Kramer VM-22H User manual

Kramer Electronics, Ltd.
USER MANUAL
Model:
VM-22H
2x1:2 HDMI Switcher/DA

Contents
i
Contents
1Introduction 1
2Getting Started 1
2.1 Quick Start 2
3Overview 3
3.1 About HDMI 3
3.2 Defining EDID 4
3.3 Recommendations for Best Performance 4
4Your VM-22H 2x1:2 HDMI Switcher/DA 5
5Using the VM-22H 2x1:2 HDMI Switcher/DA 5
5.1 Connecting the VM-22H 2x1:2 HDMI Switcher/DA 6
5.2 Acquiring the EDID 7
6Technical Specifications 8
Figures
Figure 1: VM-22H 2x1:2 HDMI Switcher/DA 5
Figure 2: Connecting a VM-22H 2x1:2 HDMI Switcher/DA 6
Tables
Table 1: VM-22H 2x1:2 HDMI Switcher/DA Features 5
Table 2: Technical Specifications of the VM-22H 8

Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1
Thank you for purchasing your Kramer DigiTOOLS® VM-22H 2x1:2
HDMI
that are clearly
defined by function.
2
•Home theater, presentation and multimedia applications
Switcher/DA.The VM-22H is ideal for:
•Rental and staging
Note, that the Kramer VS-22H is identical to the VS-22HDMI; just the
name has changed replacing the suffix “HDMI” by “H” (according to
the HDMI Guideline).
The package includes the following items:
•VM-22H 2x1:2 HDMI Switcher/DA
•Power adapter (5V DC Input)
•Infrared remote control transmitter
•This user manual3
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high performance high-resolution cables4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 High-Definition Multimedia Interface
3 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Overview
3
3
3 Overview
The high quality VM-22H is a switcher/distribution amplifier for HDMI
signals. It reclocks and equalizes one of two selectable input signals and
distributes it to two identical outputs. In particular, the VM-22H features:
•Up to 2.25Gbps bandwidth per graphic channel1
•I-EDIDPro™ Kramer Intelligent EDID Processing™, an
intelligent EDID handling and processing algorithm that ensures
Plug and Play operation for HDMI systems
•3D pass-through
•HDMI Support – HDMI (V.1.4 with Deep Color, x.v.Color™, Lip
Sync, CEC)
•HDCP compliance
•Selected input and active output LED indicators
The VM-22H is 5V DC fed and is housed in a DigiTOOLS®enclosure.
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital2
In particular, HDMI
audio/video interface, widely supported in the entertainment and home
cinema industry. It delivers the highest high-definition image and sound
quality.
3
•Provides a simple
:
4interface between any audio/video source, such
as a set-top box, DVD player, or A/V receiver and video monitor,
such as a digital flat LCD/plasma television (DTV), over a single
lengthy5
•Supports standard, enhanced, high-definition video, and multi-
channel digital audio
cable
6
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
on a single cable
2 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
3 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
4 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
5 HDMI technology has been designed to use standard copper cable construction at up to 15m
6 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
•Transmits all ATSC HDTV standards and supports 8-channel
digital audio, with bandwidth to spare to accommodate future
enhancements and requirements
•Benefits consumers by providing superior, uncompressed digital
video quality via a single cable1
•Is backward-compatible with DVI (Digital Visual Interface)
, and user-friendly connector
•Supports two-way communication between the video source (such
as a DVD player) and the digital television, enabling new
functionality such as automatic configuration and one-button play
HDMI has the capacity to support existing high-definition video formats
(720p, 1080i, and 1080p/60), as well as standard definition formats such as
NTSC or PAL.
3.2 Defining EDID
The Extended Display Identification Data (EDID2
3.3 Recommendations for Best Performance
) is a data-structure,
provided by a display, to describe its capabilities to a graphics card (that is
connected to the display’s source). The EDID enables the VM-22H to
“know” what kind of monitor is connected to the output. The EDID
includes the manufacturer’s name, the product type, the timing data
supported by the display, the display size, luminance data and (for digital
displays only) the pixel mapping data.
To achieve the best performance:
•Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
•Avoid interference from neighboring electrical appliances and position
your VM-22H away from moisture, excessive sunlight and dust
1 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
2 Defined by a standard published by the Video Electronics Standards Association (VESA)

Your VM-22H 2x1:2 HDMI Switcher/DA
5
5
4 Your VM-22H 2x1:2 HDMI Switcher/DA
Figure 1and Table 1define the VM-22H 2x1:2 HDMI Switcher/DA:
Figure 1: VM-22H 2x1:2 HDMI Switcher/DA
Table 1: VM-22H 2x1:2 HDMI Switcher/DA Features
#
Feature
Function
1 5V DC +5V DC connector for powering the unit
2 HDMI OUT2 Connects to the HDMI acceptor 2
3 HDMI OUT1 Connects to the HDMI acceptor 1
4 HDMI IN 2 Connects to the HDMI source 2
5 HDMI IN 1 Connects to the HDMI source 1
6 REMOTE IR The red LED illuminates when receiving signals from the Infrared remote control
transmitter
7 EDID SETUP Button Press briefly to determine the type of EDID stored in the non-volatile
memory
Press and hold to select the desired EDID setup and then release to acquire
EDID (see section 5.2)
8 IN SELECT Button Press to select the input. The relevant IN LED illuminates
9 IN 1 LED Illuminates when input 1 is selected
10 IN 2 LED Illuminates when input 2 is selected
11 OUT 1 LED Illuminates when output 1 is connected and active
1
12 OUT 2 LED Illuminates when output 2 is connected and active1
13 ON LED Illuminates when receiving power
5 Using the VM-22H 2x1:2 HDMI Switcher/DA
This section describes how to connect the VM-22H (see section 5.1) and how
to use the EDID SETUP button (see section 5.2).
1 Also illuminates or blinks during EDID setup (see section 5.2)

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Using the VM-22H 2x1:2 HDMI Switcher/DA
6
5.1 Connecting the VM-22H 2x1:2 HDMI Switcher/DA
To connect the VM-22H, as the example in Figure 2shows, do the
following1
1. Connect the HDMI source (for example, a DVD player) to the HDMI
IN 1 connector.
:
2. Connect the HDMI source (for example, a DVD player) to the HDMI
IN 2 connector.
3. Connect the HDMI OUT connectors to up to two HDMI acceptors, as
follows:
HDMI OUT 1 connector to an LCD TV
HDMI OUT 2 connector to a plasma display
4. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity.
5. Press the EDID SETUP button to acquire or change the EDID information
(see section 5.2).
Figure 2: Connecting a VM-22H 2x1:2 HDMI Switcher/DA
1 Switch OFF the power on each device before connecting it to your VM-22H. After connecting your VM-22H, switch on its
power and then switch on the power on each device

Using the VM-22H 2x1:2 HDMI Switcher/DA
7
7
5.2 Acquiring the EDID1
Initially, the VM-22H operates with the factory default EDID
2
You can acquire the EDID from:
. This lets
you connect the power before connecting one of the acceptors or sources.
•One Output (the relevant output illuminates)
•The Default EDID (both output LEDs blink)
•Two Connected Outputs, the Auto-mix Mode3
When pressing the EDID SETUP button briefly, the OUT LEDs indicate
which type of EDID was last acquired. If the:
(both output LEDs
illuminate)
•OUT 1 LED illuminates, the OUT 1 EDID is stored in the non-
volatile memory
•OUT 2 LED illuminates, the OUT 2 EDID is stored in the non-
volatile memory
•OUT 1 and OUT 2 LEDs blink, the Default EDID is stored in the
non-volatile memory
•OUT 1 and OUT 2 LEDs illuminate, the Auto-Mix3EDID is
stored in the non-volatile memory
To acquire the EDID, do the following:
1. Connect the power.
2. Connect the output or outputs from which you want to acquire the EDID.
3. Press and hold the EDID SETUP button to select the desired EDID.
The OUT LEDs illuminate in the following cycle: OUT 1, OUT 2, both
blink (Default) and both illuminate (Auto-mix3).
4. Release the button when reaching the desired set up4
.
The EDID is now acquired.
1 This is usually done only once, when the machine is being set up in an installation. Once acquired, the EDID is saved in
non-volatile memory and further acquisition is not necessary
2 The VM-22H reads the EDID, which is stored in the non-volatile memory
3 The EDID acquired is a weighted average of all the connected outputs. For example, if several displays with different
resolutions are connected to the outputs, the acquired EDID supports all the resolutions, as well as other parameters included
in the EDID
4 If you set the machine to acquire the EDID from an output that is not connected, the Default EDID will be acquired

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
6 Technical Specifications
Table 2includes the technical specifications1
Table 2: Technical Specifications of the VM-22H
of the VM-22H:
INPUTS: 2 HDMI connectors
OUTPUTS: 2 HDMI connectors
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD:
Supports HDMI and HDCP
CONTROLS: EDID SETUP button, input select button
INDICATOR LEDs: IN 1, IN 2, OUT 1, OUT 2, and ON LEDs
POWER SOURCE: 5V DC, 910mA
DIMENSIONS: 12cm x 7.15cm x 2.44cm (4.7" x 2.8" 0.96") W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply, bracket installation kit, infrared remote control transmitter
OPTIONS: HDMI/HDMI male-to-male cables
1 Specifications are subject to change without notice

9
9
LIMITED WARRANTY
WHOIS PROTECTED?
WHAT IS COVEREDANDWHATIS NOTCOVERED
WHAT W E WIL L PAY FO R AND WHAT WE W ILL NO T PAY F O R
HOW YOU CAN GET WARRANTY SERVICE
LIMITATIONOFIMPLIEDWARRANTIES
EXCLUSIONOFDAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONGIS THE WARRANTY
Labor and parts are warranted for three years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items.We will notpay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives youspecific legal rights, andyou may alsohave other rights, which varyfrom place to place.
Allproducts returned to Kramer for service must have prior approval.Thismay be obtained from your dealer.
Thisequipment has been tested todetermine compliance with therequirements of:
EN-50081: "Electromagnetic compatibility(EMC);
generic emission standard.
Residential, commercial and lightindustry"
EN-50082: "Electromagnetic compatibility(EMC) generic immunity standard.
Part 1: Residential, commercialand lightindustryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other actsof nature
ii) Product modification, orfailure to followinstructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presentedto the carrier)
v) Removal or installationof the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessoriesused inconjunction with the product
1. Removal or installations charges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects inthis product, damages basedupon inconvenience,loss of useof theproduct, loss
of time, commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions maynot applyto you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approvedusingSTPcable (for twisted pair products)
NOTE:
Part 1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [email protected]
P/N: 2900-000663 REV 2
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
P/N:
2900- 000663
Rev:
2
