Kraus KPF-2110 User manual

KPF-2110
Single Lever Kitchen Faucet
With Pull-Out Sprayer
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. August 7, 2017
INSTALLATION GUIDE

1
Congratulations on the purchase of your new
Kraus plumbing xture!
Please keep teh box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE

2
Prior to Installation
• Make sure that the cold and hot water lines are turned o
• Wrap all threaded connections with Teon tape. Always wrap in a clockwise direction
• Cover your drain to avoid losing parts
• Do not disassemble the main faucet body, as it has been factory assembled by Kraus
for stress-free installation.
• Using condition: Working pressure at 0.05-1.0MPa (including cold & hot water
pressure) with applicable water temperature: 4C-90C
• Remove the check valve assembly (24) at the end of the hose (10)
• Discard plastic caps from the hot and cold inlets
Tools you will need:
Phillips
Screwdriver
Adjustable
Wrench

3
Included Parts:
1. Index Button
2. Set Screw
3. Handle
4. Cartridge Cover
5. Locking Nut
6. Cartridge
7. O-Ring
8. Faucet Body
9. Spray Head
10. Hose
11. Plastic Cover
12. O-Ring
13. Noise Silencer
14. M4 Screw
15. Faucet Body Base
16. O-Ring
17. O-Ring
18. Faucet Extender
19. Rubber U- Washer
20. Metal U-Washer
21. Plastic Base Hose Ring
22. A. Mounting Nut
B. Mounting Nut
23. Extending Pipe
24. Check Valve Assembly
25. Weight
26. Screws (2)
27. Hot & Cold Waterlines (2)
28. Wrench
29. Spanner
30. Aerator Key
31. Spacer
KPF-2110 Diagram and Parts List
1
2
3
4
5
6
7
8
9
10
11
12
13
13 14
14
15
16
17
18
19
20
25
26
21
22
23
24
27
28
29
31
30

4
225 mm
(8.86”)
Ø 63 mm
(2.48”)
270 mm
(10.63”)
250 mm
(9.8”)
100 mm
(4”)
170 mm
(6.7”)
210 mm
(8.3”)
180 mm
(7.09”)
Y 7/16 X 24
G1/2
G1/2
23˚
26˚
45˚
45˚
225 mm
(8.86”)
Ø 63 mm
(2.48”)
270 mm
(10.63”)
250 mm
(9.8”)
100 mm
(4”)
170 mm
(6.7”)
210 mm
(8.3”)
180 mm
(7.09”)
Y 7/16 X 24
G1/2
G1/2
23˚
26˚
45˚
45˚
Dimension Drawings
Safety Tips
• If soldering the water connections when installing the faucet, remove the O-rings,
cartridges, and washers before applying any heat
• Protect your eyes with safety glasses when cutting or soldering
8 7/8”
9 13/16”
7 1/16”
10 5/8”
2 1/2”

5
Dimension Drawings
225 mm
(8.86”)
Ø 63 mm
(2.48”)
270 mm
(10.63”)
250 mm
(9.8”)
100 mm
(4”)
170 mm
(6.7”)
210 mm
(8.3”)
180 mm
(7.09”)
Y 7/16 X 24
G1/2
G1/2
23˚
26˚
45˚
45˚
Safety Tips
• Do not overtighten xing screws/nuts. Tighten nger-tight, then use a wrench/
screwdriver to tighten the xing screw/nut until snug

6
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Step 1
Step 2
Remove metal nuts (22a and 22b)
from end of mounting pipe
Insert hose (10) into faucet body (8)
and through plastic base hose ring
(21)
Faucet Installation Procedures

7
Step 4
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Install faucet extender (18), rubber
u-washer (19), and metal u-washer (20)
on mounting pipe until it touches base
of countertop. Place metal nut (22a)
onto mounting pipe and tighten with
provided spanner (29) until snug
Step 3
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Insert faucet body (8) on
pre-drilled hole 1-3/8”
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Installer Tip: Screwdriver can
be placed through opening of
spanner for additional leverage

8
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Step 5
Step 6
Place metal nut (22b) on mounting pipe
and tighten with provided spanner until
snug underneath countertop
Secure extending pipe (23) on mounting
pipe and tighten with provided spanner
(29) until snug

9
Step 7
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Secure check valve assembly (24)
onto extending pipe (23). Tighten
with adjustable wrench until snug
Installer Tip: Check if O-rings
are installed in check valve
assembly (24) before installing
hose (10)
Step 8
18
19
Spanner
Tool
20
23
22a
10
22 a+b
8
8
Ø35mm
(Ø 1 3/8 “)
22b
Spanner
Tool
Screwdriver
Screwdriver
Screwdriver
Spanner
Tool
22b
24
10
24
23
10
10
25
27
10
9
10
25
Secure end of hose (10) onto check
valve assembly (24) and tighten
with adjustable wrench until snug
