Kramer DigiTOOLS VM-2HDMI User manual

Kramer Electronics, Ltd.
USER MANUAL



Model:
VM-2HDMI
1:2 HDMI Distributor

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 1
3 Overview 3
3.1 About HDMI 3
3.2 Defining EDID 4
3.3 Recommendations for Best Performance 4
4 Your VM-2HDMI 1:2 HDMI Distributor 5
5 Using the VM-2HDMI 1:2 HDMI Distributor 6
5.1 Connecting the VM-2HDMI 1:2 HDMI Distributor 6
5.2 Using the VM-2HDMI EDID SETUP Button 7
5.2.1 Acquiring / Changing the EDID 8
5.2.2 Acquiring the Clone EDID 8
6 Technical Specifications 9
Figures
Figure 1: VM-2HDMI 1:2 HDMI Distributor 5
Figure 2: VM-2HDMI 1:2 HDMI Distributor (Top and Lower Side Panesl) 5
Figure 3: Connecting a VM-2HDMI 1:2 HDMI Distributor 7
Tables
Table 1: VM-2HDMI 1:2 HDMI Distributor (Top and Lower Side Panels) Features 5
Table 2: Technical Specifications of the VM-2HDMI 9

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups
1
that are clearly defined
by function.
Congratulations on purchasing your Kramer DigiTOOLS® VM-2HDMI 1:2
HDMI
2
Distributor!The VM-2HDMI is ideal for:
Home theater, presentation and multimedia applications
Rental and staging
The package includes the following items:
VM-2HDMI 1:2 HDMI Distributor
Power adapter (12V DC Input)
This user manual
3
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
4
2.1 Quick Start
This Quick start chart summarizes the basic setup and operation steps of the
VM-2HDMI.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories
and Rack Adapters; GROUP 11: Sierra Products
2 High-Definition Multimedia Interface
3 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2

Overview
3
3 Overview
The high quality VM-2HDMI accepts an HDMI input and distributes the
signal to two outputs. In particular, the VM-2HDMI:
Supports up to 1.65Gbps bandwidth per graphic channel
1
Can read and store, in non-volatile memory
2
, the EDID
3
block from either
of the output display devices, so it can then provide the EDID information
to the HDMI source even if the display device is not connected
Has a default EDID for fast and efficient connection of the unit
4
Is 12VDC fed
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital
5
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality.
In particular, HDMI
6
:
Provides a simple
7
interface between any audio/video source, such as a
set-top box, DVD player, or A/V receiver and video monitor, such as a
digital flat LCD / plasma television (DTV), over a single lengthy
8
cable
Supports standard, enhanced, high-definition video, and multi-channel
digital audio
9
on a single cable
Transmits all ATSC HDTV standards and supports 8-channel digital audio,
with bandwidth to spare to accommodate future enhancements and
requirements
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
2 While the machine is ON
3 EDID is Extended Display Identification Data (see section 5.2 for a detailed definition)
4 Lets you use the EDID default value when no display from which to read the EDID is connected
5 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
6 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
7 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
8 HDMI technology has been designed to use standard copper cable construction at up to 15m
9 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
Benefits consumers by providing superior, uncompressed digital video
quality via a single cable
1
, and user-friendly connector
Is backward-compatible with DVI (Digital Visual Interface)
Supports two-way communication between the video source (such as a
DVD player) and the digital television, enabling new functionality such
as automatic configuration and one-button play
HDMI has the capacity to support:
Existing high-definition video formats (720p, 1080i, and 1080p/60), as
well as standard definition formats such as NTSC or PAL
3.2 Defining EDID
The Extended Display Identification Data (EDID
2
) is a data-structure,
provided by a display, to describe its capabilities to a graphics card (that is
connected to the display’s source). The EDID enables the VM-2HDMI to
“know” what kind of monitor is connected to the output. The EDID includes
the manufacturer’s name, the product type, the timing data supported by the
display, the display size, luminance data and (for digital displays only) the
pixel mapping data.
3.3 Recommendations for Best Performance
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your VM-2HDMI away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
3
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
2 Defined by a standard published by the Video Electronics Standards Association (VESA)
3 For example: model number AD2512C, part number 2535-000251

Your VM-2HDMI 1:2 HDMI Distributor
5
4 Your VM-2HDMI 1:2 HDMI Distributor
Figure 1 illustrates the VM-2HDMI 1:2 HDMI Distributor:
Figure 1: VM-2HDMI 1:2 HDMI Distributor
Figure 2 and Table 1 define the top and lower side panels:
Figure 2: VM-2HDMI 1:2 HDMI Distributor (Top and Lower Side Panesl)
Table 1: VM-2HDMI 1:2 HDMI Distributor (Top and Lower Side Panels) Features
# Feature Function
1 HDMI IN Connects to the HDMI source
2 HDMI OUT1 Connects to the HDMI acceptor 1
3 HDMI OUT2 Connects to the HDMI acceptor 2
4 12V DC +12V DC connector for powering the unit
5 INPUT LED Blinks when the stored EDID does not match the display device EDID;
illuminates when the EDID corresponds to the display device and that HDMI
source is active
6 OUT2 LED Blinks during the EDID setup; illuminates when output 2 is connected
7 OUT1 LED Blinks during the EDID setup; illuminates when output 1 is connected
8 POWER LED Illuminates when receiving power
9 EDID SETUP Button Press for more than 3 seconds to acquire the EDID information from the
display

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the VM-2HDMI 1:2 HDMI Distributor
6
5 Using the VM-2HDMI 1:2 HDMI Distributor
This section describes how to connect the VM-2HDMI (see section 5.1) and
how to use the EDID SETUP button (see section 5.2).
5.1 Connecting the VM-2HDMI 1:2 HDMI Distributor
To connect the VM-2HDMI, as the example in Figure 3 shows, do the
following
1
:
1. Connect the HDMI source (for example, a DVD) to the HDMI IN
connector.
2. Connect the HDMI OUT connectors
2
to up to 2 HDMI acceptors, as
follows:
HDMI OUT1 connector to HDMI acceptor 1 (for example, an LCD
TV)
HDMI OUT2 connector to HDMI acceptor 2 (for example, a plasma
display)
3. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
4. Press the EDID SETUP button to acquire or change the EDID
information (see section 5.2).
1 Switch OFF the power on each device before connecting it to your VM-2HDMI. After connecting your VM-2HDMI, switch
on its power and then switch on the power on each device
2 If you are using only one HDMI acceptor, you should connect it to OUT 1

Using the VM-2HDMI 1:2 HDMI Distributor
7
Figure 3: Connecting a VM-2HDMI 1:2 HDMI Distributor
5.2 Using the VM-2HDMI EDID SETUP Button
Initially, the VM-2HDMI operates with the factory default EDID
1
. This lets
you connect the power before connecting either of the acceptors or the source.
You can acquire the EDID From:
The Default EDID (both output LEDs blink)
One Output (the relevant output illuminates)
You can also acquire the Clone EDID which copies the EDID data from the
acceptor bit-by-bit.
1 The VM-2HDMI reads the EDID, which is stored in the non-volatile memory

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the VM-2HDMI 1:2 HDMI Distributor
8
5.2.1 Acquiring / Changing the EDID
You can work with the default EDID or acquire or change an EDID via one
of the connected outputs. Use the EDID Setup button to acquire the output
EDID information.
To acquire or change the EDID of a new output display:
1. Connect the power supply.
The ON LED lights.
2. Connect the new output display device.
3. Press and hold the EDID SETUP button for more than three seconds and
release.
The INPUT LED blinks and the OUT2 LED and OUT1 LED blink alternately.
4. Press the EDID SETUP button again when the appropriate OUT LED
lights, that is to copy the EDID from the display connected to the HDMI:
OUT1 connector, press the EDID button when the OUT1 LED is on
OUT2 connector, press the EDID button when the OUT2 LED is on
In either case, the VM-2HDMI copies the EDID from the display. If no
display is connected to the selected HDMI output, the default EDID will
be chosen.
Note that during the EDID setup, the respective OUT LED blinks. When that
output is connected, that OUT LED illuminates
5.2.2 Acquiring the Clone EDID
To acquire the Clone EDID, do the following
1
:
1. Connect the new output display device (for example, to OUT 1).
2. Disconnect the power supply.
3. Reconnect the power supply while pressing the EDID SETUP button.
The ON LED lights and the OUT 1 and OUT 2 blink alternately.
4. Release the EDID SETUP button when the OUT 1 LED blinks.
The Clone EDID is stored in the non-volatile memory when the OUT 1
LED ceases to blink.
1 This example refers to OUT 1. The same applies for OUT 2 if the acceptor is connected to OUT 2

Technical Specifications
9
6 Technical Specifications
Table 2 includes the technical specifications
1
of the VM-2HDMI:
Table 2: Technical Specifications of the VM-2HDMI
INPUT: HDMI Connector
OUTPUTS: 2 HDMI Connectors
BANDWIDTH: Supports up to 1.65Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD:
Supports HDMI 1.1 and HDCP
CONTROLS: EDID SETUP button
INDICATOR LEDs: INPUT, OUT1, OUT2, and POWER LEDs
POWER SOURCE: 12 VDC 400mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" 0.98", W, D, H)
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply, bracket installation kit
OPTIONS: HDMI/HDMI male-to-male cables
1 Specifications are subject to change without notice

KRAMER: SIMPLE CREATIVE TECHNOLOGY
10
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
followingterms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expensesfor covered items.We will notpayfor thefollowing:
Theliability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
Thiswarranty gives you specificlegal rights, and you may also have other rights, which varyfromplace to place.
All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
Thisequipment has been tested todetermine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility(EMC);
generic emissionstandard.
Residential, commercial and lightindustry"
EN-50082: "Electromagnetic compatibility(EMC)genericimmunitystandard.
Part 1: Residential, commercial and light industryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunctionresulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning orotheractsof nature
ii) Product modification, or failure to follow instructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Anyshipment of theproduct(claims must bepresented tothe carrier)
v) Removalorinstallationoftheproduct
vi) Anyother cause, whichdoes not relate to a product defect
vii) Cartons,equipment enclosures, cables or accessoriesusedinconjunctionwiththe product
1. Removal or installationscharges.
2. Costs of
initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramerdealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defectsin this product,damages basedupon inconvenience, loss of use of the product, loss
of time, commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitationsandexclusions maynotapplytoyou.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Usethe suppliedDC power supply to feed power to the machine.
Please use recommended interconnection cablesto connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approved using STPcable (for twisted pair products)
NOTE:
Part1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [email protected]
P/N: 2900-000153 REV 5
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
