Kramer RTBUS-25xl User manual

P/N: 2900-301160 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
RTBUS‑25xl
Round Table Connection Bus

Kramer Electronics Ltd.
RTBUS‑25xl –Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Defining the RTBUS‑25xl 3
Power Socket Options 4
The RTBUS‑25xl Connecting Surface 5
Installing the RTBUS‑25xl 6
Drilling a Hole in the Table 6
Installing the Power Socket 6
Mounting the RTBUS‑25xl in the Table 7
Connecting the Cables and Wires 8
Using the RTBUS‑25xl 9
Technical Specifications 10

Kramer Electronics Ltd.
RTBUS‑25xl –Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
•Review the contents of this user manual.
Go to www.kramerav.com/downloads/RTBUS‑25xl to check for up-to-date user manuals,
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
•Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
•Do not secure the cables in tight bundles or roll the slack into tight coils.
•Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
•Position your Kramer RTBUS‑25xl away from moisture, excessive sunlight and dust.
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
Safety Instructions
Caution: There are no operator serviceable parts inside the unit.
Warning: Do not open the unit. High voltages can cause electrical shock! Servicing by
qualified personnel only.
Warning: Disconnect the power and unplug the unit before installing.

Kramer Electronics Ltd.
RTBUS‑25xl –Introduction
2
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/support/recycling.
Overview
Congratulations on purchasing your Kramer RTBUS‑25xl Round Table Connection Bus.
The RTBUS‑25xl is an elegant furniture-mounted, round connection bus. The RTBUS‑25xl
features a pneumatic mechanism for pneumatic lifting and smooth closing of its lid. It is easily
installed into a table or podium top, and its interface enables you to connect any equipment
to systems installed in a room via the following pass-through connectors:
•1 PC on a 15-pin HD connector.
•1 USB connector.
•1 stereo audio on a 3.5mm connector.
•1 HDMI™connector.
•1Ethernet port on an RJ-45 connector.
The RTBUS‑25xl supports HDMI with Deep Color, x.v.Color™, Lip Sync, HDMI
Uncompressed Audio Channels, Dolby TrueHD, DTS-HD, and CEC.

Kramer Electronics Ltd.
RTBUS‑25xl –Defining the RTBUS‑25xl
3
Defining the RTBUS‑25xl
Figure 1: View
#
Feature
Function
Pneumatic Mechanism
Enables automatic lifting and smooth closing of the lid
Mounting Screws
For securing the RTBUS‑25xl to the table (2)
Locking Butterfly Nuts
Tighten to lock the mounting butterfly screw (2)
Mounting Butterfly Nuts
Tighten to secure the unit to the table surface (2)
Mounting Brackets (2 units)
Place in the bracket slits after inserting the enclosure into the table –
for securing the unit to the table surface
Black anodized or brushed
aluminum semi-automatic lid
Covers the connecting surface, leaving the table surface neat and
tidy
Outer Rim
Fits over the table surface
Connecting Surface
See Figure 2
Power Socket Opening
For installing a power socket (can be purchased separately).
IEC socket
Connect to an IEC power cord (can be purchased separately)
Mounting Bracket Slits (two
sets on each side)
Insert the mounting brackets to the slits when installing the
RTBUS‑25xl (see Mounting the RTBUS‑25xl in the
Table on page 7).

Kramer Electronics Ltd.
RTBUS‑25xl –Defining the RTBUS‑25xl
4
Power Socket Options
A choice of power sockets is available for purchase in several versions, including power sockets
for the USA, Brazil, Germany (the Europlug), UK, Switzerland, Belgium-France, Italy, South
Africa, Israel and Australia. A “Universal” socket for general use is also available (see the
compatibility restrictions in the table below). Note that the photos below are for illustration
purposes only.
Power Socket Type
Power Specs
Description
Universal:
TS-201U (80-000043)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Fully compatible with power plugs in the UK, India,
Italy and Denmark, as well as with the 2-prong
Europlug.
Partially compatible (if the polarity is reversed) with
plugs in China, Switzerland, Israel and the USA. The
universal socket does not supply grounding to plugs in
Central Europe and France and so you should order
country specific sockets instead.
Not compatible with South African plugs.
Power Socket Type
Power Specs
Power Socket Type
Power Specs
USA:
TS-201US (80-000046)
100-125V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Italy:
TS-201IT (80-000047)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Germany and EU:
TS-201DE (80-000044)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Australia:
TS-201AU (80-000050)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Belgium and France:
TS-201FR (80-000045)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Israel:
TS-201IL (80-000053)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
South Africa
TS-201ZA (80-000052)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Brazil
TS-201BR (80-000051)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
Switzerland
TS-201CH (80-000049)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet
England
TS-201GB (80-000048)
100-240V AC, 50/60Hz, 5A
Maximum 5A per power
outlet

Kramer Electronics Ltd.
RTBUS‑25xl –Defining the RTBUS‑25xl
5
The RTBUS‑25xl Connecting Surface
Figure 2 defines the connecting surface (note that although ‘RTBUS-21’ is printed on the
panel, the name of the modular product is RTBUS‑25xl).
Figure 2: RTBUS‑25xl Connecting Surface
#
Feature
Function
ETHERNET RJ-45 Connector
Connect to a network
PC 15-pin HD Connector
Connects to a VGA source
USB Connector
Connects to a USB source
AUDIO 3.5mm Mini Jack
Connects to an unbalanced stereo audio source
HDMI™Connector
Connect to HDMI source
5A MAX. Power Socket
Connects to 90-240V AC power consuming device
Lid Latch
For safely closing the lid

Kramer Electronics Ltd.
RTBUS‑25xl –Installing the RTBUS‑25xl
6
Installing the RTBUS‑25xl
To install the RTBUS‑25xl perform the following steps:
1. Drill a hole in the table (see Drilling a Hole in the Table on page 6).
2. Install the power socket (see Installing the Power Socket on page 6).
3. Secure the unit to the table (see Mounting the RTBUS‑25xl in the Table on page 7).
4. Connect the cables (see Connecting the Cables and Wires on page 8).
Drilling a Hole in the Table
To drill an opening in the table:
1. Using any standard cup bit drill with a diameter ranging from 111mm to 114mm (4.37in to
4.49in), drill a hole in the table in the desired location.
The thickness of the table should be 3in (76mm) or less.
2. Clean the table surface.
Take care not to damage the table. Kramer Electronics is not responsible for any damage
caused to the table.
Installing the Power Socket
Figure 3 shows an example of the Universal power socket housing which is one of the
optional power sockets for the RTBUS‑25xl, see Power Socket Options on page 4.
To install the power socket (purchased separately):
1. Close the RTBUS‑25xl lid.
2. Carefully insert the power socket housing so that
the power socket fits into the power socket
opening on the connecting surface and the four
standoffs fit the four screw holes on the
RTBUS‑25xl.
When positioned correctly, the IEC socket faces
downwards.
3. Screw the four screws included in the power
socket kit into the designated holes to fix the
power socket housing in place.
4. Unscrew the power connector lock.
5. Connect the IEC power cord to the IEC socket.
Figure 3: RTBUS‑25xl Universal Power
Socket Housing

Kramer Electronics Ltd.
RTBUS‑25xl –Installing the RTBUS‑25xl
7
Mounting the RTBUS‑25xl in the Table
To mount the unit, follow these steps:
Step 1: Insert the RTBUS‑25xl into the
hole cut into the table making sure the
outer rim is firm against the surface of the
table.
Step 2: From underneath the table, slide
the mounting brackets into the appropriate
slots.
Step 3: Tighten the butterfly mounting
screws securely upward against the table.
Step 4: Lock the mounting screws into
position with the locking butterfly screws.

Kramer Electronics Ltd.
RTBUS‑25xl –Installing the RTBUS‑25xl
8
Connecting the Cables and Wires
Figure 4 illustrates how to connect the cables to the underside of the unit:
Figure 4: Connecting the Cables
Note that the cables shown in Figure 4 are 50cm long and have a MALE connector at the free
end so they can be plugged directly into the acceptors. You can extend these cables if
required.
Note that the connecting surface is an integral part of the RTBUS‑25xl enclosure and cannot
be detached.
We recommend that you use the Kramer C-AC AC Power Cord series to power the unit.
