RTBUS-28xl Quick Start
P/N:
2900- 301535QS
Rev:
2
Scan for full manual
RTBUS-28xl Quick Start Guide
This guide helps you install and use your RTBUS-28xl for the first time.
Go to www.kramerav.com/manual/RTBUS-28xl to download the latest user manual
Step 1: Check What’s in the Box
RTBUS-28xl Round Table Connection Bus
1 User manual
1 Quick start guide
Step 2: Get to know your RTBUS-28xl
#
Feature
Function
1
Pneumatic Mechanism
Enables automatic lifting and smooth
closing of the lid.
2
Outer Rim
Fits over the table surface.
3
Mounting Screws (x2)
For securing RTBUS-28xl to the table.
4
Locking Butterfly Nuts (x2)
Tighten to lock the mounting butterfly
screw.
5
Mounting Butterfly Nuts (x2)
Tighten to secure the unit to the table
surface.
6
Mounting Brackets (x2)
For securing the unit to the table surface.
7
Black Anodized or Brushed
Aluminum Semi-Automatic
Lid (with Opening for Cable
Pass-Through)
Covers the connecting surface, leaving
the table surface neat and tidy.
8
Lid Latch (x2)
For safely closing the lid.
9
Inner Pass-Through
Opening and Bushing (x1)
Insert a cable through the opening and the
bushing –for larger or multiple cables
(inner diameter approx. 12.5mm Ø).
10
Pass-Through Opening and
Bushing (x3)
Insert a cable through the opening and the
bushing (inner diameter approx. 10 mm
Ø).
11
5V-2.4A USB Charging Port
Use to charge a device.
12
5V-1A USB Charging Port
Use to charge a device.
13
5A MAX. Power Socket
Connect to a 90-240V AC power
consuming device.

Step 3: Install RTBUS-28xl
To mount the unit, follow these steps:
1. Cut a round hole in the table, in the desired location, with a diameter ranging from 140mm to 142mm (5.5” to 5.6”).
2. Insert the cables through the pass-through openings:
A
B
C
3. Mount RTBUS-28xl into the table.
4. Connect the cables:
Connect devices to the pass-through cables
and power socket.
Safety Instructions
Caution:
There are no operator serviceable parts
inside the unit.
Warning:
Do not open the unit. High voltages can
cause electrical shock! Servicing by
qualified personnel only.
Warning:
Disconnect the power and unplug the unit
from the wall before installing.
See www.KramerAV.com for updated safety information.
