RamusTM Single Lever
Vessel Faucet
FVS-1007
R
INSTALLATION MANUAL

2
Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and
parts list. If any part is missing or damaged, please contact Kraus
Customer Service at 800-775-0703 for a replacement.
·Turn off the hot and cold water supply at the angle stops and turn on
the old faucet to release any built up pressure. Remove existing faucet.
Clean sink or countertop to remove any debris, plumber’s putty, or
silicone.
·Flush angle stops to release any debris prior to installation.
·Pre-drilled hole size requirement: 1 3/8" (min)
·Max countertop thickness: 1 3/8”
3
Tools Required
Adjustable Wrench Phillips Screwdriver Silicone Sealant
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
Pipe Tape Hex Wrench

44
Diagram and Parts List
1. Faucet Body
2. Aerator
3. Faucet Base
A. Base Trim Ring
B. Rubber Washer
4. Mounting Hardware
A. Rubber Washer
B. Metal Washer
C. Mounting Nuts
D. Mounting Screws
5. Hex Wrench
6. Aerator Key
3A
4A
4B
4C
4D
2
6
5
3B
1

55
Installer Tip:
Shut off main water supply before installing new faucet.
Faucet Dimensions
12 1/2"
(316mm)
Ø1 3/4"
(45mm)
Ø2"
(50mm)
1 5/8"
(42.5mm Max)
3/8" Compression
3 3/4"
(96mm)
Ø3/8"
(10mm)
1 3/8"
(35mm)
10 1/8"
(257mm)
Ø7/8"
(22mm)
8 1/4"
(211mm)
6 5/8" (168mm)
20°
5 3/4"
(146mm)

66
Faucet Installation Procedure
Step 2.
Install the faucet through the
1-3/8" predrilled hole in the
countertop. Attach rubber washer
(4A), metal washer (4B), mounting
nut (4C), and mounting screws
(4D) on the threaded mounting
pipe. Tighten the mounting nut
(4C) until snug. Tighten screws
(4D) on the mounting nut (4C)
with a Phillips head screwdriver
until snug.
Step 1.
Remove rubber washer (4A), metal
washer (4B), mounting nut (4C),
and mounting screws (4D). Keep
the base trim ring (3A) and rubber
washer (3B) on the base of the
faucet.
3A
4A
4B
4C
4D
27mm ~ 41.3mm
1 1/16” ~ 1 5/8”

7
Step 3.
Install flex water supply lines on
the angle stops and tighten with
an adjustable wrench. Turn on
both the cold and hot main valves
Apply pipe tape (optional).
Step 4.
After installing the faucet, remove
the aerator (2) with the included
aerator key (6). Turn on the water
to remove any leftover debris,
then reassemble the aerator (2).

8
Replacement Parts
1. Metal Handle
2. Cartridge Cover
3. Locking Nut
4. Cartridge
6. Base Trim Ring
7. Mounting Hardware
8. Hex Wrench 2.5mm
9. Aerator Key
Replacement Parts List Finish/Color Part #
KP44069
KP44070
KP44071
KP44072
KP44073
KP44074
KP44075
KP44076
KP44077
KP44022
CH, SN, ORB, MB, SFS*
5. Aerator
*Denotes faucet component color options:
CH - Chrome
SN - Satin Nickel
ORB - Oil Rubbed Bronze
MB - Matte Black
SFS - Spot Free Stainless Steel
1
2
3
4
5
6
7
8
9
CH, SN, ORB, MB, SFS*
CH, SN, ORB, MB, SFS*
10
10. Filter Washers

9
Trouble-Shooting
If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps:
Leakage under the faucet
handle
Adjusting locking nut has come loose. Remove handle index button. Loosen set
screw with hex wrench. Remove handle
(by hand only). Tighten locking nut with
an adjustable wrench.
Aerator drips or has inconsistent
water flow pattern
Aerator is dirty or not
seated properly.
Unscrew aerator with aerator key and clean
out debris.
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
Water does not shut off
completely
Cartridge may be defective. Remove handle index button. Loosen set
screw with hex wrench. Remove handle
(by hand only). Unscrew trim cap (by hand
only). Unscrew the locking nut with an
adjustable wrench. Remove ceramic disc
cartridge. Check for cracks.
Leaking between spout and body Loose spout or damaged O-rings on
connector.
Tighten set screw under the spout.
ACID
PROBLEM CAUSE ACTION

FAUCET WARRANTY
Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. ("Kraus").
Kraus extends this warranty to the original purchaser for personal household use of the "Faucet" in its original location.
The warranty is non-transferable.
Kraus warrants the structure and finish of the product to be free from defects in material and workmanship under normal
usage for the lifetime of the product. The warranty commences from the initial date of purchase by the owner or trade
professional, from an authorized Kraus dealer, through the lifetime of the original owner or end-user.
Kraus warrants the mechanical components such as but not limited to sprayhead assembly (includes engine, aerators,
structure, restrictors, back flow preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon
and stainless steel,etc) of the product to be free from defects in material and workmanship under normal usage for a
period of one (1) year. The warranty commences from the initial date of purchase by the owner or trade professional,
from an authorized Kraus dealer, through the one (1) year term of the original owner or end-user.
Kraus warrants the mechanical component (cartridge) of the product to be free from defects in material and
workmanship under normal usage for a period of five (5) years. The warranty commences from the initial date of
purchase by the owner or trade professional, from an authorized Kraus dealer, through the five (5) year term of the
original owner or end-user.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user,
and is not transferable to a subsequent owner.
RESTRICTIONS
This warranty does not cover antediluvian, discontinued, or display products, whether such items are purchased at
discount outlets, unauthorized dealers, and/or sold on clearance.
This warranty does not cover instances of negligence, misuse, abuse, improper installation, carelessness, accident, hard
water or mineral deposits, exposure to corrosive materials, misapplication, damages caused by improper maintenance,
alteration of the product, or failure to follow care or installation instructions enclosed with your product. Avoid using
abrasive cleaners such as powders, bleach, ammonia, alcohol, or chlorine. Avoid using abrasive pads, steel wool, or wire
brushes, as these will damage and wear down the finish.
This warranty does not apply to Products that have not been installed or operated in accordance with instructions
supplied by Kraus and all applicable rules, regulations, and legislation pertaining to such installations.
This warranty does not apply unless the Kraus product is installed by a fully insured and licensed trade professional.
Kraus insists that such professionals have experience in the installation of bathroom and kitchen manufactured goods.
This warranty does not cover labor charges or costs of removal and reinstallation of said product. This warranty does not
allow recovery of incidental or consequential damages, such as loss of use, delay, property damage, or other
consequential damages, and Kraus accepts no liability for such damages.
This warranty does not cover Marine or Outdoor Installation.
Codes/Standards Applicable:
10
UPC
CR
UPC
R
NSF/ANSI 372 GREEN
ASME A112.18.1
1.2GPM 4.5L/min maximum
Water Efficiency
IP
TM
LEAD FREE
Water Efficiency
NSF / ANSI 61
AMOR&T

11
Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of
merchantability and fitness for a particular purpose, or compliance with any code.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
COMMERCIAL WARRANTY
Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and
business use.
All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given,
including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long
an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
KRAUS USA has the right to change, modify, and/or update the warranty policy at any time. For the latest, most up to
date comprehensive warranty, go to www.kraususa.com/warranty
If you are a homeowner please contact a Kraus Customer Service Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an Authorized Partner please contact a Partner Support Representative at:
Kraus USA, Inc.
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide:
1. Proof of purchase.
2. A description of the problem.
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
R
www.kraususa.com
IMPORTANT

Glass Vessel Sinks
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. September 2, 2020
R
INSTALLATION MANUAL

Congratulations on the purchase of your new Kraus plumbing fixture!
Please keep the box and packaging materials until your product is completely installed. If you have
any questions, require technical assistance or have any problems with your product:
2
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your receipt with purchase date for
reference.
If for any reason this product does not meet your expectations, please be sure to repack this
product in the original box and packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP

3
Prior to Installation:
• Unpack your new product and ensure that all the parts are contained in the
packaging
• Keep the product in its original box until you’re ready to install it
• The counter top must be flat
• Shut off the water supply if replacing a previously-installed vessel sink
•Observe all plumbing and building codes in your area
•It is recommended that installation of the product be done by a professional
plumber
For technical assistance or replacement parts, please contact Kraus Customer Service
and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus sink. Should
there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a
licensed professional.

44
Dimensions
Model #: GV-101-14, GV-101FR-14,
GV-103-14, GV-104-14
Sink Dimensions: Ø14” x 5 1/2”
Glass Thickness: 12mm
5 1/2"
(140mm)
Ø14"
(356mm)
Ø17"
(432mm)
Ø1 3/4"
(45mm)
Model #: GV-100, GV-101, GV-101FR,
GV-104, GV-200, GV-204, GV-580,
GV-651, GV-684
Sink Dimensions: Ø16 1/2” x 5 1/2”
Glass Thickness: 12mm
5 1/2"
(140mm)
Ø16 1/2"
(419mm)
Ø1 3/4"
(45mm)
Model #: GV-101-19mm, GV-391-19mm,
GV-398-19mm, GV-399-19mm, GV-680-19mm
Sink Dimensions: Ø17” x 6”
Glass Thickness: 19mm
Model #: GV-150-19mm
Sink Dimensions: Ø17” x 6”
Glass Thickness: 19mm
Rim Thickness: 34mm
Ø1 3/4"
(45mm)
6"
(152mm)
Ø17"
(432mm)
Ø1 3/4"
(45mm)
6"
(152mm)

55
Model #: GVR-204-RE, GVR-210-RE
Sink Dimensions: 21 7/8” x 13 7/8" x 4”
Glass Thickness: 15mm
Model #: GVS-901-19mm
Sink Dimensions: 16 1/2” x 16 1/2" x 6”
Glass Thickness: 19mm
Dimensions
Ø1 3/4"
(45mm)
13 7/8" (353mm)
21 7/8" (556mm)
4"
(101.6mm)
16 1/2" (419mm)
16 1/2" (419mm)
Ø1 3/4"
(45mm)
6"
(152mm)

66
Rough-In Dimensions
Installer Tip
Shut off main water supply before installation.
Finished Wall
Ø1 3/4” Drain Hole
Top View
14” - 17”
Countertop
Mounting Ring 1/2”
Floor
34” Suggested
28” Suggested
5 1/2”
6”

7
Above Counter Installation Instructions
Before You Begin
Prepare counter top by drilling a 1 3/4’’ diameter drain hole at the desired location. Install
mounting ring. Place vessel sink on the mounting ring or counter top as shown below.
Vessel Sink
Countertop
Mounting
Ring
Ø1 3/4”
(Suggested)
1. Make sure the vessel sink is not scratched, chipped or broken prior to installation.
2. Check to see if your set contains the following parts:
·Vessel sink
·Pop up drain (optional, may be sold separately)
·Mounting Ring (optional, may be sold separately)
3. Locate and place the mounting ring over the drain hole with the rubber side facing down and
the white washer side facing up.
4. Gently set your sink on top of the mounting ring.

8
Pop Up Drain & Mounting Ring Installation (Only if Included)
Locate and disassemble your pop up drain in the following order:
·Unscrew the tail piece
·Unscrew the brass nut
·Remove the firm washer
·Remove the concave washer, leaving the top thin rubber washer on.
Pop Up Drain
Mounting Ring
White Rubber Washer
Top View
Inner Black Rubber Washer
Bottom View
