VP-551X Quick Start
P/N:
2 9 0 0 - 3 0 0 9 7 2 QS
Rev:
1
Scan for full manual
VP-551X Quick Start Guide
This guide helps you install and use your VP-551X for the first time.
Go to www.kramerav.com/downloads/VP-551X to download the latest user manual and check if firmware
upgrades are available.
Step 1: Check what’s in the box
VP-551X 4K Presentation Matrix Switcher/Scaler
1 Set of rack ears
4 Rubber feet
IR remote control transmitter with batteries
1 Power cord
1 Quick start guide
Step 2: Get to know your VP-551X
#
Feature
Function
1
IR Receiver
Receives signals from the remote-control transmitter.
2
IR LED
Lights when the unit accepts IR remote commands.
3
Input Selector
Buttons
HDMI™
Press to select the HDMI input (from INPUT 1 to INPUT 8).
4
PC
Press to select the computer graphics input.
5
CV
Press to select the composite video input.
6
FREEZE Button
Press to freeze/unfreeze the output video image.
Not applicable when in video bypass mode.
7
MUTE Button
Press to toggle between muting (blocking out the sound) and enabling the audio output (both
line and speakers).
Muting the audio is not applicable when in audio bypass mode.
8
MENU Button
Press to enter/escape the on-screen display (OSD) menu.
9
Navigation
Buttons

Press to decrease numerical values or select from several definitions.
When not within the OSD menu mode, press to decrease the output volume.

Press to move up the menu list.

Press to increase numerical values or select from several definitions.
When not within the OSD menu mode, press to increase the output volume.

Press to move down the menu list.
ENTER
Press to accept changes and change the SETUP parameters.
10
RESET TO XGA/1080p
Button
Press and hold for about 5 seconds to toggle resetting the video resolution to XGA or 1080p.
11
PANEL LOCK Button
Press and hold for about 5 seconds to lock/unlock the front panel buttons (note that more
secure locking options may be set by the user).
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

#
Feature
Function
12
VIDEO INPUT
Connectors
HDMI™
Connect to an HDMI source (from INPUT 1 to INPUT 8).
13
PC 15-pin HD
Connect to a computer graphics source.
14
CV RCA
Connect to a composite video source.
15
48V MIC 1 Switch
Move up (ON) to select a condenser type microphone; down (OFF) to select
a dynamic type microphone.
16
MIC 1 6mm Jack
Connect to the microphone source 1.
17
48V MIC 2 Switch
Move up (ON) to select a condenser type microphone; down (OFF) to select
a dynamic type microphone.
18
MIC 2 6mm Jack
Connect to the microphone source 2.
19
AUDIO INPUT
Unbalanced Stereo
Terminal Blocks
HDMI
Connect to an analog audio HDMI source (from 1 to 8).
20
PC IN
Connect to an analog audio computer graphics source.
21
CV IN
Connect to an analog audio composite video source.
22
LINE OUT Balanced Stereo 5-pin Terminal
Block Connector
Connect to a balanced stereo analog audio acceptor.
23
S/PDIF OUT 3.5 Mini Jack Connector
Connect to a digital audio acceptor.
24
Speaker Terminal Block Connector
Connect to a pair of loudspeakers.
25
Mains Socket
Connect the mains power cord.
26
Mains Fuse Holder
Fuse for protecting the device.
27
Power Switch
Switch for turning the unit ON or OFF.
28
HDMI™ OUT
Connect to the HDMI acceptor.
29
HDBT OUT RJ-45 Connector
Connect to an HDBaseT receiver.
30
RS-232 9-pin D-sub
Connector
DATA
Connect to a PC or controller to tunnel RS-232 via HDBT OUT or connect to
the output display to control it.
31
CTRL
Connect to a PC or remote controller to control VP-551X.
32
ETHERNET Connector
Connects to the PC or other Serial Controller through computer networking.
Step 3: Install the VP-551X
To rack mount the machine, attach both rack ears
(by removing the screws from each side of the
machine and replacing those screws through the
rack ears) or place the machine on a table.
• Ensure that the environment (e.g., maximum ambient temperature &
air flow) is compatible for the device.
• Avoid uneven mechanical loading.
• Appropriate consideration of equipment nameplate ratings should be
used for avoiding overloading of the circuits.
• Reliable earthing of rack-mounted equipment should be maintained.
Step 4: Connect the inputs and outputs
Always switch OFF the power on each device before connecting it to your VP-551X. For best results, we recommend that you
always use Kramer high-performance cables to connect AV equipment to the VP-551X.
Condenser Microphone Pinout
Dynamic Microphone Pinout

For optimum range and performance use the recommended Kramer cables available at
www.kramerav.com/product/VP-551X.
Connect the Audio
To a balanced stereo audio input/output:
To an unbalanced stereo audio input/output:
Step 5: Connect the power
Connect the power cord to VP-551X and plug it into the mains electricity.
Safety Instructions (See www.kramerav.com for updated safety information)
Caution:
• For products with relay terminals and GPI\O ports, please refer to the permitted rating for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• Disconnect the power and unplug the unit from the wall before installing.
• Do not open the unit. High voltages can cause electrical shock! Servicing by qualified personnel only.
• To ensure continuous risk protection, replace fuses only according to the rating specified on the product label which located on the bottom of the unit.
Step 6: Set operation parameters via OSD menu
Enter the OSD menu via the MENU button on
the front panel or the IR remote control
transmitter. Select a menu item and set
parameters as required.
Menu Item
Function
PICTURE:
Set the contrast, brightness and color. Fine-tune the PC
and video settings.
This menu is not available in bypass mode
INPUT:
Select the input source.
If you cannot see any video output, verify that
the display, TV, or projector is in good working
order, is connected to the VP-551X, and that
the VP-551X is selected as its source. If you
still cannot see any image, press and hold the
RESET TO XGA/1080p button for 3 seconds to
reset the output to XGA or 1080p resolution.
OUTPUT:
Set device to bypass mode (ON/OFF), when not in
bypass mode, select the image size and the resolution.
AUDIO:
Select the input volume for each input; set the output
volume and speaker volume; set the audio source;
adjust audio settings (delay, DRC, bass, treble and
loudness) and mute/unmute line and speaker outputs
separately. Adjust microphone settings and volume and
set the embedding mode (DSP or bypass).
Note that the mute features are not available in the
audio bypass mode.
OSD:
Set the position of the OSD on the screen, the OSD
timeout and so on.
EDID:
Set the EDID on the inputs.
ADVANCED:
Set HDCP on the input and output, set auto sync off and
auto switching mode. Set the Ethernet parameters and
lock modes. Define daily reset time. View the device
lifetime timer (in hours).
INFO:
Display the device information.
FACTORY:
Select to reset the device to its factory default settings,
including Ethernet parameters or perform a soft reset,
keeping current Ethernet parameters.

Step 7: Operate VP-551X:
Operate VP-551X via:
• Front panel buttons.
• Remotely, by RS-232 serial
commands transmitted by a
touch screen system, PC, or
other serial controller.
• Remotely, using the IR remote
control transmitter.
• Embedded web pages via the
Ethernet.
RS-232
Protocol 3000
Baud Rate:
115,200
Data Bits:
8
Stop Bits:
1
Parity:
None
Ethernet
IP Address:
192.168.1.39
Subnet mask:
255.255.0.0
TCP Port #:
5000
UDP Port #:
50000
Default gateway:
192.168.0.1
Default Username / Password:
Admin / Admin
Full Factory Reset
OSD
Go to: Menu-> Factory-> RESET-> YES and press Enter
RS-232/Ethernet Command Protocol
Command Format:
ASCII protocol 3000
Example (Route the video HDMI2 input to the output ports):
#ROUTE 1,1,2<cr>
