Kraus Oletto KPF-2822 User manual

Oletto™ Single Handle Bar Faucet
KPF-2822
INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. NOV 17, 2021

Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
1

Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•Pre-drilled countertop hole size requirement: 1-3/8”(min)
•Max countertop thickness: 2 3/4”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
2
to release any built-up pressure

3
A. Faucet Body
C. Flange
D. Plastic Washer
F. Mounting Nut
A
Diagram and Parts List
D
E
F
G. Screws
H
H. Hex Wrench
B
B. Aerator
G
C
E. Metal Washer

4
Faucet Dimension
Installer Tip:
Ø2 1/4"
[57.0mm]
6 1/2"
[165.1mm]
8 1/8"
[204.9mm]
8"
[202.7mm]
3 1/2"
[90.1mm]
2 3/4"
[70.0mm]
12"
[303.5mm]
3/8” compression

Step 1: Remove washers and mounting nut
Shut o the water supply. Remove the
old faucet. Clean the mounting surface.
Remove the mounting nut & screws (F&G),
metal washer (E) and plastic washer (D)
from the faucet (A).
Step 2: Installing the faucet
Place faucet (A) through the hole in countertop.
Secure the faucet (A) to the countertop using
the plastic washer (D), metal washer (E) and
mounting nut (F) provided. Tighten screws (G).
E
5
F&G
A
D
E
G
D
A
F
G

6
Step 3: Connectwaterlines tomain valve
Step 4: Flush faucet
Attach waterlines to angle stops
and tighten until snug. Turn on angles
stops and check for leaks (DO NOT TURN
FAUCETON)
After installing faucet, remove aerator (B)
with a coin. Turn water on for 30 seconds
to remove any debris. Reassemble aerator(B).
B
NOTE
are installed before connecting to
the main valve.

7
Replacement Parts
1. Aerator
Replacement Parts List Part #
2. Washer
3. Block
5. Screw
7. Cartridge
8. Bonnet Nut
10. Handle
11. Screw
12. Cover Button
Finish / Color
KP27223
KP27069
KP27202
KP27203
KP27204
KP27001
KP27199
KP27201
KP27030
3
1
11
12
13
9. Cap & O-ring
4. O-ring KP27029
13. Flange
KP27002
18
SFS, MB,BB,CH
SFACB , SFSB* KP27205
GR, BL*
14. Plastic Washer KP27146
*Denotes faucet component color options:
SFS - Spot Free Stainless Steel
MB - Matte Black
SFACB - Spot Free Antique Champagne Bronze
SFSB - Spot Free Black Stainless
BB - Brushed Brass
GR - Grey
BL - Black
SFS, MB, BB,CH
SFACB , SFSB*
12
3
4
5
789
10
11
12
13
14
15
16
15. Metal Washer
16. Mounting Nut & Screw
KP27147
17. Filter Washer
KP27148
KP27167
SFS, MB, BB,CH
SFACB , SFSB*
17
18. Hex Wrench KP27020
6. Cover Button KP27222GR, BL*
6
CH - Chrome
MBSFSB - Matte Black+Spot Free Black Stainless

8
Troubleshooting
If you have followed the instructions carefully and your faucet still does not work
properly, take the following coorective steps:
Care & Maintenance
*To keep the product clean & shining, follow the steps below：
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
*This installation manual is subject to change without further notice.
10
9
11
12 13
Hexagon Nut
Hot
Water
Cold
Water
11
Close
Open Left
Hot Water
Push
25˚ 90˚
12
13
PROBLEM CAUSE ACTION
Leakage under the
handle
Bonnet nut (8) has
come loose
Remove the cover button (12).
Loosen screw (11) with hex
wrench (18). Remove the
handle (10). Unscrew cap (9) (by
hand only). Tighten bonnet nut
(8) with an adjustable wrench
Aerator drips or has
inconsistent water
ow pattern
Aerator (1) is dirty or
not seated properly
Unscrew aerator (1) with
a coin and clean out debris
Water will not shut o
completely
Cartridge may need to
be adjusted or replaced
Remove the cover button (12).
Loosen screw (11) with hex
wrench (18). Remove the
handle (10). Unscrew cap (9) (by
hand only). Tighten bonnet nut
(8) with an adjustable wrench.
Remove the cartridge (7).
Check for cracks
There is a low ow of
water.
The lter washer in the
hose connectors is dirty.
Turn o the water supply at
water valve and unscrew the
hose connectors from water
supply lines. Clean the lter
washer in the water lines with
hot water, removing any debris
or calcium build up

9
Codes/Standards Applicable:
UPC
CR
APM
TM
NSF/ANSI 372
NSF/ANSI 61 ASME A112.18.1
1.8GPM 6.8L/min maximum
Faucet - Lifetime Limited Warranty
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.
R
LEAD FREE
I
&
OR
T
•
•

10
Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem. Shipping charges
will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto Rico shipping charges may apply).
International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied warranty lasts, so the
below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ANY IMPLIED WARRANTY,
INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO
THE STATUTORY PERIOD OR THE DURATION OF THIS WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special, incidental or
consequential damages, so the below limitations and exclusions may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS
PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR
OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to state/province.
R

IMPORTANT
Register Your Kraus Product
REGISTER TODAY
http://www.kraususa.com/registration
Activate Your Warranty
Access Premium Customer Support
Get Product Information
www.kraususa.com
