Kramer MODULAR TBUS-1Axl User manual

Installation Instructions
MODELS:
Power Socket Installation for Inner Frame
Power Cord Options for Modular TBUS
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
For the latest information on our products and a list of Kramer distributors, visit our Web site where
updates to these installation instructions may befound.
We welcome your questions, comments, andfeedback.
www.kramerAV.com
[e-mail]
P/N:
2900-300061
Rev:
6

Power Sockets for TBUS products
Congratulations on purchasing your Kramer Table Connection Bus (TBUS-1AXL, TBUS-3XL,
TBUS-4XL, TBUS-5XL, TBUS-6XL, TBUS-10XL, UTBUS-1XL and/or UTBUS-2XL).
Some inner frame modules require single or dual power sockets. A choice of one or more power
sockets per inner frame is available in several versions, including power sockets for the USA, the
UK, Germany (the Europlug), Belgium-France, Italy, Switzerland, South Africa, Israel, Brazil and
Australia. A “Universal” socket for general use is also available (see the compatibility restrictions in
the table below).
Note that Brazilian power sockets are supplied as dual power sockets in a single power socket
assembly (see the table below).
Single Power Socket Assemblies
Power Socket Type
Power Specs
Power Socket Type
Power Specs
Universal:
TS-1U (80-000899)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Fully compatible with power plugs in the UK, India,
Italy and Denmark, as well as with the 2-prong
Europlug.
Partially compatible (if the polarity is reversed) with
plugs in China, Switzerland, Israel and the USA. The
universal socket does not supply grounding to plugs
in Central Europe and France and so you should
order country specific sockets instead.
Not compatible with South African plugs.
Power Socket Type
Power Specs
Power Socket Type
Power Specs
USA:
TS-1US (80-000999)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
UK
TS-1UK (91-000022)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Belgium and France:
TS-1FR (80-001399)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Israel:
TS-1IL (80-001799)
220V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Germany and EU:
TS-1DE (80-001299)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
South Africa
TS-1ZA (80-001699)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Italy:
TS-1IT (80-001499)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Australia:
TS-1AU (80-001599)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Switzerland
TS-1CH (80-000027)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Brazil
TS-BR (80-000034)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power
outlet

Dual Power Socket Assemblies
Dual Power Socket Assemblies:
Power Specs
Universal:
TS-2U (80-001899)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
USA:
TS-2US (80-001999)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Belgium and France:
TS-2FR (80-002299)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Germany and EU:
TS-2DE (80-002199)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Italy
TS-2IT (80-002399)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Switzerland
TS-2CH (80-000026)
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
UK
TS-1UK (91-000023)
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Israel:
TS-2IL (80-002699)
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
South Africa:
TS-2ZA (80-002599)
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Australia:
TS-2AU (80-002499)
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet

Power Cord Options
You can order any of the following power cords to use with a modular TBUS:
Power Cord Type
Description
P/N
6ft/110V (North America)
C-AC/US (110V)
91-000099
6ft/125V (Japan)
C-AC/JP (125V)
91-000699
6ft/220V (Europe)
C-AC/EU (220V)
91-000199
6ft/220V (Israel)
C-AC/IL (220V)
91-000999
6ft/250V (UK)
C-AC/UK (250V)
91-000299
6ft/250V (India)
C-AC/IN (250V)
91-001099
6ft/250V/10A (China)
C-AC/CN (250V)
91-001199
6ft/250V/10A (South Africa)
C-AC/ZA (250V)
91-001299
To use one power cord for a 4-socket configuration, you can order any of the following
types of power cords separately:
Power Cord Type
Description
P/N
110V Y-version (6ft), North America
C-ACY/US
91-000399
220V Y-version (6ft), Europe
C-ACY/EU
91-000499
240V Y-version (6ft), UK
C-ACY/UK
91-000599
Installation Instructions
Before installing the inner frame, you need to install the power sockets. To do so:
1. Insert the power socket module into the power socket opening from beneath.
2. Use the two power socket screws to tighten the power socket in place.
The power socket is installed and ready to use.
Figure 1: Power Socket Installation
