Kramer TBUS-4 User manual

Kramer Electronics, Ltd.
USER MANUAL
Model:
TBUS-4
Table Connection Bus

Contents
i
Contents
1
Introduction 1
2
Getting Started 1
3
Overview 3
4
Your TBUS-4 4
5
Installing the TBUS-4 Table Connection Bus 6
5.1
Cutting an Opening in the Table 6
5.2
Adjusting the Height of the Connecting Surface 7
5.3
Installing the Optional Insert Kit 8
5.4
Installing TBUS-4 in the Cut-Out Opening 8
5.5
Connecting the Cables 9
6
Technical Specifications 10
Figures
Figure 1: TBUS-4 Table Connection Bus 3
Figure 2: TBUS-4 Table Connection Bus (Top View) 4
Figure 3: TBUS-4 Connecting Surface 5
Figure 4: Cutout Dimensions 7
Figure 5: Optional Insert Kit 8
Figure 6: Installing TBUS-4 9
Figure 7: Connecting the Cables 9
Tables
Table 1: TBUS-4 Table Connection Bus Features 5
Table 2: TBUS-4 Connecting Surface Features 6
Table 3: Technical Specifications of TBUS-4 10

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 500-plus different models now
appear in eight groups
1
that are clearly defined by function.
Thank you for purchasing the Kramer TBUS-4 table connection bus, which is
ideal for boardrooms, conference and training rooms!
The package includes the following items:
TBUS-4 Table Connection Bus
2 table clamps
Power cord
2
6 self-locking ties
Cut-out template
4 screws for holding template
Optional insert kit
This user manual
3
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high-performance, high-resolution cables
4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 We recommend that you use only the power cord supplied with this device
3 Download up-to-date Kramer user manuals from our Web site: http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
The following Quick Start Chart highlights the main steps for installing
TBUS-4:

Overview
3
3 Overview
The Kramer TBUS-4 is a high-quality, anodized aluminum, table-mounted
connection bus for boardrooms and conference rooms. Its attractive enclosure
is designed to provide maximum connectivity in the smallest possible
footprint. The unit is sturdy, cost-effective, and easy to install.
TBUS-4 includes:
Eight permanent components suitable for connecting two PCs:
two HD15F connectors, two Ethernet connectors, two stereo audio
3.5mm mini jacks, and two USB-A connectors
Two power sockets – available in 7 versions: USA, UK, Germany-EU,
Belgium-France, South Africa, Australia, and “Universal” (for use
anywhere)
One optional insert kit
1
to replace one power socket
TBUS-4 is height-adjustable and the
cover opens and closes manually,
keeping the cables and the connectors out of sight when not used.
To achieve the best performance:
Use only good quality connection cables
2
to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances that may
adversely influence signal quality
Position TBUS-4 away from moisture, excessive sunlight, and dust
Figure 1: TBUS-4 Table Connection Bus
1 The insert kit can include two wall plate module inserts, two cable pass-through connectors, or one of each
2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your TBUS-4
4
Beware of sharp edges on the inner and outer rim of the
mounting plate and on the lid of TBUS-4. They can cause
serious injury.
Do not place heavy objects on top of the TBUS-4
.
4 Your TBUS-4
Figure 2 and Table 1 define the unit.
Figure 2: TBUS-4 Table Connection Bus (Top View)

Your TBUS-4
5
Table 1: TBUS-4 Table Connection Bus Features
# Feature Function
1 Connecting Surface See Figure 3 and Table 2
2 Black Anodized Lid Covers the connecting surface, leaving the table surface neat and tidy
3 Mounting Plate Outer Rim Fits over the table surface
4 Enclosure Inserts into the table cutout
5 Height Adjustment Screws Ten screws for adjusting the height of the connecting surface, three on
the front and back, and two on each side
6 Rubber Protectors Protect the table surface when mounting the unit (one on each side)
7 Locking Butterfly Screws Tighten to lock the mounting butterfly screw (one on each side)
8 Mounting Brackets Fit in the bracket slits after inserting the enclosure into the table – to
secure the unit to the table surface (one on each side)
9 Mounting Butterfly Screws Tighten to secure the unit to the table surface (one on each side)
10 USB Sockets Receptacles for external USB cables
11 Tie Holes
1
Anchor the self-locking ties to secure the pass-through cables to the
inside walls of the unit (8 pairs of holes, 4 pairs on the front and 4 pairs on
the rear panel)
12 Protective Rubber Guard Protects the mounting plate outer rim during shipping. Remove before
installing TBUS-4
Figure 3 and Table 2 define the connecting surface:
Figure 3: TBUS-4 Connecting Surface
1 Some versions may not include tie holes

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Installing the TBUS-4 Table Connection Bus
6
Table 2: TBUS-4 Connecting Surface Features
# Feature Function
1 Power Socket 1 Power socket for PC1
2 Ethernet connector 1 RJ-45 (female / female)
3 USB connector 1 USB-A (female / female)
4 Audio connector 1 3.5 mm stereo audio (female / female)
5 PC connector 1 Computer graphics 15 pin HD (female / female)
6 Power Socket 2 Power socket for PC2
7 Ethernet connector 2 RJ-45 (female / female)
8 USB connector 2 USB-A (female / female)
9 Audio connector 2 3.5 mm stereo audio (female / female)
10 PC connector 2 Computer graphics 15 pin HD (female / female)
5 Installing the TBUS-4 Table Connection Bus
To install TBUS-4, perform the following steps:
1. Cut an opening in the table (see section 5.1).
2. Adjust the height of the connecting surface (see section 5.2).
3. Install optional insert (see section 5.3).
4. Install TBUS-4 in the cut-out opening (see section 5.4).
5. Connect the cables (see section 5.5).
5.1 Cutting an Opening in the Table
To cut an opening in the table:
1. Place the included cut-out template on the surface of the table where you want
to install TBUS-4.
2. Attach the template to the table with the included screws.
3. Following the inside edge of the template, cut a hole in the table surface with a
sabre or keyhole saw according to the dimensions shown in Figure 4 (not to
scale).
Note: The thickness of the table should be 3 inches or less.

Installing the TBUS-4 Table Connection Bus
7
Figure 4: Cutout Dimensions
4. Unscrew and remove the template from the surface of the table and clean the
table surface.
Take care not to damage the table.
If needed, you can download a full-scale template from our Web site
1
.
Kramer Electronics is not responsible for any damage caused to the table
5.2 Adjusting the Height of the Connecting Surface
If needed, you can adjust the connecting surface to one of four possible
heights to accommodate large or bulky cables. By default, the height is set to
the second level from the top. To adjust, perform the following:
1. Remove the ten height adjustment screws (three screws on the front and back,
two screws on each side, as shown in Figure 2), while supporting the surface
from underneath with your fingers.
2. Raise or lower the connecting surface to the required height, insert the
screws, and tighten them in place.
1 At http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Installing the TBUS-4 Table Connection Bus
8
5.3 Installing the Optional Insert Kit
An optional insert kit can be installed before or after installing the TBUS-4
unit. The insert replaces one power module (see Figure 3).
To mount the insert, perform the following steps:
1. Unscrew the two screws that fasten the power module to the connecting
surface, keep the screws, and remove the power module from below.
2. Place and align the insert under the opening, insert the two screws to fix the
insert in place, and tighten them.
Figure 5: Optional Insert Kit
5.4 Installing TBUS-4 in the Cut-Out Opening
To install TBUS-4 in the opening:
1. Remove the protective rubber guard from around the outer rim of the
mounting plate. Beware of the sharp edge!
2. Carefully insert the unit into the prepared opening (see Figure 6).
3. Take the support brackets under the table and place them into the support
bracket grooves on both sides of the unit (see Figure 2).
4. Verify proper alignment of the unit before tightening the mounting screws.
5. Screw both mounting butterfly screws upward until they reach the table
surface (from underneath). Tighten firmly (see Figure 6).
6. Screw the locking butterfly screws downward until tight against the mounting
bracket.

Installing the TBUS-4 Table Connection Bus
9
Figure 6: Installing TBUS-4
5.5 Connecting the Cables
To connect the cables:
1. Insert the cables into their appropriate connectors from underneath (see
Figure 7).
2. Secure the cables to the tie holes using the included self-locking ties.
Do not secure the cables too tightly or too loosely. Leave a small amount of
slack.
After the unit is connected to mains power and the proper cables, TBUS-4 is ready
for use.
Figure 7: Connecting the Cables

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
10
6 Technical Specifications
TBUS-4 technical specifications are shown in Table 3:
Table 3: Technical Specifications
1
of TBUS-4
Universal 100-240V AC, 50/60 Hz, 5A
USA 100-240V AC, 50/60 Hz, 5A
UK 100-240V AC, 50/60 Hz, 5A
Germany and EU 100-240V AC, 50/60 Hz, 5A
Belgium and France
100-240V AC, 50/60 Hz, 5A
South Africa 100-240V AC, 50/60 Hz, 5A
POWER SOURCE
(AC power limits):
Australia 100-240V AC, 50/60 Hz, 5A
FUSE RATING: T 6.3A 250V
OPERATING TEMPERATURE RANGE: +5 to +45 Deg. Centigrade
OPERATING HUMIDITY RANGE: 10 to 90% RHL, non-condensing
STORAGE TEMPERATURE RANGE: -20 to +70 Deg. Centigrade
STORAGE HUMIDITY RANGE: 5 to 95% RHL, non-condensing
DIMENSIONS: Top plate: 243mm x 140.4mm (9.6" x 5.5") W, D
Enclosure: 203mm x 102mm x 130mm (8.0" x 4.0" x 5.1") W, D, H
WEIGHT: TBUS-4: 1.35 kg. (2.8 lbs.) approx.
Table clamps: 0.25 kg (0.6 lbs)
ACCESSORIES: Power cord, table clamps, self locking ties, template,
template screws
OPTIONAL: Optional insert kit
1 Specifications are subject to change without notice

11
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items.We will not pay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
This equipment has been tested to determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.
Part 1: Residential, commercial and lightindustry environment".
CFR-47: FCC Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed.
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water,lightning or other acts of nature
ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presented to the carrier)
v) Removalor installation of the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
1. Removal or installations charges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects in this product, damages basedupon inconvenience, loss ofuse of the product, loss
of time, commercial loss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
NOTE:
Part 1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
P/N: 2900-000340 REV 2
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
Table of contents
Other Kramer Cables And Connectors manuals

Kramer
Kramer HDBT User manual

Kramer
Kramer CLS-AOCH/xl User manual

Kramer
Kramer WP-210E User manual

Kramer
Kramer WP-209 User manual

Kramer
Kramer C-FODM/FODM-33 User manual

Kramer
Kramer WP-211DS User manual

Kramer
Kramer WP-210 User manual

Kramer
Kramer WP-220 User manual

Kramer
Kramer WP-210A User manual

Kramer
Kramer WP-230 User manual

Kramer
Kramer CLS-AOCH/60 Series User manual

Kramer
Kramer TBUS-100XL User manual

Kramer
Kramer RTBUS-27xl User manual

Kramer
Kramer RTBUS-24 User manual

Kramer
Kramer 612T User manual

Kramer
Kramer RTBUS-28XL User manual

Kramer
Kramer SV-301 User manual

Kramer
Kramer RTBUS-21 User manual

Kramer
Kramer MODULAR TBUS-1Axl User manual

Kramer
Kramer UTBUS-1XL User manual
