USER MANUAL
MODEL:
VS-611DT
UHD 6x1:2 Auto Switcher
P/N: 2900-300464 Rev 3 www.kramerAV.com

VS-611DT – Contents i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3Overview 4
3.1 About Fast Switching 5
3.2 Defining the VS-611DT UHD 6x1:2 Auto Switcher 6
4Connecting the VS-611DT 8
4.1 Connecting a Serial Controller to the VS-611DT via RS-232 9
5Operating the VS-611DT 10
5.1 Switching – Manual and Auto 10
5.2 Performing a Factory Reset 11
5.3 Locking the Front Panel Buttons 12
5.4 Turning the Output Off 12
5.5 Copying the EDID 12
5.6 Setting the 5V Output Time Delay 13
5.7 Setting HDCP Capability 13
5.8 Setting the Audio Output 14
5.9 Setting the Switching Speed 15
5.10 Using VCOM on USB 15
5.11 Upgrading the Firmware 16
5.12 Step-In Support 16
5.13 Controlling the VS-611DT via the Terminal Block Connector 16
6Using the Web Pages 17
6.1 Routing Inputs to Outputs 17
6.2 Using EDID Settings 19
6.3 Setting Device ID Parameters 21
6.4 Contacting Kramer 22
7Technical Specifications 23
8Supported Resolutions 24
9Default Settings 26
9.1 Default Communication Settings 26
9.2 First Power On Default Settings 26
9.3 Default EDID 27
10 Protocol 3000 29
10.1 Understanding Protocol 3000 30
10.2 Kramer Protocol 3000 Syntax 31
10.3 Protocol 3000 Commands 33
Figures
Figure 1: VS-611DT UHD 6x1:2 Auto Switcher 6
Figure 2: Connecting the VS-611DT UHD 6x1:2 Auto Switcher 9
Figure 3: Connecting the Contact Closure Remote Control Pins 16

VS-611DT – Introduction 1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 14 groups that are clearly defined by
function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:
Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and
GROUP 14: Collaboration.
Congratulations on purchasing your Kramer VS-611DT UHD 6x1:2 Auto Switcher,
which is ideal for the following typical applications:
•Education
•Corporate
•Any other AV installation that requires selecting and switching between several
HDMI sources automatically

2 VS-611DT - Getting Started
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
Go to www.kramerav.com/manual/VS-611DT to check for up-to-date user
manuals, application programs, and to check if firmware upgrades are
available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
•For optimum range and performance, use the recommended Kramer cables
available at www.kramerav.com/product/VS-611DT
•Do not secure the cables in tight bundles or roll the slack into tight coils.
•Avoid interference from neighbouring electrical appliances that may adversely
influence signal quality.
•Position your VS-611DT away from moisture, excessive sunlight and dust.
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit.
Warning: Use only the Kramer Electronics power supply that is
provided with the unit.
Warning: Disconnect the power and unplug the unit from the wall
before installing.

VS-611DT – Getting Started 3
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims
to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country go
to our recycling pages at www.kramerav.com/support/recycling/.

4 VS-611DT - Overview
3 Overview
The VS-611DT is a high-performance automatic switcher for HDMI video signals
with resolution up to 4K@60 UHD (4:2:0). With six HDMI inputs, the unit can
automatically or manually switch to a predefined or last connected input whenever
the currently active video signal is interrupted or whenever a higher-priority video
signal is introduced. The output signal is distributed to HDBaseT and HDMI (4K)
outputs.
The VS-611DT features:
•A maximum data rate of up to 8.91Gbps (2.97Gbps per graphic channel)
•Extended Range (100m) of HDBaseT 4K@60Hz (4:2:0)
•HDTV compatible
•HDCP and HDMI compliant
•Six HDMI inputs and HDBT and HDMI outputs (DA)
•HDMI support for Deep Color, Ethernet, ARC, up to 7.1 audio channels
•HDMI ARC de-embedding from output to balanced stereo audio line out
uncompressed
•Step-in support
•Automatic input detection and selection
•Auto-power off when no HDMI input for 30 seconds (selectable)
•HDCP on/off switching
•EDID configuration options
•Selectable switching – manual or fast auto switching according to last
connected or preset priority
•Full HDBaseT certification (including bidirectional RS-232, Ethernet, IR and
POE)
•POE source for HDBaseT receiver (that is PoE compliant)
•Contact closure for remote manual switching override
•Firmware upgrade over mini-USB, RS-232, RJ-45

VS-611DT – Overview 5
•Varied control options – front panel keyboard, HDBaseT(local and through
HDBaseT), Ethernet, RS-232 (local and through remote HDBaseT source with
K-Link support), IR (local and through HDBaseT)
•Built-in Web server
•Support for Protocol 3000 and K-Upload
3.1 About Fast Switching
Older display devices required a longer time between the loss of one digital signal
and the introduction of another, as well as a physical disconnection of the
interconnecting cable in order to be able to detect and adjust to the new video
attributes and parameters. Normal switching, therefore, introduced a 5V signal
disconnection along with a delay in switching. Many newer display devices,
however, are now capable of “on-the-fly” switching.
Depending on the display device in use, the VS-611DT allows for fast switching
(minor reset and the connection kept alive) and extra fast switching (no reset and
the connection kept alive). Using the fast switching mode allows for fraction-of-a-
second switching times when using high performance display devices or when
using a scaler on the video output.

6 VS-611DT - Overview
3.2 Defining the VS-611DT UHD 6x1:2 Auto Switcher
This section defines the VS-611DT.
Figure 1: VS-611DT UHD 6x1:2 Auto Switcher
#
Feature
Function
1
ON LED
Lights when the unit is powered on
2
LAST LED
Lights when in Last Connected mode
3
AUTO LED
Lights when in Auto Switching mode
4 AUTO/MAN. Button Press to select between auto-switching or manual
switching mode (see Section 5.1)
5 LAST/PRIO. Button Press to select between last connected mode or
priority switching mode (see Section 5.1)
6 INPUT Buttons (1-6) Press to select an HDMI source to route to the
output. The LEDs indicate:
Lit: the input is selected
Dim: the input signal is active but not selected
Off: the input signal is not active and not selected
7
OFF
Button
Press to disconnect the output mode (see
Section 5.4)
8
EDID Button
Press to capture the EDID (see Section 5.5)
9
LOCK Button
Press and hold to toggle locking and unlocking the
front panel buttons (see Section 5.3)
10
INPUT HDMI Connectors (1-
6)
Connect to up to 6 HDMI sources
11
AUDIO OUT Terminal Block
Connects to a balanced stereo audio acceptor

VS-611DT – Overview 7
#
Feature
Function
12
PROG USB Mini-B Connector
Used for upgrading firmware (see Section 5.10)
13
RS-232 LOCAL/VIA HDBT
Button
Press to select between a local RS-232 source, or
RS-232 over HDBT
14
RS-232 LOCAL LED
Lights when local RS-232 is active
15
INPUT SELECT Contact
Closure Terminal Block
Connects to external contact closure input switches
(see Section 5.13)
16 RS-232 Terminal Block Connects to a local RS-232 source (see
Section 4.1)
17
ETHERNET RJ-45 Connector
Connects to a network for control
18
IR 3.5mm Mini Jack
Connects to an HDBT IR transmitter
19
HDBT OUT RJ-45 Connector
Connects to an HDBT TP line
20
HDMI OUT Connector
Connects to an HDMI acceptor
21
12V DC Connector
Connects to a power supply for the unit

8 VS-611DT - Connecting the VS-611DT
4 Connecting the VS-611DT
Always switch off the power to each device before connecting it to
your VS-611DT. After connecting your VS-611DT, connect its power
and then switch on the power to each device.
You do not have to connect all the inputs and outputs, connect only
those that are required.
To connect the VS-611DT as illustrated in the example in Figure 2:
1. Connect up to six HDMI sources (for example, KDS-MP4(s), laptop(s),
DIP-31(s)) to INPUTs 1-6 using HDMI cables.
2. Connect the HDBT OUT RJ-45 connector to an HDBaseT acceptor (for
example, a TP-780Rxr HDBaseT receiver or an HDBaseT projector) using
an HDBT twisted pair cable.
3. Connect the HDMI OUT connector to an HDMI acceptor (for example, a 4K
display) using an HDMI cable.
4. Connect the AUDIO OUT terminal block (line out) to a balanced audio
acceptor (for example, a power amplifier with speakers) using an audio
cable.
5. If needed for control, connect the ETHERNET RJ-45 and/or the RS-232
terminal block ports to a network or a serial control device.
6. If needed, connect the INPUT SELECT terminal block to up to six contact
closure switches.
7. If needed, connect an HDBT IR transmitter to the IR 3.5mm mini jack.

VS-611DT – Connecting the VS-611DT 9
Figure 2: Connecting the VS-611DT UHD 6x1:2 Auto Switcher
4.1 Connecting a Serial Controller to the VS-611DT via
RS-232
The VS-611DT operates at 9600 baud rate (see all communication parameters in
Section 9.1).
To connect a serial controller to the VS-611DT:
•From the RS-232 9-pin D-sub serial port on the serial controller connect:
Pin 2 to the TX pin on the VS-611DT RS-232 terminal block.
Pin 3 to the RX pin on the VS-611DT RS-232 terminal block.
Pin 5 to the GND pin on the VS-611DT RS-232 terminal block.

10 VS-611DT - Operating the VS-611DT
5 Operating the VS-611DT
This section describes how to operate the VS-611DT.
5.1 Switching – Manual and Auto
Switching can be performed automatically or manually using the device’s keypad,
Web pages (see Section 6.1), or control commands (see Section 10.3.2). This
section describes using the keypad buttons to select Auto or Manual switch modes.
5.1.1 Manual Switch Mode
In Manual switch mode, the VS-611DT does not automatically switch to another
channel even if an input signal is not detected on the manual input.
To select the manual switch mode:
1. Press the Auto/Man. button to turn the Auto/Man. LED off.
2. Press any of the Input 1-6 buttons to switch the input.
The keys respond as follows:
Input LED bright: input active and selected
Input LED dim: input active and not selected
Input LED off: input is not active and not selected
5.1.2 Auto Switch Mode
In Auto switch mode, the VS-611DT automatically switches one of six HDMI inputs
to a predefined or the last connected input whenever the currently active video
signal is interrupted or whenever a higher-priority video signal is detected.

VS-611DT – Operating the VS-611DT 11
To select the auto switch mode:
1. Press the Auto/Man button to turn the Auto LED on.
2. Press the Last/Prio button to select an auto switch mode:
Last connected (Last LED on) – The device always switches to a newly
detected active video source. When the device is powered on, the
output switches to the highest priority input.
Priority (Last LED off) – The device always switches to the highest
priority input source. The default priority is Input 1 then Input 2.
5.1.3 Manual Override Mode
Auto switch mode can be overridden by a manual command, such as pressing an
input button or sending a control command. In such a case, the system switches to
the manually selected source. If this manually selected source is not active, the
system waits a set amount of time (10 seconds, default, adjustable on the Web
page) and then switches back to Auto mode. Manual override selection is not stored
in non-volatile memory.
A step-in command is considered a manual switching command.
5.2 Performing a Factory Reset
Factory reset returns all the parameters of the device to their factory default
settings.
To perform a factory reset:
1. Disconnect device power.
2. Press and hold Input 1 while reconnecting device power.
All indicators flash while resetting to the factory default parameters. When all
the lights turn off the reset is complete.

12 VS-611DT - Operating the VS-611DT
5.3 Locking the Front Panel Buttons
Lock the front panel buttons to prevent tampering.
•Press and hold Lock until the button lights.
The front panel buttons are locked.
•Press and hold Lock until the button goes off.
The front panel buttons are unlocked.
5.4 Turning the Output Off
•Press the Off button to turn off the outputs.
Both HDMI and HDBaseT outputs turn off.
5.5 Copying the EDID
The EDID is a data structure transmitted by the display that enables the VS-611DT
to recognize the display connected to the output. The VS-611DT acquires and
stores the EDID to make reconnection to the display effortless.
You can acquire the EDID from the:
•HDMI output to the selected inputs.
•HDBaseT output to the selected inputs.
•Default EDID to the selected inputs (for the default EDID, see Section 9.3).
Pressing the front panel EDID button captures the EDID either from the HDMI
output port or from the HDBaseT output port to all inputs according to the following
scenario:
To copy the EDID from the HDMI output:
1. Press the EDID button to cycle through the EDID sources until all front panel
LEDs flash once, indicating that the EDID is copied from HDMI.
2. Press the button of the input that receives the EDID.
3. Press and hold EDID for 5 seconds to copy.

VS-611DT – Operating the VS-611DT 13
To copy the EDID from the HDBT output:
1. Press the EDID button to cycle through the EDID sources until all front panel
LEDs flash twice, indicating that the EDID is copied from HDBT.
2. Press the button of the input that receives the EDID.
3. Press and hold EDID for 5 seconds to copy.
To copy the default EDID:
1. Press the EDID button to cycle through the EDID sources until all front panel
LEDs flash three times, indicating that the default EDID is copied
2. Press the button of the input that receives the EDID.
3. Press EDID and hold for 5 sec to copy.
5.6 Setting the 5V Output Time Delay
When there is no signal clock or 5V input on all inputs for 15 minutes, the device
shuts down the 5V output. This enables output devices such as projectors or
displays to go to sleep. The 15 minute default time delay can be changed to 5
minutes or 10 minutes using the Auto Sync Off feature on the Device Settings Web
page (see Section 6.3).
5.7 Setting HDCP Capability
Each input can be individually set to HDCP support on or off.
To set HDCP support:
1. Disconnect device power.
2. Press and hold the Lock button while reconnecting device power.
The Lock LED flashes indicating HDCP setup mode.
3. Press the Input 1-6 button(s) to set HDCP.
4. If the LED is on, HDCP passes to the port.
If flashing, HDCP does not.

14 VS-611DT - Operating the VS-611DT
5. Press the Lock button to confirm the choice or the Off button to quit.
If no button is pressed, the mode quits after 10 seconds.
5.8 Setting the Audio Output
The audio output can be set to ARC or de-embedded audio output.
When inputting ARC or HDMI multi-channel LPCM audio, the analog
outputs the front right and front left components. If the device is in
ARC mode and compressed audio is input, speakers connected to
the analog output produce noise.

VS-611DT – Operating the VS-611DT 15
To set the audio output:
1. Press and hold the Off + Input 3 buttons.
The Lock and Input 3 LEDs flash.
2. Press the Input 3 button to set ARC/de-embedding audio:
ARC audio out – Flashing LED 3
De-embedding audio out – Solid LED 3
5.9 Setting the Switching Speed
The VS-611DT supports setting normal and fast (default) switching speeds.
To set switching speed modes:
1. Disconnect device power.
2. Press and hold one of the following buttons together with the OFF button:
IN 1 button – for setting fast switching speed mode.
IN 2 button – for setting normal switching speed mode.
3. Power the device on.
The device switching speed is modified.
Switching speed can also be set using the Routing Web page (see Section 6.1).
5.10 Using VCOM on USB
The device’s USB port can work as a virtual COM (VCOM) port. Verify that the USB
port on the PC that connects to the VS-611DT is configured as a VCOM port. You
may need to install a driver to do this. Use a tool such as Hercules or K-Config to
use P3K over USB. For more information on using the commands see Section 10.
