Kraus Allyn KPF- 4103 User manual

Allyn™ Pull-Out Kitchen Faucet
KPF- 4103
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. DEC 08, 2021

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
2

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•
Pre-drilled countertop hole size requirement: 1-3/8”(min)
• Max countertop thickness: 3-1/2”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
3
Turn o the hot and cold water lines at the angle stops and turn on the old faucet
to release any built-up pressure
Read all instructions and safety warnings and ensure you have all tools, parts,
and equipment necessary for a safe installation.
•
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
ACID
STOP

4
A. Spray Head
C. Rubber Washer
D. Metal Washer
F. Screws
B
Diagram and Parts List
G. Weight
J
H. Weight Clip
B. Faucet Body
E. Mounting Nut
C
D
H
I. Quick Connector
J. Hex Wrench
G
A
E
F
I

5
Faucet Dimension
Installer Tip:
3/8" compression
2 3/8"
[59.0mm]
3 1/2"
[87.8mm]
10"
[255.6mm]
2 3/8"
[59.0mm]
6 1/4"
[157.9mm]
9"
[227.6mm]
11"
[280.9mm]

6
F
Step 1: Installing the faucet
Shut o the water supply. Place faucet (B)
through the hole in countertop.
Secure the faucet (B) to the countertop using
the rubber washer (C), metal washer (D) and
mounting nut (E) provided. Hand tighten
the nut (E) onto the faucet assembly. Lock
the nut (E) into position by tightening the
screws (F) with a phillips screwdriver.
Step 2: Securing the faucet assembly
Push the quick connector (I) rmly upward
and attach it to the receiving block (a). Pull
down moderately to ensure the connection
has been made.
C
D
F
B
E
a
I
(2 N.m
Max)

Step 3: Securing the faucet assembly
Install the weight clip (H) at the point of
the hose marking "weight here". Insert
the weight (G) onto the weight clip (H)
by sliding it down onto the weight clip (H).
Step 4: Connect waterlines to main valve
7
Step 5: Flush faucet
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCET ON)
Pull the hose assembly out of the spout and
remove the spray head (A) by unscrewing it
from the hose in a counterclockwise direction.
Be sure to hold the end of the hose down into
the sink and turn the faucet on to the warm
position where it mixes hot and cold water.
Flush the water lines for one minute. This
Fushesaway any debris that could cause
damage to internal parts. Check for leaks.
Re-tighten any connections if necessary, but
do not overtighten. Reinstall the spray head (A)
by hand tightening it back onto the spray hose.
After installation is completed, turn on the
hot and cold water supplies. Check for leaks.
Weight
here
Weight
here
H
G
NOTE: Please make sure washer is
installed attaching spray head to hose.
A
NOTE: Please make sure lter washers
are installed before connecting to
the main valve.

Replacement Parts
1. Index
Replacement Parts List Part #
2. Screw
3. Handle Assembly
5. Bonnet
6. Connector
7. Cartridge
9.Nut&Screw
10. Inverter
Finish / Color
KP27379
KP27380
KP27028
KP27079
KP27194
KP27001
KP27377
8. Washer
4. Cap KP27378
11. Spray Head
KP27123
KP27381
*Denotes faucet component color options:
Black hose with Spot Free Black Stainless connector (BLSFSB) ;
Gray hose with Chrome connector (GRCH) ; Gray hose with Spot-Free Stainless connector (GRSFS);
Black hose w/ Matte Black connector (BLMB); Black hose with Spot-Free Antique Champagne Bronze (BLSFACB);
SFSB - Spot Free Black Stainless ; SFS - Spot Free Stainless ; CH - Chrome ; MB - Matte Black；
SFACB - Spot Free Antique Champagne Bronze；GR - Grey；BL - Black
12. Hose
13. Quick connector assembly
KP27382
KP27090
14. 1.8GPM Flow Restrictor
15. Weight & Clip Assembly
KP27074
16. Hex wrench
KP27212
KP27020
17. Block
18. O-Ring
19. Filter Washer
KP27092
KP27167
KP27073
8
1
2
3
4
5
6
7
8
9
10
11
12 13
14
16 17
18
19
15
CH, MB, SFACB,
SFSB, SFS*
GRCH, GRSFS,
BLMB, BLSFSB,
BLSFACB*
CH, MB, SFACB,
SFSB, SFS*
CH, MB, SFACB,
SFSB, SFS*
BL, GR*
KP27257
BL, GR*

Troubleshooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following coorective steps:
PROBLEM CAUSE ACTION
Leakage under the
handle
Bonnet nut (5) has
come loose
Remove the cover button (1).
Loosen set screw (2) with hex
wrench (16). Remove the
handle (3). Unscrew cap (4) (by
hand only). Tighten bonnet nut
(5) with an adjustable wrench
The aerator has an
irregular or reduced
water ow
The aerator is dirty or
mis-tted
Remove the aerator and
check for debris.
Ensure that the rubber
washer is properly installed.
Water will not shut o
completely
Cartridge may need to
be adjusted or replaced
Remove the cover button (1).
Loosen set screw (2) with hex
wrench (16). Remove the
handle (3). Unscrew cap (4)
(by hand only). Tighten bonnet
nut (5) with an adjustable
wrench. Remove the cartridge
(7). Check for cracks
There is leaking from the
sink drain at the base of
the sink.
The sink has a rough or
irregular surface.
Apply additional silicone
sealant to the beveled side of
the drain ange. Retighten
and test for leaks
There is a low ow of
water.
The lter washer in the
hose connectors is dirty.
Turn o the water supply at
water valve and unscrew the
hose connectors from water
supply lines. Clean the lter
washer in the water lines with
hot water, removing any debris
or calcium build up
9

10
Faucet - Lifetime Limited Warranty
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.
Codes/Standards Applicable:
UPC
CR
NSF/ANSI 372
ASME A112.18.1
1.8GPM 6.8L/min maximum
IP
TM
LEAD FREE
NSF / ANSI 61
A
MOR&T
R
•
•

11
How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied
warranty lasts, so the below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE DURATION OF THIS
WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special,
incidental or consequential damages, so the below limitations and exclusions may not apply to you. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA
PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING
OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to
state/province.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
R

IMPORTANT
Register Your Kraus Product
REGISTER TODAY
http://www.kraususa.com/registration
Activate Your Warranty
Access Premium Customer Support
Get Product Information
www.kraususa.com
