Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1
Thank you for purchasing the Kramer TOOLS PL-18 Control Port
Expander, which is ideal for:
that are clearly
defined by function.
•Controlling multimedia rooms, such as classrooms, auditoriums,
conference rooms, and so on
Each package includes the following items:
•The PL-18 Control Port Expander
•Windows®-based Kramer control software and Kramer RC-SV
Configuration software
•Power adapter (5V DC input)
•This user manual2
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high-performance high-resolution cables3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Overview
3
3
3 Overview
The PL-18 is a highly versatile port expander that adds RS-232, IR and
relay ports to an RS-232 controller, especially a Kramer RC device such as
RC-2, RC-2C or RC-62/RC-63. It acts as an all-in-one extended remote
control panel for control of A/V equipment—especially projectors and
associated equipment—in any room (such as classrooms, boardrooms, or
auditoriums).
The PL-18 Control Port Expander features:
•One bi-directional serial port for controlling RS-232 based devices
(for example, projectors) on RS-232/1
•One bi-directional port for receiving control commands from a PC,
touch screen, other serial controller or an RC series device on
RS-232/2
•Four relays for the simplified and centralized control of room
functions (such as lighting, closing blinds, screen settings, and so
on)
•Two IR output ports for IR control
•A USB port for firmware upgrade
To achieve the best performance:
•Use only good quality connection cables1
•Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer PL-18
away from moisture, excessive sunlight and dust
to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your PL-18 Control Port Expander
4
4 Your PL-18 Control Port Expander
Figure 1and Table 1define PL-18.
Figure 1: PL-18 Control Port Expander
Table 1: PL-18 Control Port Expander Functions
#
Feature
Function
1 ON LED Illuminates green when receiving power
2 RS-232 Tx/Rx LEDs Illuminate red while transmitting and green while receiving data on
an RS-232 port
3 IR LEDs Illuminate green when an IR port is active
4 RELAY LEDs Illuminate green when an relay is active (from 1 to 4)
5 PROGRAM USB Connector Connects to a computer to upgrade firmware
6 RELAY Terminal Blocks Connect to relay-driven devices (from 1 to 4)
7 IR OUTPUT 3.5mm Mini Jacks Connect to IR emitter cables (from 1 to 2)
8 RS-232/1 Terminal Block Connects to an RS-232 device that is controlled
9 RS-232/2 Terminal Block Connects to an external controller (PC, touch screen or RC device)
10 PROGRAM Switch For factory use only. Do not operate during firmware upgrade
11 5V DC +5V DC connector for powering the unit
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Connecting the PL-18 Control Port Expander
5
5
5 Connecting the PL-18 Control Port Expander
To connect the PL-18, as the example in Figure 2illustrates, do the
following1
1. Connect the RS-232 ports as follows:
:
Connect RS-232/1 to a projector
Connect RS-232/2 to a PC, touch screen or an RC device
2. Connect the RELAY2
Connect RELAYS 1 and 2 to window blinds
terminal block connectors as follows:
Connect RELAYS 3 and 4 to a screen
3. Connect the IR OUTPUTS as follows:
Connect IR OUTPUT 1 to a DVD
Connect IR OUTPUT 2 to a display
Figure 2: Connecting the PL-18 Control Port Expander
1 Switch OFF the power on each device before connecting it to your PL-18. After connecting your PL-18, switch on its power
and then switch on the power on each device
2 On each 3-pole terminal block connector, connect either: C to NO, or C to NC (C is common, NO is normally open and NC
is normally closed)
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating the PL-18 Control Port Expander
6
6 Operating the PL-18 Control Port Expander
The PL-18 is typically used to expand the number of ports available to an
RC series remote control device. The combined RC1and PL-18 are
configured from the RC device using RC-SV software that can be
downloaded from the Kramer Web site2
The PL-18 can also be operated directly from a PC, touch screen system, or
other serial controller using the serial commands of Kramer’s Protocol
3000. For an explanation of all control commands, see section
.
9.
In addition to operating the PL-18, machine software can be upgraded, and
device parameters can be accessed and changed using P3K Wizard software
also available from the Kramer Web site2(see section 10).
7 Technical Specifications
The PL-18 technical specifications are shown in Table 2:
Table 2: PL-18 Control Port Expander Technical Specifications3
PORTS: 2 bi-directional RS-232 ports on terminal block connectors; 1 USB
OUTPUTS: 4 relays on terminal block connectors, 36V AC or DC, 1A, 60V AC max on non-
inductive load; 2 IR outputs on 3.5mm mini jack connector
LED INDICATORS: ON (green), RS-232 (Tx - red and Rx - green), IR (green), relays (green)
POWER SOURCE: 5V DC, 260mA
DIMENSIONS 12cm x 7.6cm x 2.4cm (4.72" x 2.97"x 0.96") W, D, H
WEIGHT: 0.6kg (1.4lbs)
ACCESSORIES: Power supply 5V DC
OPTIONS: 15 meter and 20 meter IR emitter extension cables
1 When configuring an RC-2 to work with the PL-18, the RC-SV software version must be at 2.1.2.32 or higher and the RC-2
firmware version must be at 1573 or higher
2 At www.kramerelectronics.com
3 Specifications are subject to change without notice
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

PL-18 Commands in Protocol 3000
7
7
8 PL-18 Commands in Protocol 3000
This section describes all commands sent to the PL-18.For an explanation
of the syntax and use of Protocol 3000, see section 9
8.1 Operating Commands
Following are the specific commands that the controller (RC device) sends
to the PL-18 on RS-232/2 to operate the external devices connected to
RS-232/1, the IR ports and relays.
Command Syntax Response
Relay control RELAY PORT_NUM ,STATE
RELAY PORT_NUM ,STATE
RESULT
Parameter Description:
PORT_NUM = 1 to 4
STATE = Relay state:
‘0’ or ‘close’ to close the relay
‘1’ or ‘open’ to open the relay
Generic Binary Port Configuration Command
Config binary port
CBIN PORT_TYPE,
PORT_NUM[,1
CBIN PORT_TYPE, PORT_NUM
[, CFG_VAL1] [, CFG_VAL2]
[, CFG_VAL3] [, CFG_VAL4]
[, CFG_VAL5] [, CFG_VAL6]
[, CFG_VAL7] [, CFG_VAL8]
RESULT
CFG_VAL1]
[, CFG_VAL2][, CFG_VAL3]
[, CFG_VAL4][, CFG_VAL5]
[, CFG_VAL6][, CFG_VAL7]
[, CFG_VAL8]
PORT_TYPE = "UART", "ETH", "IR"
PORT_NUM = IR: 1 or 2; UART: 1 (RS-232/1); The port number is written over the physical port (see
Figure 1)
BAUD = 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
DATA_BITS = 5 to 8 inclusive
PARITY = “NONE”, “ODD”, “EVEN”, “MARK”, “SPACE” or first letter of those words
STOP_BITS = 1 or 2
DUTY_CYCLE = 1 to 99 inclusive
START_TOKEN = CR followed by “[“ that is, 2 bytes in hex representation = 0x0D and 0x5B
END_TOKEN = “]”
1 CBIN is a generic command, thus CFG_VAL parameters are a generic representation of the specific configuration
parameters, for instance, CFG_VAL1 and CFG_VAL2 represent CARRIER_FREQ and DUTY respectively in case
PORT_TYPE = “IR”
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
PL-18 Commands in Protocol 3000
8
Explicit Binary Port Configuration Command
Config Serial port
(RS-232/1)
UART-CFG
PORT_NUM, BAUD,
DATA_BITS, PARITY, STOP_BITS[,
FLOW_CONTROL]
UART-CFG PORT_NUM, BAUD,
DATA_BITS, PARITY, STOP_BITS
[, FLOW_CONTROL] RESULT
Config IR out port
IR-CFG PORT_NUM,
CARRIER_FREQ, DUTY_CYCLE
IR-CFG PORT_NUM,
CARRIER_FREQ, DUTY, RESULT
Binary Data Send/Receive
Emit raw data via a
pre-configured binary
port
BIN PORT_TYPE, PORT_NUM,
RAW_DATA_SIZE START_TOKEN
RAW_DATA END_TOKEN 1
BIN PORT_TYPE, PORT_NUM,
RAW_DATA_SIZE [ ] RESULT
Convey raw data
received through a
preconfigured binary
port
RBIN PORT_TYPE, PORT_NUM,
RAW_DATA_SIZE START_TOKEN
RAW_DATA END_TOKEN 1
RBIN PORT_TYPE, PORT_NUM,
RAW_DATA_SIZE [ ] RESULT2
Factory default values of binary ports:
IR1, IR2: Carrier frequency – 38000; duty cycle – 33
RS-232-1: 9600 baud, 8 data bits, parity NONE, 1 stop bit
Configuration and Operation Examples
A binary port must be configured properly before using it to send or receive binary data. The port may be used in
static or dynamic port scenarios:
Static binary port scenario – A specific binary port controls one specific external device (e.g. one RC
button opens a projector; another RC button closes it using the same serial binary port). The port is
configured only once at installation and the value is stored in the non-volatile memory of the PL-18.
Thereafter, when the RC button is pressed it only invokes the configured BIN commands on the PL-18.
Dynamic binary port scenario – A specific binary port controls various external devices (e.g. one RC
button opens a TV, another RC button opens a DVD, and both use the same IR binary port with a dual IR
emitter cable). The binary port must be reconfigured before issuing the BIN command to a different
device. At each RC button press, a CBIN command is sent to the PL-18 before sending a BIN command.
Configure UART (RS-232) port 1, with “9600,8,n,1” serial port configuration parameters:
Binary port configuration examples:
#cbin uart, 1, 9600, 8, n, 1 <CR>
or
#uart-cfg 1, 9600, 8, n, 1 <CR>
Configure IR port 2, with “38000,33” as infrared configuration parameters:
#cbin ir, 2, 38000, 33 <CR>
or
#ir-cfg 2, 38000, 33 <CR>
1 As opposed to any other P3000 command, CR cannot be added after the END_TOKEN
2 The RC responds with this command
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

PL-18 Commands in Protocol 3000
9
9
Emit via serial port 1 four bytes – the binary representation of P2000 “all-in 2” serial command:
Using the binary port to send binary data:
#bin uart, 1, 4 <CR> “[" $01 $82 $80 $81 "]"
Emit via IR port 2 forty-two bytes – the binary representation of Kramer signal “button-1”:
#bin ir, 2, 42 <CR> “[" $FF $01 $8F $69 $67 $65 $66 $69 $66 $6C $63 $66 $C9 $68 $C8 $66 $CB $66 $C8
$CE $FF $01 $BC $69 $66 $66 $C8 $69 $66 $69 $66 $66 $66 $69 $66 $69 $65 $67 $65 $FF $EF $26 "]"
U
Using the binary port to receive and convey binary data:
Convey four binary bytes received on serial port 1 – these four binary bytes are the binary representation of the
P2000 “all-in 2” serial command:
#rbin uart, 1, 4 <CR> “[" $01 $82 $80 $81 "]"
8.2 12BHelp Commands
Command Syntax Response
Protocol handshaking #CR ~OKCRLF
8.3 13BResult and Error Codes
Result/Error Syntax
Command ran successfully, no error. COMMAND PARAMETERS OK
Protocol Errors:
Syntax error ERR001
Command not available for this device ERR002
Parameter is out of range ERR003
Unauthorized access (command run without the matching
login). ERR004
8.4 14BIdentification Commands
Command Syntax Response
Protocol handshaking #CR ~OK CRLF
Read device model MODEL? MODEL MACHINE_MODEL
Read device serial number SN? SN SERIAL_NUMBER
Read device firmware
version VERSION? VERSION MAJOR .MINOR .BUILD .REVISION
Set machine name NAME MACHINE_NAME NAME MACHINE_NAME RESULT
Read machine name NAME? NAME MACHINE_NAME
Reset machine name to
factory default* NAME-RST
NAME-RST MACHINE_FACTORY_NAME
RESULT
Visual identification IDV IDV OK
*Note: The machine name is not the same as the model name. The machine name is used to identify a specific
machine or a network in use (with DNS feature on).
MACHINE_NAME = Up to 14 alphameric chars.
*Machine factory name = Model name + last 4 digits from serial number.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Protocol 3000 Syntax
10
8.5 Machine Information Commands
Command Syntax Response
Execute firmware upgrade* UPGRADE UPGRADE OK
Firmware usually uploads to a device via a command like LDFW. The device may need to be reset to complete
the process.
Reset to factory default
configuration FACTORY FACTORY RESULT
8.6 Reset Command
Command Syntax Response
Reset device RESET RESET OK
9 Protocol 3000 Syntax
Protocol 3000 is used to control the PL-18 via the RS-232/2 connection
using an RC-type controller or a PC, touch screen, other serial controller.
9.1 RS-232/2 Settings
Port RS-232/2
Baud Rate: 115,200
Data Bits: 8
Stop Bits: 1
Parity: None
Command Format: ASCII
9.2 Host Message Format
Start Address (optional) Body Delimiter
# Destination_id@ Message CR
9.2.1 Simple Command
Command string with only one command without addressing:
Start Body Delimiter
# Command SP Parameter_1,Parameter_2,… CR
9.2.2 Command String
Formal syntax with commands concatenation and addressing:
Start Address Body Delimiter
# Destination_id@ Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3 Parameter3_1,Parameter3_2,…|…
CR
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Protocol 3000 Syntax
11
11
9.3 Device Message Format
Start Address (optional) Body delimiter
~ Sender_id@ Message CR LF
9.3.1 Device Long Response
Echoing command:
Start Address (optional) Body Delimiter
~ Sender_id@ Command SP [Param1 ,Param2 …] result CR LF
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
SP = Space (ASCII 32 = 0x20)
9.4 COMMAND TERMS
Command
A sequence of ASCII letters ('A'-'Z', 'a'-'z' and '-').
Command and parameters must be separated by at least one space.
Parameters
A sequence of alphameric ASCII characters ('0'-'9','A'-'Z','a'-'z' and some
special characters for specific commands). Parameters are separated by
commas.
Message string
Every command entered as part of a message string begins with a message
starting character and ends with a message closing character.
Note: A string can contain more than one command. Commands are
separated by a pipe ( '|' ) character.
Message starting character
'#' – For host command/query
'~' – For machine response
Device address (Optional, for K-NET)
K-NET Device ID followed by '@'
Query sign
'?' follows some commands to define a query request.
All outputs sign
'*' defines all outputs.
Message closing character
CR – For host messages; carriage return (ASCII 13)
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Protocol 3000 Syntax
12
CRLF – For machine messages; carriage return (ASCII 13) + line-feed
(ASCII 10)
Command chain separator character
When a message string contains more than one command, separate each
command with a pipe ( '|' ) character.
Spaces between parameters or command terms are ignored.
9.5 Entering Commands
You can directly enter all commands using a terminal with ASCII
communications software, such as HyperTerminal, Hercules, etc. Connect
the terminal to the serial, Ethernet, or USB port on the Kramer device. To
enter CR , press the Enter key.
( LF is also sent but is ignored by command parser).
For commands sent from some non-Kramer controllers like Crestron, some
characters require special coding (such as, /X##). Refer to the controller
manual.
9.6 Command Forms
Some commands have short name syntax in addition to long name syntax to
allow faster typing. The response is always in long syntax.
9.7 Command Chaining
Multiple commands can be chained in the same string. Each command is
delimited by a pipe character ( '|' ). When chaining commands, enter the
message starting character and the message closing character only once,
at the beginning of the string and at the end.
Commands in the string do not execute until the closing character is
entered.
A separate response is sent for every command in the chain.
9.8 Maximum String Length
64 characters
9.9 Backward Support
Protocol 2000 is transparently supported by Protocol 3000. You can switch
between protocols using a switch protocol command from either platform.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Using the P3K Wizard
13
13
10 Using the P3K Wizard
The P3K Wizard is a Kramer software program for:
•Upgrading the machine firmware (see section 10.1)
•Accessing and changing device parameters (see section 10.2).
The P3K Wizard can be downloaded from the Kramer Web site1
10.1 Updating the PL-18 Firmware
.
The PL-18 uses a microcontroller that runs firmware located in FLASH
memory. The latest version of firmware can be downloaded from the
Kramer Web site and updated in minutes using the PK3 Wizard and the
following procedures.
To update the PL-18 firmware:
•Download the firmware file from the Internet (see section 10.1.1)
•Connect a PC directly2to the PL-18 (see section 10.1.2)
•Update the firmware using the P3K Wizard (see section 10.1.3)
10.1.1 Downloading The Firmware
To download the latest firmware file3
1. Go to the Kramer Web site at
from the Internet:
www.kramerelectronics.com.
2. Navigate to SUPPORT / Software Firmware Updates.
3. Click on the link of the firmware that applies to your product. Download it
and save it to your disk.
4. Extract the file to a folder (for example, C:\Program Files\Kramer Flash).
10.1.2 Connecting a PC to the PL-18
To connect a PC to the PL-18:
•Connect a serial cable from an RS-232 9-pin D-sub rear panel port
on the PC to the RS-232/2 port of the PL-18 as explained in section
5, or
•Connect a USB cable from a USB port on the PC to the USB port
on the PL-18
1 www.kramerelectronics.com
2 You cannot upgrade the firmware of the PL-18 through an RC connection. The PL-18 must be connected directly to a PC
3 The files indicated in this section are given as an example only. File names are liable to change from time to time
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the P3K Wizard
14
10.1.3 Updating the Firmware
To update the firmware, perform the following steps:
1. Open the Kramer P3K Wizard1by double-clicking the desktop icon P3K
Wizard.
The P3K Wizard screen appears2
:
Figure 3: P3K Wizard Screen
2. Click the Connect button.
The Connect Window appears.
Note: The PL-18 does not have an Ethernet interface. Do not select any of
the Ethernet options on the Connect window.
1 You can download and install the latest version of the P3K Wizard from www.kramerelectronics.com.
2 The screens appearing in this manual are examples of the process. The actual screens may differ in their content.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Using the P3K Wizard
15
15
Figure 4: Connect Serial/USB
3. To upgrade using an RS-232 or USB connection, click Serial/USB (see
Figure 4).
Click the drop-down box to show the COM ports
Select a COM port to connect (from COM1 to
COM13) and click OK
Note: If you try to connect to a device and it does not respond, the
following error message appears. Click OK. Verify that the device is
powered on, the cable connection is good, and that you are trying to connect
by the correct method.
Do not operate the PROGRAM switch on the back panel. It is for factory
use only.
Figure 5: Error Message
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the P3K Wizard
16
4. After pressing OK on the Connect Window, the wizard searches the line for
connected devices. All detected devices are displayed in the device list box
under “Please select the device for update”:
Note: In the Device Properties section, you can update any of the active
fields that have a white background. After making any changes, click Set.
Figure 6: Device Selection
5. In the device list box, click to select the target device.
6. Next, select the firmware file to upgrade by clicking Browse next to the
Firmware file box.
The Open File window opens:
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]

Using the P3K Wizard
17
17
Figure 7: Open File Window
7. Navigate to the folder containing the firmware file (for example,
C:\Program Files\Kramer Flash).
8. Select the firmware file you downloaded in section 10.1.1 and click Open.
The firmware file appears in the Firmware file box.
im Vertrieb von
CAMBOARD Electronics
www.camboard.de
Tel. [phone]
Fax [phone]
[email protected]
