 68 74 72 72 73 74
Pump + motor
– at 40 bar 63 69 75 75 74 79
– at 80 bar 63 68 73 73 75 75
Size
W
15
W
20
W
32
W
42
W
55
W
74
W
85
W
105
W
118
W
160
W
210
W
235
W
275
Weight [kg] 13 13 19 19 36 36 36 44 44
Motor size Motor weight [kg]
Size
W
15
W
20
W
32
W
42
W
55
W
74
W
85
W
105
W
118
W
160
W
210
W
235
W
275
Weight of pump bracket with coupling and screws [kg]
80 10 3.5 —
90S 12 3.5 —
90L 14 3.5 —
100L 21 4.5 3
112M 28 3
132S 39 4
132M 45 4
160M 110 —5.5 3
160L 120 —5.5 3
180M 165 — 8
180L 170 — 8
200L 230 —10
225M 280 —13
250M 365 —22
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 9
Weights
Technical data
Tab. 6 Weight table of completion with pedestal
Motor size Motor weight [kg]
Pump size
W
15
W
20
W
32
W
42
W
55
W
74
W
85
W
105
W
118
W
160
W
210
W
235
W
275
Weight of pump bracket with pedestal, coupling and screws [kg]
80 10 4 —
90S 12 4 —
90L 14 4 —
100L 21 5 4
112M 28 4
132S 39 5
132M 45 5
160M 110 —7.5 10
160L 120 —7.5 10
180M 165 —12
180L 170 —12
200L 230 —16
225M 280 —14
250M 365 —50
www.northridgepumps.com

10 OIW 01en Edition 2019-11 Operating Instructions
General drawing of a screw pump
Function description
Function descript ion General drawing of a screw pump
General drawing of screw pump with coupling and motor
Fig. 1 Structure of a screw pump
1Suction cover
2Back pressure valve
3Pressure casing
4Leakage connection
5Ball bearing
6Main screw
7Mechanical seal
8Balancing cylinder
9Pump casing
10 Idle screw
Fig. 2 Design of screw pump with coupling and motor
K1 Pump
K2 Pump-end coupling half
K3 Coupling intermediate ring
K2 Motor-end coupling half
K5 Motor
1
234
5
6
7
8
9
10
K1
K2 K3 K4 K5
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 11
Function description
Function description
Function description
Screw pumps belong to the rotating displacement group of pumps. In these pumps a special form allows
an almost tight engagement of three intermeshing screws 6,10 to be achieved. Together with the pump
casing 9 that encompasses the screw package, closed volumes are achieved by this means.
The standard direction of rotation of the pump is clockwise as seen from the drive (indicated by an arrow
on the pressure casing 3). When the main screw 6 is driven by a motor, the idle screws 10 follow the
main screw due to the meshing. The displacement effect of the pump results from the rotation of the
screws that leads to a continuous filling, axial displacement and discharge of the volumes described
above.
Shaft seal
The pump is sealed at the main screw outlet by a shaft seal. Depending on the pump type, the following
types of seal are used:
□Mechanical seal
□Radial shaft seal
□Magnetic coupling
Mechanical seal
Mechanical seals require constant lubrication. The inevitable minimal leakage caused by the lubrication
of the mechanical seal only amounts to a few cubic centimeters per hour and is imperative for proper
functioning of the seal. Generally this leakage will evaporate and not even be noticeable. However, with
low-volatility liquids such as heavy oil, the leakage will be visible. The leakage vent hole in the pressure
casing allows draining of this regular leakage 4. At use of a mechanical seal the permeability of the
leakage vent holes has to be ensured. Dry running must be avoided at all costs, as the seal will overheat
and be destroyed in a matter of minutes.
Seal variants
Tab. 1 Seal variants
Figure Legend Description
Mechanical seal
1Mechanical seal
2Ball bearing
3Main screw
Mechanical seals are used as durable shaft
seals in the standard design for liquids up
to 150 °C. In the version made of
mechanically resistant material, high-
quality elastomers allow sealing for
temperatures of up to 180 °C as well as
slightly abrasive liquids. Higher inlet
pressures of 6 bars are permissible.
Radial shaft seal
1Radial shaft seal
2Ball bearing
3Main screw
Radial shaft seals can be used for
temperatures up to 90 °C or 150 °C,
depending on the material. Each seal rings
used has a lip for sealing against the loss of
liquid and the entry of air.
1
2
3
1
2
3
www.northridgepumps.com

12 OIW 01en Edition 2019-11 Operating Instructions
Back pressure valve
Function description
Back pressure valve
To ensure the proper functioning of mechanical seals, they must be constantly lubricated by the pumped
liquid. This also requires greater pressure on the liquid-filled inside of the seal than in the atmosphere.
To ensure this even when the pump is installed above the liquid level, a spring-loaded back pressure
valve is mounted in the relief line of the seal chamber.
Fig. 3 Back pressure valve installation position
1Adapter sleeve
2Spring
3Ball
4Leakage
1234
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 13
Unpacking and checking the state of delivery
Transportation, storage and disposal
Transportation, storage and disposal Unpacking and checking the state of delivery
1. On delivery unpack the pump/motor-driven pump and check for damage during transportation.
2. Report damage during transportation immediately to the manufacturer.
3. Dispose of packing material in accordance with the locally applicable regulations.
Raising the pump/motor-driven pump
Prerequisites:
□Sufficiently dimensioned hoisting equipment
□The used hoisting equipment conforms to the local regulations and regulations for the prevention of
accidents
1. Pump: Screw eye bolts into two opposing holes at the flange cover.
Motor-driven pump: Fasten the slinging devices at the motor-driven pump at an angle between 60°
and 90°. Ensure that the center of gravity of the motor-driven pump lies between and below the
attachment points. If this is not possible, take other suitable measures to prevent the motor-driven
pump from tilting.
2. Pump: Hang the slinging devices into the eyebolts.
Motor-driven pump: Secure the slinging devices against slipping, for example through screwed-in
eye bolts.
3. Hang the crane hook into the slinging device.
4. Raise the pump/motor-driven pump.
Storage
During the test run, the internal components of the pump are wetted with test oil, which has a
preservative effect. The pipe connections are fitted with protective caps. Unless otherwise specified, the
external components of the pump are preserved with a single-coat PU-based two-component paint. The
preservative applied at the factory will protect the pump for about six weeks, if it is stored in a dry and
clean location. Adverse ambient conditions, such as high humidity, salty air, etc., will noticeably reduce
the possible storage time. If storage over longer periods and in adverse storage conditions is necessary,
the pump will have to be preserved.
Fig. 1 Raising the pump/motor-driven pump
DANGER
Risk of injury and/or damage to equipment should the pump/motor-driven pump fall.
► Use intact and correctly dimensioned hoisting equipment.
► Attach the hoisting equipment in accordance with Figure 1.
► Do not stand under raised loads.
www.northridgepumps.com

14 OIW 01en Edition 2019-11 Operating Instructions
Preservation
Transportation, storage and disposal
Preservation
Preserving the internal surfaces of the pump
1. Set up the pump so that the pressure-side connection is pointing upward.
2. Close the suction-side connection of the pump with a cover plate.
3. Pour non-corrosive, resin-free oil into the pressure flange until the oil reaches the pressure flange
and the air bubbles stop rising, while slowly turning the main screw against the direction of rotation.
4. Close the pressure-side connection of the pump with a cover plate.
After about 6 months storage check the oil level in the pump and if necessary top up oil.
Preserving the external surfaces of the pump
Aids:
□Castrol Rustilo DWX 33 or other preservative offering comparable protection
► Paint or spray the preservative onto all plain and unpainted parts.
At intervals of about six months, check the preservative effect and if necessary paint or spray the
plain und unpainted parts with the preservative again.
Removing the preservative
Aids:
□Solvents such as diesel fuel, alcohol, industrial cleaner or steam-jet cleaning device with wax-
dissolving additives
□Vessel to collect the preservative oil
1. Clean the outside of the pump with solvents, if necessary using a steam-jet cleaning device.
2. Remove the cover plate on the pressure side.
3. Drain the pump, collecting the preservative oil in a suitable vessel.
4. Remove the cover plate on the suction side.
5. To remove the residual oil, rinse the pump with the pumped liquid.
Safety instruction for disposal
► Observe the local regulations on disposal.
Disposing of the pump
Aids:
□Solvents or industrial cleaners suitable for the pumped liquid
1. Disassemble the pump.
2. Clean residues of the pumped liquid from the individual parts.
3. Separate sealing elements made of elastomers and ceramics (SiC) from the pump and dispose of
them in the residual waste.
4. Recycle iron parts.
WARNING
Danger of poisoning and damage to the environment through pumped liquid or oil!
► Wear protective clothing during all the work on the pump.
► Before disposing of the pump, collect the discharging pumped liquid and oil or grease and
dispose of it in accordance with the locally applicable regulations.
► Before disposing of the pump neutralize the residues of the pumped liquid in the pump.
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 15
Installation
Installation, removal and connection
Installati on, removal and c onnection Installation
Installing the pump
KRAL pumps of the W series can be used vertically in any position. Operation in the horizontal position
requires that the pressure connection of the pump is oriented upward, see Fig. 2, Page 15. W-pumps
can be supplied for dry or wet installation. A mounting flange has already been provided for vertical wet
installation.
We also recommend that the pump should not be mounted above the motor, since pumped liquid can
ingress the motor if a leak occurs.
Prerequisite:
□The pump connections are to be protected against soiling, for example by using the protective cover
mounted in the factory
1. Bring the pump into position.
2. Fasten the fastening elements on the underground.
Fig. 1 Vertical installation Fig. 2 Horizontal installation
WARNING
Leaking pumped liquid can damage the motor.
► Do not mount the pump above the motor.
WARNING
Damage to the pump and piping through insufficient fastening.
► Only fasten the pump on a stable bearing underground.
► Ensure that fastening elements are fastened sufficiently.
www.northridgepumps.com

16 OIW 01en Edition 2019-11 Operating Instructions
Installation
Installation, removal and connection
Protect the pump against soiling
► Carefully clean the piping system.
If the piping system is to be flushed out with the pump during commissioning, the pump must be
protected by a start-up filter to stop particles of dust getting inside see "Cleaning the piping system",
Page 20.
Mesh width of the commissioning filter:
□0.025 mm
Connecting the pump to the piping system
The pump connection to the piping system must be stress-free, as otherwise there is no guarantee that
the pump will operate safely.
1. Turn the pump shaft or the fan impeller of the motor. This tests that the pump runs smoothly.
If the pump cannot be turned by hand, remedy the fault before installing the pump, see
"Troubleshooting", Page 33.
2. If piping has to be adapted, attach cover plates in front of the connecting flanges when welding.
3. Place the piping in position.
4. Support the weight of the piping.
5. Check the clearance and the angular, vertical and linear offset, adjusting where necessary.
If the screws tighten easily, this is a sure sign that the installation is stress-free.
6. Tighten the connecting bolts in an alternating fashion using the correct tightening torque, see Tab. 1,
Page 38.
WARNING
Damage through impurities in the piping system.
► During welding work attach cover plates in front of the connecting flanges.
► Ensure when welding that welding beads and abrasive dust cannot get into the piping system and
the pump.
Fig. 3 Incorrect flange connections
Fig. 4 Correct flange connection
WARNING
Danger of damage to the device or impaired functionality through mechanical stresses.
► Ensure that the pump mounting on the piping system is free of mechanical stress.
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 17
Installation
Installation, removal and connection
Aligning and checking the shaft coupling
Prerequisites:
□Pump, shaft coupling and motor have been mounted by the customer
Tab. 1 Limits for aligning the shaft coupling
1. Check the linear offset c of the coupling using a slide gauge or feeler gauge.
If the limits of the above table are exceeded, loosen the fastening of the pump or motor and move
the device in order to adjust the linear offset c.
2. Check the lateral offset a of the coupling using a hairline gauge and feeler gauge. Check several
points along the periphery of the coupling.
If the limits of the above table are exceeded, loosen the fastening of the pump or motor and move
the device in order to reduce the lateral offset a.
3. Check the angular offset b of the coupling using a hairline gauge.
If the limits of the above table are exceeded, loosen the fastening of the pump or motor and move
the device in order to reduce the angular offset b.
aLateral offset
bAngular offset
cLinear offset
Fig. 5 Measuring points for tolerances of the coupling alignment
Coupling diameter Lateral offset a Angular offset bLinear offset c
[mm] max. [mm] max. [°] min. [mm] max. [mm]
40 0.2 0.9 2 3
55 0.2 0.9 23.5
65 0.25 0.9 2.5 4
80 0.3 1.0 34.5
95 0.3 1.0 3 5
120 0.4 1.1 4 6
135 0.4 1.2 4.5 7
160 0.5 1.2 5 8
CAUTION
Incorrect alignment of the shaft coupling causes noise, vibrations and damage to the bearing.
► Check the alignment of the coupling.
www.northridgepumps.com

18 OIW 01en Edition 2019-11 Operating Instructions
Electrical connection
Installation, removal and connection
Electrical connection
Connecting the pump
Prerequisite:
□Sufficiently dimensioned cables
1. Observe the operating instructions of the premounted motor.
2. If the motor is supplied separately from the pump, connect the motor in accordance with the
operating instructions of the motor.
3. Ensure that the operating data on the rating plate of the motor agree with the operating data of the
pump.
4. Ensure that the operating data on the rating plate of the motor agree with the local power supply.
5. Open the terminal box at the motor.
6. Ensure that the connecting cable is not live.
7. Connect the phase and PEN conductors in accordance with the diagram in the motor terminal box.
8. Close the terminal box of the motor.
Removing the pump
Removing the pump
Prerequisite:
□Pump is switched off
Aids:
□Vessels for leaking pumped liquid
DANGER
Risk of death resulting from electric shock.
► The pump may only be connected by an authorized electrician.
► Ensure that the power supply is de-energized.
► Ground the pump carefully.
DANGER
Risk of death resulting from electric shock.
► Ensure that the power supply is de-energized.
► The pump may only be separated from the power supply by an authorized electrician.
DANGER
Risk of injury through emitted hot, poisonous or corrosive pumped liquid when removing the pump.
► Observe the safety regulations for handling dangerous liquids.
www.northridgepumps.com

Operating Instructions OIW 01en Edition 2019-11 19
Removing the pump
Installation, removal and connection
1. In case of operation at higher temperatures wait until the motor-driven pump has cooled down to the
ambient temperature.
2. Disconnect the pump from the power supply.
3. Open the terminal box at the motor.
4. Disconnect the connecting cable.
5. Close the pressure-side and suction-side shut-off fittings.
6. Loosen the connecting screws of the pressure-side pipe connection. Collect the emitted liquid in a
suitable vessel.
7. After the liquid has been drained completely, dismantle the pressure-side flange.
8. Loosen the connecting screws of the suction-side pipe connection. Collect the emitted liquid in a
suitable vessel.
9. After the liquid has been drained completely, dismantle the suction-side flange.
10. Loosen the fastening of the motor-driven pump on the foundation.
11. Dismantle the motor and pump bracket.
www.northridgepumps.com

20 OIW 01en Edition 2019-11 Operating Instructions
Commissioning
Operation
Operation Commissioning
Safety instructions for commissioning
Protect the pump against soiling
The pump has to be protected against soiling during commissioning.
Possibilities:
□Clean dirt particles from the piping system before initial commissioning.
□Install additional commissioning filter.
Cleaning the piping system
The complete piping system has to be cleaned diligently before initial commissioning of the pump. If this
is to be realized by rinsing using the pump, an additional commissioning filter has to be installed before
the pump.
Mesh width of the commissioning filter:
□0,025 mm
► Recommended rinsing duration with commissioning filter: 50 – 100 hours
Filling and venting the pump
There are 2 possible ways to fill the pump:
□Pumped liquid already exists on the suction or pressure side:
Filling via suction or pressure connection
□There ist no pumped liquid at the suction or pressure side:
Filling via the bypass connection
The following instructions must always be observed.
► The pump may only be commissioned by authorized qualified personnel.
► Before commissioning, make sure that the pump is filled.
CAUTION
Damage to the pump through additional pressure loss in the commissioning filter.
► Calculate the flow resistance and determine the remaining pump intake.
► Monitor the suction-side pressure.
► Check and clean the commissioning filter regularly.
1Seal vent hole
2Bypass connection
Fig. 1 Vent holes
1
2
www.northridgepumps.com
